D-Link DCS- User manual

CONFIGURATION GUIDE
For DCS Series Cameras
www. d l i n k.co.in

ACCESSING DEVICE
CONFIGUTING INTERNET
Configuration Guide
for DCS series cameras

HOW TO ACCESS THE DEVICE:-
3.
I.
Connect the Ethernet cable in
Ethernet Port of camera from your
router. LED should be steady /
stable Green.
2. Connect the power adaptor to
device and power on the device.
Power LED should be RED.
1. Unbox the Camera.
OR
Camera can be connected wirelessly
to your router, for that you have to
follow below steps as shown below.
Connect camera to PC via Ethernet
cable assign Static IP address to
PC LAN Card.
Properties

Go to Setup > Wireless Setup
Connection mode is Infrastructure.
Click on Enable Wireless > Select
Site Survey
HOW TO ACCESS THE DEVICE:-
II.
III.
Then access camera WEB GUI
using default settings. IP Address:
192.168.0.20 User Name: admin
Password: blank

IV.
V.
Select your SSID from the list and
click on Select.
Select Wireless Security Mode
same as your wireless router and
then put the password/Security
of your wireless router Key then
click save settings.
VI. You can check wireless connectivity
status in the status page.
HOW TO ACCESS THE DEVICE:-

5. If you don’t have Wi-Fi enabled
computer then you can connect
the lan cable provided in the box
between any LAN port of the
router and computer LAN port.
6. Run the Camera utility from product
CD. It will guide you through the setup.
HOW TO CONFIGURE THE INTERNET:-
4. If you have the computer with wi-fi
then, go to wireless utility to display
available Wireless networks and select
the Wi-Fi name of device to connect.
(By default Wi-Fi name is DLink). By
default there is no security/ password
for this network.

7. It will check for the required
activex on your PC
8. Select No and click Next.
9. Click Next.
HOW TO CONFIGURE THE INTERNET:-

10. Click Next if the connections are
done as per the image.
HOW TO CONFIGURE THE INTERNET:-
HOW TO CONFIGURE THE INTERNET:-
11. If the LED is green, click Yes.

12. The setup will detect the camera
with the IP address. Click Next. If
not detected then kindly check
the connectivity and then retry.
If there is no password set for camera,
you have to set it when below
window appears and click Next.
HOW TO CONFIGURE THE INTERNET:-
HOW TO CONFIGURE THE INTERNET:-
Select Wired if camera is connected
through Ethernet cable to router.
OR
Select wireless if camera is connected
through wirelessly to router.
13.

HOW TO CONFIGURE THE INTERNET:-
HOW TO CONFIGURE THE INTERNET:-
If you already have a mydlink
account, then select Yes. If you
don’t have, select No and register
for same.
If you have registered MyDlink
account then put username and
password. For Ex: Username:
[email protected]
Password: *******
14.
You are ready to view the camera
from MyDlink website. Click Finish
to exit the wizard.
Click on Visit mydlink now to visit
the site.
15.

HOW TO CONFIGURE THE INTERNET:-
HOW TO CONFIGURE THE INTERNET:-
This will prompt for username and
password to login into the account.
16.
For first time it will ask to update the
firmware. By clicking on Update now
you can update the firmware.
By selecting camera you can view
the video.
17.
