CYP CS-802D User manual

CS-802D
mDP/DVI-DL/VGA to HDMI Scaler
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2017 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE (DD/MM/YY) SUMMARY OF CHANGE
VR0 03/09/13 Preliminary release
VS1 09/12/14 Updated text/diagrams
VS2 30/03/17 Updated formatting

CONTENTS
1. Introduction......................................................1
2. Applications.....................................................1
3. Package Contents ..........................................1
4. System Requirements......................................1
5. Features............................................................1
6. Operation Controls and Functions.................2
6.1 Front Panel ................................................. 2
6.2 Rear Panel.................................................. 3
6.3 Remote Control......................................... 4
6.4 OSD Menu.................................................. 5
6.5 RS-232 Protocol.......................................... 6
6.6 RS-232 and Telnet Commands ................ 7
7. Connection Diagram ......................................9
8. Specications ................................................10
8.1 Technical Specications ........................ 10
8.2 Video Specications............................... 11
8.3 Audio Specications............................... 12
9. Acronyms .......................................................13

1
1. INTRODUCTION
This HDMI Scaler can switch and convert Dual-link DVI, Mini DisplayPort
and VGA/Component Video inputs to an HDMI output, along with
their associated audio signals. With the ability to scale a wide range
of resolutions, the operation of all features can be easily handled
through on-panel controls, IR remote control, or by RS-232 protocol.
2. APPLICATIONS
• Scale Dual-link DVI, Mini DisplayPort and VGA/Component Video
input resolutions to HDMI output resolutions
• Convert Dual-link DVI, Mini DisplayPort, VGA and Component Video
signals to HDMI signal
• Commercial presentation switching scaler
3. PACKAGE CONTENTS
• 1×mDP/DVI-D/VGA to HDMI Scaler
• 1×Remote Control (CR-123)
• 1×5V/2.6A DC Power Adaptor
• 1×Operation Manual
4. SYSTEM REQUIREMENTS
Dual-Link DVI/Mini DisplayPort/PC/YUV sources and output to an HDMI
display.
5. FEATURES
• Supports Dual-link DVI and Mini DisplayPort input resolutions up
to 2560×1600@60Hz (RB), PC up to 1920×1200@60/75Hz and
Component Video up to 1080p@50/60Hz
• Supports digital and analog audio bi-directional conversion,
embedding and de-embedding for the audio signals from individual
inputs
• Supports Component Video input via D-sub 15-pin to 3 RCA phono
adaptor

2
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
ENTER
MENU/
OPTICAL
OUT
IN
AUDIO HDMI OUT
DC 5V
POWER
OPTICAL AUDIO
XGA
720P
3
6
2 4
7
5 8 9 101
1MENU/ENTER: Press this button to ENTER the On-screen Display (OSD)
menu. Press again to conrm the selection.
2 −/IN: When in the OSD menu, press this button repeatedly to move
down through the menu. When not in the OSD menu, press this
button to quickly select the required input.
3+/OUT: When in the OSD menu, press this button repeatedly to
move up through the menu. When not in the OSD menu, press this
button to quickly select the required output resolution.
 Note:Pressing“−”(MINUS)and“ENTER”simultaneouslywill
immediatelyswitchtheoutputresolutionofthedeviceto
720p@60Hz.Pressing“+”(PLUS)and“ENTER”simultaneouslywill
immediatelyswitchtheoutputresolutionofthedevicetoXGA.
4OPTICAL IN: Digital audio TOSLINK input. Use this input to connect
to a source with an OPTICAL cable.
5AUDIO IN: Analog audio input. Use this input to connect to analog
source with a 3.5mm mini-jack cable.
6OPTICAL OUT: Digital audio TOSLINK output. Use this output to
connect to an Amplier or Active Speakers to an optical digital
input with an OPTICAL cable.
7AUDIO OUT: Analog audio output. Use this output to connect to
Active Speakers or an Amplier with a 3.5mm mini-jack cable.
8HDMI OUT: Connect to a HDMI equipped TV/monitor for display of
the source signal.

3
9IR WINDOW: Receives the IR signal from the supplied IR Remote
only.
10 DC 5V & POWER LED: Connect the supplied 5V DC power supply
to the unit and plug the power supply to AC wall outlet. Once the
system turns on the LED will turn RED.
6.2 Rear Panel
RS232
SERVICE MDP
Dual-Link DVI PC/COMP
IN
21 3 4 5
1RS232: Connect to a PC or RS-232 control system with a D-sub 9-pin
cable for RS-232 control.
2SERVICE: Manufacturer use only.
3MDP IN: Connect to a DisplayPort source device such as a PC/
laptop with a mini-DisplayPort cable.
4Dual-Link DVI IN: Connect to a DVI source device such as a PC/
laptop with a DVI cable.
5PC/COMP IN: Connect to a VGA source such as a PC/laptop
source equipment with a D-sub 15-pin cable or to a Component
Video source with a D-sub 15-pin to 3 RCA phono adaptor for
component video signal input.

4
6.3 Remote Control
1POWER: Press to turn the system
ON/OFF.
2VIDEO IN: Press the required
key to directly select the video
source (DVI/MDP/PC/COMP).
3AUDIO IN: Press the required
key to directly select the audio
source (AUDIO/OPTICAL/MDP)
or to MUTE the system.
4MENU: Press this button to
ENTER the OSD menu.
5EXIT: Press this button to EXIT the OSD menu.
6 ENTER & ▲/▼/◄/►: Press ENTER button to conrm the selection
and press the arrow keys to navigate the OSD menu.
7INFO: Press to show the input and output resolution information.
8OUTPUT: Press to show the output resolution table.
9NATIVE: Press to switch to the native resolution.
MDP
MENU
OUTPUTINFO
DVI
PC
AUDIO
MUTE
EXIT
NATIVE
MDP
COMP
OPTICAL
ENTER
CR-123
AUDIO IN
VIDEO IN
2
3
4
8
9
5
1
7
6

5
6.4 OSD Menu
LEVEL 1 LEVEL 2 LEVEL 3
Input Video PC
COMP
DVI
MDP
Exit
Input Audio Audio
Optical
MDP
Mute
Exit
Output Resolution 720×480P
1280×720P
1920×1080P
640×480 (VGA)
800×600 (SVGA)
1024×768 (XGA)
1280×1024 (SXGA)
1600×1200 (UXGA)
1920×1200 (WUXGA)
1280×800 (WXGA)
By Native
Exit
Misc. Setup EDID Mode Internal
External
Exit
Info. OSD Mode Off
On

6
LEVEL 1 LEVEL 2 LEVEL 3
Misc. Setup (cont.) Info. OSD Mode Exit
About CS-802D FW Ver.
Factory Reset System Reset
Exit
Exit
6.5 RS-232 Protocol
UNIT
►
◄
REMOTE CONTROLLER
Pin Assignment Pin Assignment
1 NC 1 NC
2TxD 2RxD
3RxD 3TxD
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rate: 19200bps
Data Bits: 8
Parity: None
Flow Control: None
Stop Bits: 1

7
6.6 RS-232 and Telnet Commands
COMMAND DESCRIPTION
POWER ? Power Status
POWER ON Power On
POWER OFF Power OFF
VIDEO ? Video Input Source
DVI Video Input in DVI
MDP Video Input in MDP
PC Video Input in PC
COMP Video Input in Component
AUDIO ? Audio Input Source
AUDIO Audio Input in AUDIO
OPTICAL Audio Input in OPTICAL
MDPA Audio Input in MDP
MUTE ? MUTE On/Off
MUTE ON MUTE On
MUTE OFF MUTE Off
INFO ? Info. OSD Status
INFO ON Info. OSD On
INFO OFF Info. OSD Off
INFO DISPLAY Info.OSD On/Off
OUTPUT ? Output Status
480P Output in 480p
720P Output in 720p
1080P Output in 1080p
VGA Output in VGA (640×480)
SVGA Output in SVGA (800×600)
XGA Output in XGA (1024×768)
SXGA Output in SXGA (1280×1024)

8
COMMAND DESCRIPTION
UXGA Output in UXGA (1600×1200)
WUXGA Output in WUXGA (1920×1200)
WXGA Output in WUXGA (1280×800)
NATIVE Output by Native
EDID ? EDID Status
EDID INT EDID By Internal
EDID EXT EDID By External
STATE ? Video Input Signal Status
VERSION ? Display Firmware Version
FEEDBACK ? Key Feedback Status
FEEDBACK ON Key Feedback Enable
FEEDBACK OFF Key Feedback Disable
DEFAULT Reset to Factory Default
ABOUT ? About the Unit
Note:Commandswillnotbeexecutedunlessfollowedbyacarriage
return.Commandsarenotcase-sensitive.

9
7. CONNECTION DIAGRAM
HDMI OUT
DC 5V
POWER
OPTICAL
OUT
AUDIO
IN
OPTICALAUDIO
ENTER
MENU/
XGA
720P
RS232
SERVICE MDP
Dual-Link DVI PC/COMP
IN
Laptop
RS-232
Dual-link DVI
Input VGA Input
Digital Audio
Input (Optical)
Analog Audio
Input (3.5mm)
HDMI Output
Power
Supply
Mini DisplayPort Input
PCPC
HDTVAV Receiver
Digital Audio
Output (Optical)
Analog Audio
Output (3.5mm)

10
8. SPECIFICATIONS
8.1 Technical Specications
DP Video Bandwidth 2.7Gbps & 2.7Gbps/Lane
Input Ports 1×Mini DisplayPort
1×Dual-link DVI
1×VGA (15-pin D-sub)
1×Digital Audio (Optical/TOSLINK)
1×Analog Audio (3.5mm)
Output Ports 1×HDMI
1×Optical Audio (TOSLINK)
1×Stereo Audio (3.5mm)
Control Interfaces 1×RS-232 (9-pin D-sub)
Power Supply 5V/2.6A DC (US/EU standards, CE/FCC/UL
certied)
ESD Protection Human Body Model:
±12kV (Air Discharge)
±8kV (Contact Discharge)
Dimensions 141mm×50mm×179mm (W×H×D)
[Case Only]
141mm×50mm×181mm (W×H×D)
[All Inclusive]
Weight 700g
Chassis Material Aluminum
Silkscreen Color Black
Operating Temperature 0˚C - 40˚C/32˚F - 104˚F
Storage Temperature −20˚C - 60˚C/−4˚F - 140˚F
Relative Humidity 20 - 90% RH (Non-condensing)
Power Consumption 8.9W

11
8.2 Video Specications
Supported Resolutions (Hz)
Input Output
mDP DVI-DL PC COMP HDMI
640×350@85   
640×400@85   
720×400@85   
640×480@60/72/75/85    
800×600@56/60/72/75/85/120 (RB)    
848×480@60   
1024×768 @60/75/85/120 (RB)    
1280×720@60   
1280×768@60 (RB)/60/75/85/120 (RB)   
1280×800@60 (RB)/60/75/85/120 (RB)    
1280×960@60/85   
1280×1024@60/75/85    
1360×768@60/120 (RB)   
1366×768@60 (RB)/60   
1400×1050@60 (RB)/60/75   
1440×900@60 (RB)/60/75/85   
1600×900@60 (RB)   
1600×1200@60    
1680×1050@60 (RB)/60   
1792×1344@60/75  
1856×1392@60/75 
1920×1080@60   
1920×1200@60 (RB)/60   60 (RB) 60
1920×1440@60  
2048×1080@@50/60   
2048×1152@@60 (RB)  

12
Supported Resolutions (Hz)
Input Output
mDP DVI-DL PC COMP HDMI
2560×1600@60 (RB)  
480i 
480p  
576i 
576p 
720p@24/25/30/50 /60  
1080i@50/60 
1080p@24/30/50/60  
Note:Whenoutputtimingissetto“ByNative”yetthetimingdoesnot
matchthebuilt-insupporttiming,outputtimingwillsettodefaultat
1280×720pautomatically.
8.3 Audio Specications
Input
Terminal
Output
Terminal
Output
Level THD+N
Frequency
Response SNR Crosstalk
Digital
(S/PDIF)
HDMI 0 ~ −1dB < 0.1% N/A > 70dB < −60dB
Optical 0 ~ −1dB < 0.1% N/A > 70dB < −60dB
Analog 2Vrms±10% < 0.1% 2Vrms±10% > 70dB < −60dB
Analog
(2CH)
HDMI 0 ~ −1dB < 0.1% 2Vrms±10% > 70dB < −60dB
Optical 0 ~ −1dB < 0.1% 2Vrms±10% > 70dB < −60dB
Analog 2Vrms±10% < 0.1% 2Vrms±10% > 70dB < −60dB

13
9. ACRONYMS
ACRONYM COMPLETE TERM
DP DisplayPort
DVI Digital Visual Interface
EDID Extended Display Identication Data
HD High-Denition
HDCP High-bandwidth Digital Content Protection
HDMI High-Denition Multimedia Interface
LPCM Linear Pulse-Code Modulation
OSD On-Screen Display
PC Personal Computer
PCM Pulse-Code Modulation
S/PDIF Sony/Philips Digital Interface Format
USB Universal Serial Bus
VGA Video Graphics Array (640×480@60Hz)
WUXGA Wide Ultra Extended Graphics Array
(1920×1200@60Hz)

CYPRESS TECHNOLOGY CO., LTD.
www.cypress.com.tw
