CYP PU-607BDWP-RX User manual

PU-607BDWP-RX
HDMI over Single CAT5e/6/7 HDBaseT™ - Bi-Directional PoC
Wallplate Receiver (full 5Play™ & Single LAN up to 100m)
OPERATION MANUAL

3
DISCLAIMERS
The information in this manual has been carefully checked and is
believed to be accurate. CYP (UK) Ltd assumes no responsibility for any
infringements of patents or other rights of third parties which may result
from its use.
CYP (UK) Ltd assumes no responsibility for any inaccuracies that may be
contained in this document. CYP (UK) Ltd also makes no commitment to
update or to keep current the information contained in this document.
CYP (UK) Ltd reserves the right to make improvements to this document
and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted, transcribed,
stored in a retrieval system, or any of its part translated into any language
or computer le, in any form or by any means—electronic, mechanical,
magnetic, optical, chemical, manual, or otherwise—without express
written permission and consent from CYP (UK) Ltd.
© Copyright 2019 by CYP (UK) Ltd.
All Rights Reserved.
Version 1.1
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

4
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or operate
this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts inside
the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU if
it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sucient space for air to circulate around the unit.
REVISION HISTORY
VERSION NO. DATE SUMMARY OF CHANGE
v1.00 13/01/2014 First release
v1.01 31/03/2014 Corrected Contents List
v1.02 23/08/2019 Updated Specications

5
CONTENTS
1. Introduction...........................................6
2. Applications ...........................................6
3. Package Contents ..................................6
4. System Requirements ...........................6
5. Features..................................................7
6. Operation Controls and Functions.......8
6.1 Receiver......................................................... 8
6.2 Rear Panel..................................................... 9
6.3 IR Cable Pin Assignment ......................10
6.4. D-Sub 9-Pin Denitions........................10
7. Connection Diagrams......................... 11
8. Specications...................................... 13
8.1 Technical Specications ........................13
8.1 Cable Specications ...............................14
9. Acronyms............................................. 15

6
1. INTRODUCTION
The PU-607BDWP-RX Wallplate Receiver allows uncompressed HDMI
signals and IP data to be received via a Single CAT5e/6/7 cable.
This solution has the added features of RS-232 and 2-way IR control
functionality over the same CAT5e/6/7 cable up to 100m/328ft at 1080p
and 70m/229ft at 4K.
This Receiver is designed to be used with the PU-607BD-TX and PU-
607BDWP-TX Transmitters only, which enables Bi-Directional Power over
Ethernet (PoE) functionality.
2. APPLICATIONS
Household entertainment sharing and control
Lecture room display and control
Showroom display and control
Meeting room presentation and control
Classroom display and control
3. PACKAGE CONTENTS
1×HDMI over Single CAT5e/CAT6 Receiver
1×IR Blaster
1×IR Receiver
Operation Manual
4. SYSTEM REQUIREMENTS
Input HDMI source equipment such as DVD/Blu-ray player and HDMI
equipped output display (TV or monitor)with HDMI input jack.

7
5. FEATURES
HDMI 1.x and DVI 1.0 compliant
HDCP compliant
Supports HDMI 3D and 4K x 2K features
Supports HDCP repeater and CEC bypass
Supports distance up to 100m/328ft at 1080p and 70m/229ft at 4K
through CAT5e/6/7 cable
HDMI input resolutions up to 4K@60Hz (YUV 4:2:0, 8-bit) or 4K@30Hz
( YUV 4:4:4, 8-bit)
Supports pass-through of audio formats including LPCM 2.0/5.1/7.1,
and Bitstream over HDMI
5Play™ convergence: HDMI, bi-directional PoC, (bi-directional IR &
RS232) & LAN
Wall plate design and Installation Friendly
Note
1. This system was tested with CAT6/23AWG and CAT5e/24AWG cable, so if
using cables of another type, results may vary.
2. For playback of 4K2K HDMI source signals, a 4K2K capable display and
High Speed HDMI cables are required.
3. Only compatible with PU-607BD-TX & PU-607BDWP-TX Receivers

8
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Receiver
HDMI OUTLAN
POWER
LINK
IR 1
EXTENDER
IR 2
BLASTER
DC 24V
RS-232
OUT
1 2
3 4 5 6 7 8
1IR 1 EXTENDER: Connect to the supplied IR Extender cables for IR
signal reception. Ensure that remote being used is within the direct
line-of-sight of the IR Extender.
2DC 24V: The device can get power supply from the transmitter side
and or use its own power supply by plug the 24V DC power supply
into the unit and connect the adaptor to an AC outlet.
3IR 2 BLASTER: Connect to the supplied IR Blaster cable for IR
signal transmission. Place the IR Blaster in direct line of sight of the
equipment to be controlled.
4RS-232 OUT: This slot is to connect with D-Sub 9-pin female cable
from device equipment for receiving RS-232 commands.
5LAN: Connect to an active network or internet service.
When the Transmitter or any compatible LAN equipped Receivers are
connected to a network, this allows the network access (including
internet access if available) to be shared between the Transmitter and
all connected Receivers. Connect any Ethernet equipped device e.g.
a Smart TV or games console to the LAN port of a Receiver for that
device to share the network/internet access.

9
6HDMI OUT: This slot is to connect with HDMI TV/monitor for display
HDMI input source signal.
7Power LED: This LED will illuminate when the device is connected to a
power supply.
8LINK LED: This LED will illuminate when both the input source and
output display signals are connected through CAT cable. When it
blinks regularly it indicates the display is NOT sending signals to the
Receiver but the Transmitter and Receiver are linked and if it blinks
irregularly it indicates an error has occurred.
6.2 Rear Panel
1
1CAT5e/6/7 IN: Connect to the Transmitter unit with a single

10
6.3 IR Cable Pin Assignment
3
1
2
3
2
1Power 3.3V
IR Blaster Signal
NC
IR Signal
Power 3.3V
Ground
IR Extender
IR Blaster
6.4. D-Sub 9-Pin Denitions
Pin Dene TX/RX
1N/C
2TxD/RxD
3RxD/TxD
4N/C
5GND
6N/C
7N/C
8N/C
9N/C

11
7. CONNECTION DIAGRAMS
Option 1
HDMI OUTLAN
POWER
LINK
IR 1
EXTENDER
IR 2
BLASTER
DC 24V
RS-232
OUT
HDMI INLAN
POWER
LINK
IR 2
EXTENDER
IR 1
BLASTER
DC 24V
RS-232
IN
1.5m
60°
1.5m
60°
7m
3m 3m
60°
7m
3m
3m
60°
IR Blaster
Internet Modem or
Router
CAT5e/6/7
RS-232 Power
Supply
Power
Supply
RS-232 Equipped
HDMI Switcher
Notebook
TV or Monitor
IR Extender
IR Extender
DVD or Blu-ray
Player
RS-232 Equipped PC or
Notebook
IR Blaster

12
Option 2
7m
3m 3m
60°
m
7m
3m 3m
60°
m
1.5m
60°
1.5m
60°
CONTROL
RS232
SERVICE
IR OUT
IR IN
IR OUT
IR IN
IR OUT
IR IN
ALL A B C D E F G H
CAT5e/6OUT
IR OUT
IR IN
CAT5e/6OUT
IR OUT
IR IN
CAT5e/6OUT
IR OUT
IR IN
CAT5e/6OUT
IR OUT
IR IN
CAT5e/6OUT
IR OUT
IR IN
CAT5e/6OUTCAT5e/6OUT
IR OUT
IR IN
CAT5e/6OUT
MAIN 24V
POE 24V
1
HDMI IN
2
HDMI IN
3
HDMI IN
4
HDMI IN
5
HDMI IN
6
HDMI IN
7
HDMI IN
8
HDMI IN
1
2
3
4
V+
GND
GND GND
V+
HDMI OUTLAN
POWER
LINK
IR 1
EXTENDER
IR 2
BLASTER
DC 24V
RS-232
OUT
IR2 Receiver
IR1 Blaster IR2 Blaster
IR1 Receiver
HD Monitor or TV
Projector
HDMI Cable HDMI Cable
DC
Blu-ray
PC
CAT5e(100M)/
CAT6(100M)
TV/HD Monitor's
Remote
Blu-ray's
Remote
RS-232 Cable RS-232 Cable

13
8. SPECIFICATIONS
8.1 Technical Specications
Video Bandwidth 340MHz/10.2Gbps
Input Ports 1×CAT5e/6/7, 1×IR Extender, 1xLAN
Output Ports 1×HDMI, 1×RS-232, 1×IR Blaster
IR Frequency 30 - 50kHz
(30 - 60kHz under ideal conditions)
Baud Rate up to 115200/sec
Power Supply PoC
24V DC / 1.25A (Optional)
(US/EU standards, CE/FCC/ UL certied)
ESD Protection Human-body Model:
±8kV (air-gap discharge)
±4kV (contact discharge)
Dimensions (mm) 145.7(W) x 85.7(D) x 36.5(H)/Jacks Excluded
145.7(W) x 85.7(D) x 39.5(H)/Jacks Included
Weight (g) 160/Rx
Chassis Material Plastic
Silkscreen Color White
Operating Temperature 0 °C~40 °C/32 °F~104 °F
Storage Temperature −20 °C ~ 60 °C/−4 °F~140 °F
Relative Humidity 20~90 % RH (non-condensing)
Power Consumption 12W/PoC, 9W/Stand Alone

14
8.1 Cable Specications
Cable Length
1080p 4K30 4K60
8-bit 12-bit
(4:4:4)
8-bit
(4:2:0)
8-bit
High Speed HDMI Cable
HDMI Input 15m 10m 5m 5m
HDMI Output 15m 10m 5m 5m
Ethernet Cable
Cat.5e/6/7 100m 70m
1080p (FHD Video)
-Up to 1080p@60Hz, 12-bit color
-Data rates lower than 5.3Gbps or below 225MHz TMDS clock
4K30 (UHD Video)
-4K@24/25/30Hz & 4K@50/60Hz (4:2:0), 8-bit color
-Data rates higher than 5.3Gbps or above 225MHz TMDS clock but
below 10.2Gbps

15
9. ACRONYMS
ACRONYM COMPLETE TERM
CAT5e Category 5 Cable
CAT6 Category 6 Cable
CEC Consumer Electronics Control
DVI Digital Visual Interface
HDCP High-bandwidth Digital Content Protection
HDMI High Denition Multimedia Interface
IR Infrared

CYP (UK) Ltd., Unit 7, Shepperton Business Park, Govett Avenue, Shepperton,
Middlesex, TW17 8BA
Tel: [phone] | Fax: [phone]
Email: [email protected]
www.cypeurope.com
v1.02
