Quick Reference 931843A © 2021, CyberData Corporation, ALL RIGHTS RESERVED© 2021, CyberData Corporation, ALL RIGHTS RESERVED 931843A Quick Reference
Parts
Typical Installation
(1) 2-Port IP67
802.3bt to
802.3at PoE
Gigabit Switch
Assembly
(3) Cable Glands (1) Wrench Screw Accessory Kit(1) Ground wire
(4) Anchors
(4) Screws
Mounting Template
Contacting CyberData
5.512 [140.00]
2.362 [60.00]
Dimensions are in Inches [Millimeter]
Drill Bit Size for Plastic Ribbed Anchors: 7/32"
Keyhole Ø0.177 [Ø4.5] Fits M4 or #8 Screw
Sales: 831-373-2601 ext. 334
Support: 831-373-2601 ext. 333
Support Website: http://support.cyberdata.net/
RMA Department: 831-373-2601 ext. 136
RMA Email: [e-mail]
RMA Status: http://support.cyberdata.net/
Warranty Information: http://support.cyberdata.net/
Corporate Headquarters
CyberData Corporation
3 Justin Court
Monterey, CA 93940, USA
Phone: [phone]
Fax: [phone]
http://www.cyberdata.net/
The IP Endpoint Company
Installation Quick Reference
2-Port IP67 802.3bt to 802.3at PoE Gigabit Switch
011539
All manuals and user guides at all-guides.com

© 2021, CyberData Corporation, ALL RIGHTS RESERVED 931843A Quick Reference Quick Reference 931843A © 2021, CyberData Corporation, ALL RIGHTS RESERVED
Powering on the IP67
The switch is powered by an 802.3bt or 802.3at network switch or Injector. Below is a chart that describe the input and output details.
LED Function
Power Chart
Input Corresponding Output
802.3bt Type 4 (90W) each 802.3at output port supports up to 29.5W
802.3bt Type 3 (60W) 802.3at output port 1 supports 29.5W and
802.3at output port 2 supports 25W
802.3at (25.5W) each 802.3at output port supports 10W
LED Color Function
LAN Green Off: No device is connected to the corresponding port.
Light: Indicates the link through that port is successfully established.
Blink: Transmitting data and power.
Dimensions
IP67 Cable Gland Detail
