EZ-BTTM MODULE PROGRAMMING KIT
CYBT-343026-PROG
The EZ-BTTM Module Programming Kit (CYBT-343026-PROG)
enables you to easily program the following EZ-BTTM WICED
modules prior to manufacturing: CYBT-343026-01 and
CYBT-343151-02.
The life time of the socket used in this programming kit is
50,000 insertions.
For more information, visit:
www.cypress.com/products/ez-ble-and-ez-bt-bluetooth-modules - EZ-BT Module home pages
http://www.cypress.com/WICEDModuleProgrammerUserGuide -
WICED Module Programmer User Guide – KBA225060
www.cypress.com/EZ-Serial - EZ-Serial Firmware Platform page
www.cypress.com/WICED - WICED SDK page
Figure 1: CYBT-343026-PROG Top View
P5LP PROG Header
USB Connector
BT Module

© 2019 Cypress Semiconductor Corporation. All rights
reserved. All trademarks or registered trademarks referenced herein
are the properties of their respective owners. 002-26067 Rev.**
EZ-BTTM MODULE PROGRAMMING KIT
CYBT-343026-PROG
Visit www.cypress.com/support for technical support.
To use the CYBT-343026-PROG:
1) Put the BLE module in the socket (ensure that the BLE module is in the correct position
of the socket, as shown below)
2) Connect the programming device with a USB cable to a computer that has been installed
with WICED Module Programmer (www.cypress.com/WICEDModuleProgrammer)
3) Run the programming software to program the targeted BLE module with your
selected rmware.
Figure 2: Module in the socket
