Cybex Platinum SOLUTION Z-FIX User manual

L2 EN
SOLUTION Z-FIX
READ this Owner’s Manual carefully before rst use, and keep it for future reference.
LEA con cuidado este Manual del propietario antes de usar el producto por primera vez y guárdelo para uso futuro.
Owner’s Manual
Manual del propietario
ENES

2
Thank you for purchasing the CYBEX Solution Z-x High Back Booster Seat. We are proud to bring this German engineered
seat to North America. We hope the Solution Z-x will make your child’s travel both safer and more pleasant, as well as
making installation and use for you as simple and easy as possible.
The Solution Z-x is the next generation of the award winning CYBEX booster seats. With greatly improved protection in side
impact and forward facing crashes, the Solution Z-x takes booster safety to a new level.
Statistics show that over 75% of car seats are installed incorrectly!
Please read and follow these instructions to install this booster seat correctly, even if the installation and use of this booster
seat might seem simple and intuitive. The safety of your child depends on it! Although many booster seats may be used
without the backrest attached, the Solution Z-x should NEVER BE USED WITHOUT THE BACKREST ATTACHED as it
dramatically reduces the protection in a crash.
We recommend keeping your young child in a properly sized and installed car seat as long as possible before making the
switch to the Solution Z-x High Back Booster Seat.
No car seat can guarantee protection from injury in every situation, but proper use helps reduce the risk of death or serious
injury. If you have any questions or need assistance, please contact Cybex at 1-877-242-5676
Also, please remember to register your booster seat so we can contact you in the unlikely event of a recall. Register online:
• In the United States, at http://register.cybex-online.com/us/carseats
• In Canada, at http://register.cybex-online.com/ca/carseats
Keep this Owner’s Manual for future reference by storing it in the pocket behind the Backrest pad. We appreciate your
purchase and invite you to visit our web site www.cybex-online.com to see other great CYBEX products.
Before the rst use of this booster seat, please make sure you have followed all the steps in the Safety Checklist found on
page 31.
WELCOME TO THE CYBEX FAMILY,

EN
3
INDEX
SOLUTION Z-FIX FEATURES ..................................................................................................................................... 2
REGISTRATION AND RECALL INFORMATION ....................................................................................................... 3
BOOSTER SEAT OVERVIEW...................................................................................................................................... 4
WHEN TO PLACE YOUR CHILD IN A BOOSTER SEAT.......................................................................................... 6
CHILD SIZE: HEIGHT, WEIGHT, AND AGE RANGES .............................................................................................. 7
WARNINGS AND IMPORTANT SAFETY INFORMATION........................................................................................ 8
ASSEMBLY.................................................................................................................................................................... 12
VEHICLE SEAT LOCATION REQUIREMENTS ......................................................................................................... 13
VEHICLE SEAT BELT REQUIREMENTS ................................................................................................................... 15
VEHICLE LATCH/UAS REQUIREMENTS.................................................................................................................. 16
INSTALLING USING LATCH/UAS .............................................................................................................................. 17
INSTALLING WITH SEAT BELT ONLY....................................................................................................................... 19
ADJUSTING THE SEAT FOR YOUR CHILD.............................................................................................................. 20
SECURING YOUR CHILD IN THE BOOSTER SEAT ............................................................................................... 22
UNINSTALLING THE BOOSTER SEAT .................................................................................................................... 26
FABRIC COVERS ......................................................................................................................................................... 27
CARE AND CLEANING................................................................................................................................................ 30
SAFETY CHECKLIST................................................................................................................................................... 31
RESOURCES................................................................................................................................................................. 32
WARRANTY................................................................................................................................................................... 33

Three Position
Reclining
Headrest
D
E
E
P
S
A
F
E
T
Y
Z
O
N
E
2
The Solution Z-x brings all new technologies to the High
Back Booster Seat category to enhance the safety of your
child in the event of a side impact collision.
LINEAR SIDE-IMPACT PROTECTION™ (L.S.P.)
The L.S.P. system allows the forces from a side impact
collision to be reduced gradually to help minimize injuries.
The Head and Shoulder Protectors are made of extra deep
and thick energy absorbing EPS foam to create a deep
Safety Zone™ around your child.
THREE POSITION RECLINING HEADREST
When a child sleeps, their head can fall forward. The CYBEX
Three Position Reclining Headrest helps avoid this by
allowing your child’s head to recline and remain protected in
the Safety Zone of the Head Protectors. If your child slumps
forward out of position when asleep, there is an increased
risk that your child will not be well protected in the event of a
collision.
Thanks to the Reclining Headrest of the Solution Z-x, your
child will be able to lean back and sleep comfortably with the
head inside the Safety Zone.
SOLUTION Z-FIX FEATURES

EN
3
REGISTRATION AND RECALL INFORMATION
Please complete the Registration Card that came with
your Child Restraint and mail it immediately or register
online.
Child restraints could be recalled for safety reasons. You
must register this restraint to be reached in a recall. Send
your name, address, e-mail address if available, and the
restraint’s model number and manufacturing date to:
Columbus Trading-Partners USA Inc.
Attn: ParentLink
1801 Commerce Drive
Piqua, Ohio 45356, USA
or call 1-877-242-5676 or register online at
http://register.cybex-online.com/us/carseats
For recall information, call the U.S. Government’s Vehicle
Safety Hotline at: 1-888-327-4236 (TTY: 1-800-424-9153), or
go to www.NHTSA.gov.
PUBLIC NOTICE FOR CANADIAN CUSTOMERS
To register your booster, return the registration card, call
1-877-242-5676, or register online at http://register.cybex-
online.com/ca/carseats
For recall information, call Transport Canada at 1-800-
333-0510 (1-613-993-9851 in Ottawa region) or Goodbaby
Canada Inc. at 1-877-242-5676.
CERTIFICATION
In the United States, this child restraint system conforms to
all applicable Federal Motor Vehicle Safety Standards.
In Canada, this child restraint system meets all the
applicable requirements of Canadian Motor Vehicle Safety
Standard 213.2.
This restraint is certied for use only in passenger and
multi-purpose passenger motor vehicles, buses, and trucks
equipped with lap/shoulder belt systems.
THIS RESTRAINT IS NOT CERTIFIED
FOR AIRCRAFT USE as shoulder belts
are not available for proper use.
Registration information may be found a󰀩xed to the
underside of the Booster Base.

4
Backrest
Rigid LATCH/UAS
Booster Base
BOOSTER SEAT OVERVIEW
FRONT VIEW
Owner’s Manual
EN
Reclining Headrest
Shoulder Pad
Head Protection
Armrest
L.S.P. Bolster
Lower Belt Guide
Owner’s Manual
(behind Backrest pad)

EN
5
LATCH/UAS Guides
(tied to Booster Base
for shipping)
BOTTOM VIEW
REAR VIEW
Expanding Backrest
Shoulder
Belt Guide
LATCH/UAS
Connector
(stored inside base)
Headrest Height
Adjustment Handle
LATCH/UAS Adjustment Handle
Product Information Label
Model Name:
Solution Q-fix
Model Number:
120884814
Color:
Allen Gray
CY
BEX Article: 7706256101
Manufactur
ed in: 01/2014
Do not use after:
01/2021
Distributed by Regal Lager
, Inc.
11
00 Cobb Place Blvd., Ste. 120
K
ennesaw, GA 30144, USA.
Made in China.
BOOSTER SEAT OVERVIEW

6
WHEN TO PLACE YOUR CHILD IN A BOOSTER SEAT
Booster seats raise the child up and help to position the
vehicle lap and shoulder belt correctly. When the child is
properly restrained in a booster seat, their risk of injury in
all types of crashes is reduced.
It is important for the child to
sit properly within the vehicle
seat belts. When the vehicle
seat belt is buckled, the lap belt
must be positioned low and
snug at the child’s hips, just
touching the thighs (a), and the
shoulder belt should lie across
the middle of the shoulder
(b). If the child leans out or
moves the belt behind the back
or places it under the arm, it will not provide the intended
restraint.
There are a number of things to consider when deciding
whether the child is ready to sit in a booster seat, including:
the weight and height rating on their current child seat, the
child’s own weight and height, their maturity, and the seating
positions available in your vehicle.
How is a booster seat used?
Using a booster seat is very similar to buckling yourself into
the vehicle:
• Read the instruction manuals for both the booster seat
and the vehicle before you start.
• Put the booster in the back seat in a location with a lap
and shoulder belt. Never use a booster with only a lap
belt, as this could cause serious injuries.
• After the child is in the booster, pull the lap and shoulder
belt across him/her and buckle it.
• Check that the shoulder belt lies across the middle of
the shoulder and that the lap belt is low on the hips, just
touching the thighs.
How can you tell if your child is ready to transition to a
booster seat?
You should consider using a booster seat if the following
conditions apply:
• The child is mature enough to sit in the booster seat and
not put the belts under their arm or behind their back.
• The child is approaching the weight or height limit of the
child restraint they are currently using.
• If you have a vehicle that does not have a tether
anchorage but has lap/shoulder belts available in the back
seat.
b
a

EN
The tops of the child’s ears (Orange Line) are below the top
of the booster seat (Red Line).
When sitting in a booster seat, the shoulder belt should lie
across the middle of the shoulder (GREEN ZONE) and
snug across the midpoint of the child‘s chest.
The lap portion of the seat belt MUST be positioned low and
snug at the child‘s hips.
7
CHILD SIZE: HEIGHT, WEIGHT, AND AGE RANGES
• USE ONLY with children who are 3
years of age or older AND who weigh
18-50 kg (40-110 lb) AND whose height
is 96-152 cm (38-60 inches). Using this
booster seat with a child who does not
meet ALL of these requirements may
increase the risk of death or serious injury.
• Use this booster seat FORWARD
FACING ONLY.
18-50 kg (40-110 lb)
AND
96-152 cm (38-60 in)
WARNING!
DEATH or SERIOUS INJURY can occur

8
• YOUR CHILD’S SAFETY depends
on you correctly installing and using this
booster seat.
• READ and FOLLOW all booster seat
and vehicle instructions carefully. Failure
to follow these instructions and the
product labeling can result in DEATH
or SERIOUS INJURY of your child in a
sharp turn, sudden stop, or crash.
• DO NOT install or use this booster seat
until you have read and understand the
instructions in this manual and in your
vehicle Owner’s Manual . If there is
a conict between the two, the vehicle
Owner’s Manual must be followed unless
explicitly warned against in this manual.
• NEVER USE this booster seat with a
lap belt only, or with any motorized, door
mounted, or inatable vehicle belts. Your
child would not be properly restrained in
the event of a crash.
• DO NOT let others install or use this
booster seat unless they understand how
to correctly install and use it.
• KEEP this Owner’s Manual for future
reference by storing it in the pocket
behind the Backrest pad.
• NEVER USE the Booster Base without
the Backrest attached.
• NEVER TAKE your child out of the
booster seat to tend to his or her needs
while the vehicle is moving. Unrestrained
occupants are at a greatly increased risk
of DEATH or SERIOUS INJURY in a car
crash.
• NEVER TEND to your child’s needs
while driving. Driving while distracted is
the cause of many car crashes. Safely
stop your vehicle in order to tend to your
child.
• NEVER LEAVE children unattended in a
vehicle, even for a short period of time
• The primary protection for occupants of
a vehicle in a collision is the structure of
the vehicle itself; a booster seat and the
vehicle restraint system may not protect
a child from injury when a vehicle is
seriously impacted. Correctly used per the
!WARNING! DEATH or SERIOUS INJURY can occur

EN
9
instruction and labeling, this booster seat
will substantially improve the chances for
survival in most crashes.
• TOO MUCH RECLINE IN THE
VEHICLE SEAT BACK can result in
improper seat belt position. An improperly
positioned seat belt increases the risk
of DEATH or SERIOUS INJURY in
a crash. Follow your vehicle Owner’s
Manual instructions for proper seat
back positioning.
• USE ONLY the vehicle’s lap and
shoulder belt system when restraining
your child in this booster seat.
• IMPROPER PLACEMENT of this
booster seat in a vehicle a󰀨ects the
booster seat’s performance and can
result in DEATH or SERIOUS INJURY.
• ONLY PLACE this booster seat
FORWARD FACING in a vehicle
seating location allowed by the vehicle
manufacturer. Refer to your vehicle
Owner’s Manual for information about
vehicle seat belt systems, air bags, and
child restraint/booster seat installation to
determine allowable seating positions.
• Use this booster seat FORWARD
FACING ONLY.
• ACCORDING TO ACCIDENT
STATISTICS, children are safer when
properly restrained in rear vehicle seating
positions.
• DO NOT USE this booster seat in a
seating position with an airbag unless the
vehicle manufacturer specically allows
placement of a child restraint there. If
an air bag inates, it can hit your child
with such a great force that it may cause
DEATH or SERIOUS INJURY.
• The Backrest of this booster seat MUST
REST against the vehicle seat back.
• Vehicle headrest MUST NOT
INTERFERE with the booster seat
Backrest. See the vehicle Owner’s
Manual for adjustment or possible
removal of vehicle headrest.
• NO PART of this booster seat should
hang over the front of the vehicle seat.
!WARNING! DEATH or SERIOUS INJURY can occur

10
• NEVER USE a locking clip when
installing this booster seat.
• NEVER leave this booster seat
unsecured in your vehicle. This booster
seat MUST remain connected to the lower
LATCH/UAS anchors in the vehicle or
secured by the vehicle’s seat belt even
when not in use. In a sharp turn, crash or
sudden stop, an unsecured booster seat
can be thrown around and could severely
injure vehicle occupants.
• DO NOT SECURE this booster seat to
the vehicle’s lower LATCH/UAS anchors
if the seat belt or seat belt buckle is not
easily accessible when the booster seat is
securely installed.
• NEVER LEAVE a vehicle seat with a
folding mechanism unlocked. In the event
of a sudden stop, a loose vehicle seat
back could prevent this booster seat from
protecting your child as well as it should.
• DO NOT LEAVE loose objects (e.g.
books, bags, etc.) in a vehicle. In the
event of a sudden stop, loose objects will
become projectiles, potentially causing
serious injuries.
• DO NOT USE anything to raise this
booster seat o󰀨 the vehicle seat.
• NEVER USE this booster seat in the
home, on aircraft, boats, low speed
vehicles (LSV), all-terrain vehicles (ATV),
golf carts, or any other non-certied
application.
• NEVER ALLOW children to play with
this booster seat.
• NEVER ALLOW children to play with
vehicle seat belts as they may create an
ENTANGLEMENT HAZARD for any
child that can reach the seat belt and may
wrap it around his or her neck.
• DO NOT USE this booster seat if it has
been in a crash. There may be hidden
damage and it must be replaced. Your
insurance company may provide some
assistance replacing the booster seat.
!WARNING! DEATH or SERIOUS INJURY can occur

EN
11
• NEVER USE this booster seat if it has
been damaged in any way or has missing
parts.
• NEVER USE a cut, damaged, frayed, or
inoperable vehicle seat belt.
• DO NOT ATTEMPT to make repairs to
or otherwise modify or tamper with this
booster seat.
• NEVER USE this booster seat without
properly installed fabric covers.
• NEVER USE a second-hand booster
seat or a booster seat whose history you
do not know.
• DO NOT USE accessories or parts
with this booster seat other than those
approved by CYBEX. Use of accessories
or parts from other manufacturers could
alter the performance of the booster seat.
• DISCONTINUE USING this booster
seat when it is older than eight (8) years
and recycle it. The date of manufacture
can be found on a label a󰀩xed to the
bottom of the Booster Base.
• This booster seat and the vehicle seat
belt can become very hot if left in the sun
and can burn your child’s skin. ALWAYS
TOUCH the surfaces of the parts before
putting your child in the booster seat.
!WARNING! DEATH or SERIOUS INJURY can occur

L
L
12
STEP 1
Connect the Backrest to the Booster Base.
STEP 2
Fold the Backrest up until it CLICKS into place.
STEP 3
Line up the tabs on the left L.S.P. Bolster with key holes on
the Shoulder Pad and slide down to lock in place.
Repeat with the Right L.S.P. Bolster.
ASSEMBLY
• NEVER USE the Booster Base without the Backrest attached.
• NEVER use this booster seat with the Backrest past the allowable adjustment range. An
audible CLICK will alert you when you have gone too far.
!WARNING! DEATH or SERIOUS INJURY can occur
12
3

EN
13
• ACCORDING TO ACCIDENT STATISTICS, children are safer
when properly restrained in rear vehicle seating positions.
• ONLY PLACE this booster seat FORWARD FACING in a
vehicle seating location allowed by the vehicle manufacturer.
Refer to your vehicle Owner’s Manual for information about
vehicle seat belt systems, air bags, and child restraint/booster
seat installation to determine allowable seating positions.
• Use this booster seat ONLY IN FORWARD FACING VEHICLE
SEATS.
VEHICLE SEAT LOCATION REQUIREMENTS
!WARNING! DEATH or SERIOUS INJURY can occur

CLICK!
14
The Backrest will adjust to the vehicle seat back through an
allowable adjustment range of approximately 15° as shown
in green.
• Vehicle headrest MUST NOT
INTERFERE with the booster seat
Backrest. See the vehicle Owner’s Manual
for adjustment or possible removal of
vehicle headrest.
• NO PART of this booster seat should
hang over the front of the vehicle seat.
• NEVER ALLOW your child to use this
booster seat if the vehicle seat back is in a
reclined position.
• NEVER use this booster seat with the
Backrest past the allowable adjustment
range. An audible CLICK will alert you when
you have gone too far.
• The Backrest of this booster seat MUST
REST against the vehicle seat back.
VEHICLE SEAT LOCATION REQUIREMENTS
WARNING!
DEATH or SERIOUS INJURY can occur

EN
15
VEHICLE SEAT BELT REQUIREMENTS
The design and operation of vehicle seat belt systems vary from vehicle to vehicle and from seating location to seating
location in the same vehicle. Refer to your vehicle Owner’s Manual for proper use, placement, and adjustment of the
vehicle’s lap and shoulder belts.
This booster seat may not t some vehicle seating positions.
Select a seat location allowed by your vehicle manufacturer that is equipped with a LAP AND SHOULDER BELT system.
• USE ONLY the vehicle’s lap and shoulder belt system when restraining your child in
this booster seat.
• NEVER USE this booster seat with a lap belt only, or with any motorized, door
mounted, or inatable vehicle belts. Your child would not be properly restrained in the
event of a crash.
!WARNING! DEATH or SERIOUS INJURY can occur

16
Applicable only if installing
booster seat using the lower
LATCH/UAS anchors:
NOTE: Your vehicle owner‘s
manual may refer to this system
as LATCH (Lower Anchors and
Tethers for CHildren) or UAS
(Universal Anchorage System).
• LATCH/UAS refers to a pair
of xed Lower Anchors and a Top Tether built into your
vehicle. The Solution Z-x has been designed to attach to
the Lower Anchors of this system.
• The lower LATCH/UAS anchors are located in the crease
between the vehicle seat back and seat cushion. If they
are not visible, their position will be indicated by
symbols located near the crease.
• Vehicles manufactured for the 2003 model year or
newer have at least two rear seating locations with lower
LATCH/UAS anchors. Some 2001 and 2002 model
year vehicles have lower anchors. Vehicles from model
years 2000 and older DO NOT have lower LATCH/UAS
anchors. Refer to your vehicle Owner’s Manual for
lower anchor positions in your vehicle.
VEHICLE LATCH/UAS REQUIREMENTS
• NEVER leave this booster seat
unsecured in your vehicle. This booster
seat MUST remain connected to the lower
LATCH/UAS anchors in the vehicle or
secured by the vehicle’s seat belt even
when not in use. In a sharp turn, crash or
sudden stop, an unsecured booster seat
can be thrown around and could severely
injure vehicle occupants.
• DO NOT SECURE this booster seat to
the vehicle’s lower LATCH/UAS anchors
if the seat belt or seat belt buckle is not
easily accessible when the booster seat is
securely installed.
WARNING!
DEATH or SERIOUS INJURY can occur

EN
17
The Solution Z-x is designed to be used with the vehicle’s
lower LATCH/UAS anchors, if available. This booster seat
may also be used in seating positions without lower LATCH/
UAS anchors (see page 19).
STEP 1
Select a seat location allowed by your vehicle manufacturer
equipped with a LAP AND SHOULDER BELT system.
Locate the lower LATCH/UAS anchors or the symbols
indicating their location.
STEP 2
If the lower anchors are hidden behind the crease between
the seat back and seat cushion, install the supplied LATCH/
UAS Guides to the lower LATCH/UAS anchors for easier
installation of the booster seat.
To install, connect the two LATCH/UAS Guides to the two
lower anchors by sliding the LATCH/UAS Guides into the
crease and under the lower anchor.
INSTALLING USING LATCH/UAS
12

6
18
STEP 3
Place the Solution Z–x on its side. While squeezing the
orange LATCH/UAS Adjustment Handle located on the
bottom of the Booster Base, pull the LATCH/UAS Connectors
out until they stop. Then rotate the LATCH/UAS Connectors
180°.
STEP 4
Push the LATCH/UAS Connectors onto the lower anchors
until you hear them CLICK. The GREEN security bar will
be visible on the release button when the LATCH/UAS
Connectors are securely attached to the lower anchors.
STEP 5
While squeezing the LATCH/UAS Adjustment Handle, push
the booster until it rests at against the vehicle seat back.
Release the handle and the booster seat will lock into place.
STEP 6
Make sure that the booster seat is connected safely by trying
to pull it out on both sides.
INSTALLING USING LATCH/UAS 3 4
5
