CYP PU-607BD-RX User manual

PU-607BD-RX
HDMI over Single CAT5e/6/7 HDBaseT™ - Bi-Directional
PoE Receiver (Full 5Play™ & Single LAN up to 100m)
OPERATION MANUAL

3
DISCLAIMERS
The information in this manual has been carefully checked and is
believed to be accurate. CYP (UK) Ltd assumes no responsibility for any
infringements of patents or other rights of third parties which may result
from its use.
CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be
contained in this document. CYP (UK) Ltd also makes no commitment to
update or to keep current the information contained in this document.
CYP (UK) Ltd reserves the right to make improvements to this document
and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer le, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express
written permission and consent from CYP (UK) Ltd.
© Copyright 2011 by CYP (UK) Ltd.
All Rights Reserved.
Version 1.1 August 2011
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

4
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts inside
the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if
it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sucient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE SUMMARY OF CHANGE
v1.00 11/02/2014 First release

5
CONTENTS
1. Introduction...........................................6
2. Applications ...........................................6
3. Package Contents ..................................6
4. System Requirements ...........................6
5. Features..................................................7
6. Operation Controls and Functions.......8
6.1 Receiver Front and Rear Panels ............ 8
6.2 IR Cable Pin Assignment ......................... 9
6.3 D-Sub 9 Pin Denitions ........................... 9
7. Connection Diagram .......................... 10
8. Specications...................................... 11
9. Acronyms............................................. 12

6
1. INTRODUCTION
The PU-607BD-RX Receiver allows uncompressed HDMI signals and IP
data to be received via a Single CAT5e/6/7 cable. This solution has the
added features of RS-232 and 2-way IR control functionality over the
same CAT5e/6/7 cable. These combined HDMI and control signals can be
transmitted up to lengths of 100 metres. This Receiver is designed to be
used with the PU-607BD-TX or PU-607BDWP-TX Transmitters only, which
enables Bi-Directional Power over Ethernet (PoE) functionality.
2. APPLICATIONS
Household entertainment sharing and control
Lecture room display and control
Showroom display and control
Meeting room presentation and control
Classroom display and control
3. PACKAGE CONTENTS
1×PU-607BD-RX Receiver
1×IR Blaster
1×IR Receiver
1×24V/1.25A DC Power Adaptor
Operation Manual
4. SYSTEM REQUIREMENTS
Input HDMI source equipment such as DVD/Blu-ray player and HDMI
equipped output display (TV or monitor).

7
5. FEATURES
Supports all v1.4 HDMI resolutions including 4K.
Supports uncompressed video/audio up to 10.2Gbps
Common supported resolutions: HDTV: 480p, 576p, 720p, 1080i,
1080p, 1080p24; PC: VGA, SVGA, XGA, WXGA, SXGA, UXGA, WUXGA.
HDMI, HDCP, & DVI compliant
Supports HDCP repeating and CEC functions
Uncompressed data transfer over single CAT cable (100m - CAT6/7;
80m - CAT5e)
Uncompressed video 1080p, 60Hz, 48bits
Audio support up to 7.1CH & Dolby TrueHD, DTS-HD
5Play™ convergence: HDMI, LAN, Bi-Directional POE & Control (IR &
RS232)
Supports 3D signals
Supports Bi-Directional Power over Ethernet (PoE)
Note: Only compatible with PU-607BD-TX & PU-607BDWP-TX Transmitters

8
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Receiver Front and Rear Panels
RS-232 Out
LAN
HDMI Out
Receiver
RearFront
CAT5e/6 In
Link
IR1 Extender
IR2 Blaster
Power
DC 24V
2 31 74 8 965
1HDMI Out: Connect to a HDMI equipped TV/monitor for display of the
HDMI input source signal.
2LAN: Connect to a PC or Laptop to the Internet or network connection.
3RS-232 Out: Connect to the device that is to be controlled (via D-Sub
9 pin female cable) by RS-232 commands.
4Power LED: This blue LED will illuminate when the device is connected
to a power supply.
5DC 24V: Plug the 24 V DC power supply into the unit and connect
the adaptor to an AC outlet. Only one side of power needs to be
connected to activate both transmitter and receiver.
6IR 2 Blaster: Connect to the supplied IR blaster cable for IR signal
transmission. Place the IR blaster in direct line of sight of the
equipment to be controlled.
7IR 1 Extender: Connect to the supplied IR receiver cables for IR signal
reception. Ensure that remote being used is within the direct line-of-
sight of the IR extender.
8Link LED: The yellow LED will illuminate when both the input and
output signals are connected.
9CAT5e/6 In: Connect to the transmitter unit with a Single CAT5e/6
cable for transmission of all data signals.

9
6.2 IR Cable Pin Assignment
3
1
2
3
1
2
Power 5V
IR Blaster Signal
NC
IR Signal
Power 5V
Grounding
IR Receiver
IR Blaster
6.3 D-Sub 9 Pin Denitions
Pin Dene TX / RX
1 N/C
2 TxD / RxD
3 RxD / TxD
4 N/C
5 GND
6 N/C
7 N/C
8 N/C
9 N/C

10
7. CONNECTION DIAGRAM
TV or Monitor
CAT5e/6 In
Link
IR1 Extender
IR2 Blaster
Power
DC 24V
RS-232 In
LAN
HDMI In
Transmitter
CAT5e/6 Out
Link
IR2 Extender
IR1 Blaster
DC 24V
Power
RS-232 Out
LAN
HDMI Out
Receiver
1.5m
60°
1.5m
60°
7m
3m 3m
60°
7m
3m 3m
60°
RS-232 Equipped
PC or Notebook
RS-232 Equipped
HDMI Switcher
Notebook
DVD or Blu-ray Player
Internet Modem or
Router
Power
Supply
IR Blaster
HDMI
CAT5e/6
RS-232
HDMI
IR Extender
IR Extender
IR Blaster
RX
TX
CAT5e/6
RS-232
Note: Only one of the units need to be connected to power, either the
transmitter or receiver, on order for both to operate. In this example the
transmitter is powering the receiver
