Daikin FVXG25K2V1B Instruction manual

FVXG-K
Naamloze Vennootschap - Zandvoordestraat 300, B-8400 Oostende - Belgium - www.daikin.eu - BE 0412 120 336 - RPR Oostende
TECHNICAL DATA  FLOOR STANDING
Technical Data
Floor standing
Technical Data
Air Conditioners
Floor standing
EEDEN11-100
EEDEN11-100
Daikin’s unique position as a manufacturer of air
conditioning equipment, compressors and refrigerants
has led to its close involvement in environmental issues.
For several years Daikin has had the intention to become
a leader in the provision of products that have limited
impact on the environment. This challenge demands the
eco design and development of a wide range of products
and an energy management system, resulting in energy
conservation and a reduction of waste.
EEDEN11-100 • 03/11 • Copyright © Daikin Printed on non-chlorinated paper. Prepared by Goekint Graphics NV, Belgium Responsible Editor: Daikin Europe N.V., Zandvoordestraat 300, B-8400 Oostende
Daikin products are distributed by:
Please fill out the requested information
Please fill out the requested information
The present leaflet is drawn up by way of information only and does not
constitute an offer binding upon Daikin Europe N.V.. Daikin Europe N.V. has
compiled the content of this leaflet to the best of its knowledge. No express
or implied warranty is given for the completeness, accuracy, reliability or fitness
for particular purpose of its content and the products and services presented
therein. Specifications are subject to change without prior notice. Daikin Europe
N.V. explicitly rejects any liability for any direct or indirect damage, in the
broadest sense, arising from or related to the use and/or interpretation of this
leaflet. All content is copyrighted by Daikin Europe N.V.
Daikin Europe N.V. participates in the Eurovent
Certification Programme for Air Conditioners (AC),
Liquid Chilling Packages (LCP) and Fan Coil Units (FC);
the certified data of certified models are listed in the
Eurovent Directory. Multi units are Eurovent certified
for combinations up to 2 indoor units.

• Split - Sky Air® • Indoor Unit 1
• Indoor Unit • Floor standing unit • FVXG-K
TABLE OF CONTENTS
FVXG-K
1Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4 Dimensional drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Dimensional Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5 Centre of gravity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Centre of Gravity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6 Piping diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Piping Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
7 Wiring diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Wiring Diagrams - Single Phase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
8 Sound data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Sound Pressure Spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

• Indoor Unit • Floor standing unit • FVXG-K
1
1
• Split - Sky Air® • Indoor Unit
2
1 Features
IndoorUnit Split-Sk FVXG-KFloorstand • The aluminium part of the front panel of the Nexura indoor unit has
the capability of warming up, just like a traditional radiator, to add
even more comfort on cold days
• The indoor unit distributes air at the sound of a whisper. The noise
produced amounts to barely 22dB(A) in cooling and 19dB(A) in
radiant heat mode. In comparison, the ambient sound in a quiet room
amounts to 40dB(A) on average
• Comfortable vertical auto swing ensures draughtfree operation and
prevents ceiling soiling
• Ideal for installation beneath a window
• ECONO mode decreases power consumption so that other
appliances that need large power consumption can be used
• Night set mode saves energy by preventing overcooling or
overheating during night time
• Powerful mode can be selected for rapid heating or cooling; after the
powerful mode is turned off, the unit returns to the preset mode
• Titanium apatite photocatalytic air purification filter removes airborne
microscopic particles, powerfully decomposes odours and helps to
prevent the propagation of bacteria, viruses, microbes to ensure a
steady supply of clean air
• Can be installed against a wall or recessed
• 24 hour timer can be set to start heating or cooling anytime during a
24 hour period
• Weekly timer can be set to start heating or cooling anytime on a daily
or weekly basis
5 steps
standard optional

3
1
2
• Split - Sky Air® • Indoor Unit 3
• Indoor Unit • Floor standing unit • FVXG-K
2 Specifications
2-1 Technical Specifications FVXG25K2V1B FVXG35K2V1B FVXG50K
Power input -
50Hz Cooling Nom. kW 0.019 0.210 0.032
Heating Nom. kW 0.022 0.02 0.035
Casing Colour Fresh white (6.5Y 9.5/0.5)
Dimensions Unit Height mm 600
Width mm 950
Depth mm 215
Packed unit Height mm 761
Width mm 1,030
Depth mm 314
Weight Unit kg 22
Packed unit kg 28
Packing Weight kg 6
Heat exchanger Length mm 665
Rows Quantity 2
Fin pitch mm 1.2
Stages Quantity 18
Tube type ø6.35 Hi-XU tube
Fin Type Multi slit fin
Fan Type Cross flow fan
Air flow rate Cooling High m³/min 8.9 9.1 10.6
cfm 314 321 374
Nom. m³/min 7.0 7.2 8.9
cfm 247 254 314
Low m³/min 5.3 7.3
cfm 187 258
Silent operation m³/min 4.5 6.0
cfm 159 212
Heating High m³/min 9.9 10.2 12.2
cfm 349 360 431
Nom. m³/min 7.8 8.0 10.0
cfm 275 282 353
Low m³/min 5.7 5.8 7.8
cfm 201 205 275
Silent operation m³/min 4.7 5.0 6.8
cfm 166 177 240
Fan motor Model KFD-280-40-8H
Speed Steps 5 + silent, + auto
Cooling High rpm 1,350 1,390 1,630
Medium rpm 1,140 1,170 1,440
Low rpm 940 950 1,250
Silent operation rpm 850 860 1,100
Heating High rpm 1,430 1,470 1,700
Medium rpm 1,190 1,210 1,450
Low rpm 950 960 1,200
Silent operation rpm 840 870 1,080
Output High W 32
Sound power level Cooling Nom. dBA 54 55 56
Heating Nom. dBA 55 56 58
Sound pressure
level Cooling High dBA 38 39 44
Nom. dBA323340
Low dBA 26 27 36
Silent operation dBA 23 24 32
Heating High dBA 39 40 46
Nom. dBA323340
Low dBA 26 27 34
Silent operation dBA 22 23 30

• Indoor Unit • Floor standing unit • FVXG-K
1
2
• Split - Sky Air® • Indoor Unit
4
2 Specifications
Standard Accessories : Thermal insulation (thermal insulation tube); Quantity : 1;
Standard Accessories : Installation plate; Quantity : 1;
Standard Accessories : Insulation sheet; Quantity : 2;
Standard Accessories : Titanium apatite photocatalytic air purification filter; Quantity : 2;
Standard Accessories : Drain hose; Quantity : 1;
Standard Accessories : Remote control holder; Quantity : 1;
Standard Accessories : Batteries; Quantity : 2;
Standard Accessories : Wireless remote control; Quantity : 1;
Standard Accessories : Operation manual; Quantity : 1;
Standard Accessories : Installation manual; Quantity : 1;
Notes
(1) 220V
(2) 230V
(3) 240V
(4) SL: The silent fan level of the air flow rate setting
Temperature control Microcomputer control
Air direction control Right, left, upwards
Air filter Removable / washable / mildew proof
2-2 Electrical Specifications FVXG25K2V1B FVXG35K2V1B FVXG50K
Power supply Phase 1~
Frequency Hz 50
Voltage V 220-240
Current Nominalrunningcurrent(RLA)
- 50Hz Cooling A 0.10(1) 0.09 (2) 0.09 (3) 0.11(1) 0.10(2) 0.10 (3) 0.17(1) 0.16(2) 0.15 (3)
Heating A 0.11(1) 0.11 (2) 0.10
(3) 0.12(1) 0.12(2) 0.11 (3) 0.18(1) 0.17(2) 0.17 (3)
Current - 50Hz Nominal running current A -
Current - 60Hz Nominal running current A -
Wiring
connections -
50Hz
For power supply Remark 3 for power supply, 4 for interunit wiring (Earth wire included)
2-1 Technical Specifications FVXG25K2V1B FVXG35K2V1B FVXG50K

3
1
3
• Split - Sky Air® • Indoor Unit 5
• Indoor Unit • Floor standing unit • FVXG-K
3 Options
3 - 1 Options

• Indoor Unit • Floor standing unit • FVXG-K
1
4
• Split - Sky Air® • Indoor Unit
6
4 Dimensional drawings
4 - 1 Dimensional Drawings

3
1
5
• Split - Sky Air® • Indoor Unit 7
• Indoor Unit • Floor standing unit • FVXG-K
5 Centre of gravity
5 - 1 Centre of Gravity

• Indoor Unit • Floor standing unit • FVXG-K
1
6
• Split - Sky Air® • Indoor Unit
8
6 Piping diagrams
6 - 1 Piping Diagrams

3
1
7
• Split - Sky Air® • Indoor Unit 9
• Indoor Unit • Floor standing unit • FVXG-K
7 Wiring diagrams
7 - 1 Wiring Diagrams - Single Phase
∼
∼
∼
∼

• Indoor Unit • Floor standing unit • FVXG-K
1
8
• Split - Sky Air® • Indoor Unit
10
8 Sound data
8 - 1 Sound Pressure Spectrum

3
1
8
• Split - Sky Air® • Indoor Unit 11
• Indoor Unit • Floor standing unit • FVXG-K
8 Sound data
8 - 1 Sound Pressure Spectrum
