Cypress CPT-386 User manual

CPT-386
CPT-386 PC to
Component
Scan Converter
Operation Manual
2008.3.7 MPM-CPT386
TABLE OF CONTENTS
3
4. Connection and Installation
5. Specifications
Input resolutions VGA up to 140Hz refresh rate
SVGA up to 120Hz refresh rate
XGA up to 85Hz refresh rate
SXGA up to 60Hz refresh rate
UXGA at 60Hz refresh rate
Output resolutions Component Y/Cb/Cr of 480i or 576i
Input port 1 x D-Sub 15-pin (Female R/G/B/H/V)
Output port Component (3 x RCA jacks)
Power Supply 3.3V/1A DC (US/EU standards, CE/FCC/UL certified)
Dimensions (mm) 100(W) x 64(D) x 18.5(H)
Weight 100g
Chassis Material Plastic
Silk Skin Color Gray
Operating Temperature Operating from 0°C ~ 48°C
PC LCD TV
Y/Cb/Cr
1
1
2
2
2
2
3
3
3
1. Introduction....................................................................................
2. Main Features................................................................................
3. Hardware Description...................................................................
3.1 Top Panel.................................................................................
3.2 Front Panel...............................................................................
3.3 Rear Panel................................................................................
3.4 Side Panel.................................................................................
4. Connection and Installation.........................................................
5. Specifications.................................................................................
OUTPUT
1
1. Introduction
This is a scan converter box to convert a variety of PC resolutions (from VGA
to UXGA) to TV resolutions (Component Y/Cb/Cr of 480i or 576i). With its
good performance of conversion and flexibility of TV system selection (480i
and 576i), the product becomes an ideal solution to video conference,
home theater, business presentation, lecturing room, and different personal
applications.
2. Main Features
● Convert from PC resolutions to TV resolutions.
● Supports high resolution PC input up to UXGA (1600x1200@60Hz).
● Supports output resolutions: 480i or 576i.
● Easy to carry and simple to install.
2
3. Hardware Description
The following sections describe the hardware components.
3.1. Top Panel
1 Power switch and LED Indicator: When power is turned on the LED will
illuminate in green color. When press power switch once to turn the system
in standby mode and the LED will illuminate in red color.
Note: The factory setting is in power on mode.
3.2. Front Panel 3.3. Rear Panel
1 PC Input: Connect the PC input port to the output port of your computer
(desktop, notebook/laptop, or device providing PC resolution output),
using D-Sub 15-pin cable.
2 Power Supply: Plug the 3.3V DC 1A power supply into the unit and connect
the adaptor to AC wall outlet.
3 Component Output: Connect the component output port to the input port
of your display, using 3 RCA cable.
480 i576 i
1 2
PC
INPUT
DC
3.3 V
3
Cr Cb Y
OUTPUT
1
POWER
PC to Component
3.4. Side Panel
Switch between 480i and 576i resolution output.

2008.3.7 MPM-CPT3861
1. Introduction
This is a scan converter box to convert a variety of PC resolutions (from VGA
to UXGA) to TV resolutions (Component Y/Cb/Cr of 480i or 576i). With its
good performance of conversion and flexibility of TV system selection (480i
and 576i), the product becomes an ideal solution to video conference,
home theater, business presentation, lecturing room, and different personal
applications.
2. Main Features
● Convert from PC resolutions to TV resolutions.
● Supports high resolution PC input up to UXGA (1600x1200@60Hz).
● Supports output resolutions: 480i or 576i.
● Easy to carry and simple to install.
2
3. Hardware Description
The following sections describe the hardware components.
3.1. Top Panel
1 Power switch and LED Indicator: When power is turned on the LED will
illuminate in green color. When press power switch once to turn the system
in standby mode and the LED will illuminate in red color.
Note: The factory setting is in power on mode.
3.2. Front Panel 3.3. Rear Panel
1 PC Input: Connect the PC input port to the output port of your computer
(desktop, notebook/laptop, or device providing PC resolution output),
using D-Sub 15-pin cable.
2 Power Supply: Plug the 3.3V DC 1A power supply into the unit and connect
the adaptor to AC wall outlet.
3 Component Output: Connect the component output port to the input port
of your display, using 3 RCA cable.
480 i576 i
1 2
PC
INPUT
DC
3.3 V
3
Cr Cb Y
OUTPUT
1
POWER
PC to Component
3.4. Side Panel
Switch between 480i and 576i resolution output.

2008.3.7 MPM-CPT386
TABLE OF CONTENTS
1
1
2
2
2
2
3
3
3
1. Introduction....................................................................................
2. Main Features................................................................................
3. Hardware Description...................................................................
3.1 Top Panel.................................................................................
3.2 Front Panel...............................................................................
3.3 Rear Panel................................................................................
3.4 Side Panel.................................................................................
4. Connection and Installation.........................................................
5. Specifications.................................................................................
1
1. Introduction
This is a scan converter box to convert a variety of PC resolutions (from VGA
to UXGA) to TV resolutions (Component Y/Cb/Cr of 480i or 576i). With its
good performance of conversion and flexibility of TV system selection (480i
and 576i), the product becomes an ideal solution to video conference,
home theater, business presentation, lecturing room, and different personal
applications.
2. Main Features
● Convert from PC resolutions to TV resolutions.
● Supports high resolution PC input up to UXGA (1600x1200@60Hz).
● Supports output resolutions: 480i or 576i.
● Easy to carry and simple to install.
2
3. Hardware Description
The following sections describe the hardware components.
3.1. Top Panel
1 Power switch and LED Indicator: When power is turned on the LED will
illuminate in green color. When press power switch once to turn the system
in standby mode and the LED will illuminate in red color.
Note: The factory setting is in power on mode.
3.2. Front Panel 3.3. Rear Panel
1 PC Input: Connect the PC input port to the output port of your computer
(desktop, notebook/laptop, or device providing PC resolution output),
using D-Sub 15-pin cable.
2 Power Supply: Plug the 3.3V DC 1A power supply into the unit and connect
the adaptor to AC wall outlet.
3 Component Output: Connect the component output port to the input port
of your display, using 3 RCA cable.
480 i576 i
1 2
PC
INPUT
DC
3.3 V
3
Cr Cb Y
OUTPUT
1
POWER
PC to Component
3.4. Side Panel
Switch between 480i and 576i resolution output.

2008.3.7 MPM-CPT3861
1. Introduction
This is a scan converter box to convert a variety of PC resolutions (from VGA
to UXGA) to TV resolutions (Component Y/Cb/Cr of 480i or 576i). With its
good performance of conversion and flexibility of TV system selection (480i
and 576i), the product becomes an ideal solution to video conference,
home theater, business presentation, lecturing room, and different personal
applications.
2. Main Features
● Convert from PC resolutions to TV resolutions.
● Supports high resolution PC input up to UXGA (1600x1200@60Hz).
● Supports output resolutions: 480i or 576i.
● Easy to carry and simple to install.

2008.3.7 MPM-CPT3862
3. Hardware Description
The following sections describe the hardware components.
3.1. Top Panel
1 Power switch and LED Indicator: When power is turned on the LED will
illuminate in green color. When press power switch once to turn the system
in standby mode and the LED will illuminate in red color.
Note: The factory setting is in power on mode.
3.2. Front Panel 3.3. Rear Panel
1 PC Input: Connect the PC input port to the output port of your computer
(desktop, notebook/laptop, or device providing PC resolution output),
using D-Sub 15-pin cable.
2 Power Supply: Plug the 3.3V DC 1A power supply into the unit and connect
the adaptor to AC wall outlet.
3 Component Output: Connect the component output port to the input port
of your display, using 3 RCA cable.
1 2
PC
INPUT
DC
3.3 V
3
Cr Cb Y
OUTPUT
1
POWER
PC to Component

3
4. Connection and Installation
5. Specifications
Input resolutions VGA up to 140Hz refresh rate
SVGA up to 120Hz refresh rate
XGA up to 85Hz refresh rate
SXGA up to 60Hz refresh rate
UXGA at 60Hz refresh rate
Output resolutions Component Y/Cb/Cr of 480i or 576i
Input port 1 x D-Sub 15-pin (Female R/G/B/H/V)
Output port Component (3 x RCA jacks)
Power Supply 3.3V/1A DC (US/EU standards, CE/FCC/UL certified)
Dimensions (mm) 100(W) x 64(D) x 18.5(H)
Weight 100g
Chassis Material Plastic
Silk Skin Color Gray
Operating Temperature Operating from 0°C ~ 48°C
PC LCD TV
Y/Cb/Cr
480 i576 i
3.4. Side Panel
Switch between 480i and 576i resolution output.

2008.3.7 MPM-CPT386
TABLE OF CONTENTS
3
4. Connection and Installation
5. Specifications
Input resolutions VGA up to 140Hz refresh rate
SVGA up to 120Hz refresh rate
XGA up to 85Hz refresh rate
SXGA up to 60Hz refresh rate
UXGA at 60Hz refresh rate
Output resolutions Component Y/Cb/Cr of 480i or 576i
Input port 1 x D-Sub 15-pin (Female R/G/B/H/V)
Output port Component (3 x RCA jacks)
Power Supply 3.3V/1A DC (US/EU standards, CE/FCC/UL certified)
Dimensions (mm) 100(W) x 64(D) x 18.5(H)
Weight 100g
Chassis Material Plastic
Silk Skin Color Gray
Operating Temperature Operating from 0°C ~ 48°C
PC LCD TV
Y/Cb/Cr
1
1
2
2
2
2
3
3
3
1. Introduction....................................................................................
2. Main Features................................................................................
3. Hardware Description...................................................................
3.1 Top Panel.................................................................................
3.2 Front Panel...............................................................................
3.3 Rear Panel................................................................................
3.4 Side Panel.................................................................................
4. Connection and Installation.........................................................
5. Specifications.................................................................................
OUTPUT
1
1. Introduction
This is a scan converter box to convert a variety of PC resolutions (from VGA
to UXGA) to TV resolutions (Component Y/Cb/Cr of 480i or 576i). With its
good performance of conversion and flexibility of TV system selection (480i
and 576i), the product becomes an ideal solution to video conference,
home theater, business presentation, lecturing room, and different personal
applications.
2. Main Features
● Convert from PC resolutions to TV resolutions.
● Supports high resolution PC input up to UXGA (1600x1200@60Hz).
● Supports output resolutions: 480i or 576i.
● Easy to carry and simple to install.
2
3. Hardware Description
The following sections describe the hardware components.
3.1. Top Panel
1 Power switch and LED Indicator: When power is turned on the LED will
illuminate in green color. When press power switch once to turn the system
in standby mode and the LED will illuminate in red color.
Note: The factory setting is in power on mode.
3.2. Front Panel 3.3. Rear Panel
1 PC Input: Connect the PC input port to the output port of your computer
(desktop, notebook/laptop, or device providing PC resolution output),
using D-Sub 15-pin cable.
2 Power Supply: Plug the 3.3V DC 1A power supply into the unit and connect
the adaptor to AC wall outlet.
3 Component Output: Connect the component output port to the input port
of your display, using 3 RCA cable.
480 i576 i
1 2
PC
INPUT
DC
3.3 V
3
Cr Cb Y
OUTPUT
1
POWER
PC to Component
3.4. Side Panel
Switch between 480i and 576i resolution output.

Home page: http://www.cypress.com.tw
CYPRESS TECHNOLOGY CO., LTD.
2008.3.7 MPM-CPT386
TABLE OF CONTENTS
3
4. Connection and Installation
5. Specifications
Input resolutions VGA up to 140Hz refresh rate
SVGA up to 120Hz refresh rate
XGA up to 85Hz refresh rate
SXGA up to 60Hz refresh rate
UXGA at 60Hz refresh rate
Output resolutions Component Y/Cb/Cr of 480i or 576i
Input port 1 x D-Sub 15-pin (Female R/G/B/H/V)
Output port Component (3 x RCA jacks)
Power Supply 3.3V/1A DC (US/EU standards, CE/FCC/UL certified)
Dimensions (mm) 100(W) x 64(D) x 18.5(H)
Weight 100g
Chassis Material Plastic
Silk Skin Color Gray
Operating Temperature Operating from 0°C ~ 48°C
PC LCD TV
Y/Cb/Cr
1
1
2
2
2
2
3
3
3
1. Introduction....................................................................................
2. Main Features................................................................................
3. Hardware Description...................................................................
3.1 Top Panel.................................................................................
3.2 Front Panel...............................................................................
3.3 Rear Panel................................................................................
3.4 Side Panel.................................................................................
4. Connection and Installation.........................................................
5. Specifications.................................................................................
OUTPUT
1
1. Introduction
This is a scan converter box to convert a variety of PC resolutions (from VGA
to UXGA) to TV resolutions (Component Y/Cb/Cr of 480i or 576i). With its
good performance of conversion and flexibility of TV system selection (480i
and 576i), the product becomes an ideal solution to video conference,
home theater, business presentation, lecturing room, and different personal
applications.
2. Main Features
● Convert from PC resolutions to TV resolutions.
● Supports high resolution PC input up to UXGA (1600x1200@60Hz).
● Supports output resolutions: 480i or 576i.
● Easy to carry and simple to install.
2
3. Hardware Description
The following sections describe the hardware components.
3.1. Top Panel
1 Power switch and LED Indicator: When power is turned on the LED will
illuminate in green color. When press power switch once to turn the system
in standby mode and the LED will illuminate in red color.
Note: The factory setting is in power on mode.
3.2. Front Panel 3.3. Rear Panel
1 PC Input: Connect the PC input port to the output port of your computer
(desktop, notebook/laptop, or device providing PC resolution output),
using D-Sub 15-pin cable.
2 Power Supply: Plug the 3.3V DC 1A power supply into the unit and connect
the adaptor to AC wall outlet.
3 Component Output: Connect the component output port to the input port
of your display, using 3 RCA cable.
480 i576 i
1 2
PC
INPUT
DC
3.3 V
3
Cr Cb Y
OUTPUT
1
POWER
PC to Component
3.4. Side Panel
Switch between 480i and 576i resolution output.
