CycleOps SuperMagneto User manual

SuperMagnetoTM
Pro Trainer
User Guide

2
Common Sense Precautions
Before starting any exercise program,consult with
your physician or health professional.He or she can
help establish the exercise frequency, intensity and
time appropriate for your particular age and condi-
tion. If you have any pain or tightness in your chest,
an irregular heartbeat, shortness of breath, feel faint,
or have any discomfort while you exercise, STOP!
Consult your physician before continuing. Failure to
follow any of these safeguards may result in injury or
serious health problems.
· Do not remove feet from pedals while cycling.
· Do not attempt to ride the bike at high RPM’s or in
a standing position until you have practiced at
lower RPM’s.
· Do not place fingers or any other objects into
moving parts of the trainer or bicycle.
· Keep children and pets away from your bike and
the trainer while in use.Do not allow children to
ride on your bike.
· Never turn pedal crank arms by hand.To avoid
entanglement and possible injury, do not expose
hands or arms to the drive mechanism.
· Do not dismount from your bike until both the
pedals and the rear wheel are at a complete STOP.
INTRODUCTION
Congratulations! You’ve purchased one of the finest
cycling trainers available.
Never before has a trainer provided the versatility
and real-world feel of the CycleOps SuperMagne-
toTM Pro. By selecting one of the four PowerTuned
resistance curves,the CycleOps SuperMagnetoTM Pro
offers the ultimate for every ride type and rider.
Easy allows you to pedal easily during a
low power recovery ride.
This user guide will take you through setting up the
CycleOps SuperMagnetoTM Pro trainer, and thorough-
ly explains how to use the CycleOps SuperMagnetoTM
Pro’s four power curves to give you an edge over the
competition.
Road provides true road like feel for longer
rides.
Mountain delivers gear grinding resistance
for high power workouts.
Interval provides slightly less resistance
at moderate speeds while giving you leg
burning resistance for high speed inter-
vals.

3
Part 1: Setting Up Your CycleOps SuperMagnetoTM Pro
1.1: Parts Listing
Your CycleOps SuperMagnetoTM Pro trainer should come with all of the following components:
Assembled CycleOps SuperMagneto• TM Pro Trainer resistance unit and frame (A)
CycleOps Skewer (B)•
Race Day• training DVD (C)
Warranty registration card (Not Shown) (You may also register your CycleOps trainer at www.cycleops.•
com)
If you do not find all of these items in the box, please contact Saris customer service at 800-783-7257 (op-
tion 3).
(A)
(B)
(C)

4
1.2:Trainer Setup
To set your trainer up, extend the legs as shown be-
low, then set the trainer on a flat surface.
Turn the thumb wheel to adjust the leg and level the
frame as shown below.
1.3: Attaching your Bike to the Trainer
The CycleOps SuperMagnetoTM Pro trainer is de-
signed to be used with the provided skewer. Replace
the skewer on the rear wheel of your bike with the
one provided. Make sure the quick release handle is
on the left side of the bicycle and faces upward.
Rotate the yellow skewer clamp knob clockwise to
allow sufficient clearance for your skewer.
Press
Extend

5
Pull the yellow cam lever down and rotate 90 de-
grees clockwise to unlatch the resistance unit. Pivot
the resistance unit down to allow clearance for your
rear wheel.
CAUTION: In this position the resistance unit can
move freely, keep fingers clear of moving parts.
Latch the resistance unit in a down position by rotat-
ing the cam lever 90 degrees counter clockwise and
push the cam lever against the resistance unit.
Lift your bike up by the seatpost and insert the right
side (drive side) of the skewer into the fixed cone on
the corresponding side of the frame.
Align the left side of the skewer with the adjustable
cone, lining the notches in the cone up with the
quick release handle/lever. Rotate the yellow skewer
clamp knob as shown below to secure your rear
wheel into the trainer. Securely tighten the knob
until tightly in place.
Note: Your bike does not need to be centered on the
roller for it to function properly
Pull the yellow cam lever down and rotate 90 de-
grees clockwise to unlatch the resistance unit.Push
the resistance unit towards your rear wheel until the
roller contacts the tire.Latch the resistance unit by
rotating the cam lever 90 degrees counter clockwise,
while holding the resistance unit.Compress the
roller against the tire by pulling up on the cam lever
as shown below.

6
The resistance unit should be tight enough to pre-
vent the tire from slipping during accelerations.
A small indentation will be seen in the tire when
tightened properly. If slipping occurs, increase tire
compression by relatching the resistance unit.Pull
the yellow cam lever furthur down while performing
the initial unlatching step.
Note: If the cam lever pops open while riding, move
the resistance unit and mount it to the front bolt
hole as shown below. Most tires will fit using either
mounting hole.Larger tires including 29”MTB tires
require mounting to the rear hole.
Note: Be certain your tires are inflated to their proper
pressure.Knobby tires will cause noise and vibration.
For best results,use a slick-tread tire.Note that any
stationary trainer will increase the wear on your tires.
Using harder rubber composed tires will improve
their life.
1.5 Detaching your Bike from the Trainer
Pull the yellow cam lever down and rotate 90 de-
grees clockwise to unlatch the resistance unit.Pivot
the resistance unit down to allow clearance for your
rear wheel. Latch the resistance unit by rotating the
cam lever 90 degrees counter clockwise and pushing
up.
Hold your bike by the seatpost.Rotate the yellow
skewer clamp lever counter clockwise to release your
bike.

7
Part 2: Using the CycleOps SuperMagneto’sTM Four Power Curves
To adjust the CycleOps SuperMagnetoTM Pro’s set-
tings,hold the flywheel with one hand and turn the
adjuster cover to the desired position. There will be
an audible“click.”The arrow on the flywheel will be
pointing at one if the four icons when the adjuster
cover is properly positioned.
For more information about using the four settings,
please go on to Part 3.

8
Part 3:Which Power Curve is Right for Me?
Easy Setting Interval Setting
You can change the resistance of the trainer to meet your unique goals and fitness levels. As you get fitter
and your goals change, the CycleOps SuperMagnetoTM Pro grows along with you.
Intensity and duration of training will vary drastically from athlete to athlete. Whether you are training to
increase endurance, to lose weight,to be at the front of the pack on your weekly group ride, or are warming
up for races,the CycleOps SuperMagnetoTM Pro offers enough variety to address all these training needs and
more. The four settings offer four distict power curves, each calculating the power you must use to maintain
the corresponding speed. The four progressive curves of the CycleOps SuperMagnetoTM Pro start with lower
power and quickly ramp up as your speed increases.
Mountain Setting
This setting is the easiest curve on the CycleOps
SuperMagnetoTM Pro. This will give inexperienced
riders a great place to start, while giving stronger rid-
ers a great place to cool down or recover.
Road Setting
This setting gives you a gentle road like feel. A
lightly progressive curve folllows your cadence up to
speed and allows you to ride at a comfortable speed
and resistance.
This setting provides low steady state power with
the ability to deliver plenty of resistance as you bring
your bike up to speed.
This is the hardest, most progressive setting on the
CycleOps SuperMagnetoTM Pro. It can deliver moun-
tain climbing resistance for high power and slow
speed workouts.
SuperMagneto Pro
0
100
200
300
400
500
600
700
0 5 10 15 20 25 30 35
Speed (mph)
Power (watts)
Mountain
Interval
Road
Easy

9
Warranty
The CycleOps SuperMagnetoTM Pro is designed spe-
cifically for home use and as such carries the follow-
ing warranty:
All Saris Cycling Group CycleOps SuperMagnetoTM
Pro products are warranted to the retail purchaser to
be free from defects in materials and workmanship.
Warranty coverage valid to the original purchaser
only and proof of purchase will be required.
Residential Environment:
Frame: Lifetime
Parts: 3 years
Labor: 1 year
This warranty excludes wear items that need to be
replaced due to normal wear and tear.
This warranty does not cover:
Normal wear and tear.1.
Any damage, failure or loss caused by accident,2.
misuse, neglect, abuse, improper assembly, im-
proper maintenance, or failure to follow instruc-
tions or warnings in Owner’s Manual.
Use of products in a manner or environment for3.
which they were not designed.
Limitations
The foregoing warranties are in lieu of and exclude
all other warranties not expressly set forth herein,
whether expressed or implied by operation of law or
otherwise, including, but not limited to, warranties
of merchantability or fitness for a particular purpose.
Saris Cycling Group shall in no event be liable for
incidental or consequential losses,damages or ex-
penses in connection with its exercise products. Saris
Cycling Group’s liability hereunder is expressly limit-
ed to the replacement of goods not complying with
this warranty or, at Saris Cycling Group election, to
the repayment of an amount of the purchase price of
the exercise product in question. Some states do not
permit the exclusion or limitation of implied warran-
ties or incidental or consequential damages, so the
preceding limitations and exclusions may not apply
to you.
Procedures
Warranty service will be performed by Saris Cycling
Group or an authorized Saris Cycling Group Dealer.
The original purchaser must provide proof of pur-
chase.Service calls and/or transportation to and
from the Authorized Saris Cycling Group Dealer are
the responsibility of the purchaser.
Saris Cycling Group will have the option to repair1.
or replace any product(s) which requires war-
ranty service.
Saris Cycling Group will replace any unit that is2.
structurally defective with a new unit or a unit of
equal value.
In the event a product cannot be repaired, Saris3.
Cycling Group will apply a limited credit reim-
bursement toward another CycleOps SuperMa-
gnetoTM Pro Trainer product of equal or greater
value.
Saris Cycling Group
5253 Verona Rd.
Madison,WI 53711
p. 800-783-7257
f. 608-274-1702
www.saris.com
www.cycleops.com
18455 07/08
