D-link Dap-1320 User manual

DAP-1320

300

Wireless Range Extender

Delivering up to 300Mbps

wireless performance

Extend the range of your

existing wireless network

Easy setup with the touch

of a button

Ideal for hard to reach locations – basements,

upstairs bedrooms and outdoor areas

Universally works with any wireless router brand5

Ideal for mobile device connections – reduce

3G/4G mobile data usage by connecting to your

home Wi-Fi

Product Hightlights Eortlessly extend coverage of your home network

TheWireless Range Extender (DAP-1320) extends your existing wireless network coverage

with the push of a button, delivering up to 300Mbps for whole-home coverage. Ideal for

hard-to-reach areas like basements, upstairs bedrooms or outdoor areas, the compact

Wireless Range Extender gives you performance where you need it most.

Why D-Link Wireless N Is Better

This Wireless N Range Extender uses Wireless N technology with multiple intelligent

antennas to maximize the speed and range of your wireless signal to signicantly

outperform previous-generation Wireless G devices1. The antennas make use of your

home’s environment by bouncing multiple wireless signals o walls and ceilings to work

around obstructions and help eliminate dead spots.

DAP-1320 Wireless Range Extender

Package Contents

• WirelessRangeExtender(DAP-1320)

• QuickInstallGuide4

• Wi-FiCongurationNote

Web Browser Setup Requirements

• InternetExplorerv6orhigher,MozillaFirefox,

Google chrome or Safari

Features

• IEEE802.11nand802.11gCompliant

• ExtendInternetaccessforwirelessdevicessuchas

laptops, Smartphones, tablets and more

• SupportsSecureWirelessEncryptionUsingWPA™

 orWPA2™Security

• Wi-FiProtectedSetup™(WPS)PushButton

• 24/7BasicInstallationSupport2

• 1-YearLimitedWarranty3

Step 1:

Press the WPS button

on your router.

Step 2:

Press and hold WPS button

on Wireless Range Extender

until the LED indicator start

ashing and then release.

You’re successfully connected!

Step 3:

Works with any Wi-Fi device5

Extended Range

DAP-1320

Wireless Range Extender

After

Before

Extend your network to cover hard-to-reach areas of your home

Place the Wireless Range Extender (DAP-1320) between your wireless router and your wireless

devices to create wall-to-wall coverage while eliminating dead zones

Easy Push Button Setup

Existing wireless network Extended wireless network

©2012 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link, the D-Link logo, RangeBooster N, and the D-Link RoHS logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries in the

United States and/or other countries. Other trademarks or registered trademarks are the property of their respective owners.

Updated 9/24/12

DAP-1320 Wireless Range Extender

Building Networks for People

Technical Specications

Standards

• IEEE802.11n

• IEEE802.11g

Antenna Type

• 2InternalAntennas

Security

• Wi-FiProtectedAccess(WPA,WPA2)®

• Wi-FiProtectedSetup™(WPS)

Device Management

• WebUI

• InternetExplorer®v6orhigher

• Mozilla®Firefox®

• GoogleChrome

• Safari

LEDs

• Power/Status

Certications

• FCC

• Wi-Fi®

Dimensions

• 1.89”x1.65”x2.11”

 (4.8x4.19x5.36cm)

Weight

• 0.152lb(68.94g)

Warranty

• 1-YearLimited3

1 MaximumwirelesssignalratederivedfromIEEEStandard802.11gand802.11nspecications.Actualdatathroughputwillvary.Networkconditionsandenvironmentalfactors,includingvolumeofnetworktrac,buildingmaterialsand

 construction,andnetworkoverhead,loweractualdatathroughputrate.Environmentalfactorswilladverselyaectwirelesssignalrange.WirelessrangeandspeedratesareD-LinkRELATIVEperformancemeasurementsbasedonthe

 wirelessrangeandspeedratesofastandardWirelessGproductfromD-Link.MaximumthroughputbasedonD-Link802.11ndevices.

2 24/7BasicInstallationSupportisavailableonlyintheUSAfortherst30daysfromdateoforiginalpurchase.

3 1-YearLimitedWarrantyavailableonlyintheU.S.AandCanada.

4 Latestsoftwareanddocumentationareavailableathttp://support.dlink.com.

5 CompliantwithIEEE802.11g/nwirelessRouter/AP.

All references to speed are for comparison purposes only. Product specications, size and shape are subject to change without notice, and actual product appearance may dier from that depicted herein. See inside package for warranty details.

LEDIndicator
