ATON G Infant Car Seat
Owner’s Manual
READ this Owner’s Manual carefully before rst use, and keep it for future reference.

2
Thank you for purchasing the CYBEX ATON G. We are proud to bring this German-
engineered product to the United States and Canada. We hope the ATON G will make your
child’s travel both safer and more pleasant, as well as make installation and use for you as
simple as possible.
Statistics show that over 75% of Child Restraints are being used incorrectly!
Please read and follow these instructions carefully to install the CYBEX ATON G correctly,
even if the installation and use of this Infant Car Seat might seem simple and intuitive.
Before the rst use of the CYBEX ATON G Infant Car Seat, please make sure you have
followed all the steps in the Safety Checklist on pg. 72.
Following the American Academy of Pediatrics' recommendations for safe transportation
of infants, we recommend children remain in a REAR-FACING car seat as long as
possible, until they reach the highest weight or height allowed by their seat. Visit
www.aap.org for more information on the Academy's recommendation.
No car seat can guarantee protection from injury in every situation, but proper use helps
reduce the risk of death or serious injury. If you have any questions or need assistance,
please contact ParentLink Customer Service at 1-877-242-5676 (USA and Canada).
Also, please remember to register your Infant Car Seat so we can contact you in the
unlikely event of a recall. Register online at: http://register.cybex-online.com/us/
carseats (USA) or http://register.cybex-online.com/ca/carseats (Canada).
Keep this Owner’s Manual for future reference by storing it in the slot at the front of the
ATON G Base. We appreciate your purchase and invite you to visit www.cybex-online.
com to see other great CYBEX products.
Welcome to CYBEX!

3
According to the U.S. National Highway Trafc Safety Administration (NHTSA), car
seats and boosters provide protection for infants and children in a crash, yet car
crashes are a leading cause of death for children.
To reduce the risk of SERIOUS INJURY or DEATH, read this owner’s manual and your
vehicle owner’s manual before installing and using this Car Seat. Using a Car Seat
makes a big difference. By properly using this Car Seat and following these instructions,
the instructions on the Car Seat, and the instructions that accompany your vehicle, you
will greatly reduce the risk of serious injury or death to your child from a crash. Do not
be misled by the commonly used term “safety seat”; no restraint system can prevent all
injuries in all crashes. Many properly restrained adults and children are injured in motor
vehicle crashes, including relatively minor crashes. A properly used Car Seat is the best
way to minimize injuries to your child and to increase the chances for your child’s survival
in most crashes.

4
Table of Contents
Welcome to CYBEX! ........................................................................................................2
Registration and Recall Information .................................................................................6
Child Usage Guidelines ....................................................................................................8
Premature Infant Use ................................................................................................10
Warnings ........................................................................................................................12
Overview of the ATON G Infant Car Seat .......................................................................22
Overview of the ATON G Base .......................................................................................24
Product Features and Descriptions
No Rethread Harness ................................................................................................25
Harness Buckle .........................................................................................................26
Chest Clip ..................................................................................................................26
Harness Adjustment ..................................................................................................27
Handle Positions ........................................................................................................27
Infant Insert................................................................................................................28
Shoulder Pads ...........................................................................................................28
Integrated XXL Canopy .............................................................................................29
SafeLock™ Belt Tensioner .........................................................................................29
READ OWNER'S MANUAL PRIOR TO INSTALLING AND USING THIS CHILD
RESTRAINT. KEEP INSTRUCTIONS FOR FUTURE USE.

5
Table of Contents
Installing and Removing the Infant Car Seat
Installing with Base Using LATCH/UAS .....................................................................30
Installing with Base Using Lap/Shoulder Belts ..........................................................34
Installing with Base Using Lap Belt Only ...................................................................39
Installing the Infant Car Seat Only Using Lap/Shoulder Belts ...................................43
Installing the Infant Car Seat Only Using Lap/Shoulder Belts (Alternate) .................47
Installing the Infant Car Seat Without Base Using Lap Belt Only ..............................50
Using the Infant Car Seat with the Base
Attaching the Infant Car Seat to the Base .................................................................53
Removing the Infant Car Seat from the Base ............................................................54
Adjusting the Recline Angle ............................................................................................55
Securing the Child ..........................................................................................................57
Changing the Buckle Strap Position ...............................................................................60
Using the Infant Car Seat on Aircraft ..............................................................................62
Removing and Replacing Seat Cover .............................................................................64
Care and Cleaning ..........................................................................................................71
Safety Checklist ..............................................................................................................72
Resources ......................................................................................................................73
Warranty .........................................................................................................................74

6
REGISTERING YOUR CHILD RESTRAINT
Please complete the registration card
that came with your Child Restraint and
mail it in immediately or register online.
Child restraints could be recalled for safety
reasons. You must register this restraint to
be reached in a recall. Send your name,
address, e-mail address if available, and the
restraint’s model number and manufacturing
date to:
Columbus Trading-Partners USA Inc.
Attn: ParentLink Customer Service
1801 Commerce Drive
Piqua, Ohio 45356, USA
or call 1-877-242-5676 or register online at
http://register.cybex-online.com/us/
carseats
For recall information, call the U.S.
Government’s Vehicle Safety Hotline at:
1-888-327-4236 (TTY: 1-800-424-9153), or
go to www.NHTSA.gov.
Registration and Recall Information
PUBLIC NOTICE FOR CANADIAN
CUSTOMERS
Child restraints could be recalled for safety
reasons. To register your Child Restraint,
return the registration card, call Goodbaby
Canada Inc. at 1-877-242-5676, or register
online at http://register.cybex-online.com/
ca/carseats
For recall information, call Transport
Canada at 1-800-333-0510
(1-613-993-9851 in Ottawa region) or
Goodbaby Canada Inc. at 1-877-242-5676,
or go to www.tc.canada.ca.
For public notice information, call Transport
Canada at 1-800-333-0510 (1-613-993-
9851 in Ottawa region).

7
CERTIFICATION
Regulatory Notice: This Child Restraint system meets all applicable requirements of
Federal Motor Vehicle Safety Standard (FMVSS) 213 and Canadian Motor Vehicle Safety
Standards (CMVSS) 213 and 213.1.
This restraint is certied for use only in passenger and multi-purpose passenger motor
vehicles, buses, and trucks equipped with Lap/Shoulder Belt systems.
THIS RESTRAINT IS CERTIFIED FOR USE IN AIRCRAFT IF USED WITHOUT
THE BASE.
Check with your airline before departure to make sure this Child Restraint meets
their requirements, then refer to pgs. 62-63 for complete instructions on installing
your Child Restraint in aircraft.
Registration and Recall Information

8
This Child Restraint is designed for use by children in REAR-FACING MODE ONLY. To
use this Child Restraint properly, children MUST meet the size and age requirements on
the following pages.
The American Academy of Pediatrics (AAP) recommends keeping children REAR-FACING
for as long as possible, until they reach the maximum height or weight for their Child
Restraint in REAR-FACING orientation.* Additionally, some states’ laws require children
to be REAR-FACING until age 2. Accordingly, you will see this guidance reected in the
Child Requirements on the following pages. Please review any applicable local, state or
provincial laws related to child passenger safety before installing and using this Child
Restraint.
!WARNING! DEATH or SERIOUS INJURY can occur.
*Pediatrics. 2018;142(4):e20182460
Child Usage Guidelines

9
Minimum 2.5 cm
(1 in)
Child Usage Guidelines
Do not use this Child Restraint if your child does not meet
all of these requirements:
• Weight is between 1.8 and 15.8 kg (4 and 35 lbs)
• Height is between 43 and 81 cm (17 and 32 in)
• Top of child's head is a minimum of 2.5 cm (1 in) below the
top of the Infant Car Seat or Headrest, WHICHEVER IS
HIGHER.
IMPORTANT: Once your child EXCEEDS any of the size
requirements above, they MUST DISCONTINUE use of this
Child Restraint. After your child outgrows the ATON G, keep
your child REAR-FACING in a convertible or all-in-one car seat
as long as the seat allows, according to the manufacturer's
specications, before turning them around to ride FORWARD-
FACING.
IMPORTANT: For proper use of the Infant Car Seat, the
Harness Straps MUST be AT OR JUST BELOW your child's
shoulders.
NOTE: Regularly check for proper Harness height as your child
grows.

10
Before using this Child Restraint for preterm or low birth weight infants, ensure the
Child Requirements are met and follow the guidelines in this section.
According to the National Highway Trafc Safety Administration (NHTSA), a properly
installed Child Restraint reduces the risk of death by over 70% for infants involved in
crashes. Federal Motor Vehicle Safety Standard (FMVSS) 213 establishes design and
dynamic performance requirements for Child Restraint systems. However, the standard
has no minimum weight limit and does not address the special medical needs of preterm
or low birth weight infants. To ensure that preterm and low birth weight infants are
transported safely, the guidelines published by the American Academy of Pediatrics (AAP)
in Pediatrics 2009;123:1424–1429 (reafrmed June 2018) must be followed.
Preterm and low birth weight infants are at additional risk of breathing difculties and
heart problems when placed in a Child Restraint. CYBEX requires that the evaluation
recommended by the AAP be conducted for all infants born earlier than 37 weeks and all
newborn infants who weigh less than 2.26 kg (5 lbs) at birth before their rst car trip to
check for breathing difculties or heart rate problems when traveling in a REAR-FACING
Child Restraint. Newborn infants should NEVER travel in a FORWARD-FACING Child
Restraint.
The AAP recommends that appropriate hospital staff observe your infant in the Child
Restraint for a period of 90 to 120 minutes or the duration of travel, whichever is longer.
This period of observation must be performed with the infant properly positioned as
described in these instructions and with the Child Restraint placed at an angle that is
approved for use in the vehicle. The hospital staff will check for any breathing difculties
or heart rate problems. Your child’s pediatrician will let you know if there are any special
Child Usage Guidelines
Premature Infant Use

11
considerations for travel. The number of trips and the duration of time the infant is seated
in the Child Restraint should be minimized. A caregiver should ride in the back seat to
monitor the infant during travel.
You can learn more about the AAP’s recommendations as well as other resources for
parents and medical professionals, at https://www.healthychildren.org/english/safety-
prevention/on-the-go/Pages/default.aspx.
Child Usage Guidelines
Premature Infant Use
Routing the Harness Buckle for Use with
Premature and Smaller Infants
1. Partially remove the Seat Cover from the
front of the seat.
2. From the top of the seat, feed the Buckle
Anchor and Harness Buckle Cover
through the rear slot in the Seat Cover.
3. Feed the Buckle Anchor through the
rear slot and then from underneath the
seat, feed the Buckle Anchor up through
the middle slot, making sure it goes
completely through the slot and lays at
against the bottom of the seat.
4. Replace the Seat Cover.
5. See pages 60 - 61 for more information.

12
!WARNING! DEATH or SERIOUS INJURY can occur.
AIRBAG WARNINGS
• DO NOT place a REAR-
FACING Child Restraint on
a front seat with an active
airbag. DEATH OR SERIOUS
INJURY can occur. The back
seat is the safest place for children 12
and under.
• DO NOT use this Restraint in the front
seat of a vehicle equipped with an air
bag. Interaction between a Rear-Facing
Child Restraint and air bags may cause
death or serious injury. If your vehicle has
an air bag, refer to the vehicle owner’s
manual for Child Restraint installation.
• DO NOT use this Child Restraint in a
vehicle seating position equipped with
a side air bag unless authorized by the
vehicle manufacturer. Refer to vehicle
owner's manual.
• DO NOT place any objects between the
Restraint and the side air bag, as an
expanding air bag may cause the items to
strike your child.
GENERAL WARNINGS
The primary protection for occupants of
a vehicle in a collision is the structure
of the vehicle itself. Correctly used per
the instructions and labeling, this Child
Restraint will substantially improve the
chances for survival in most crashes.
• READ this Owner’s Manual carefully
before rst use and keep it for future
reference.
• FOLLOW ALL INSTRUCTIONS on
this Infant Car Seat and in the written
instructions stored in the slot at the front
of the ATON G Base.

13
!WARNING! DEATH or SERIOUS INJURY can occur.
• NEVER install or use this Child Restraint
until you have read and understand the
instructions in this manual, your vehicle
Owner’s Manual, and the labels on your
Infant Car Seat. If there is a conict
between this manual and the vehicle
Owner's Manual, the vehicle Owner’s
Manual must be followed. Failure to follow
these instructions can result in death or
serious injury to your child in a crash.
• DO NOT allow others to install or use this
Child Restraint unless they understand
how to correctly install and use it.
• NEVER allow someone else to use this
Child Restraint without also passing
along this manual to them.
• DO NOT use a Child Restraint with an
unknown history.
• NEVER USE CHILD RESTRAINT IF
IT HAS DAMAGED, BROKEN, OR
MISSING PARTS.
• DO NOT attempt to make repairs to or
otherwise modify or tamper with this Child
Restraint.
• ALWAYS REPLACE THE CHILD
RESTRAINT AFTER A CRASH OF ANY
KIND, EVEN IF IT WAS UNOCCUPIED.
A crash can cause damage to the Child
Restraint that may not be visible.
• ALWAYS check Buckles and other
parts for hot surfaces before placing
your child in the Child Restraint . A hot
surface could burn your child! Cover
an unoccupied Child Restraint with a
blanket when leaving it in a vehicle. The
interior of a vehicle can become hot
enough to burn child even on a cloudy
day.
LOCATION WARNINGS
• ACCORDING TO ACCIDENT
STATISTICS, children are safer when
properly restrained in rear vehicle seating
positions.

14
!WARNING! DEATH or SERIOUS INJURY can occur.
• ONLY place this Child Restraint in a
vehicle seating location allowed by the
vehicle manufacturer. To determine
allowable seating positions, refer to your
vehicle owner's manual for information
about vehicle seat belt systems, air bags,
side air bags, front passenger side air
bags and Child Restraint installations.
• NOT EVERY LOCATION WITHIN A
VEHICLE MAY BE SAFE FOR THE
INSTALLATION OF THIS CHILD
RESTRAINT. In fact, some vehicles
have no seating position that is safe for
the installation of this Child Restraint.
Improper placement of this Child
Restraint within a vehicle will increase the
risk of death or serious injury.
• NEVER use this Child Restraint in a
vehicle seating position where it cannot
be secured tightly. A loosely installed
Child Restraint will not protect your child
in a crash.
• ONLY use this Child Restraint on
FORWARD-FACING vehicle seats.
• NEVER install this Child Restraint in
vehicle seats that face the rear or side of
the vehicle.
• VEHICLE TYPES WHERE THE
RESTRAINT SYSTEM CAN NOT BE
USED: This Child Restraint is NOT to be
used in vehicles that do not have vehicle
seat belts or lower anchors (see pg. 26).
• ONLY use this Child Restraint on vehicle
seats with backs that lock into place. In
the event of a sudden stop, an unlocked
vehicle seat back could prevent this Child
Restraint from protecting your child.

15
!WARNING! DEATH or SERIOUS INJURY can occur.
• NEVER use this Child Restraint on boats,
low speed vehicles (LSV), all-terrain
vehicles (ATV), golf carts, or any other
non-certied application.
USAGE WARNINGS
• ONLY USE with children who weigh
between 1.8 and 15.8 kg (4 and 35 lbs)
AND whose height between 43.2 and 81
cm (17 and 32 in).
• DO NOT USE this Child Restraint if top
of child's head is a minimum of 2.5 cm (1
in) below the top of the Infant Car Seat or
Headrest, WHICHEVER IS HIGHER.
• ONLY USE this Child Restraint REAR-
FACING.
• ALWAYS USE the complete and buckled
ve-point Harness around your child.
• ALWAYS CHECK the Harness Buckle to
make sure it is securely latched.
• Children have STRANGLED in loose or
partially buckled Harness Straps. FULLY
RESTRAIN the child even when the
carrier is used outside the vehicle.
• ALWAYS have the Handle in a LOCKED
position while using this Child Restraint in
a vehicle (see pg. 27).
• ALWAYS have the Handle LOCKED
in the CARRY position when lifting by
the Handle. Lifting from ANY OTHER
LOCKED or UNLOCKED Position could
cause the child to fall.
• ALWAYS CHECK to make sure the Infant
Car Seat is securely attached to the Base
each time you use this Restraint. After
attaching the Infant Car Seat to the Base,
LIFT UP on the Handle to ensure the
Carrier is securely attached to the Base.

16
!WARNING! DEATH or SERIOUS INJURY can occur.
• BEFORE each use, ALWAYS CHECK
that the Child Restraint is tightly secured
in the vehicle seat and does not move
more than 2.5 cm (1 in) in any direction
when checked at the Belt Path.
• WHEN NOT IN USE, securely store
LATCH/UAS Connectors.
• NEVER allow children to play with the
SafeLock Belt Tensioner (pg. 24).
• SUFFOCATION HAZARD: Infant Car
Seat can roll over on soft surfaces and
suffocate child. NEVER place Infant
Car Seat on beds, sofas, or other soft
surfaces.
• FALL HAZARD: Child’s activity can move
Carrier. NEVER place Carrier on counter
tops, tables, or any other elevated
surfaces.
• FALL HAZARD:
The Carrier can fall
from the shopping
cart. Do not use on
shopping cart.
• ONLY USE Infant
Car Seat with
strollers that
are approved by
CYBEX. Refer to the stroller Owner's
Manual for details about how to attach the
Infant Car Seat to your stroller. For a list
of compatible strollers, please visit www.
cybex-online.com.
ADDITIONAL WARNINGS
• REGISTER your Child Restraint with
the manufacturer. This is the best way to
reach you in the event of a recall.
• NEVER USE this Child Restraint when
it is older than six (6) years. The date
of manufacture can be found on a label
afxed to the bottom of the Infant Car
Seat, as well as on the Base.

17
!WARNING! DEATH or SERIOUS INJURY can occur.
• NEVER USE this Child Restraint if
the Harness Straps are cut, frayed, or
damaged in any way.
• NEVER LEAVE child unattended.
• NEVER USE accessories or parts with
this Child Restraint other than those
approved by CYBEX. Use of accessories
or parts from other manufacturers
could alter the performance of the Child
Restraint .
• DO NOT attach additional padding, toys,
or other devices not made by CYBEX or
described in these instructions for the
Child Restraint. Items not tested with
the Child Restraint could injure the child.
Additional pads or pillows may interfere
with the function of the Harness system,
or cause breathing problems if the child’s
head falls forward, increasing the risk of
serious injury or death.
SEAT BELT WARNINGS
• ALWAYS read your
vehicle owner's manual
to determine what
vehicle belts and
retractors are used in
your vehicle.
• DO NOT use this Child
Restraint in a seating
position with door-
mounted seat belts.
• DO NOT use this Child
Restraint in a vehicle
with seat belts that
automatically move along
the vehicle frame when
the door is opened.
Retractor

18
• DO NOT use this Child Restraint with
inatable seat belts.
• Check your vehicle owner’s manual to
determine how to lock your seat belt for
Child Restraint installation. The seat belt
MUST be locked to properly secure the
Child Restraint.
• DO NOT allow the vehicle seat belt
release button to touch the Child
Restraint. Accidental contact may cause
the seat belt to release. If necessary, turn
the seat belt release button away from
the Child Restraint or move the Child
Restraint to a different location.
• Child Restraint systems should be
securely belted to the vehicle, even when
they are not occupied, since in a crash
an unsecured Child Restraint system may
injure other occupants.
• DO NOT use this Child
Restraint in a vehicle
equipped with Lap Belts that
only lock during a sudden
stop or crash (Emergency
Locking Retractor - ELR).
You must use a seating
location with a Lap/Shoulder
Belt or a locking Lap Belt. Check your
vehicle owner’s manual to see if you have
Lap Belts with ELRs.
• DO NOT use on vehicle
seats when both portions
of the lap-only belt are
positioned forward of the
seat crease.
• DO NOT use with Lap/
Shoulder Belts with two
retractors. If the vehicle seat
belts are not routed and
fastened correctly, the Child
Restraint may not protect the
child in a crash.
!WARNING! DEATH or SERIOUS INJURY can occur.

19
Free end
!WARNING! DEATH or SERIOUS INJURY can occur.
If you have any of these types of vehicle
belt systems listed, these are SAFE to use
to install your Child Restraint in the vehicle.
Review vehicle owner’s manual for specic
instructions on Child Restraint installation.
Lap Belt with Locking Latch Plate
• Once buckled, the
vehicle belt is tightened
by pulling on the free
end of the strap until
the belt is tight.
Lap/Shoulder Belt with Locking Latch
Plate
• The lap portion of
this belt does not
loosen once the belt is
buckled.
• The vehicle belt is tightened by pulling
up hard on Shoulder Belt and feeding the
extra webbing into the retractor.
Lap Belt with Automatic Locking
Retractor (ALR)
• The automatic
locking retractor
does not allow the
Lap Belt to get longer once it is buckled.
The vehicle belt is tightened by feeding
seat belt webbing into retractor.
Lap/Shoulder Belt with Sliding Latch
Plate with Locking Retractor
• The latch plate slides
freely along the Lap/
Shoulder Belt. Vehicle
belts with sliding latch
plates are typically
locked at the Shoulder Belt Retractor by
buckling the belt and pulling all of the
webbing out slowly to switch the retractor.
• Check vehicle owner’s manual for specic
instructions. The vehicle belt is tightened
after switching the retractor by pulling up
on Shoulder Belt and feeding the webbing
into the retractor.

20
Vehicle Lower
Anchors
Vehicle Top Tether Anchor Points
Vehicle Seat
Crease
LATCH and UAS are acronyms for Lower Anchors and
Tethers for CHildren (USA) and Universal Anchorage System
(Canada), and refer to a pair of xed Lower Anchors (or bars)
and a Top Tether Anchor that are built into your vehicle, in
vehicles built after September 1, 2002. Your vehicle owner’s
manual may also refer to this system as ISOFIX or Lower
Universal Anchorage System (LUAS).
The lower LATCH/UAS anchors are located in the crease, or
bight, between the vehicle seat back and seat cushion, and
if not visible, will typically be indicated by the symbol. Top
Tether Anchors are located in various places behind the rear
vehicle seat.
Center Seating Positions. CYBEX allows this Child Restraint
to be installed using the two inner Lower Anchors from the
outboard seating positions if (1) your vehicle owner's manual allows such an installation;
and (2) the distance between the inner Lower Anchors is 28-51 cm (11-20 in). When using
the inner Lower Anchors make sure there are no obstructions from a Buckle Stalk for the
installation or that the LATCH/UAS Connectors do not block vehicle belt buckles.
This Child Restraint can be safely installed using either LATCH/UAS or vehicle belts and
meets the requirements of Federal Safety Standard FMVSS 213 and Canadian Safety
Standard CMVSS 213 with either installation method. Either method is safe for your child
when installed correctly.
!WARNING! DEATH or SERIOUS INJURY can occur.
