D-link Voip wireless router dvg-g5402sp User manual

DVG-G5402SP

Wireless VoIP Gateway

User’s Manual

Version 1.0

(31 May 2007)

Reproduction in any manner whatsoever without the written permission of D-Link Corporation is strictly forbidden.

Trademarks used in this text: D-Link and the D-Link logo are trademarks of D-Link Corporation/D-Link Systems

Inc.; Other trademarks and trade names may be used in this document to refer to either the entities claiming the

marks and names or their products. D-Link Corporation disclaims any proprietary interest in trademarks and trade

names other than its own.

Warranty: please contact your D-Link Authorized Reseller or the D-Link Branch Office nearest your place of

purchase for information about the warranty offered on your D-Link product.

Information in this document is subject to change without notice.

FCC Warning

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15

of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio communication. However,

there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off and on, the user

is encouraged to try to correct the interference by one or more of the following measures:

‧Reorient or relocate the receiving antenna.

‧Increase the separation between the equipment and receiver.

‧Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

‧Consult the dealer or an experienced radio/TV technician for help.

CE Mark Warning

This is a Class B product. In a domestic environment, this product may cause radio interference in which case the

user may be required to take adequate measures.

Warnung!

Dies ist ein Produkt der Klasse B. Im Wohnbereich kann dieses Produkt Funkstoerungen verursachen. In diesem

Fall kann vom Benutzer verlangt werden, angemessene Massnahmen zu ergreifen.

Precaución!

Este es un producto de Clase B. En un entorno doméstico, puede causar interferencias de radio, en cuyo case, puede

requerirse al usuario para que adopte las medidas adecuadas.

Attention!

Ceci est un produit de classe B. Dans un environnement domestique, ce produit pourrait causer des interférences

radio, auquel cas l`utilisateur devrait prendre les mesures adéquates.

Attenzione!

Il presente prodotto appartiene alla classe B. Se utilizzato in ambiente domestico il prodotto può causare interferenze

radio, nel cui caso è possibile che l`utente debba assumere provvedimenti adeguati.

Contents

1. Introduction .............................................................................................................................................4

1-1 Product Overview ............................................................................................................................4

1-2 Hardware Description......................................................................................................................5

2. Gateway Configuration – Use Web Browser........................................................................................7

2-1 SETUP.............................................................................................................................................8

2-1-1 WAN Settings........................................................................................................................8

2-1-2 LAN Settings ....................................................................................................................... 11

2-1-3 Wireless Settings ................................................................................................................13

2-1-4 VoIP Settings (SIP Basically setting)...................................................................................21

2-1-5 Time and Date (NTP)..........................................................................................................25

2-2 ADVANCED...................................................................................................................................26

2-2-1 Firewall Settings..................................................................................................................29

2-2-2 NAT Traversal......................................................................................................................36

2-2-3 VOIP....................................................................................................................................37

2-3 MAINTENANCE.............................................................................................................................58

2-3-1 Firmware Upgrade ..............................................................................................................58

2-3-2 Login Account......................................................................................................................59

2-3-3 Ping Test..............................................................................................................................60

2-3-4 System ................................................................................................................................61

2-3-5 System Log .........................................................................................................................62

2-3-6 Provision Settings ...............................................................................................................63

2-4 STATUS.........................................................................................................................................65

2-4-1 Current Status .....................................................................................................................65

2-4-2 System Information.............................................................................................................66

2-4-3 RTP Packet Summary.........................................................................................................67

2-4-4 Logout .................................................................................................................................67

3. Configuring the Gateway through IVR................................................................................................68

3-1 IVR (Interactive Voice Response) .................................................................................................68

3-1-1 IVR Functions Table:...........................................................................................................70

3-2 IP Configuration Settings—Set the IP Configuration of the WAN Port..........................................71

3-2-1 PPPoE Character Conversion Table:..................................................................................73

4. Dialing Principles..................................................................................................................................74

4-1 Dialing Options ..............................................................................................................................74

4-2 Dialed Number Processing Flow...................................................................................................74

Appendix....................................................................................................................................................76

Product Features .................................................................................................................................76

DVG-G5402SP User’s Manual Product Overview

D-Link Systems, Inc. 4

1. Introduction

1-1 Product Overview

The DVG-G5402SP Wireless VoIP Gateway is designed to carry both voice and facsimile over the IP network and

wirelessly share Internet access. It uses the industry standard SIP call control protocol so as to be compatible

with free registration services or VoIP service providers’ systems. As a standard user agent, it is compatible with

all common Soft Switches and SIP proxy servers. While running optional server software, the gateway can be

configured to establish a private VoIP network over the Internet without a third-party SIP Proxy Server.

The gateway can be seamlessly integrated into an existing network by connecting to a phone set and fax

machine. With only a broadband connection such as an ADSL bridge/router, a Cable Modem or a leased-line

router, the gateway allows you to use voice and fax services over IPin order to reduce the cost of all long distance

calls.

The DVG-G5402SP is also an 802.11b/g wireless access point. Allow wireless clients to connect to it and share

your broadband Internet connection. A built-in 4-port switch makes it possible to connect up to 4 Ethernet-enabled

computers or devices to also share your Internet connection.

The wireless voip gateway can be configured a fixed IP address or it can have one dynamically assigned by

DHCP over PPPoE. It adopts either the G.711, G.726, G.729A or G.723.1 voice compression format to save

network bandwidth while providing real-time, toll quality voice transmission and reception.

DVG-G5402SP User’s Manual Telephone Interface Description

D-Link Systems, Inc. 5

1-2 Hardware Description

Front Panel

Power: Power LED. A steady light indicates a proper connection to a power source.

Prov./Alm.: A blinking light indicates the gateway is attempting to connect with the Provisioning server.

Once the service connects, the LED will turn off. The LED will light solid if the self-test or boot-up fails.

LED will turn off if not connected to a service provider.

WAN: When a connection is established the 10 or 100 LED will light up solid. The LED will blink to indicate

WLAN: A steady light indicates a wireless connection. A blinking light indicates that the DVG-G5402SP is

receiving/transmitting from/to the wireless network.

LAN: When a connection is established the 10 or 100 LED (bottom) will light up solid on the appropriate

port. The LEDs will blink to indicate activity. If the 10 or 100 LED does not light up when a cable is

connected, verify the cable connections and make sure your devices are powered on.

Phone: This LED displays the VoIP status and Hook/Ringing activity on the phone port that is used to

connect your normal telephone(s). If a phone connected to a phone port is off the hook or in use, this LED

will light solid. When a phone is ringing, the indicator will blink.

Line: Light on means the line is in use (off-hook), and vice versa.

DVG-G5402SP User’s Manual Telephone Interface Description

D-Link Systems, Inc. 6

Rear Panel

1. Line: Connect to your original telephone line on the wall jack with RJ-11 cable.

2. Phone Port (1-2): Connect to your phones using standard phone cabling (RJ-11).

3. LAN: Connect to your Ethernet enabled computers using Ethernet cabling.

4. WAN: Connect to your broadband modem using an Ethernet cable.

5. Power Receptor: Receptor for the provided power adapter.

6. Ground: A conducting connection with the earth Connect with the ground so as to make the earth a

part of an electrical circuit using metal wire.

7. Antenna: Connect to a wireless network.

WARNING: DO NOT (1) connect the phone ports to each other (FXS to FXS) or (2) connect any

phone port directly to a PSTN line (FXS to PSTN) or to an internal PBX line (FXS to PBX extension).

Doing so may damage your VoIP gateway.

Use Reset Button to restore factory default settings (IP address, Login ID and Password):

1. Disconnect the power plug.

2. Press and hold the reset button for 6 seconds.

3. Reconnect the power plug while pressing down on the reset button.

4. Release the reset button after 6 seconds. Factory settings will be restored.

DVG-G5402SP2 User’s Manual Gateway Configuration-Web Browser

D-Link Systems, Inc. 7

2. Gateway Configuration – Use Web Browser

The VoIP gateway allows users to configure its settings using a web interface (Web UI). You can access the

Configuration Menu by opening a web-browser (e.g., Internet Explorer or Netscape Navigator) and entering the

factory default LAN IP address: 192.168.8.254. The IP address of the Web UI is same as the default LAN IP

noted elsewhere in this user’s manual.

You can also use an ordinary telephone, connect it to the gateway, and dial ”101” to inquire about the current

WAN Port IP address and then use the WAN port to log-in.

Instructions

1. Open a Web-Browser (e.g., Explorer, Navigator, Opera, Firefox).

2. Enter the LAN port IP address. The default LAN port IP address is: 192.168.8.254.

3. The log-in screen below will appear after you connect. (The factory default settings for Login ID and

Password are blank (i.e., no login ID, no password).)

The gateway does not allow multiple people to configure the gateway simultaneously. Please remember to

logout or restart the system if you are not using the web configuration function.

DVG-G5402SP User’s Manual SETUP

D-Link Systems, Inc. 8

2-1 SETUP

2-1-1 WAN Settings

WAN (Wide Area Network) Settings are settings that are used to connect to your ISP (Internet Service

Provider). The WAN settings are provided to you by your ISP and often times referred to as "public settings".

Please select the appropriate option for your specific ISP.

IP Configuration (Setting WAN Port)

There are five methods of obtaining a WAN port IP address:

1. Static IP

2. DHCP, which means a Dynamic IP (Cable Modem)

3. PPPoE (dial-up ADSL)

4. PPTP

5. BigPond (for Australia only)

Methods for using DHCP and PPPoE for obtaining an IP address may vary. If you are not familiar with

creating a network connection, please contact your local ISP.

After selecting the suitable option, click Accept at the bottom of the screen to save the settings.

You need to save the changes and restart the gateway to make the changes active. Saving the settings:

Click MAINTENANCE and select Save/Restart in System from the left menu. Tick Save Settings and

Restart, then click Accept. Wait for about 40 seconds before the gateway obtaining an IP address by the

method you selected.

Note: When the system has obtained a new IP address, and you are using a WAN port to enter the Web

Configuration Screen, the new IP address has to be used before you can get connected to the gateway.

The same principle applies to the next two settings.

DVG-G5402SP User’s Manual SETUP

D-Link Systems, Inc. 9

SETUP →WAN SETTINGS

DHCP: Select this option if your ISP (Internet Service Provider) provides you an IP address automatically.

Cable modem providers typically use dynamic assignment of IPAddress. The Host Name field is optional

but may be required by some Internet Service Providers.

Static IP: Select this option if your ISP (Internet Service Provider) provides you a Static IP address. Enter

the IP address, Subnet Mask and Default Gateway IP.

PPPoE: Select this option if your ISP requires you to use a PPPoE (Point-to-Point Protocol over Ethernet)

connection. Enter the PPPoE Account, PPPoE Password and re-enter Password to confirm.

PPTP: Point-to-Point Tunneling Protocol (PPTP) is a WAN connection. Enter the IP Address, Subnet

mask, PPTP Server, PPTP ID and Password.

BigPond: Dynamic IP Address for BigPond is a WAN connection used in Australia. Enter the username

and password for the BigPond account and the login server if required.

DVG-G5402SP User’s Manual SETUP

D-Link Systems, Inc. 10

Domain Name Server Assignment: Select Auto or Manual to get the IP address of Domain Name Server

assigned by ISP or manually.

Domain Name Server IP: Enter the primary and secondary IP address of Domain Name Server if Domain

Name Server Assignment is Manual. Otherwise, the gateway will not be able to access hosts using

hostnames instead of IPs.

SETUP →WAN SETTINGS

QoS: Check the box to guaranty the voice quality. Voice packets have the highest priority in IP networks,

and the data transmission is distributed to less bandwidth.

Downstream Bandwidth - Select the downstream bandwidth that is the same as the actual bandwidth

subscribed from the drop-down menu.

Upstream Bandwidth - Select the upstream bandwidth that is the same as the actual bandwidth

subscribed from the drop-down menu.

ToS IP Precedence: Select the precedence for signaling (data) and voice (voice data) from the drop-down

menu.

DiffServ (DSCP): Select the number of signaling (data) and voice (voice data) values for priority marking

from the drop-down menu.

Note: For the gateway, ToS IP Precedence and DiffServ are the same function. You only select one for

priority marking.

SETUP →WAN SETTINGS

DVG-G5402SP User’s Manual SETUP

D-Link Systems, Inc. 11

Factory Default MAC Address: The original MAC address of the gateway.

Your MAC Address: It is left blank as you log-in via the WAN port.

Current MAC Address: It shows the current MAC Address if you ever used the difference MAC address

from Factory Default MAC Address. You can click Clone to automatically copy the MAC address of the

Ethernet Card installed in the computer used to configure the device.

Note: This is only necessary to fill the field if required by your ISP.

2-1-2 LAN Settings

SETUP →LAN SETTINGS

LAN Interface Mode: Select the gateway serving as a Router with NAT or Bridge between WAN port and

LAN port without NAT.

Note: It is still accessible if LAN Interface Mode is Bridge.

SETUP →LAN SETTINGS

LAN IP / LAN default gateway: Enter the LAN IP address of the gateway. It is also the default gateway for

DHCP clients.

Subnet make: Enter the subnet mask for DHCP clients.

Enable DHCP Server: This variable is to assign the IP address for the devices connected to LAN port of

the gateway.

DVG-G5402SP User’s Manual SETUP

D-Link Systems, Inc. 12

IP Pool Starting Address: Enter the starting IP address for the DHCP server's IP assignment.

IP Pool Ending Address: Enter the ending IP address for the DHCP server's IP assignment.

IP Pool Uses Other Default Gw: Check the box to assign different default gateway for DHCP clients.

IP Pool Default Gateway: Enter the new default gateway that is different from LAN IP of the gateway.

IP Pool Subnet mask: Enter the new subnet mask.

Lease Time: Enter the length of time for the IP lease.

Domain Name Server Assignment: Select Auto or Manual to get the IP address of Domain Name Server

assigned by ISP or manually.

Domain Name Server IP: Enter the primary and secondary IP address of Domain Name Server if Domain

Name Server Assignment is Manual. Otherwise, the gateway will not be able to access hosts using

hostnames instead of IPs.

SETUP →LAN SETTINGS

Enable LAN QoS: Check the box to enable LAN QoS by Hardware.

Priority: Use the drop-down menu to select Low or High for the gateway to deliver the packets from LAN

interface when the packets arrive at the same time.

Flow Control: Check the box to limit incoming and outgoing rate if ticked.

Incoming Rate Limit: Use the drop-down menu to select the proper rate limit for the specific LAN port. The

flow is from LAN to WAN, and the rate limit can not exceed the real upstream bandwidth.

Outgoing Rate Limit: Use the drop-down menu to select the proper rate limit for the specific LAN port. The

flow is from WAN to LAN, and the rate limit can not exceed the real downstream bandwidth.

DVG-G5402SP User’s Manual SETUP

D-Link Systems, Inc. 13

2-1-3 Wireless Settings

This section instructs you how to setup your wireless network on the Gateway device.

Setup Hint:

1. Every device in the same wireless network must use the same SSID.

2. To avoid wireless network overlap, a specific and different channel is needed.

3. Make sure security used by every device in the same wireless network is compatible with the wireless

AP.

2-1-3-1 Basic Settings

Wireless Settings →Basic Settings

Enable Wireless LAN Interface: Enable wireless basic settings on LAN interface.

Band: The Gateway can operate in 2.4GHz ISM band with different speed of wireless connection, Select

the wireless band of your network.

2.4GHz (B) - Allow all 802.11B compliant wireless devices to associate with the wireless AP.

2.4HGz (G) - Allow all 802.11G compliant wireless devices to associate with the wireless AP.

2.4GHz (B+G) - Allow a mix of both IEEE802.11b and IEEE802.11g compliant wireless devices to

associate with the wireless AP.

Associated Clients: Click on Show Active Clients button, you can see all clients associated to the AP.

SSID: SSID is the name of your wireless network. All wireless-equipped devices share the same SSID to

communicate with each other. It must be unique to identify separated wireless network. For security, you

should change the default SSID to a special ID.

Channel Number: Select a clear and appropriate channel for your wireless network. A device on your

wireless network must use a specific channel to transmit and receive data. If wireless network has overlap,

change a different channel number.

DVG-G5402SP User’s Manual SETUP

D-Link Systems, Inc. 14

2-1-3-2 Advanced

This section introduces advanced configuration for the wireless access point. If you are not familiar with the

following functions, keep the default parameters. In some cases, incorrect settings may reduce wireless

performance.

Wireless Settings →Advanced

Authentication Type: Select the type of authentication.

Open System - Any wireless client can associate with the wireless access point but the client must

have the same WEP key to exchange data.

Shared Key - Wireless clients must have the same WEP key to associate with wireless access point

and exchange data.

Auto – Auto-detect the authentication type.

Fragmentation: A packet can be fragmented into small units to pass over a network medium that can not

support the original packet size. If you encounter a busy network, a lower value of Fragment Threshold

could improve performance. If the traffic flows are not very busy, a higher Fragment Threshold provides

good network performance. In most case, keeping the default value=2346 is recommended.

RTS Threshold: RTS Threshold is a mechanism to implement in collision avoidance. In a large wireless

network, two stations do not hear each other but can hear wireless access point. When the two send data

to Access Point at the same time, it may result in data collision and a loss of messages for both wireless

stations. In most case, keeping the default value=2347 is recommended.

Beacon Interval: The default value is 100. The Beacon Interval indicates the frequency interval of target

beacon transmission time which can be found in a packet body. The Gateway transmits the beacon packet

to help a wireless client to identify the existence of nearby access point. If the beacon intervals are too long,

it would be hard to access the network. If the beacon intervals are too short, the resources would be

wasted.

DVG-G5402SP User’s Manual SETUP

D-Link Systems, Inc. 15

Data Rate: IEEE802.11b supports Auto, 1, 2, 5.5, 11 Mbps signaling rate. EEE802.11g supports Auto, 6, 9,

12, 18, 24, 36, 48, 54 Mbps signaling rate. The data rate will change automatically to get better throughput

depending on range and environment of the wireless network.

Preamble Type: Preamble Type defines the length of the preamble which sends out with a packet format.

Specify an appropriate preamble type for your network, if you do not know which one to select, keeping the

default setting Long Preamble is recommended.

Broadcast SSID: Disable the SSID broadcast. This is to prevent users from seeing your wireless network.

IAPP: IAPP (Inter Access Point Protocol) provides the communication among access points in order to

support mobile station roaming mechanism from one access point to another.

802.11g Protection: In 802.11b/g Mixed mode, it can be used for protection mechanism. The 802.11g

OFDM traffic can keep the connection stable and avoid 802.11b interference. But that might cause the poor

throughput.

RF Output Power: You can adjust the percentage of power 100, 50, 25, 10, 5 of your Gateway to change

the coverage of wireless network. Keep the default value, 100% to reach full range.

Turbo Mode: The AP would identify the wireless station’s chipset to improve the performance.

2-1-3-3 Security Settings

This section introduces you different ways of wireless security you can setup. It is important to enable

secure algorithm to protect your data from eavesdropping by unauthorized wireless users.

Wireless Settings →Security Settings

Encryption: Select the encryption/authentication type: None, WEP, WPA, WPA2 and WPA2 Mixed.

DVG-G5402SP User’s Manual SETUP

D-Link Systems, Inc. 16

Wireless Settings →Security Settings (WEP)

Key Length: Select 64-bit or 128-bit data encryption.

Default Tx Key: You can select one of the keys as active key at a time.

WEP Key Format: Select the preferred WEP Key Format according to which WEP encryption you choose.

When WEP 64bits is enabled, you can select ASCII (5 characters) and Hex (10 characters). When WEP

128bits is enabled, you can select ASCII (13 characters) and Hex (26 characters).

WEP Encryption Key 1 – 4: You can manually input key value from Key1 to Key4. Type a character sting

and apply changes.

For a 64-bit WEP key-- Enter 5 characters (ASCII sting) or 10 hexadecimal characters (“0-9”, “A-F”).

For a 128-bit WEP key-- Enter 13 characters (ASCII sting) or 26 hexadecimal characters (“0-9”, “A-F”).

DVG-G5402SP User’s Manual SETUP

D-Link Systems, Inc. 17

Wireless Settings →Security Settings (WEP)

Use 802.1x Authentication: Enable or disable using 802.1x Authentication.

Authentication RADIUS Server:

Port - Enter the port number of the authentication RADIUS server. Keep the default value: 1812 unless

the server required change to another number.

IP address - Enter the IP address of the authentication RADIUS server.

Password - Enter a password as the key of the communication between the authentication server and

the access point. The password of the access point must be the same with that of the authentication

sever.

WPA Authentication Mode

The wireless network can use WPA Authentication to verify whether a wireless device is allowed to access

your Access Point or not. You can choose to use Enterprise (RADIUS) method or Personal (Pre-Shared

Key). The encryption mechanism used for RADIUS and WPA-PSK is the same. The difference between the

two is that WPA-PSK uses a specific characters sting like password instead of a user-authentication.

DVG-G5402SP User’s Manual SETUP

D-Link Systems, Inc. 18

Wireless Settings →Security Settings (WPA)

Select the type of WPA (WPA, WPA2, WPA2 Mixed), choose the proper security mode according to your

wireless network.

WPA Cipher Suite: WPA Cipher Suite is used for the configuration of WPA or WPA2 Mixed.

TKIP - TKIP is the security protocol used in WPA. The length of TKIP encryption is longer than WEP

encryption that increases the complexity of decoding for crackers.

AES - The most powerful encryption algorithm that is commonly used in WPA.

WPA2 Cipher Suite: WPA2 Cipher Suite is used for the configuration of WPA2 or WPA2 Mixed.

TKIP - TKIP is the security protocol used in WPA. The length of TKIP encryption is longer than WEP

encryption that increases the complexity of decoding for crackers.

AES - The most powerful encryption algorithm that is commonly used in WPA.

Enable Pre-Authentication: To use pre-authentication before actually associating with a new AP.

Authentication RADIUS Server:

Port - Enter the port number of the authentication RADIUS server. Keep the default value: 1812 unless

the server required change to another number.

IP address - Enter the IP address of the authentication RADIUS server.

Password - Enter the password such as a security Key.

DVG-G5402SP User’s Manual SETUP

D-Link Systems, Inc. 19

Wireless Settings →Security Settings (WPA-PSK)

Select the type of WPA-PSK (WPA-PSK, WPA2-PSK, WPA2 Mixed-PSK), choose the proper security

mode according to your wireless network.
