1. Special Features
We thank you for using our product. Please refer to this manual or contact our office if you find
any problems during using our product.
This product is an indicator that emplifies the micro voltage signals from each sensor and
display in digital. It is mainly used to measure physical quantities of the items using strain
guage such as loadcell, pressure sensor, displacement sensor and torque sensor.
This product has the following special features.
1-1. High-speed Conversion Method
24bit High-speed A/D converter that can detect the sensor’s input signal at a rate of
1000times per second is used. For analog output, 16bit D/A converter with 1000times per
second is used so that there is almost no devuatuib betweeb display value and output value.
1-2. Calibration Method
2 types of calibration systems are adopted. Calibration by actual load (standard weight) and
calibration by rated output of sensor (mV/V).
1-3. Hold and Peak Hold
You can choose Analog peak hold (High-speed) or Digital preak hold (Low-speed) as per
your need.
1-4. Comparison Output
You can do set-up the maxium and lower limit value by the keys on the front panel and output
contact point signal of the rear panel.
1-5. Data Back-up
All the set-up values will be memorized on the flash memory so the inputted data can be
saved and no need to do the re-setting even in case of the interruption of the electric power
or power disconnection.
1-6. Watch dog
This function is for automatic reset in case the system is stopped due to the external factors
such as noise.

3
1-7. Option
You can use RS232C, RS485 and 4 relay output as the optional specification.
1-8. Power
AC 220V 50/60Hz

4
2. Attention
For the efficient and safe use, please carefully read and be fully aware of the
following details before using this product.
It is strictly forbidden to use this product for any other purpose of use or to attempt
to make any alteration on this product.
2-1. Attention for installation
• Please keep it out of wet places.
• Do not set it up near vibration & impulse, high temperature and humidity.
Keep it out of the direct rays of the sun. Set it up where there is less dust, and Keep
it out of direct air including salt and ion.
• Do not use when there is inflammable gas or heavy machinery, and smog.
• Ground earth-terminal ( ).
• Make wire separately from power system wiring and noise wiring.
• Make sure the use of 4 line sealed cable as a sensor cable. Too long cable leads to
measurement error due to wiring resistance (around 10meters).
2-2. Attention for use
During calibration, Do not input free-load state and real-weight load until it becomes
stable. Pressing Enter Key in unstable condition leads to calibration error.
Do not press any Key in use at one's discretion. Please refer to 7. Setting-up mode
for the function and method of Key.

5
3. Specification
• Available sensor : Strain Gauge sensor (Bridge 120Ω, 350Ω, 700Ω)
• Upper limit Display : -19999 ~ +99999
• A/D Converter : 24bit, 1000 times/sec
• Temperature Characteristic (Amp Characteristic)
Zero : 0.5μV/℃
Span : 50ppm/℃
• Front Panel
Measured value display : 7 segment 5 Digit, Character Height 14mm
Status display : Red LED 3 pcs
Key Switch : 4 pcs
• Output
Comparison output : Upper limit(HI), Lower limit(LO), Normal(OK) Output
Contact Capacity - AC 250V 5A
Analog Output : DC 0~10V/4~20mA (Optional at the time of
order)
• Temperature range for use: -10℃~ 60, >82% RH (No dewing)
• External dimension : 96 × 48 × 128 mm (W × H × D)
• Panel cutting size : 91 × 45 mm
• Weight : About 450g
• Power Supply : AC 220V, 50/60㎐
• Option : 4~20mA(OP-1), RS232C (OP-02), RS485 (OP-03)

6
4. Front Panel
① HI, LO Indication LED : Hi or LO LED will be lighted when measured value exceeds
the setting value.
② HOLD indication LED : This LED will be lighted when the measured value is on Hold.
③ Measured value Indication: It indicates the measured value and each setting value.
④ ZERO/SPAN setting up VR
: It is used when ZERO and SPAN calibration of Analog output (DC 0 ~ 10V or 4 ~
20mA) is carried out.
⑤
Measruing Mode: Once this Key is pressed for more than 1 second, the current
measuring value will be Zero (0) and the Analog output will be 0V (4mA) as well.
SET-UP Mode: Once this is pressed on the Function Set-up Mode, you will return to
the measuring mode.
⑥
Measuring Mode: Once this Key is pressed, the lower limit setting value will be
displayed and this value also can be changed.
SET-UP Mode: The location of row for the number flickering can be moved.
⑦
Measuring Mode: Once this Key is pressed, the upper limit setting value will be
displayed and the value can be changed.
SET-UP Mode: The flickering number will be increased by 1 and 1.
⑧
Measuring Mode: Once this Key is pressed, HOLD will be selected and once this key
is pressed again, HOLD will be cancelled.
SET-UP Mode: Save each set-up value.

7
5. Rear Panel
Please check the location of terminal and its use. While the projected button is being
pressed, please insert the cable into the lower hole completely. As soon as you release
the button, the connection will be completed. At the point, please slightly pull the calbe
and check whether the cable is come off or not.
(The most suitable calbe is Φ 0.5~1. Linking cable must be brazing or used with 1
terminal)
① AC IN : Main Power Supply Wiring Terminal
② : Ground Terminal (as an independent ground connection.)
③ OUT : Analog (DC 0 ~10V/DC 4 ~ 20mA) Output Terminal
④ EXC+ : Sensor Supply Voltage + Connection Terminal
⑤ EXC- : Sensor Supply Voltage + Connection Terminal
⑥ SIG+ : Sensor Ouput Signal + Connection Terminal
⑦ SIG- : Sensor Output Signal – Connection Terminal
⑧ GND : SHIELD connection terminal of sensor
⑨ GND, TXD, RXD : RS232C SERIAL INTERFACE (RS485 : TXD → TX+, RXD → TX-)
⑩ GND : External Input Common Terminal
⑪ IN1 : External HOLD Input Terminal
⑪ IN1 : External HOLD Input Terminal
⑫ IN2 : External ZERO Input Terminal
⑬ IN3 : External printer signal Input Terminal (when PT-100 use)
⑭ IN4 : No use

8
⑮ COM : RELAY Output Common Terminal
○
16 RY1 : RELAY 1(Lower Limit) Output Terminal
○
17 RY2 : RELAY2 (Upper Limit) Output Terminal
○
18 RY3 : RELAY3( Normal) Output Terminal (OK )
○
19 RY4 : RELAY 4 Output Terminal
○
20 ANALOG OUT LOW PASS FILTER (10Hz, 100Hz, 1 kHz) Selet Switch
SW1 : 10Hz
SW2 : 100Hz
SW3 : 1kHz
◀Attention▶
1. When wiring, please pull out the power plug. (Main power supply)
2. Please use the thick calbe for ground terminal ( ) so that you can avoid any trouble
due to the impulse voltage or surge. If possible, please keep it as an independent
ground.
(This must be used in the area with heavy noise. If the ground is made with other
device, it will be affected by noise.)
3. Please check the function of the terminal before you do the wiring so that you can
prevent any malfunction in advance.
4. Manufacture will be relieved of its responsibility for any damge or injury due to the
disassembly and alteration made without any agreement. Also, no A/S will be made.

9
6. Wiring Diagram
<Wiring Diagram>
<Example - External Input PLC Connection>

10
7. Components & Function
7-1. Flow Chart
Sensor Input
Analog peak hold
circuit
A/D conversion
1000 times/s
Fixed filter
Average : 32 times
Output count : 32 times/s
Display filter
Display update rate : 1~32times/s
Average : 1 ~ 32times/s
Display peak hold
circuit
Comparator
OP-02(RS232C)
OP-03(RS485)Display
Relay output
Serial output

11
7-2. How to use Hold mode
Hold mode is largely divided into Peak Hold and Sample Hold. Please select Analog,
Digital or Display Hold as per your purpose of use (Hi or Low Speed)
To input Hold, you can use Hold key on the front panel or external input. For the
operation method, please refer to the drawing below.
1) Peak Hold : To Hold the maxium value among the measured values.
Analog peak hold mode : It is a high-speed Peak hold. It is to hold and display the
maximum value of (+) direction.
Display peak hold mode : It is a low-sped Peak hold. It is to hold and display the
maximum value of (+) direction.
Absolute peak hold mode : It is a low-speed Peak hold. It is to hold and display the
maximum value of the absolute value (+/-).
2) Sample hold : It is to hold and display the value at the time of Hold signal input
among the measured values.
Digital sample hold mode : It is operated by high-speed sample hold.
Display sample hold mode : It is operated by low-speed sample hold.
On
Off
On
Off
On
off
① − : Sensor input value
② − : Display value &
Analog ouput value
Front Panel HOLD LED
External HOLD Input
Terminal
Front Panel HOLD Key
M
e
a
s
u
r
e
d
v
a
l
u
e
Time
①
②
M
e
a
s
u
r
e
d
v
a
l
u
e
Time
①
②
<Peak HOLD> <Sample HOLD>

12
7-3. How to use comparison ouput function
For comparison output function, there are 3 different modes such as Decision, High
limit, Low limit. It displays through the relay of rear panel comparing each setup value.
On High limit and Low limit mode, Hysteresis can be used.
To set up upper limit (High) and lower limit(Low), please use the key on the front panel.
1) Decision mode : Measured Value ≤ Lower limit setup value ⇒ RY1 ON (HI)
Measured Value ≥ Upper limit setup value ⇒ RY2 ON (LO)
Lower limit setup value < Measured value < Upper limit setup
value ⇒ RY3 ON (OK)
2) High limit mode : Measured Value ≥ RY1 setup value ⇒ RY1 ON
Measured Value ≥ RY2 setup value ⇒ RY2 ON
Measured Value ≥ RY3 setup value ⇒ RY3 ON
Measured Value ≥ RY4 setup value ⇒ RY4 ON
Measured Value < RY1 setup value – Hysteresis value⇒ RY1 OFF
Measured Value< RY2 setup value - Hysteresis value⇒ RY2 OFF
Measured Value < RY3 setup value – Hysteresis value⇒ RY3 OFF
Measured Value< RY4 setup value - Hysteresis value⇒ RY4OFF
3) Low limit mode : Measured Value ≤ RY1 setup value ⇒ RY1 ON
Measured Value ≤ RY2 setup value ⇒ RY2 ON
Measured Value ≤ RY3 setup value ⇒ RY3 ON
Measured Value ≤ RY4 setup value ⇒ RY4 ON
Measured Value > RY1 setup value + Hysteresis value⇒ RY1 OFF
Measured Value > RY2 setup value + Hysteresis value⇒ RY2 OFF
Measured Value > RY3 setup value + Hysteresis value⇒ RY3 OFF
Measured Value > RY4 setup value + Hysteresis value⇒ RY4 OFF
4) Low & High limit mode
Measured Value ≤ RY1 setup value ⇒ RY1 ON
Measured Value ≤ RY2 setup value ⇒ RY2 ON
Measured Value ≥ RY3 setup value ⇒ RY3 ON
Measured Value ≥ RY4 setup value ⇒ RY4 ON
Measured Value > RY1 setup value + Hysteresis value ⇒ RY1 OFF
Measured Value > RY2 setup value + Hysteresis value ⇒ RY2 OFF
Measured Value < RY3 setup value - Hysteresis value ⇒ RY3 OFF
Measured Value < RY4 setup value - Hysteresis value ⇒ RY4 OFF

13

14
7-4. Analog output function
If key press more than 3 seconds (Zero key) , the display is Zero(0) and Analog
Output becomes 0V (4mA).
Zero is possible to maximum 50% by 3 mv/V standard.
Analog out Low pass switch :10Hz, 100Hz, 1 kHz
At Low pass selective switch off, maximum 10 kHz.

15
8. Setting Modes
8-1. Types of Setting mode & Set-up
For Setting mode, there are 4 different types of mode such as Function mode, Digital
calibration mode, Actual load calibration mode and SPAN constant calibration mode.
Measuring Mode
While ke
y
is bein
g
pressed, press key.
Function mode
END
①
Digital calibration
mode
END
②
END
③
Actual load
calibration mode
① Function mode: Access to each function setup mode. Please refer 8-2 Function
Mode.
② Digital calibration mode: It is to calibrate into the sensor’s out
p
ut value. No need
to prepare for the actual load (standard weight). Please refer 8-3 How to calibrate.
③ Actual load calibration mode: It is to calibrate by adding the actual load (Standard
weight or the load you know). Please refer 8-4 How to calibrate.
④ SPAN constant calibration mode: It is to calibrate with the S.CAL value written
down for load calibration. Please refer 8-5 How to calibrate.
END
④
SPAN constant
calibration mode

16
8-2. Function mode
1) How to set function.
Measuring Mode State
While key is being
pressed, press key.
END

17
2) How to set RELAY data
① Decision mode (Decision mode : mode 0)
② Limit mode (Low & High limit mode: mode 1 ~ 3)
Measuring Mode
press key
END
Input data

18
# Function mode list #
Name Function Setting
The standard set-
up value at the
time of delivery
from the factory
F-01 Decimal point 0, 1, 2, 3 1
F-02 Division 1, 2, 5, 10, 20, 50 1
F-03 Display filter 0, 4, 8, 16, 32 8
F-04 Hold mode Display SH, Digital SH, Dis
p
lay PH(+),
Absolute PH(±), Analog PH(+) Display PH(+)
F-05 Comparison mode Decision, High limit, Low limit,
Low&High limit Decision
F-06 Hysteresis 0 ~ 99 0
F-09 ID Number 0 ~ 32 0
F-10 Baud rate & PRINT 2400, 4800, 9600, 19200, 38400, 57600, print 9600
F-11 Auto zero tracking 0 ~ 99 0
F-12 Auto zero tracking time 0.0 ~ 5.0 sec 0.0
F-13 Force unit Kg(kg/㎠), N, ℓb, bar, MPa Kg
F-14 Key disabling Zero key, Lo key, Hi key, Hold key 0000
F-01. Decimal point (Decimal point Set-up)
(Standard setup value : 1)
Display data Setting
0 00000 : No decimal point
1 0000.0 : One decimal place
2 000.00 : Two decimal places
3 00.000 : Three decimal places

19
F-02. Division (Minimum display unit setup)
(Standard setup value : 1)
Display data Setting
1 Displayed In 1 (0, 1, 2, 3, 4 …….)
2 Displayed in 2 (0, 2, 4, 6, 8 …….)
5 Displayed in 5 (0, 5, 10, 15 …….)
10 Displayed in 10 (0, 10, 20, 30 …….)
20 Displayed in 20 (0, 20, 40, 60 …….)
50 Displayed in 50 (0, 50, 100, 150 …….)
F-03. Display filter (Display speed setup)
(Standard setup value : 8)
Display data Setting
0 No filter
4 Average time 1/8 sec
8 Average time 1/4 sec
16 Average time 1/2 sec
32 Average time 1 sec
F-04. Hold mode
Display data Setting
0 Display sample Hold : To hold the display value at the time of Hold signal input.
1 Digital sample Hold : To hold the A/D convertion value at the time of Hold
signal input.
2 Diplay Peak Hold
: To hold the maximum value of display values during Hold signal
input.
3 Absolute Peak Hold :
To hold the maximum absolute value of display values during
Hold signal input.
4 Analog Peak Hold :
To hold the maximum value of sensor input during Hold signal
input.
F-05. Comparision mode (Comparision output mode setup
(Standard setup value : 0)
Display data Setting
0 Decision mode : Relay RY1(Lo), RY2(Hi), RY3(Ok) Output
1 High limit mode : Relay RY1, RY2, RY3, RY4 output
2 Low limit mode : Relay RY1, RY2, RY3, RY4 output
3 Low & High limit mode : Relay RY1, RY2, RY3, RY4 output
