CYP CPLUS-1082CVAL User manual

CPLUS-1082CVAL
10×10 HDMI and HDBaseT Matrix
with Audio Matrixing
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2016 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
VS1 20/09/16 Updated text/diagrams
VS2 09/03/17 Added new commands to
section 6.8.3

CONTENTS
1. Introduction......................................................1
2. Applications.....................................................1
3. Package Contents ..........................................2
4. System Requirements......................................2
5. Features............................................................2
6. Operation Controls and Functions.................4
6.1 Front Panel ................................................. 4
6.2 Rear Panel.................................................. 5
6.3 Side Panel .................................................. 8
6.4 Remote Control......................................... 9
6.5 OLED Menu .............................................. 10
6.6 IR Cable Pin Assignment......................... 11
6.7 RS-232 Protocol........................................ 11
6.8 RS-232 and Telnet Commands .............. 12
6.8.1 Command Syntax.......................... 12
6.8.2 Real World Command Use ........... 14
6.8.3 Full Command List.......................... 17
6.9 Telnet Control .......................................... 34
6.10 WebGUI Control .................................... 36
6.10.1 Video Switch................................. 38
6.10.2 Zone Audio ................................... 43
6.10.3 Extended Audio ........................... 45
6.10.4 CAT Audio..................................... 47
6.10.5 HDMI Audio................................... 48
6.10.6 HDBaseT Audio............................. 49
6.10.7 Mixer Audio................................... 51
6.10.8 Zone A/V Pairing .......................... 52
6.10.9 EDID Settings................................. 53
6.10.10 HDBaseT & H/W Info................... 55
6.10.11 User Cong ................................. 56

6.10.12 System Settings........................... 56
6.10.13 Logout ......................................... 57
7. Connection Diagram ....................................58
8. Specications ................................................59
8.1 Technical Specications ........................ 59
8.2 Video Specications............................... 60
8.2.1 Supported HDMI Resolutions ........ 60
8.2.2 Maximum HDMI Cable Length..... 61
8.3 Audio Specications............................... 61
8.3.1 Analog Audio ................................. 61
8.3.2 Linear PCM Audio .......................... 62
8.3.3 Compressed Audio........................ 62
8.3.4 Audio Adjustments......................... 62
8.4 Category Cable Specications............. 63
8.5 HDBaseT Features.................................... 63
9. Acronyms .......................................................64

1
1. INTRODUCTION
This 10×10 HDMI and HDBaseT Matrix supports routing and transmission
of video (resolutions up to 4K@60Hz w/ HDMI 2.0 & HDCP 2.2) and
audio (multi-channel digital/stereo analog) while providing exible
control via IR, RS-232, Telnet or WebGUI. As many as ten UltraHD
sources may be routed to any of ten destinations, eight via single
Cat.5e/6/7 cables (up to 60m at 1080p or up to 35m at 4K@30Hz)
and two via HDMI 2.0 outputs. The two HDMI 2.0 outputs support
transmission of 18Gbps UltraHD HDMI sources (up to 4K@60Hz, 4:4:4)
from any HDMI input or they can mirror any of the HDBaseT outputs for
local monitoring. 3D video is also supported when compatible sources
and displays are connected.
This product supports passing 7.1 channel LPCM digital audio as well
as advanced bitstream and HD bitstream audio formats. Additionally,
four analog audio outputs are available to provide stereo breakout
audio from the associated HDBaseT output (LPCM 2.0 sources
only). Beyond basic video routing, this product also incorporates an
independent audio matrix with 14 audio outputs and 10 audio inputs.
Offering discrete audio routing, insertion and extraction, this product
makes it possible to have multiple audio zones within your installation.
Additionally the matrix contains 3 independent audio mixers allowing
for applications such as adding music or a voice over to existing
video. This product supports the Optical Audio Return (OAR) channel
feature, found on compatible HDBaseT receivers, allowing optical
audio sources connected to those receivers to be sent back to the
matrix unit.
Internally generated test patterns (up to 18Gbps UHD resolutions) are
provided to assist with setup, providing a simple way to verify both
matrix and sink functionality. The Power over HDBaseT (PoH) function
can power compatible receivers, providing greater exibility in your
installations. Control is via manual selection buttons, WebGUI, Telnet,
RS-232 or IR remote.
2. APPLICATIONS
• Full audio/video matrix systems
• Residential AV matrix installations
• Commercial AV matrix installations

2
• Security systems
• University lecture hall systems
• Retail installation systems
3. PACKAGE CONTENTS
• 1× 10 by 10 HDMI and HDBaseT Matrix with Audio Matrixing
• 1× Remote Control (CR-163)
• 2× IR Extender Cable
• 2× IR Blaster Cable
• 2× 24V/6.25A DC Power Adaptor
• 2× Power Cord
• 1× Rack Ear Set
• 1× Operation Manual
4. SYSTEM REQUIREMENTS
• HDMI or DVI source equipment such as media players, video game
consoles, set-top boxes, PCs or laptops. DVI equipped source
devices must be connected via DVI to HDMI cables/adapters
• HDMI receiving equipment such as HDTVs, monitors or audio
ampliers
• The use of industry standard Cat.6, Cat.6a or Cat.7 cable is highly
recommended
• HDBaseT™ receivers equipped with Optical Audio Return (OAR)
channel support are strongly recommended
• The use of “Premium High Speed HDMI” cables is highly
recommended
5. FEATURES
• HDMI 2.0, HDCP 1.4 and HDCP 2.2 compliant
• Routes 10 HDMI sources to 10 displays using 8 HDBaseT outputs and
2 independent or mirrored HDMI outputs
• HDBaseT feature support: High-Denition video and audio, 48v PoH
(Power over HDBaseT) and control (Bi-directional IR & RS-232 pass

3
through)
• Supported HDBaseT resolutions: VGA~WUXGA, 480i~1080p,
4K@24/25/30Hz (RGB, YUV 4:4:4 & YUV 4:2:2) & 4K@60Hz (YUV 4:2:0)
dependent upon the output display’s EDID settings
• Supports HDMI output resolutions up to 4K@60Hz (RGB/YUV 4:4:4)
• Supports automatic 4K@60Hz RGB/YUV 4:4:4 to YUV 4:2:0 conversion
for HDBaseT outputs
• 4K@30Hz signals can be transmitted up to 35m via Cat.5e/6 and up
to 40m via Cat.6a/7
• Supports pass-through of all standard digital audio formats: LPCM
2.0/5.1/7.1, bitstream, and HD bitstream
• Supports audio matrix functionality enabling full audio management
of the system including HDBaseT audio selection, fully independent
audio-only zones and HDMI audio embedding and de-embedding
(LPCM only)
• Supports Digital to Analog Conversion (DAC) and Analog to Digital
Conversion (ADC) for audio integration
• Supports integrated audio over CAT inputs and outputs for
transmission up to 300m
• Supports volume, treble, bass, and audio delay for lip-sync (up to
230ms) on analog audio outputs and mute on all outputs
• HDBaseT outputs with Optical Audio Return (OAR) support
• Audio mixer functionality (three mixers in total)
• Advanced internal and external EDID management with 4 sets of
congurable EDID settings
• Internal test pattern generation for self and sink testing
• Capable of generating test signals up to 4K@60Hz
• Bi-directional IR support over HDBaseT
• Supports supplying 48 PoH (Power over HDBaseT) to compatible
receivers (with use of optional 2nd power supply)
• Control via front panel controls, Ethernet (Telnet & WebGUI), RS-232,
& IR remote
• 2U rack mounted design

4
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER
ENTER
PRESET
MENU
/CANCEL
LOCK
ABCDE
FGHIJ
12345
6789
10
+
-
IN
OUT
2.2
isolated
+
35M
1 2 3 6 7 8 95 104
1POWER: Press this button to power the unit on or place it into stand-
by mode.
Note: Network functionality and PoH (if the second power supply is
connected) remain active when the unit is in stand-by mode.
2POWER LED: This LED will illuminate GREEN to indicate the unit is on
and receiving power. When the unit is in stand-by mode the LED
will illuminate RED.
3IR WINDOW: Accepts IR signals from the included IR remote for
control of this unit only.
4OUTPUT A~J & INPUT/NUMBER 1~10: Press the “OUT” button to enter
output selection mode. Next, press the output keys (A~J) of the
outputs you wish to route a source to (they will ash to indicate
selection). Next, press the “IN” key followed by the input (1~10)
you wish to route to the selected outputs. Finally, press “ENTER” to
conrm your selection and execute the routing change.
For example, if you wish to display input 1 on outputs A~D then the
following sequence of button presses should be performed: OUT →
A, B, C, D → IN → 1 → ENTER
When directly entering Ethernet address information into the unit
all 10 buttons are used to represent the numbers from 0 to 9 (button
10 = 0) to make number entry more streamlined.
5MENU/CANCEL: Press the “MENU/CANCEL” button to enter the
OLED menu, or to back out from menu items. For a description of
the menu tree, please refer to section 6.5.
6ENTER: Press this button to conrm selections.
