CYP OR-32USBC-4K22 User manual

OR-32USBC-4K22
UHD+3×2 Matrix Switcher with USB Ethernet Hub
OPERATION MANUAL

DISCLAIMERS
The information in this manual has been carefully checked and is
believed to be accurate. CYP (UK) Ltd assumes no responsibility for any
infringements of patents or other rights of third parties which may result
from its use.
CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be
contained in this document. CYP (UK) Ltd also makes no commitment to
update or to keep current the information contained in this document.
CYP (UK) Ltd reserves the right to make improvements to this document
and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer file, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express
written permission and consent from CYP (UK) Ltd.
© Copyright 2020 by CYP (UK) Ltd.
All Rights Reserved.
Version 1.1
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply. Please keep the
following in mind as you unpack and install this equipment:
• Always follow basic safety precautions to reduce the risk of fire,
electrical shock and injury to persons.
• To prevent fire or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts inside
the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if
it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufficient space for air to circulate around the unit.
• Please completely disconnect the power when the unit is not in use
to avoid wasting electricity.
VERSION HISTORY
REV. DATE SUMMARY OF CHANGE
RDV1 2020/10/29 Preliminary release

CONTENTS
1. Introduction..............................................................1
2. Applications ..............................................................1
3. Package Contents .....................................................1
4. System Requirements ..............................................2
5. Features.....................................................................2
6. Operation Controls And Functions..........................3
6.1 Front Panel ............................................................................3
6.2 Rear Panel..............................................................................4
6.3 RS-232 Pinouts and Defaults ..........................................5
6.4 WebGUI Control ..................................................................6
6.4.1 AV Switch Tab............................................................8
6.4.2 USB Settings Tab ................................................... 10
6.4.3 Automation Tab..................................................... 11
6.4.4 EDID Tab................................................................... 14
6.4.5 Network Tab............................................................ 16
6.4.6 System Tab .............................................................. 17
6.5 Telnet Control.................................................................... 18
6.6 Serial and Telnet Commands....................................... 18
7. Connection Diagram ..............................................48
8. Specifications..........................................................49
8.1 Technical Specifications ................................................ 49
8.2 Video Specifications........................................................ 50
8.3 Audio Specifications....................................................... 52
8.3.1 Digital Audio .......................................................... 52
8.3.2 Analogue Audio.................................................... 52
8.4 Cable Specifications ....................................................... 53
9. Acronyms.................................................................54

1
1. INTRODUCTION
This 3×2 matrix switch is designed for use in environments needing a
wide range of flexibility when it comes to inputs, outputs, and control.
The two most common video input interfaces (HDMI, USB-C) are included
along with a pair of HDMI outputs and a single analogue audio breakout
port, providing the ultimate in source compatibility and flexibility.
All inputs and outputs on this unit are HDCP 2.2 compliant and provide
support for resolutions up to a maximum of 4K@60Hz (4:4:4, 8-bit or
4:2:0, 12-bit HDR). The included USB-C input complies with the USB 3.0
standard and supports audio/video bypass, and device charging, as well
as the ability to provide a network connection.
This matrix also includes standard USB 3.0 hub functionality with two
host ports (one Type-B and one Type-C), plus two device ports (Type-A)
for a flexible KVM configuration. It is ideal for use in meeting rooms or
classrooms. This unit is controllable via front panel controls, WebGUI,
Telnet and RS-232.
2. APPLICATIONS
Home entertainment room
Lecture hall display and control
Showroom displays
Meeting room presentation and control
Classroom presentations
3. PACKAGE CONTENTS
1× UHD+3×2 Matrix Switcher with USB Ethernet Hub
1× 24V/5A DC Power Adapter
1× Shockproof Feet (Set of 4)
1× Operation Manual

2
4. SYSTEM REQUIREMENTS
HDMI or USB-C source equipment such as media players, video game
consoles, laptops, or set-top boxes.
HDMI receiving equipment such as HDTVs, monitors, or audio
amplifiers.
The use of Premium High Speed HDMI cables is highly recommended.
5. FEATURES
HDMI 2.0 and DVI 1.0 compliant
HDCP 1.x and 2.2 compliant
1 USB Type-C and 2 HDMI inputs
2 HDMI outputs with independent matrix switching and auto-switch
support
Supports up to 4K UHD (18Gbps, 4K@60Hz 4:4:4, 8-bit) video input and
output
Supports Deep Colour input and output up to 12-bit
Supports 10-bit and 12-bit HDR (High Dynamic Range) input/output
Supports pass-through of many audio formats including 8 channel
LPCM, Bitstream, and HD Bitstream
HDMI Output A supports 4K to 1080p downscaling
USB-C port functionality is switchable between a A/V focused
mode (4K@60Hz) with USB 2.0 data and a mixed media mode with
simultaneous A/V (4K@30Hz), USB 3.0, and Ethernet support
USB-C port provides up to 20V/3A (60W) power to the connected
device
Supports pass-through of 8 channel LPCM, bitstream & HD bitstream
audio formats
Analogue audio output source audio can be from output A or B (LPCM
2.0 sources only)
Integrated USB 3.0 hub with one dedicated Type-B host port and two
Type-A device ports (The USB-C port may optionally be used as an
alternate host port)
Supports basic signal event automation (via RS-232, Ethernet, or CEC)
Controllable via front panel controls, WebGUI, Telnet and RS-232

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWER
USB USB
USB SEL
A
B
OUT
OUT
USB 1 USB 2
OR-32USBC-4K22
USB-C USB-CHDMI 1 HDMI A HDMI BHDMI 2
1 2 3 4 5 6 7
1POWER LED: This LED will illuminate to indicate the unit is on and
receiving power.
2OUT A & B LEDs: The illuminated LED indicates which source is
currently selected for each output.
3HDMI A & HDMI B Buttons: Press either button to sequentially switch
through the available inputs for the associated HDMI output.
4USB-C & USB LEDs: The illuminated LED indicates which USB host
port is currently active.
5USB Button: Press this button to select which USB host port is
currently active.“USB” selects the USB Type-B port on the front of the
unit, “USB-C” selects the USB Type-C port on the rear of the unit.
6USB 1 & 2 Device Ports (Type-A): Connect directly to standard USB
devices such as a mouse, keyboard or flash drive to extend their USB
functionality to the currently active USB host port.
7USB Host Port (Type-B): Connect directly to a standard USB host
such as a PC or laptop to extend their USB functionality to all currently
connected USB devices.
Note: Only active when the USB mode selection is set to “USB”.

4
6.2 Rear Panel
DC 24VLAN
LINE OUT
OUT
HDMI BHDMI A
IN
HDMI 1 HDMI 2 RS-232
CTL CLI
USB-C
21 3 4 5 6 7
1USB-C IN Port: Connect to USB Type-C host or video source
equipment such as a PC or laptop. When the USB-C port has “Super
Speed” support active, this port can support 4K30 A/V, Ethernet, and
USB simultaneously. When“Super Speed” is disabled, this port will
support full bandwidth 4K60 A/V content but USB data functionality
will be limited to USB 2.0 levels.
Note: Not all devices with USB Type-C ports can support video output.
Please verify that the device supports video output from the USB Type-C
port before attempting to use it as a video source.
2HDMI IN 1 & 2 Ports: Connect to HDMI source equipment such as
media players, game consoles, or set-top boxes. DVI sources are
supported with the use of an HDMI to DVI adapter.
3HDMI OUT A & B Ports: Connect to HDMI TVs, monitors, or amplifiers
for digital video and audio output.
4LINE OUT Port: Connect to powered speakers, headphones, or
an amplifier for analogue stereo audio output extracted from the
selected HDMI output (LPCM 2.0 sources only).
5RS-232 CTL 4-pin Terminal Block: Connect to the device you wish to
control via a 3-pin adapter cable to receive event automation RS-232
commands from the unit.
RS-232 CLI 4-pin Terminal Block: Connect directly to a PC, laptop, or
other serial control device with a 3-pin adapter cable to send RS-232
commands to control the unit.
Note: The 24 volt pins are included to provide power to a dedicated
external control product and should NOT be used when connecting a
standard RS-232 device.
6LAN Port: Connect directly, or through a network switch, to your
PC/ laptop to control the unit via Telnet/WebGUI and to extend the
network across the USB Type-B and Type-C ports.
Note: The USB Type-C port must be in “Super Speed” mode to support
Ethernet extension.
7DC 24V Port: Plug the 24V DC power adapter into this port and
connect it to an AC wall outlet for power.

5
6.3 RS-232 Pinouts and Defaults
Serial Port Default Settings
Baud Rate 19200
Data Bits 8
Parity Bits None
Stop Bits 1
Flow Control None
RS-232 Port 1 (CTL) RS-232 Port 2 (CLI)
Note: The 24 volt pins (pin 1) are included to provide power to a dedicated
external control product and should NOT be used when connecting a
standard RS-232 device

6
6.4 WebGUI Control
Device Discovery
Please obtain the “Device Discovery” software from your authorised dealer
and save it in a directory where you can easily find it.
Connect the unit and your PC/Laptop to the same active network and
execute the“Device Discovery” software. Click on “Find Devices on
Internet” and a list of devices connected to the local network will show up
indicating their current IP address.
Note: The unit’s default IP address is 192.168.1.50.
By clicking on one of the listed devices you will be presented with the
network details of that particular device.
1) IP Mode: If you choose, you can alter the static IP network settings for
the device, or switch the unit into DHCP mode to automatically obtain
proper network settings from a local DHCP server. To switch to DHCP
mode, please select DHCP from the IP mode drop-down, then click
“Save” followed by “Reboot”.
2) WebGUI Hotkey: Once you are satisfied with the network settings,
you may use them to connect via Telnet or WebGUI. The network
information window provides a convenient link to launch the WebGUI
directly.

7
WebGUI Overview
After connecting to the WebGUI’s address in a web browser, the login
screen will appear. Please enter the appropriate user name and password
then click “Submit” to log in.
Note: The default user name and password is “admin”.
On the left side of the browser you will see the following menu tabs
where all primary functions of the unit are controllable via the built in
WebGUI. The individual functions will be introduced in the following
sections.
Clicking the red “Logout” tab will automatically log the currently
connected user out of the WebGUI and return to login page.

8
6.4.1 AV Switch Tab
This tab provides A/V routing control, HDCP management, auto switch
control, analogue audio controls, and I/O renaming options. To assign a
new
A/V route, select one or both output buttons on the left and then click on
the button of the preferred input source on the right. As each button is
selected they will become highlighted. The new route will become active
immediately and the routing information displayed on the buttons will
change accordingly.
1) Output: These buttons display each output’s name and details about
the currently routed inputs. Clicking on the “Edit” icon ( ) opens up
the Output Edit window.
2) Input: Buttons for selecting the input to route to an output. Details
about each input’s name and current sync/HDCP settings are also
displayed here. Clicking on the “Edit” icon ( ) opens up the Input Edit
window.
3) Auto: Auto input switching may be enabled or disabled by clicking on
the On/Off slider to toggle the setting.
Note: This setting affects the source selection behavior for both outputs at
the same time.
4) Output Edit: Provides control over the name of the output and, for
output A only, control over the 4K downscale options.

9
Set Output Name: To rename the output, type the new name in
the space provided in the edit window. The name can be up to 32
characters long. Click the“Save” button to confirm the change.
4K2K Downscale: Select the 4K to 1080p downscaling behavior for
output A.
-Pass Through: Send all signals through without any modification.
-Auto: Only activate the downscaling function if the EDID of the
connected display does not support 4K.
-1080P: Downscales all 4K sources to 1080p.
Note: This option is available for output A only. When active, no
framerate conversion is performed. For example, a 4K@24Hz source
would be output as 1080p@24Hz.
5) Input Edit: Provides individual control over the name of each input as
well as the behavior of HDCP on that input.
Set Input Name: To rename an input, type the new name in the
space provided in the edit window. The name can be up to 32
characters long. Click the“Save” button to confirm the change.
HDCP: Selects the HDCP logic to use with this HDMI input. Changes
made to this setting occur immediately.
-Disabled: Completely disables support for HDCP on this input.
-Follow Source: Makes the input port support the same HDCP
version as required by the connected source.
-Follow Display: Makes the input support the HDCP version of
the currently routed display(s).

10
6) Analogue Audio Output: Select the audio source for the analogue
audio output.
Note: Only LPCM 2.0 sources are supported.
7) Analogue Audio Mute: Mute or unmute the analogue audio output.

11
6.4.2 USB Settings Tab
This tab provides control over the settings for the USB ports on the unit.
1) USB Host setting: Enable or disable automatic selection of the USB
host port.
2) USB-C Super Speed Selection: Select the operational mode of the
USB Type-C port. When “Super Speed” is turned on, the Type-C port
can support 4K30 A/V, Ethernet, and USB simultaneously. When “Super
Speed” is turned off, the Type-C port will support full bandwidth 4K60
A/V content but USB data functionality will be limited to USB 2.0
levels.
3) USB Host Switch: Select which USB host port is active on the internal
USB hub. Selecting “Local USB” will make the Type-B port on the front
of the unit active. Selecting “Type-C”will make the Type-C port on the
rear of the unit active.

12
6.4.3 Automation Tab
This tab provides control over the unit’s automatic control command
broadcast behavior when any of the specified Automation Events occur.
Automation commands can control connected devices via CEC, RS-232,
and Telnet.
Note: CEC events are only sent to the device connected to HDMI output A.
1) Event: Use the dropdown to select the Automation Event to configure.
Available Automation Events are:
-Power On: This unit is powered on.
-Out A Source Active: The currently selected input changes from
inactive to active.
-Out A Source Lost: The currently selected input changes from
active to inactive.
2) CEC: Enable or disable sending a CEC command when the currently
selected Automation Event is activated.
Note: CEC support must also be enabled on the device connected to HDMI
output A.
Delay: Set the length of time, in seconds, that the specified
Automation Event must continue to be true before sending the
defined CEC command.
Wait: Set the length of time, in seconds, to wait after this
Automation Event has been activated before ANY other Automation
Event can be detected.

13
CEC Command: Set the CEC command to send when the specified
Automation Event is activated. Click the“Test” button to send the
command immediately. Available CEC commands are:
-Power Off: Turn off the connected HDMI display device.
-Power On: Turn on the connected HDMI display device.
-Active Source: Force the connected HDMI display device to
switch to the HDMI input that this unit is connected to.
Note: Not all HDMI devices support all CEC commands.
3) RS-232: Enable or disable sending an RS-232 command when the
currently selected Automation Event is activated. Click the “Edit” icon
() to configure the RS-232 port.
Note: RS-232 Automation commands will only be output over the “CTL”
RS-232 port.
Delay: Set the length of time, in seconds, that the specified
Automation Event must continue to be true before sending the
defined RS-232 command.
Wait: Set the length of time, in seconds, to wait after this
Automation Event has been activated before ANY other Automation
Event can be detected.
RS232 Command: Click the Edit icon ( ) to define the RS-
232 command to send when the specified Automation Event
is activated. Click the“Test” button to send the command
immediately.

14
4) Telnet: Enable or disable sending a Telnet command to the
designated IP address when the currently selected Automation Event
is activated. Click the“Edit” icon ( ) to configure the target IP address
and communication port. If the target Telnet device requires a login to
receive commands, those details may be added as well.
Delay: Set the length of time, in seconds, that the specified
Automation Event must continue to be true before sending the
defined Telnet command.
Wait: Set the length of time, in seconds, to wait after this
Automation Event has been activated before ANY other Automation
Event can be detected.
Telnet Command: Click the Edit icon ( ) to define the Telnet
command to send when the specified Automation Event
is activated. Click the“Test” button to send the command
immediately.

15
6.4.4 EDID Tab
This tab provides control over the EDID settings of all inputs. This unit
provides the option of six standard EDIDs, two sink sourced EDIDs and
three user uploaded EDIDs that can be assigned to one input or all inputs
as a group. The names of the user uploaded EDIDs can be changed if
desired.
1) User EDID
Upload: To upload a User EDID, select the User EDID slot to upload
into from the dropdown list and then click the “Upload” button.
An EDID Upload window will appear, allowing you to locate and
upload the preferred EDID file (*.bin format) from a local PC. Once
the correct file has been selected, please click the “Upload” button
in the window, and the file will be transferred to the unit.
Download: To save an existing User EDID to your local PC, select
the User EDID slot from the dropdown list and then press the
“Download” button. Depending on your browser settings you will
either be asked where to save the downloaded file, or the file will
be transferred to the default download location on your PC.
Edit Name: Click the “Edit Name”button to open a window that
allows changing the name of the User EDID. Click the “Save Change”
button within the window to confirm the change.
