D-Link DAP-1360 User manual

User Manual
DAP-1360
Wireless N300 Access Point & Router
September 2014

DAP-1360 Wireless N300 Access Point & Router
User Manual
Contents
Chapter 1. Introduction..........................................5
Contents and Audience.......................................................5
Conventions.................................................................5
Document Structure..........................................................5
Chapter 2. Overview..............................................6
General Information.........................................................6
Specifications..............................................................
Product Appearance.........................................................10
Front Panel..............................................................10
Back Panel...............................................................11
Delivery Package...........................................................12
Chapter 3. Installation and Connection..........................13
Before You Begin...........................................................13
Connecting to PC...........................................................14
PC with Ethernet Adapter.................................................14
Configuring IP Address in O Windows XP..................................14
Configuring IP Address in O Windows 7...................................17
PC with Wi-Fi Adapter....................................................22
Configuring Wi-Fi Adapter in O Windows XP...............................23
Configuring Wi-Fi Adapter in O Windows 7................................25
Connecting to Web-based Interface..........................................28
Web-based Interface Structure..............................................29
Access Point Mode........................................................30
Router Mode..............................................................32
Notifications and ystem Drop-down Menu..................................34
Device Operation Modes.....................................................36
Access Point Mode........................................................36
Router Mode..............................................................36
Chapter 4. Configuring Device (Access Point Mode)...............3
Wireless Network Settings Wizard...........................................3
Access Point Mode........................................................38
Repeater Mode............................................................40
Client Mode..............................................................43
Status.....................................................................45
Network tatistics.......................................................45
DHCP.....................................................................46
Clients..................................................................47
Net........................................................................48
LAN......................................................................48
Wi-Fi......................................................................51
Basic ettings...........................................................51
ecurity ettings........................................................53
MAC Filter...............................................................59
List of Wi-Fi Clients....................................................61
WP ......................................................................62
Using WPS Function via Web-based Interface.............................64
Using WPS Function without Web-based Interface.........................64
WD ......................................................................66
Additional ettings......................................................68
WMM......................................................................70
Client...................................................................72
Page 2 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual
Advanced................................................................... 6
DN ......................................................................76
System.....................................................................
Administrator Password...................................................78
Configuration............................................................79
ystem Log...............................................................81
Firmware Upgrade.........................................................83
Local Update........................................................... 4
Remote Update.......................................................... 5
ystem Time..............................................................86
Ping.....................................................................87
Traceroute...............................................................88
Telnet...................................................................89
Device mode..............................................................90
Chapter 5. Configuring Device (Router Mode).....................91
Monitoring.................................................................91
Click'n'Connect............................................................95
Creating WAN Connection..................................................97
PPPoE Connection.......................................................97
Static IP Connection..................................................102
Dynamic IP Connection.................................................106
Static IP + PPPoE Connection..........................................110
Dynamic IP + PPPoE Connection.........................................119
PPTP + Static IP or L2TP + Static IP Connection.......................127
PPTP + Dynamic IP or L2TP + Dynamic IP Connection.....................136
Checking Internet Availability..........................................144
Configuring Wireless Connection.........................................145
Access Point Mode.....................................................146
Repeater Mode.........................................................14
Client Mode...........................................................151
Wireless Network Settings Wizard..........................................153
Access Point Mode.......................................................154
Repeater Mode...........................................................156
Client Mode.............................................................159
Virtual Server Settings Wizard............................................161
Status....................................................................163
Network tatistics......................................................163
DHCP....................................................................164
Routing Table...........................................................165
Clients.................................................................166
Net.......................................................................16
WAN.....................................................................167
Creating PPPoE WAN Connection.........................................16
Creating Static IP WAN Connection.....................................173
Creating Dynamic IP WAN Connection....................................177
Creating Static IP + PPPoE WAN Connection.............................1 1
Creating Dynamic IP + PPPoE WAN Connection............................1
Creating PPTP + Static IP or L2TP + Static IP WAN Connection..........195
Creating PPTP + Dynamic IP or L2TP + Dynamic IP WAN Connection........201
LAN.....................................................................207
Page 3 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual
Wi-Fi.....................................................................210
Basic ettings..........................................................210
ecurity ettings.......................................................212
MAC Filter..............................................................218
List of Wi-Fi Clients...................................................220
WP .....................................................................221
Using WPS Function via Web-based Interface............................223
Using WPS Function without Web-based Interface........................223
WD .....................................................................225
Additional ettings.....................................................227
WMM.....................................................................229
Client..................................................................231
Advanced..................................................................235
UPnP IGD................................................................236
DDN ....................................................................237
DN .....................................................................238
Routing.................................................................239
Remote Access to Device.................................................241
Miscellaneous...........................................................242
Firewall..................................................................244
IP Filters..............................................................244
Virtual ervers.........................................................247
DMZ.....................................................................249
MAC Filter..............................................................250
Control...................................................................252
URL Filter..............................................................252
System....................................................................254
Administrator Password..................................................255
Configuration...........................................................256
ystem Log..............................................................258
Firmware Upgrade........................................................260
Local Update..........................................................261
Remote Update.........................................................262
ystem Time.............................................................263
Ping....................................................................264
Traceroute..............................................................265
Telnet..................................................................266
Device mode.............................................................267
Chapter 6. Operation Guidelines................................268
Safety Instructions.......................................................268
Wireless Installation Considerations......................................268
Chapter . Abbreviations and Acronyms..........................269
Page 4 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual Introduction
C APTER 1. INTRODUCTION
Contents and Audience
This manual describes the access point DAP-1360 and explains how to configure and operate it.
This manual is intended for users familiar with basic networ ing concepts, who create an in-home
local area networ , and system administrators, who install and configure networ s in offices.
Conventions
Example Description
text The body text of the manual.
Before You Begin A reference to a chapter or section of this manual.
“Quick Installation
Guide” A reference to a document.
Change A name of a menu, menu item, control (field, chec box, drop-down
list, button, etc.).
192.168.0.51 Data that you should enter in the specified field.
!Information An important note.
Document Structure
Chapter 1 describes the purpose and structure of the document.
Chapter 2 gives an overview of the device's hardware and software features, describes its
appearance and the pac age contents.
Chapter 3 explains how to install the DAP-1360 device and configure a PC in order to access its
web-based interface.
Chapter 4 describes all pages of the web-based interface for the device in the access point mode.
Chapter 5 describes all pages of the web-based interface for the device in the router mode.
Chapter includes safety instructions and tips for networ ing.
Chapter 7 introduces abbreviations and acronyms used in this manual.
Page 5 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual Overview
C APTER 2. OVERVIEW
General Information
The DAP-1360 device is a wireless access point supporting the router mode. It is an affordable
solution for creating wireless networ s at home or in an office.
Using DAP-1360, you are able to quic ly create a wireless networ and let your relatives or
employees connect to it virtually anywhere (within the operational range of your wireless networ ).
The access point can operate as a base station for connecting wireless devices of the standards
802.11b, 802.11g, and 802.11n (at the rate up to 300Mbps).
The device supports multiple functions for the wireless interface: several security standards (WEP,
WPA/WPA2), MAC address filtering, different operation modes (access point, router, client), WPS,
WDS, WMM.
You are able to connect the wireless access point DAP-1360 switched to the router mode to a cable
or DSL modem or to a private Ethernet line and use a high-speed Internet connection to
successfully fulfill a wide range of professional tas s.
In the router mode, the DAP-1360 device includes a built-in firewall. The advanced security
functions minimize threats of hac er attac s, prevent unwanted intrusions to your networ , and
bloc access to unwanted websites for users of your LAN.
You can configure the settings of the DAP-1360 device via the user-friendly web-based interface
(the interface is available in several languages).
Now you can simply update the firmware: the access point itself finds approved firmware on D-
Lin update server and notifies when ready to install it.
Page 6 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual Overview
Specifications*
ardware
WAN Interface •1 10/100BASE TX Ethernet port for cable or DSL modem or private Ethernet line
LAN Interface •1 10/100BASE TX Ethernet port
WLAN Interface •IEEE 802.11n (up to 300Mbps) •IEEE 802.11b/g
Antenna •Two 5dBi detachable
omnidirectional antennas
•RP SMA connector
Frequency Range •802.11b
◦2400 ~ 2497MHz ISM band
•802.11g
◦2400 ~ 2483.5MHz ISM band
•802.11n
◦2400 ~ 2483.5MHz ISM band
Data Rate •802.11b
◦11, 5.5, 2, and 1Mbps
•802.11g
◦54, 48, 36, 24, 18, 12, 9, and 6Mbps
•802.11n
MCS
GI3=800ns GI=400ns
20MHz
(Mbps)
40MHz
(Mbps)
20MHz
(Mbps)
40MHz
(Mbps)
0 6,5 13,5 7,2 15
1 13 27 14,4 30
2 19,5 40,5 21,7 45
3 26 54 28,9 60
4 39 81 43,3 90
5 52 108 57,8 120
6 58,5 121,5 65 135
7 65 135 72,2 150
8 13 27 14,4 30
9 26 54 28,9 60
10 39 81 43,3 90
11 52 108 57,8 120
12 78 162 86,7 180
13 104 216 115,6 240
14 117 243 130 270
15 130 270 144,4 300
Modulation Schemes •802.11b: DQPSK, DBPSK, DSSS,
CCK
•802.11g: BPSK, QPSK, 16QAM,
64QAM with OFDM
•802.11n: BPSK, QPSK, 16QAM,
64QAM with OFDM
* The device features are subject to change without notice. For the latest versions of the firmware and relevant
documentation, visit www.dlin .ru.
Page 7 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual Overview
Transmitter Output Power
The maximum value of the transmitter
output power depends upon the radio
frequency regulations applied in your
country
•802.11b (typical at room temperature 25 °C)
◦17dBm (±1.5dB) at 1, 2, 5.5, 11Mbps
•802.11g (typical at room temperature 25 °C)
◦17dBm (±1.5dB) at 6Mbps
◦17dBm (±1.5dB) at 9Mbps
◦17dBm (±1.5dB) at 12Mbps
◦16dBm (±1.5dB) at 18Mbps
◦16dBm (±1.5dB) at 24Mbps
◦15dBm (±1.5dB) at 36Mbps
◦15dBm (±1.5dB) at 48Mbps
◦15dBm (±1.5dB) at 54Mbps
•802.11n (typical at room temperature 25 °C)
HT 20 HT 40
16.5dBm (±1.5dB) at
MCS0/8
16.5dBm (±1.5dB) at
MCS0/8
16.5dBm (±1.5dB) at
MCS1/9
16.5dBm (±1.5dB) at
MCS1/9
16.5dBm (±1.5dB) at
MCS2/10
16.5dBm (±1.5dB) at
MCS2/10
16dBm (±1.5dB) at
MCS3/11
16dBm (±1.5dB) at
MCS3/11
16dBm (±1.5dB) at
MCS4/12
16dBm (±1.5dB) at
MCS4/12
15.5dBm (±1.5dB) at
MCS5/13
15.5dBm (±1.5dB) at
MCS5/13
15dBm (±1.5dB) at
MCS6/14
15dBm (±1.5dB) at
MCS6/14
14dBm (±1.5dB) at
MCS7/15
14dBm (±1.5dB) at
MCS7/15
Receiver Sensitivity •802.11b (typical at PER = 8% (1000 byte PDUs))
◦82dBm at 1Mbps
◦80dBm at 2Mbps
◦78dBm at 5.5Mbps
◦76dBm at 11Mbps
•802.11g (typical at PER = 10% (1000 byte PDUs))
◦85dBm at 6Mbps
◦84dBm at 9Mbps
◦82dBm at 12Mbps
◦80dBm at 18Mbps
◦77dBm at 24Mbps
◦73dBm at 36Mbps
◦69dBm at 48Mbps
◦68dBm at 54Mbps
•802.11n (typical at PER = 10% (1000 byte PDUs))
HT 20 HT 40
82dBm at MCS0/8 79dBm at MCS0/8
79dBm at MCS1/9 76dBm at MCS1/9
77dBm at MCS2/10 74dBm at MCS2/10
74dBm at MCS3/11 71dBm at MCS3/11
70dBm at MCS4/12 67dBm at MCS4/12
66dBm at MCS5/13 63dBm at MCS5/13
65dBm at MCS6/14 62dBm at MCS6/14
64dBm at MCS7/15 61dBm at MCS7/15
Software
Operation Modes •Access point mode •Router mode
Page 8 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual Overview
Network Functions •WAN connection types
◦PPPoE
◦Static IP
◦Dynamic IP
◦Static IP + PPPoE
◦Dynamic IP + PPPoE
◦PPTP/L2TP + Static IP
◦PPTP/L2TP + Dynamic IP
•DHCP server/relay
•DNS relay
•VPN pass through (PPTP/L2TP)
•Dynamic DNS
•Static IP routing
•Remote management
•Network statistics for each
interface
•IGMP Proxy
•RIP
•Support of UPnP IGD
•WAN ping respond
•Support of SIP
•Support of RTSP
•PPPoE pass through
Wireless Connection •Supported security settings
◦WEP
◦WPA/WPA2 Personal
◦WPA/WPA2 Enterprise
•MAC filter
•Managing connected stations
•PIN and PBC methods of WPS
•WMM (Wi Fi QoS)
•Advanced settings
•WDS
•“Client” function (access point
mode)
◦Wireless network client
◦Wireless network repeater
•“Client” function (router mode)
◦WISP repeater
Firewall Functions •Network Address Translation
(NAT)
•Stateful Packet Inspection (SPI)
•IP filters
•URL filter
•MAC filter
•DMZ
•Prevention of ARP and DDoS
attacks
•Virtual servers
Configuration and Management •Multilingual web based interface
for configuration and management
•Access via TELNET
•Firmware update via web based
interface
•Automatic notification on new
firmware version
•Saving/restoring configuration
to/from file
•Support of remote logging
•Automatic synchronization of
system time with NTP server and
manual time/date setup
•Ping function
•Traceroute utility
Physical and Environmental
LEDs •Power
•WLAN
•WPS
•LAN
•Internet
Power •External power adapter DC 12V/0.5А
Buttons •Power on/off button •WPS/RESET button
Operating Temperature •From 0 to 40 0C (from 32 to 104 0F)
Storage Temperature •From 20 to 65 0С (from 4 to 149 0F)
Operating umidity •From 10% to 90% non condensing
Storage umidity •From 5% to 95% non condensing
Page 9 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual Overview
Product Appearance
Front Panel
Figure 1. Front panel view.
LED Mode Description
Power
Solid green The device is powered on.
No light The device is powered off.
WLAN
Solid green The device's WLAN is on.
Blinking green The WLAN interface is active (upstream or
downstream traffic).
No light The access point's WLAN is off.
WPS
Blinking green Attempting to add a wireless device via the WPS
function.
No light The WPS function is not in use.
LAN
Solid green A device (computer) is connected to the port, the
connection is on.
Blinking green The port is active (upstream or downstream traffic).
No light The cable is not connected to the port.
Internet
Solid green The Internet connection is on.
Blinking green The WAN interface is active (upstream or downstream
traffic).
No light The cable is not connected.
Page 10 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual Overview
Back Panel
Figure . Back panel view.
Name Description
WPS
RESET
A button to restore the factory default settings and to quic ly add
wireless devices to the access point's WLAN (the WPS function).
To use the WPS function: with the device turned on, push the button,
hold it for 2 seconds, and release. The WPS LED should start
blin ing.
To restore the factory defaults: with the device turned on, push the
button, hold it for 10 seconds, then release it.
INTERNET
A port to connect to a cable or DSL modem or to a private Ethernet
line (it is recommended to use the cable included in the delivery
pac age).
LAN An Ethernet port to connect to a computer.
12 VDC IN Power connector.
ON/OFF A button to turn the access point on/off.
The device is also equipped with two external Wi-Fi antennas.
Page 11 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual Overview
Delivery Package
The following should be included:
•Access point DAP-1360
•Power adapter DC 12V/0.5A
•Ethernet cable (CAT 5E)
•Two detachable antennas
•“Quick Installation Guide” (brochure).
The “User Manual” and “Quick Installation Guide” documents are available on D-Lin website
(see www.dlin .ru, DAP-1360/A/E1 product page, the downloads tab).
!Using a power supply with a different voltage rating than the one included will cause
damage and void the warranty for this product.
Page 12 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual Installation and Connection
C APTER 3. INSTALLATION AND CONNECTION
Before You Begin
Please, read this manual prior to installing the device. Ma e sure that you have all the necessary
information and equipment.
Operating System
Configuration of the access point DAP-1360 supporting the router mode (hereinafter referred to as
“the access point”) is performed via the built-in web-based interface. The web-based interface is
available from any operating system that supports a web browser.
Web Browser
The following web browsers are recommended:
•Apple Safari 5 and later
•Google Chrome 5 and later
•Microsoft Internet Explorer 8 and later
•Mozilla Firefox 5 and later
•Opera 10 and later.
For successful operation, JavaScript should be enabled on the web browser. Ma e sure that
JavaScript has not been disabled by other software (such as virus protection or web user security
pac ages) running on your computer.
Wired or Wireless IC (Ethernet or Wi-Fi Adapter)
Any computer that uses the access point should be equipped with an Ethernet or Wi-Fi adapter
(NIC). If your computer is not equipped with such a device, install an Ethernet or Wi-Fi adapter
prior to using the access point.
Wireless Connection
Wireless wor stations from your networ should be equipped with a wireless 802.11b, g or n NIC
(Wi-Fi adapter). In addition, you should specify the values of SSID, channel number and security
settings defined in the web-based interface of the access point for all these wireless wor stations.
Page 13 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual Installation and Connection
Connecting to PC
PC with Ethernet Adapter
1. Ma e sure that your PC is powered off.
2. Connect an Ethernet cable between the LAN port located on the bac panel of the access
point and the Ethernet port of your PC.
3. Connect the power cord to the power connector port on the bac panel of the access point,
then plug the power adapter into an electrical outlet or power strip.
4. Turn on the access point by pressing the O /OFF button on its bac panel.
5. Turn on your PC and wait until your operating system is completely loaded.
Now you need to configure an IP address for the Ethernet adapter of your PC.
Configuring IP Address in OS Windows XP
1. Clic the Start button and proceed to the Control Panel > Network and Internet
Connections > Network Connections window.
2. In the Network Connections window, right-clic the relevant Local Area Connection
icon and select the Properties line in the menu displayed.
Figure 3. The Net ork Connections window.
Page 14 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual Installation and Connection
3. In the Local Area Connection Properties window, on the General tab, select the
Internet Protocol (TCP/IP) line. Clic the Properties button.
Figure 4. The Local Area Connection Properties window.
Page 15 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual Installation and Connection
4. Select the Use the following IP address radio button and enter the value
198.168.0.51 in the IP address field. The Subnet mask field will be filled in
automatically. Clic the OK button.
Figure 5. The Internet Protocol (TCP/IP) Properties window.
5. Clic the ОК button in the connection properties window.
Now you can connect to the web-based interface of DAP-1360 for configuring all needed
parameters. To gain access to an external networ (to the Internet), you also need to specify the
default gateway and the addresses of DNS servers.
Page 16 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual Installation and Connection
Configuring IP Address in OS Windows 7
1. Clic the Start button and proceed to the Control Panel window.
2. Select the Network and Sharing Center section. (If the Control Panel has the category
view (the Category value is selected from the View by drop-down list in the top right
corner of the window), choose the View network status and tasks line under the
Network and Internet section.)
Figure 6. The Control Panel window.
Page 17 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual Installation and Connection
3. In the menu located on the left part of the window, select the Change adapter settings
line.
Figure 7. The Net ork and Sharing Center window.
Page 18 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual Installation and Connection
4. In the opened window, right-clic the relevant Local Area Connection icon and select
the Properties line in the menu displayed.
Figure 8. The Net ork Connections window.
Page 19 of 270

DAP-1360 Wireless N300 Access Point & Router
User Manual Installation and Connection
5. In the Local Area Connection Properties window, on the Networking tab, select the
Internet Protocol Version 4 (TCP/IPv4) line. Clic the Properties button.
Figure 9. The Local Area Connection Properties window.
Page 20 of 270
