CyberPower CS20A-EBP User manual

Cyber Power
User’s Manual for
CyberShield
External Battery Pack
CS20A-EBP
20 Ah 12V Battery
CyberShield UPSs are designed to provide a local power solution for
cable telephony, wireless local loop (WLL), and fiber to the home
(FTTH) broadband equipment. CyberShield External Battery Pack
connects directly to the CyberShield providing longer runtime for
connected applications.
IMPORTANT SAFETY WARNINGS
(SAVE THESE INSTRUCTIONS)
This manual contains important instructions regarding the installation and operation of this device.
Read this manual thoroughly before attempting to unpack, install or operate this device
CAUTION! The battery can energize hazardous live parts inside even when the AC input power is
disconnected.
CAUTION! To prevent the risk of fire or electric shock, install in a temperature and humidity
controlled indoor area, free of conductive contaminants. (Please see specifications for
acceptable temperature and humidity range).
CAUTION! To reduce the risk of electric shock, do not remove the cover, except to service the
battery. No user serviceable parts inside, except for the battery.
CAUTION! To avoid electric shock, turn off the unit and unplug it from the AC power source before
servicing the battery or installing a computer component.

UNPACKING
Inspect the unit upon receipt. Notify the shipping carrier or product supplier if there is damage. The
box should contain the following:
1. ) the enclosure (cable and connector attached)
2. ) the battery (installed, not connected)
3. ) product documentation.
ENCLOSURE INSTALLATION
Carefully follow these instructions during installation of this device:
1. ) Carry out the installation in a safe area that is free of excessive dust and has adequate airflow.
2. ) Screws must be appropriate for total weight of the UPS and the mounting surface material.
3. ) Do not operate the UPS where the temperature and humidity are outside the specified limits.
(Refer to specification in this manual.)
a. Remove the battery cover. a. Unstrap strap from battery.
b. Slide battery off of the
shelf.
c. Disconnect battery cable
connector at chassis end.
Step 3:
a. Use the enclosed installation template to
mark an installation location for the unit.
b. Mount the unit on the wall with 2 mounting
screws into the keyhole slots.
c. Tighten the screws to secure the units.
d. Connect the battery connector and replace
the battery back.
BATTERY INSTALLATION
Step 1:
a. Remove the battery cover.
a. Loosen the battery strap.
b. Disconnect battery cable connector
to remove battery.
c. Replace with new battery and
re-connect the battery connector.
Step 3:
a. Tighten the battery strip and
close the battery cover.
CONNECTING A SINGLE EXTERNAL BATTERY PACK
CONNECTING MULTIPLE EXTERNAL BATTERY PACKS
BATTERY REPLA CEMENT
This UPS has an easy to replace, hot-swappable battery. Replacement is a safe procedure,
isolated from electrical hazards. You may leave the UPS and connected equipment on for this
procedure.
To replace the battery module refer to BATTERY INSTALLATION, above.
Once the battery is disconnected, the connected equipment is not protected from
power outages.
Deliver spent batteries to a recycling facility or ship to the manufacturer in the
replacement battery packing material.
The UPS battery charges when it is connected to utility power. The battery charges
fully during the first 24 hours of normal operation. Do not expect full battery run
capability during this initial charge period.

SPECIFICATION
Model
CS20A-EBP 1
Battery
Battery Type
Sealed, Maintenance Free Lead-Acid Battery
Numbers of Battery
20AH / 12V x 1
Replaceable
Yes
Physical
Maximum Dimensions (L*W*D)
30cm x 28cm x 9.9cm
Weight (kg)
7.5
Environment
Operating Temperature
32°F -104°F (0 - 40°C)
Operating Humidity
0 - 95% noncondensing within enclosure
Max Operating Elevation
10,000ft (3,000m)
Max Storage Elevation
50,000ft (15,000m)
Storage Temperature
5°F - 113°F (-15°C-45°C)
FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with these instruc¬
tions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures: (1 )Reorient or relocate the receiving antenna. (2) Increase the separation between
the equipment and receiver. (3) Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected. (4) Consult the dealer or an experienced radio/TV
technician for help.
CAUTION: Shielded signal cables must be used with this device to ensure compliance with Class
B FCC limits.
CAUTION: Any changes or modifications not expressly approved by Cyber Power could void the
authority granted by the FCC to operate this equipment.
LIMITED WARRANTY
CyberPower warrants to you, the Initial Purchaser, that the Product will be free from defects in material and
workmanship for three years from the date of original purchase, subject to the terms of this Limited Warranty.
This Limited Warranty gives you specific rights, and you may have other rights, which vary from State to State
or Province to Province.
Any Implied Warranty of Merchantability or for Fitness for a Particular Purpose, if applicable to the Product, is
limited in duration to three years. This provision shall NOT create any Implied Warranty or Merchantability or of
Fitness for a Particular Purpose that would not otherwise apply to the Product. NOTE: Some States and
Provinces do not allow limitations on how long an implied warranty lasts, so the above limitation may
not apply to you.
To be covered you must still be the owner of the Product at the time of the failure that results in the claim made
under this Limited Warranty. Your sole and exclusive remedies are those provided by this Limited Warranty.
This exclusion of other express warranties applies to written and oral express warranties. CyberPower
excludes any liability for personal injury. CyberPower excludes any liability for direct, indirect, special,
incidental, or consequential damages, whether for damage to or loss of property, loss of profits, business
interruption, information or data. This exclusion applies even though damage or loss is caused by negligence
or other fault. NOTE: Some States or Provinces do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitation may not apply to you.
DO NOT USE FOR MEDICAL OR LIFE SUPPORT EQUIPMENT OR OTHER HIGH RISK ACTIVITIES.
CyberPower does not sell the PRODUCT for use in high-risk activities. The PRODUCT is not designed or
intended for use in hazardous environments requiring fail-safe performance, including the operation of nuclear
facilities, aircraft navigation or communication systems, air traffic control, weapons systems, life support or
medical applications or for use in any circumstance in which the failure of the PRODUCT could lead directly to
death, personal injury, or severe physical or property damage, or that would affe# operation or safety of any
medical or life support device (collectively, "High Risk Activities"). CyberPower expressly disclaims any express
or implied warranty of fitness for High Risk Activities. CyberPower does not authorize use of any PRODUCT in
any High Risk activities. ANY SUCH USE IS IMPROPER AND IS A MISUSE OF A CYBERPOWER
PRODUCT.
The Limited Warranty is governed by the laws of the United States and the State of Minnesota, without
reference to conflict of law principles. The application of the United Nations Convention of Contracts for the
International Sale of Goods is expressly excluded.

For more information, please contact:
CyberPower Systems ( USA), Inc. 5555 12th Avenue East, Suite 110, Shakopee, MN55379 Phone:
CyberPower Systems B. V. ( Europe ) Uilenwaard 42, 5236 WB, ‘s-Hertogenbosch, The Netherlands Phone:
>wer
The Power To Control the Pawer s
[phone]
(31)73 649-1209
Fax: [phone]
Fax: [phone]
www.cyberpowersystems.com
www.cyberpower-eu.com
