User’s Manual
BATTERY PACK
BPE36V60AS
BPE72V60AS
Cyber Power Systems,Inc.
www.cyberpower.com
K01-0000359-00

Copyright © 2014 Cyber Power Systems, Inc.
OVERVIEW
1
The CyberPower Battery packs (BPE36V60AS / BPE72V60AS) support 60A polarized plugs, and are designed for variety of CyberPower UPS systems.
When combining with the UPS, the Battery pack provides extended runtime with a 36VDC/72VDC external connection. Additional parallel-connected Battery
packs provide the UPS for a longer extended runtime operation.
1K/1.5KVA or 2K/3KVA Battery pack
User’s manual Register card
SAFETY PRECAUTIONS
CAUTION! Installation environment should be in a temperature and humidity controlled indoor area free of conductive contaminants. Do not install this
Battery pack where excessive moisture or heat is present (Please see specifications for acceptable temperature and humidity range).
CAUTION! Never install a Battery pack, or associated wiring or equipment, during a lightning storm.
CAUTION! Do not work alone under hazardous conditions.
CAUTION! In case of the risk of electric shock, do not remove the top cover.
CAUTION! The battery can energize hazardous live parts inside even when the AC input power is disconnected.
UNPACKING

Copyright © 2014 Cyber Power Systems, Inc.
2
BASIC OPERATION
BATTERY PACK FRONT/REAR PANEL DESCRIPTION
1. On-board Replaceable Fuse Cover
Replaceable fuse is accessible from the rear panel. It must be done by
qualified personnel.
2. Input Connector
Use this input connector to daisy chain the next Battery pack. Remove
the connector cover for access.
3. Output Cable
Use this output cable to connect the Battery pack to the UPS or to the
next Battery pack.
BPE36V60AS
BPE72V60AS

Copyright © 2014 Cyber Power Systems, Inc.
BASIC OPERATION
3
CONNECTION #1 : UPS WITH ONE BATTERY PACK
Step 1: Loosen the two screws to remove the battery cable retention bracket of the UPS.
Step 2: Use the output cable of the Battery pack to connect the Battery pack to the UPS.
Step 3: Rotate the battery cable retention bracket and tighten the two screws to fix battery cable.
CONNECTION #2 : UPS WITH MULTIPLE BATTERY PACKS
Step 1: Connect the 1st Battery pack to the UPS using the instructions above.
Step 2: Loosen the two screws to remove the battery cable retention bracket of the 1st battery pack.
Step 3: Use the output cable of the 2nd Battery pack to connect the 2nd Battery pack to the 1st Battery pack.
Step 4: Rotate the battery cable retention bracket and tighten the two screws to fix battery cable.

4
BASIC OPERATION
EXTERNAL BATTERY PACKS CONFIGURATION
The UPS can be configured to reflect the correct estimated run-times for the number of battery packs installed by using the LCD
Control Panel to select the number of battery packs installed.
1. Press the “ENTER” button to activate the “MAIN MENU”.
2. Press the “▲”and “▼”buttons to scroll to the “Configure”option.
3. Press the “ENTER” button to select the “Configure”submenu.
4. Press the “▲”and “▼”buttons to scroll to the “EBP Number”option.
5. Press the “ENTER” button to select the “EBP Number”submenu.
The first configuration number will be displayed on the second column of LCD display.
6. Press the “▲”and “▼”buttons to scroll through the number of attached Battery packs.
7. Press the “ENTER” button to select the number of Battery packs installed.
You may be prompted to save the selection, if so press the “ENTER” button to save the setting.
8. Press the “ESC” button to cancel or return to the previous LCD menu.
Configure Submenu
Available Settings
Default Settings
EBM Number
= [0] [1] [2] [3] [4] [5] [6] [7] [8] [9] [10]
0
Storage
To store your Extended Battery Packs for a long period of time, cover it
and store with the batteries fully charged.
Battery Replacement
Please read and follow the Safety Instructions before servicing the
battery. Battery replacement should be performed by trained personnel
who are familiar with the procedures and safety precautions. Make a note of
the replacement Battery pack number.
Safety Precautions
CAUTION! Only use replacement batteries which are certified by
CyberPower Systems. Use of incorrect battery type is an electrical
hazard that could lead to explosion, fire, electric shock, or short circuit.
CAUTION! Batteries contain an electrical charge that can cause
severe burns. Before servicing batteries, please remove any conductive
materials such as jewelry, chains, wrist watches, and rings.
Copyright © 2014 Cyber Power Systems, Inc.
CAUTION! Do not open or mutilate the batteries. Electrolyte fluid is
harmful to the skin/eyes and may be toxic.
CAUTION! To avoid electric shock, turn off and unplug the Battery
pack from the wall receptacle before servicing the battery.
CAUTION! Only use tools with insulated handles. Do not lay tools or
metal parts on top of the UPS or battery terminals.
Replacement Batteries
Please refer to the front side of the Battery pack for the model number of
the correct replacement batteries. For battery procurement, log onto
www.CPSww.com, or contact your local dealer.
Battery Disposal
Batteries are considered hazardous waste and must be disposed of
properly. Contact your local government for more information about
proper disposal and recycling of batteries. Do not dispose of batteries
in fire.
MAINTENANCE

Copyright © 2014 Cyber Power Systems, Inc.
TECHNICAL SPECIFICATIONS
5
Cyber Power Systems,Inc.
www.cyberpower.com
Entire contents copyright©2014 Cyber Power Systems,Inc., All rights reserved. Reproduction in whole or in
part without permission is prohibited. PowerPanel®Business Edition and PowerPanel®Personal Edition are
trademarks of Cyber Power Systems,Inc.
Model
BPE36V60AS
BPE72V60AS
Configuration
DC Output Voltage
36Vdc
72Vdc
Amperage
60A
Physical
Dimensions (L x W x H =)
15.6 x 6.6 x 9.1in. (397 x 167 x 232mm)
16.3 x 8.3 x 13.2in. (414 x 212 x 336mm)
Net Weight
48.4lbs(22.0Kg)
94.6lbs(43.0Kg)
Battery
Specifications
Qty 6 (2 x Banks of 3 Batteries)
Qty 12 (2 x Banks of 6 Batteries)
Interface
PP45
Sealed, Maintenance Free
Yes
Environment
Operating Temperature
32℉to 104℉( 0℃to 40℃)
Operating Relative Humidity
0 to 90% Non-Condensing
Safety
Conformance Approvals
CE, VCCI, BSMI
RoHS
RoHS Compliant
Warranty
Product Warranty
3-year limited warranty, Free Tech Support
Problem
Possible Cause
Solution
Warning
BAT Disconnected
Missing battery power.
Check battery connector and battery breaker.
Battery Failure
UPS has failed in Battery Test.
1. Check battery connector and battery breaker.
2. Contact technical support to replace the
battery.
Replace Battery
Battery will soon need to be replaced due to
insufficient runtime.
Contact technical support to replace the battery.
Fault
Over Charge
Battery is overcharged.
1. Remove battery connector and check
charger voltage.
2. Contact CyberPower for repair.
Charger Failure
Charger has failed.
TROUBLE SHOOTING
