CyberData KS-1000 User manual

KS1000 Retail Hub
Features
 8 PoweredUSB ports
 8 powered serial ports
 PS/2 port for keyboard and/or magnetic stripe reader
 Cash Drawer port with +24V power, trigger and status
 Internal power supply
 Optional internal USB drive
 External LED’s to show port power and status
 Over current protection
 2 AC pass through connections
The CyberData KS1000 Retail Hub provides a simple and
affordable POS migration strategy for Retailers. Availability
of 8 powered serial ports allows for the legacy connectivity
of existing peripherals while the availability of 8
PoweredUSB ports allows for future peripheral connectivity.
Requiring only a single, standard USB connection to the
host PC, CyberData’s KS1000 Retail Hub is the centerpiece
of a POS migration strategy. This hub-based solution allows
Retailers the ability to upgrade the host PC or peripherals
as time and budgets permit or as new technologies become
available.
The KS1000 Retail Hub also provides these additional
Retail connectivity ports:
 PS2 port for keyboard or magnetic stripe reader
 Cash Drawer port with +24V power, trigger and status
 24V, 3A receipt printer power connector
 RS232 with +5V and +12V support
Compatibility
IBM PC Windows 2000/XP & WePOS compatible
Apple Computer & Linux also supported
USB Standard 2.0 is fully supported
PoweredUSB Ports 8
PoweredUSB Power Output*
(Standard)
1 @ 24V 2.3A
7 @ 12V 1.5A each
RS232 Ports 8 DB9M with power option
3 year limited
Power, link & status
FCC Class B, UL 60950-1, CE
Warranty
8.9 x 5.7 x 3.5” (W x D x H)Dimensions
010896Part Number
External LEDs
Regulatory Compliance
*All ports support standard "A" type +5V USB connection.
KS1000 Retail Hub Specifications
Power Input 90 - 264AC, 50/60Hz
CyberData Corporation 2555 Garden Road Monterey, California 93940
[phone] [phone] www.cyberdata.net
070109
CyberData Corporation
CyberData Corporation

Port 1 Port 2 Port 3 Port 4 Port 5 Port 6 Port 7 Port 8
Power
Status
Power
Status
Power
Status
Power
Status
Power
Status
Power
Status
Power
Status
Power
Status
Activity
Status
Activity
Status
Activity
Status
Activity
Status
Activity
Status
Activity
Status
Activity
Status
Activity
Status
Customer Display Printer Touchscreen Chip ‘n’ Pin
Scanner Scale Spare 1 Spare 2
+24V/2.3A ActiveActiveActiveActive
Power
AC INPUT: 100-240V,
50-60Hz, 6A-3A
AC OUTPUT:
100 VAC, 6A MAX
240VAC, 3A MAX
Cash Drawer PS/2 USB HostPrinter Power
1 0
PoweredUSB Connectivity
Spare
COM Port
Spare
COM Port
Legacy
Serial
Pin Pad
Legacy
Serial
Touch I/F
AC
Output
2x
Legacy
Serial
Scale
Legacy
Serial
Printer
USB Host
I/F
PS/2Legacy
Cash
Drawer
+24V Out
Power
Switch
AC
Input
Legacy
Serial
Scanner
Legacy
Serial
Display
License note:
The Powered-USB controller board contains specific technology covered by a patent held by IBM Corporation. CyberData has obtained a license from IBM that
permits CyberData Corporation, among other things, to make or sell products that incorporate this technology. The license also permits these products to be
resold by an entity after they have been initially sold by CyberData.
CyberData Corporation 2555 Garden Road Monterey, California 93940
[phone] [phone] www.cyberdata.net
CyberData Corporation
KS1000 Retail Hub
Display
Scanner
Printer
RS232 Signature Capture Pad
PC Host
Typical Installation
