Dahua VTK-VTO2000A-VTH1550 User manual

1
VTO2000A Series User’s Manual
V1.1.0

Table of Contents
Table of Contents...................................................................................................... 2
1Product Overview ........................................................................................ 1
1.1 List of Models.................................................................................................. 1
1.2 Structure......................................................................................................... 1
1.2.1 Structure............................................................................................... 1
1.2.2 Front Panel........................................................................................... 2
1.2.3 Rear Panel............................................................................................ 3
1.3 Networking Scene........................................................................................... 3
1.3.1 One-to-One Scene................................................................................ 3
1.3.2 Group Call Scene.................................................................................. 4
2Install VTO................................................................................................... 5
2.1 Direct Installation............................................................................................. 5
2.1.1 Screw.................................................................................................... 5
2.1.2 Dimension............................................................................................. 5
2.1.3 Installation Step .................................................................................... 6
2.2 Embedded in Wall........................................................................................... 8
2.2.1 Screw.................................................................................................... 8
2.2.2 Dimension............................................................................................. 9
2.2.3 Installation Step .................................................................................... 9
2.3 Wiring............................................................................................................ 11
2.4 Electric Control Lock and Electromagnetic Lock............................................ 12
2.4.1 Electric Control Lock........................................................................... 12
2.4.2 Electromagnetic Lock.......................................................................... 12
3Installation Debugging ................................................................................. 1
3.1 Modify IP Address........................................................................................... 1
3.2 General Config................................................................................................ 2
4Web Config.................................................................................................. 1

4.1 System Config................................................................................................. 1
4.1.1 Local Config.......................................................................................... 1
4.1.2 LAN Config ........................................................................................... 4
4.1.3 Indoor Manager..................................................................................... 4
4.1.4 Network Config ..................................................................................... 5
4.1.5 Video Set.............................................................................................. 7
4.1.6 User Manage ........................................................................................ 8
4.2 IPC................................................................................................................ 10
4.3 Info Search.................................................................................................... 10
4.3.1 Call History ......................................................................................... 10
4.3.2 Alarm Record...................................................................................... 11
4.3.3 Unlock Record .................................................................................... 11
4.4 Status Statistics ............................................................................................ 12
4.4.1 VTH Status ......................................................................................... 12
4.5 Logout........................................................................................................... 12
5Basic Function Introduction........................................................................ 13
5.1 Call Function................................................................................................. 13
5.1.1 Call Resident....................................................................................... 13
5.1.2 Group Call........................................................................................... 13
5.2 Monitor.......................................................................................................... 16
5.3 Unlock Function............................................................................................ 16
5.4 Compensation of Light .................................................................................. 16
5.5 Vandal Proof................................................................................................. 17
5.6 Restore Backup ............................................................................................ 17
6FAQ........................................................................................................... 18
Appendix 1 Technical Specifications....................................................................... 19
Appendix 2 Accessories............................................................................................ 1
Appendix 2.1 Cable Specification.............................................................................. 1
Appendix 2.2 Power Extension Line Specification..................................................... 1
Appendix 2.3 Embedded Box.................................................................................... 1

Important Safeguards and Warnings
Please read the following safeguards and warnings carefully before using the product in
order to avoid damages and losses.
Note:
Do not expose the device to lampblack, steam or dust. Otherwise it may cause
fire or electric shock.
Do not install the device at position exposed to sunlight or in high temperature.
Temperature rise in device may cause fire.
Do not expose the device to humid environment. Otherwise it may cause fire.
The device must be installed on solid and flat surface in order to guarantee
safety under load and earthquake. Otherwise, it may cause device to fall off or
turnover.
Do not place the device on carpet or quilt.
Do not block air vent of the device or ventilation around the device. Otherwise,
temperature in device will rise and may cause fire.
Do not place any object on the device.
Do not disassemble the device without professional instruction.
Warning:
Please use battery properly to avoid fire, explosion and other dangers.
Please replace used battery with battery of the same type.
Do not use power line other than the one specified. Please use it properly.
Otherwise, it may cause fire or electric shock.
Special Announcement
This manual is for reference only.
All the designs and software here are subject to change without prior written
notice.
d registered trademarks are the properties of their respective
owners.
If there is any uncertainty or controversy, please refer to the final explanation of
us.


1
1 Product Overview
1.1 List of Models
Model
Chassis
Material
Color
Unlock via
IC card
Button Type
Lock Control Module
VTO2000A
Metal
Silver
N/A
Mechanical
key
Built-in
1.2 Structure
1.2.1 Structure
Before installation, please make you sure know the dimensions of device and select
appropriate method of installation. See Figure 1- 1.
Figure 1- 1

1.2.2 Front Panel
Figure 1- 2
No.
Port Name
Note
1
MIC
Audio input.
2
Camera
It monitors corresponding door region.
3
Compensation
Light
Light compensation will automatically turn on
during monitoring, calling, or connecting status if
there is no enough light in environment.
4
Speaker
Audio output.
5
User Nameplate
Display username and other info.
6
Call Button
Call center or VTH.

1.2.3 Rear Panel
Figure 1- 3
No.
Component Name
Note
1
Camera Angle
Adjustment
Adjust camera angle.
2
Vandal-proof
Switch
When VTO if forced to leave wall, it will alarm and
report to MGT center.
3
Network Port
Via convertor, connect network cable (RJ45
crystal head).
4
User Port
Connect to lock, door sensor feedback and unlock
button.
5
Project Port
Reserved for project staff use.
1.3 Networking Scene
Here introduces VTO’s application scene, please read the following contents and install
according to actual condition.
1.3.1 One-to-One Scene
Visitor press Call button to call resident ( as VTH). See Figure 1- 4.

Figure 1- 4
1.3.2 Group Call Scene
When visitor press Call on VTO, multiple VTH will ring at the same time. The resident can
anwer, hang up or unlock door from any of the VTHs.
Note:
VTH has main VTH (host) and sub VTH (extension). One host can have up to 3
extensions.
See Figure 1- 5.
Figure 1- 5

2 Install VTO
VTO installation includes direct and embedded wall installation. Direct installation is to
install VTO in wall while embedded-wall is to dig a hole on wall and embed VTO into the
hole. This chapter separately introduces these two methods.
2.1 Direct Installation
2.1.1Screw
Before installing VTO, please check screws on accessory bag according to the following
specifications and install by following this guide.
Component Name
Illustration
Quantity
M3×6 Hex slot pan head tail machine screws
--- galvanizing white
4
M3×8 Cross recessed countersunk head tail
machine screws --- galvanizing white
4
ST3×18 Cross recessed countersunk head
tail tapping screws --- galvanizing white
4
White expansion tube￠6×30mm
4
Chart 2- 1
Note:
M3x6 or M3x8 either is OK.
2.1.2Dimension
Before you install the device, please make sure you know the dimension of device and
select appropriate installation method. See Figure 2- 1.

Figure 2- 1
2.1.3Installation Step
Step 1. Install metal bracket into the groove on wall. Fasten screw (ST3×18 Cross
recessed countersunk head tail tapping screws --- galvanizing white), and fix
metal bracket on wall. See Figure 2- 2
Step 2. Align the device on metal bracket according to screw hole. Fasten screw (M3×8
Cross recessed countersunk head tail machine screws --- galvanizing white),
and fix device on metal bracket. See Figure 2- 3.

Figure 2- 2

Figure 2- 3
2.2 Embedded in Wall
2.2.1Screw
Before installing VTH, please check screws on accessory bag according to the following
specifications and install by following this guide.
Component
Illustration
Quantity
M3×6 Hex slot pan head tail machine
screws--- galvanizing white
4
M3×8 Cross recessed countersunk head tail
machine screws --- galvanizing white
4
Chart 2- 2
Note:
M3x6 or M3x8 either is OK.

2.2.2Dimension
Before you install the device, please make sure you know the dimension of device and
select appropriate installation method. See Figure 2- 4.
Figure 2- 4
2.2.3Installation Step
Step 1. Dig a hole on wall, its dimension is 117*128*80(mm).See Figure 2- 5.
Step 2. Embed metal bracket into wall until its four peaks lean against the wall. See
Figure 2- 6.
Step 3. Align the device on metal bracket according to screw hole. Fasten screws (M3×8
Cross recessed countersunk head tail machine screws --- galvanizing white),
and fix device on metal bracket. See Figure 2- 7.

Figure 2- 5
Figure 2- 6

Figure 2- 7
2.3 Wiring
See Figure 2- 8.
Figure 2- 8
No.
Component
Name
Note
1
Network Port
Via convertor, connect to network cable. (RJ45
crystal head).

2
User Port
Power supply, connect to lock, door sensor and
unlock button.
3
Project Port
Reserved for project staff use.
2.4 Electric Control Lock and Electromagnetic Lock
2.4.1Electric Control Lock
When VTO connects to electric control lock, it means that the positive end of electronic
control lock connects to NO of VTO (user port 10) while its negative end connects to COM
of VTO (user port 12).
When VTO connects to unlock button, one end of unlock button connects to BUTTON of
VTO (user port 7) while the other end connects to CND of VTO (user port 9). See Figure
2- 9.
Figure 2- 9
2.4.2Electromagnetic Lock
When VTO connects to electromagnetic lock, it means that the positive end of
electromagnetic lock connects to NC of VTO (user port 11) while its negative end connects
to COM of VTO (user port 12).
When VTO connects to door sensor in electromagnetic lock, one end of door sensor
connects to FEEDBACK of VTO (user port 8) while the other end connects to GND of VTO
(user port 9). See Figure 2- 10.

Figure 2- 10

1
3 Installation Debugging
Warning:
Before debugging, the staff shall be familiar with device’s installation, wiring
and usage.
Beore debugging, check wiring for short or open circuit.
When staff find each circuit is normal, plug the device to power.
After debugging, clear the site.
3.1 Modify IP Address
VTO default IP address is 192.168.1.110. Before using VTO, you shall modify VTO IP
address to be designated IP address.
Step 1. Connect VTO to power.
About 60s after plugging to power, it auto boots up and enters working status.
Name plate area indicator turns white.
Step 2. Via direction connection of Ethernet cable to connect device and PC, set PC IP
address to be in the same network segment with VTO IP address.
Step 3. On PC, ping VTO IP command to check network.
If network is normal, then continue to Step 4; if network is abnormal, please
check cable connection, IP address setup and device power.
Step 4. Login VTO WEB nterface, modify IP address.
1. In Internet Explorer address field, enter VTO IP address, system shows
login interface.
2. Enter username and password, click “login”, see Figure 3- 1.
Note:
Default username and password is admin and admin. After first time login, please
modify your login password.
Figure 3- 1

3. Select System Config>Network, set VTO IP address, subnet mask and
defaul gateway. Click OK, see Figure 3- 2.
Figure 3- 2
3.2 General Config
If you first use VTO, you may need to operate according to the following steps:
Step 1. In Internet Explorer, input IP address of the VTO, enter username and password,
click Login to login WEB.
Note:
Default IP address of VTO is 192.168.1.110. Default username and password is
admin/admin. After first login, please change your password.
Step 2. In WEB interface, select System Config>Video Set, set video format as WVGA
as in Figure 3- 3.
Figure 3- 3

Step 3. In System Time tab, click on Sync PC to make VTO time the same with PC.
Step 4. Select System Config>Network Config, set VTO IP, Subnet Mask and Default
Gateway. See 错误!未找到引用源。.
