CYBEX 16120-999-4 Instruction Manual

Cybex®Plate Loaded Smith Press
Owner’s and Service Manual
Strength Systems
Part Number 16120-999-4 D
www.cybexinternational.com

Cybex®Plate Loaded Smith Press
Owner’s and Service Manual
Strength Systems
Part Number 16120-999-4 D
Cybex®and the Cybex logo are registered trademarks of Cybex International, Inc.
DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to
revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such
revisions or changes.
© Copyright 2010, Cybex International, Inc. All rights reserved.
Printed in the United States of America.
10 Trotter Drive Medway, MA 02053 • 508-533-4300 • FAX [phone]
www.cybexinternational.com • [email protected] • 16120-999-4 D • March 2010

1 Safety
Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Guidelines and Practices . . . . . . . 2
Warning/Caution Decals . . . . . . . . . . . . . 3
Regular Maintenance Activities . . . . . . . . 4
2 Exercise
Intended Use . . . . . . . . . . . . . . . . . . . . . . 4
Instructions. . . . . . . . . . . . . . . . . . . . . . . 4
3 Customer Service
Contacting Service. . . . . . . . . . . . . . . . . . 5
Ordering parts . . . . . . . . . . . . . . . . . . . . . 6
Return Material Authorization (RMA). . . . 6
Damaged Parts . . . . . . . . . . . . . . . . . . . . 7
4 Assembly
Tools Required. . . . . . . . . . . . . . . . . . . . . 7
5 Maintenance
Daily Procedures . . . . . . . . . . . . . . . . . . 11
Weekly Procedures . . . . . . . . . . . . . . . . 11
6 Service
Parts Lists . . . . . . . . . . . . . . . . . . . . . . . 14
Exploded-View Diagram . . . . . . . . . . . . 15
Table of Contents
Page i

Page 1
Cybex Plate Loaded 16120 Smith Press Owner’s Manual
1 - Safety
Safety
Read the Owner’s Manual carefully before assembling, servicing or using Cybex equipment.
WARNING: Serious injury could occur if these safety precautions are not observed:
User Safety Precautions
Obtain a medical exam before beginning any exercise program.•
Stop exercising if feeling faint, dizzy or experiencing pain and consult your physician.•
Obtain instructions before using. Lisez les instructions avant I’untilisation.•
Read and understand the owner’s manual and all warnings posted on the machine before using• .
Keep all children (12 and under) away. Teenagers (13 and over) and disabled must be supervised.•
Garder tous les enfants (de 12 ans et moins) éloignés. Les adolescents (de 13 ans et plus) et les
handicapés doivent être surveillés.
Use a spotter.•
Keep body and clothing free from and clear of all moving parts.•
Use the machine only for the intended use.• DO NOT modify the machine.
Inspect machine prior to use.• DO NOT use if it appears damaged or inoperable.
DO NOT• attempt to fix a broken or jammed machine.
Report any malfunctions, damage or repairs to the facility• .
Replace any warning labels if damaged, worn or illegible.•
Facility Safety Precautions
Read the Owner’s Manual carefully before assembling, servicing or using this• equipment.
Make sure that each machine is set up and operated on a solid level surface.• Do not install
equipment on an uneven surface.
NOTE: Cybex is not responsible for the actual anchoring of equipment. Consult with a professional
contractor.
NOTE: Use fasteners having a minimum of 500 lbs. tensile capacity (3/8” grade 2 bolts or better).
NOTE: If legs/frame does not contact surface, DO NOT pull down with anchors. Shim any
leg or frame not in contact with surface using flat washers.
Make sure that all users are properly trained on how to use the this equipment.•
Make sure there is enough room for safe access and operation of this equipment.•
Perform regular maintenance checks on this equipment. Also pay close attention to all areas most• susceptible to wear.

Page 2
Cybex Plate Loaded 16120 Smith Press Owner’s Manual
Immediately replace worn or damaged components. If unable to immediately replace worn or•
damaged components then remove from service until the repair is made.
NOTE: It is the sole responsibility of the user/owner or facility operator to ensure that regular maintenance is performed.
Safety Guidelines And Practices
Cybex recommends that all fitness equipment be used in a supervised area. It is recommended that the equipment be
located in an access controlled area. Control is the responsibility of the owner. The extent of control is at the discretion
of the owner.
It is the responsibility of the purchaser/user of Cybex products to read and understand the owner’s manual, and warning
labels; as well as instruct all individuals, whether end users or supervising personnel, on proper usage of the equipment.
PROPER USAGE:
Use machine only as described in the manual. Failing to follow proper instructions may result in injury.
Do Not Lean Against or Pull On the framework, weight stack, or any component, whether machine is at rest or in use.
Inappropriate or improper use may result in injury to users or third parties (bystanders).
Do not use machine if it is not located on a solid level surface or is improperly installed.
Provide an adequate safety perimeter between the machine, walls and other equipment to ensure that the facility has
the proper clearance for usage and training.
SECURING EQUIPMENT:
The machine has holes in the feet, which allow for ease in anchoring to the floor. Cybex strongly recommends that,
to eliminate rocking, tipping or falling over due to incorrect usage and misuse, equipment be secured to a solid, level
surface.
1. The solid, level surface should not deviate more than 1/8” over a 10’ distance or as defined and required by local
building and architectural codes.
2. Anchoring of equipment must be completed by a qualified licensed contractor.
3. Anchoring holes are provided on the feet of the frame. All anchoring locations must be used when anchoring the
equipment to the floor.
4. Due to the wide variation of flooring on which machines may be anchored or installed, verify anchoring method and
anchoring fasteners with a qualified and licensed contractor.
5. A minimum pull out force of 220 lbs/100 kgs is required for each anchor position..
6. Do not use machine until it is properly anchored.
MAINTENANCE:
Preventative maintenance allows proper equipment operation and reduces the risk of injury. Perform the maintenance
requirements as specified in the manual.
STANDARD COMPLIANCE:
Cybex products meet or exceed applicable ASTM and EN Standards.

Page 3
Cybex Plate Loaded 16120 Smith Press Owner’s Manual
Warning/Caution Decals
Warning decals indicate a potentially hazardous situation, which, if not avoided, could result in death
or serious injury.
Caution decals indicate a potentially hazardous situation, which, if not avoided, could result in minor
or moderate injury.
The following diagram shows where each decal is located.
A
A. Warning Decal...................5220-364-4
B. Warning Decal...................16120-340-4
C. Warning Decal...................16120-341-4
DESCRIPTION PART NO.
A
B
C
A
C
B
C
B
C
B
C
B
Smith Press - 16120

Page 4
Cybex Plate Loaded 16120 Smith Press Owner’s Manual
Regular Maintenance Activities
Preventative maintenance activities must be performed to maintain normal operation of this equipment.
Keeping a log sheet of all maintenance actions will assist you in staying current with all preventative
maintenance activities.
WARNING: Equipment found to have worn or damaged components must be removed
from service until repair(s) is made. Failure to do so could result in injury.
Daily
1. Clean upholstery.
Weekly
1. Inspect all nuts and bolts for looseness. Tighten as required.
2. Check for worn handles, and worn warning labeling. Replace all worn parts immediately.
2 - Exercise
Intended Use
The intended use of this equipment is to aid or improve general physical fitness and exercise. For Comercial use.
Instructions
Read and understand all instructions and warnings prior to using this machine. See Chapter 1, Safety in Owner’s
Manual or consult with floor staff.
NOTE: Refer to next page for set up and movement.
This machine is very versatile.
Exercises that can be performed
include: Squates, Bench and
Incline Presses, Bent-Over Rows
and Overhead Press.
Bench Press Squat

Page 5
Cybex Plate Loaded 16120 Smith Press Owner’s Manual
3 - Customer Service
Contacting Service
Hours of phone service are Monday through Friday from 8:30 a.m. to 6:00 p.m Eastern Standard Time.
For Cybex customers living in the USA, contact Cybex Customer Service at 888-462-9239.
For Cybex customers living outside the USA, contact Cybex Customer Service at 508-533-4300 or fax [phone].
Find information on the web at www. cybexintl.com or e-mail at [email protected].
Movement
1. Position yoursalf for the exercise to be performed and grasp bar.
2. Lift bar rotate to release catch. See Diagram A.
3. Lift/lower bar with smooth, controlled movements.
4. Lock bar by rotating until catch is fully engaged. See Diagram A.
NOTE: Ensure bar catch is fully engaged over hook before releasing grip on bar.
Set Up
1. Adjust bar to appropriate height for exercise. See Diagram A.
2. Adjust bar stops to appropriate height for exercise. See Diagram B.
NOTE: Ensure stops are set properly at equal height.
3. Load bar evenly with appropriate resistance.
NOTE: Unloaded bar weight = 15 pounds (7kg).
Diagram A Diagram B

Page 6
Cybex Plate Loaded 16120 Smith Press Owner’s Manual
Return Material Authorization (RMA)
The Return Material Authorization (RMA) system outlines the procedures to follow when returning
material for placement, repair or credit. The system assures that returned materials are properly handled and
analyzed. Follow the following procedures carefully.
Contact your authorized Cybex dealer on all warranty-related matters. Your local Cybex dealer will request a RMA
from Cybex, if applicable. Under no circumstances will defective parts or equipment be accepted by Cybex without
proper RMA and an Automated Return Service (ARS) label.
1. Call the Customer Service Hot Line listed above for the return of any item that is defective.
2. Provide the technician with a detailed description of the problem you are having or the defect in the
item you wish to return.
3. Provide the model and serial number of your Cybex equipment.
4. At Cybex’s discretion, the technician may request that you return the problem part(s) to Cybex for
evaluation and repair or replacement. The technician will assign you a RMAnumber and will send
you an ARS label. TheARS label and the RMA numbers must be clearly displayed on the outside of
the package that contains the item(s) to be returned. Include the description of the problem, the se-
rial number of the equipment and the name and address of the owner in the package along with the
part(s).
Ordering Parts
Fax orders to 508-533-5183. To speak with a customer service representative, call 888-462-9239 (for customers living
within the USA) or 508-533-4300 (for customers outside the USA). You may also contact us through e-mail at
[email protected].
Having the following information ready when calling, will assist our Cybex representatives in serving you.
Unit Serial Number•
Product Name•
The unit serial number and product name can be found on the serial number decal. See Chapter 6 for exact location of
serial number decal.
Part Description•
Part Number•
Part descriptions and part numbers are located in Chapter 6 of this manual.
Shipping Address•
Contact Name•
In addition to your shipping address and contact name, your account number is helpful but not required.

Page 7
Cybex Plate Loaded 16120 Smith Press Owner’s Manual
4 - Assembly
Tools Required
9/16” Socket wrench• 7/16” Wrench• 7/32” Allen wrench• 9/16” Wrench• 5/16” Allen wrench•
Smith Press - Product No.16120
Total Weight and Size
380 lbs. inches - 84 W x 54 L x 84 H
173 kg cm - 213 W x 137 L x 213 H
NOTE: Three people will be required for this procedure.
NOTE: It is the responsibility of the facility owner/owner of the equipment to ensure that
there is appropriate clearance around each machine to allow for safe use and passage.
NOTE: Refer to chapter 6 for reference diagrams.
1. Read and understand all instructions thoroughly before starting any of the procedures
listed on this instruction sheet.
Damaged Parts
Materials damaged in shipment should not be returned for credit. Shipping damages are the responsibility of the carrier
(UPS, Federal Express, trucking companies, etc.)
Apparent Damage - Upon receipt of your shipment, check all items carefully. Any damage seen with a visual check must
be noted on the freight bill and signed by the carrier’s agent. Failure to do so will result in the carriers refusal to honor your
damage claim. The carrier will provide you with the required forms for filing such claims.
Concealed Damage - Damage not seen with a visual check upon receipt of a shipment but notices later must be reported
to the carrier as soon as possible. Upon discovery of the damage, a written or phone request to the carrier asking them to
perform an inspection of the materials must be made within ten days of the delivery date. Keep all shipping containers and
packing materials as they will be needed in the inspection process. The carrier will provide you with an inspection report
and the necessary forms for filing a concealed damage claim. Concealed damage claim is the carrier’s responsibility.
5. Forward the package through UPS to Cybex.
Attn: Customer Service Department
Cybex International, Inc.
1975 24th Ave SW
Owatonna, MN 55060
NOTE: Merchandise returned without an RMA number on the outside of the package or shipments sent COD
will not be accepted by the Cybex receiving department.

Page 8
Cybex Plate Loaded 16120 Smith Press Owner’s Manual
A. Locknut .375-16 (4), HN704901
B. HHCS .250-20 x 2.00 (2), HC621215
C. SHCS .375-16 X 1.25 (8), JC702820
D. BHSCS .375-16 X2.50 (4),HC700430
E. Split, Lockwasher .375 (8), HS348300
F. Foot Pad (6), 16010-311
G. Loctite 242 (1) YA000008
A
B
C
D
E
F
G
Figure 1
NOTE: Keep all shipping packages near area of installation.
Remove hardware pack and verify contents. See Figure 1.A.
Carefully remove foam and shrink wrap securing frameB. mounts, set frame mounts aside.
Carefully remove foam and shrink wrap securing weightC. bar to frame, set weight bar aside.
Using a 7/32” Allen wrench and a 9/16” wrench removeD. the four Button Head Socket Cap Screws (BHSCS) from
shipping bracket securing frame halves together.
NOTE: Do not discard BHSCS or locknuts.
Using a 9/16” wrench remove the four lag bolts securingE. frame to pallet
NOTE: Carefully handle frame halves to prevent damage to
paint or frame.
4. Assemble frame.
With assistants hold frames in an upright position.A.
Carefully place foot pad (supplied with machine) on each footB. of the frame.
Align front frame mount in place. See Figure 2.C.
Front Frame Mount
Figure 2
BHSCS
(Qty of 2 each side)
Locknut (Qty of 2 each side)
Using a 7/32” Allen wrench and a 9/16” wrench secure front frame mount in place with the four BHSCS andD. locknuts removed in step 3C.
Place back frame mount in position. See Figure 3.E.
2. Verify you have received the appropriate configuration.
Verify that you received the correct color machine that you ordered.A.
Verify you received the appropriate owner’s manual.B.
Verify you received the warranty sheet.C.
3. Move to desired location.
WARNING: Use extreme caution when removing Smith Press assembly from pallet. Failure to do so
could result in injury.

Page 9
Cybex Plate Loaded 16120 Smith Press Owner’s Manual
Carefully place weight bar on frame and secure in place by latching bar catch on hooks.A.
Verify each bar catch is hooked properly on the hook. See Figure 4.B.
5. Install weight bar assembly.
Figure 4
Hook
Weight Bar
Bar Catch
Slide bearing housing up (located at bottom of guide shaft) and align holes with weight bar bracket. See Figure 5.C.
Figure 5
Bearing Housing
Weight Bar Bracket
SHCS (Qty 4)
Loctite
Washers (Qty 4)
Guide Shaft
Using a 7/32” Allen wrench and a 9/16” secure back frame mount to frame with theF. four BHSCS and locknuts from
shipping package. See Figure 3.
Figure 3
Back Frame Mount
Locknut (Qty of 2 each side)
BHSCS
(Qty of 2 both side)
Locknut

Page 10
Cybex Plate Loaded 16120 Smith Press Owner’s Manual
Locate four Socket Head Cap Screws (SHCS), four washers and loctite from shipping package.D.
Place a small drop of loctite on the four SHCS and in threaded holes of weight bar bracket. See Figure 5.E.
Place washer over SHCS.F.
Using a 5/16” Allen wrench tighten the four SHCS securing the weight bar bracket to the bearing housing.G.
Repeat steps 5C - 5F for opposite side.H.
6. Cable installation
Locate two Hex Head Cap Screw HHCS from shipping package.A.
Place a small drop of loctite on HHCS and in threaded hole.B.
Using a 7/16” wrench, attach cable end to weight bar bracket with HHCS.C. NOTE: Cable end must be attached
straight to avoid a kink in cable. See Figure 6.
HHCS
Cable End
Cable Weight Bar Bracket
Figure 6
Repeat steps 6B and 6C for opposite cable end.D.
8. Verify proper operation.
7. Securely anchor machine to the floor.
Securely anchor machine to the floor using the anchor holes provided in each machine.A.
NOTE: Cybex is not responsible for the actual anchoring of equipment. Consult with a professional contractor.
NOTE: Use fasteners having a minimum of 500 lbs. tensile capacity (3/8’’ grade 2 bolts or better).
NOTE: If legs/frame does not contact surface, DO NOT pull down with anchors. Shim any leg or
frame not in contact with surface using flat washers.
NOTE: Cable end must be attached
straight to avoid kink in cable.

Page 11
Cybex Plate Loaded 16120 Smith Press Owner’s Manual
1. Inspect all nuts and bolts for looseness. Tighten as required
2. Inspect all labeling for readability. This includes instructional placards, warning and caution decals.
Replace all worn labeling immediately.
Weekly Procedures
5 - Maintenance
All preventive maintenance activities must be performed on a regular basis. Performing routine preventive
maintenance actions can aid in providing safe, trouble-free operation of all Cybex Strength Systems equipment.
NOTE: Cybex is not responsible for performing regular inspection and maintenance actions for your machines.
Instruct all personnel in equipment inspection and maintenance actions and also in accident
reporting/recording. Cybex phone representatives are available to answer any questions or concerns
that you may have.
1. Upholstery - Wipe down all upholstery.
2. Frames - Wipe down all frames using a mild solution of warm water and car wash soap. Be sure to dry thoroughly.
AVOID acid or chlorine based cleaners and also cleaners containing abrasives as these could scratch or
damage the equipment.
3. Chrome - Clean chrome tubes, first using chrome polish and then using a car wax seal. Neutral cleaners
with a pH between 5.5 and 8.5 are recommended. Be sure to dry thoroughly. AVOID acid or chlorine based
cleaners and also cleaners containing abrasives as these could scratch or damage the equipment.
Daily Procedures

Page 12
Cybex Plate Loaded 16120 Smith Press Owner’s Manual

Cybex Plate Loaded 16120 Smith Press Owner’s Manual
Page 13
Please refer to the next pages for parts lists and exploded-view diagrams
6 - Service
Cybex will void warranty if
non-Cybex replacement parts
are used.
NOTE: All inspections
and repairs must be
performed by trained
service personnel only.
Plate Loaded Smith Press
PRODUCT NO. 16120
A. Placard................................ 16120-598-X
B. Warning Decal..................... 16120-340-X
C. Warning Decal..................... 16120-341-X
DESCRIPTION PART NO.
A
B
C
B
C
NOTE: See exploded view for location of E (serial number decal) and
F (Caution decal).
D. Warning Decal..................... 5220-364-X
E. Serial Number Decal
F. Caution Decal......................4000Y316-X
DESCRIPTION PART NO.
C
C
B B
D

Cybex Plate Loaded 16120 Smith Press Owner’s Manual
Page 14
1 2 11090-385 GRIP 2 6 16010-311 FOOT PAD 3 2 16120-002 CABLE ASSEMBLY 4 1 16120-200 FRAME LH 5 1 16120-201 FRAME RH 6 1 16120-202 FRAME MOUNT 7 1 16120-203 FRAME MOUNT 8 1 16120-204 WEIGHT BAR 9 2 16120-205 BEARING HOUSING 10 1 16120-206 WEIGHT BAR BRACKET LH 11 1 16120-207 WEIGHT BAR BRACKET RH 12 1 16120-208 CATCH LH 13 2 16120-209 BACKING PLATE 14 1 16120-211 CATCH RH 15 4 16120-308 PLATE, MOUNTING HOOKS 16 4 16120-318 BUSHING 17 2 16120-351 COUNTERWEIGHT 18 NA 16120-343 CAPLUG (REMOVED 7/27/09) 19 4 16120-344 CAPLUG, MODIFIED 20 2 16120-345 SPACER 21 2 16120-346 BEARING HOUSING 22 NA 23 3 3900-443 DECAL, CYBEX 1.00 HOR (BLACK) 23 3 3900-444 DECAL, CYBEX 1.00 HOR (SILVER) 24 2 4400-354 PULLEY, 3.50 INCH 25 1 51198 WARRANTY BOOK (NOT SHOWN) 26 8 5220-367 SPACER, PLASTIC 27 2 5340M042 SHAFT 1.00 DIA X 79.88 28 2 5340P003 WEIGHT TUBE 6.00 29 NA 30 2 5341-340 SPACER 31 2 5341-365 WEIGHT TUBE 32 4 5490P009 WEIGHT TUBE 10.00 33 2 5490P010 WEIGHT TUBE 8.00
ITEM QTY PART NO. DESCRIPTION
*Language Key 1-German , 2-French, 3-Spanish, 4-English, 6-Japanese, 7- Swedish, 8- Russian
34 4 BR030204 RETAIN RING LINEAR BRG 1.00 35 2 BR030222 INTERAL RETAINING RING, 52 MM 36 2 BR030223 EXT RETAINING RING, 25 MM 37 CM000211 DECAL, PATENT PENDING (REMOVED 7/6/09) 38 4 FB030234 BEARING, RADIAL 39 4 FB030257 BEARING, RADIAL 10MM EXTENDED RACE 40 4 FB050226 BEARING,FLANGE 1.000 ID x 1.25 OD x 1.00 LG 41 4 FB110201 BRG, RADIAL 42 4 FS110201 SEAL, LINEAR BRG 1.00 43 2 HC621215 HX HD CAP .250-20 X 7.50 44 8 HC700430 BHSCS .375-16 X 2.50 45 2 HC700432 BHSCS .375-16 X 2.75 46 28 HF540200 GROMMET, NYLON 47 2 HN704400 NUT, HEX JAM .375-16 48 24 HN704901 LOCKNUT, .375-16 NYLON 49 4 NA 50 28 HT542514 PN HD PHIL SC # 8 X .625 BLK 51 4 HY623410 SET SCREW 52 12 JC700420 BHSCS .375-16 X 1.25 53 2 JC700424 BHSCS .375-16 X 1.75 54 8 JC702820 SHCS .375-16 X 1.25 55 NA 56 2 PP130003 INSERT, DOMED PLASTIC 57 10 PP130006 INSERT, PLASTIC END 58 4 16120-340-X* DECAL, WARNING 59 4 16120-341-X* DECAL WARNING 60 1 16120-598-X* PLACARD (SMITH PRESS) 61 1 5220-364-X* DECAL, WARNING 62 8 HS348300 LOCKWASHER SPLIT .375 63 2 HC620431 BHSCS .250-20 X 2.00 64 2 HN625200 LOCKNUT .250-20 NYLON 65 2 4000Y316-X* DECAL, CAUTION 66 1 11040-790 DECAL, MADE IN USA
ITEM QTY PART NO. DESCRIPTION
