dallmeier SDF5410HD-DN Guide

006943 | Rev. 1.0.1 | 2018-12-19
SDF5410HD-DN
Commissioning
English

Copyright © 2018 Dallmeier electronic GmbH & Co.KG
The reproducon, distribuon and ulizaon of this document as well as the communicaon of its contents to
others without express authorizaon is prohibited. Oenders will be held liable for the payment of damages.
All rights reserved in the event of the grant of a patent, ulity model or design.
The manufacturer accepts no liability for damage to property or pecuniary damages arising due to minor
defects of the product or documentaon, e.g. print or spelling errors, and for those not caused by intenon or
gross negligence of the manufacturer.
Figures in this document may dier from the actual product.
We reserve the right to make technical modicaons.
All trademarks idened by ® are registered trademarks of Dallmeier electronic.
All trademarks idened by *) are trademarks or registered trademarks of the following owners:
Google and Google Chrome of Google Inc. headquartered in Mountain View, California, USA;
HDMI of HDMI Licensing, LLC headquartered in Sunnyvale, California, USA;
JavaScript of Oracle Corporaon (and/or its aliates) headquartered in Redwood Shores, California, USA;
microSDXC of SD-3C, LLC headquartered in North Hollywood, California, USA;
Microso, Internet Explorer, Microso Edge and Windows of Microso Corporaon headquartered in
Redmond, Washington, USA;
Mozilla and Firefox of Mozilla Foundaon headquartered in Mountain View, California, USA;
Torx of Acument Intellectual Properes, LLC headquartered in Rockford, Illinois, USA.
Third-party trademarks are named for informaon purposes only.
Dallmeier electronic respects the intellectual property of third pares and always aempts to ensure the
complete idencaon of third-party trademarks and indicaon of the respecve holder of rights.
In case that protected rights are not indicated separately, this circumstance is no reason to assume that the
respecve trademark is unprotected.
This product includes soware developed by the OpenSSL Project for use in the OpenSSL Toolkit
(hp://www.openssl.org) and cryptographic soware wrien by Eric Young (eay@cryptso.com).

Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com 3
Commissioning SDF5410HD-DN
Contents
1 Validity 4
2 Documents 4
This Document 5
Other Applicable Documents 5
3 TypographicalConvenons 6
4 SafetyInstrucons 8
5 General Notes 12
Scope of Delivery 12
Transportaon and Packaging 13
Warranty 13
Appropriate Use 14
Operaon 15
Approvals/Cercaons 16
6 Requirements 17
Ambient Condions 17
Power Supply 18
7 MaintenanceandCleaning 22
8 InstallaonandCommissioning 24
9 MounngtheCameratoaWall 38
10 InterfacesandPartDescripon 40
11 InserngaMemoryCard 42
12 Pin Assignment 44
13 ConneconandLogin 46
Connecon 47
Login 48
14 TechnicalProductSpecicaon(BasicData) 50
15 Dimensions 53

4Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com
SDF5410HD-DN Commissioning
1 Validity
This document applies to the following device:
• SDF5410HD-DN
For reasons of simplicaon, the term “device” or “camera” is used in the following.
Figures in this document may dier from the actual product.
2 Documents
The product documentaon for the device contains several documents which are
included in the scope of delivery in a printed form and/or on a digital medium.
Addional informaon, if available, is provided exclusively on the website
www.dallmeier.com.
Read the complete product documentaon for the device carefully and thoroughly
before using the device. Always observe and follow the contained instrucons,
notes and warnings as well as the technical data in the currently valid product
specicaon.
Keep all documents in legible condion and in a suitable locaon for future
reference.
Regularly check the website www.dallmeier.com for the latest product documen-
taon updates.

Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com 5
Commissioning SDF5410HD-DN
This Document
Commissioning
The document entled “Commissioning” (this document) contains detailed
informaon concerning the installaon, connecon and commissioning of the
device as well as safety instrucons and general notes.
The target audience of this document is trained system integrators (video security/
surveillance systems installaon contractors).
Other Applicable Documents
ProductSpecicaon
The product specicaon contains detailed technical data, features and character-
iscs of the device.
The target audience of the document is trained system integrators (video security/
surveillance systems installaon contractors).
Conguraon
The document entled “Conguraon” contains detailed informaon concerning
the conguraon of the device.
The target audience of the document is trained system integrators (video security/
surveillance systems installaon contractors).

6Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com
SDF5410HD-DN Commissioning
3 TypographicalConvenons
This document may contain various warning words and symbols that indicate
potenal sources of danger:
DANGER
DANGER indicates a hazardous situaon which, if not avoided, will result in
death or serious injury.
WARNING
WARNING indicates a hazardous situaon which, if not avoided, could result in
death or serious injury.
CAUTION
CAUTION indicates a hazardous situaon which, if not avoided, could result in
minor or moderate injury.
NOTICE
NOTICE addresses pracces not related to physical injury and indicates mea-
sures to prevent device and/or property damage due to improper installaon,
assembly, wiring, operaon, conguraon or maintenance of the device.

Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com 7
Commissioning SDF5410HD-DN
For reasons of clarity and readability, various text formang elements and types
of emphasis are used in this documentaon:
Instrucons are indicated by arrows (➡).
➡Always carry out instrucons one aer the other in the sequence described.
“Expressions” in quotaon marks usually refer to individual components of the
device (housing parts, mounng elements, connecons/interfaces, etc.) or to
control elements of the device’s web-based graphical user interface (menu items,
buons, etc.).
Paragraphs in italics provide informaon on basic principles, special features
and ecient procedure as well as general recommendaons.

8Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com
SDF5410HD-DN Commissioning
4 SafetyInstrucons
Only use the device if it is in technically perfect condion, according to the
intended purpose, in a safety and hazard conscious manner and in compliance
with the follow ing safety instrucons:
• QualiedPersonnel
The assembly, installaon, connecon, commissioning and conguraon of the
device may only be carried out by qualied personnel.
This also applies to the maintenance, inspecon and repair of the device in
complying with the regulaons of the DIN VDE 0701-0702 series of standards
(VDE 0701-0702: “Inspecon aer repair, modicaon of electrical appliances
– Periodic inspecon on electrical appliances – General requirements for
electrical safety”).
• Regulaons
The use of video and audio security/surveillance systems is, in general, strictly
regulated.
Before using the device, inform yourself about the currently valid laws and
regulaons regarding data, worker and environmental protecon and ensure
compliance with them.
• System Components
Only use internal components that have been tested and approved by Dallmeier.
Inappropriate internal components may cause malfuncons, damage and data
loss and may result in the loss of warranty.

Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com 9
Commissioning SDF5410HD-DN
• ModicaonstotheDevice
Do not make any modicaons to the hardware or soware of the device that
have not been tested and approved by Dallmeier.
Inappropriate modicaons may cause malfuncons, damage and data loss and
may result in the loss of warranty.
• ProductDocumentaon
The product documentaon for the device contains several documents which are
included in the scope of delivery in a printed form and/or on a digital medium.
Addional informaon, if available, is provided exclusively on the website
www.dallmeier.com.
Read the complete product documentaon for the device carefully and
thoroughly before using the device. Always observe and follow the contained
instrucons, notes and warnings as well as the technical data in the currently
valid product specicaon.
Keep all documents in legible condion and in a suitable locaon for future
reference.
Regularly check the website www.dallmeier.com for the latest product
documentaon updates.
• Condensaon
If the device is brought from a cold to a warm environment, resulng condensa-
on may cause malfuncons and damage. In this case, wait unl the device has
reached room temperature (up to 8 hours) before commissioning.

10 Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com
SDF5410HD-DN Commissioning
• Earthing&EquipotenalBonding
For the safety of persons (protecon against dangerous contact voltages) and
devices (protecon against over-voltages) as well as for the immunity of
informaon and communicaon technology equipment to electromagnec
interferences (EMI), all protecve measures, which are specied by the
currently applicable DIN, VDE and ISO standards and which provide for a
standard-compliant grounding/earthing and a correct equipotenal bonding of
electrical and electronic devices, are mandatory and must be fullled by all
means.
• LightningStorms
To avoid damage to the device by electrical surge during lightning storms, all
protecve measures, which are specied by the currently applicable DIN, VDE
and ISO standards and which provide for a standard-compliant lightning
protecon equipotenal bonding, are mandatory and must be fullled by all
means.
• OperangCondions
Unfavorable operang condions may shorten the lifeme of the device, may
cause malfuncons, damage and data loss and may result in the loss of
warranty.
Observe the specicaons given in the technical data, the operang condion
requirements and the maintenance instrucons.

Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com 11
Commissioning SDF5410HD-DN
• ForeignBodiesintheDevice
If objects or liquids get into the device, immediately disconnect it from the
power supply (pull out the power plug or disconnect the device from the PoE
enabled PSE port).
Contact the sales partner responsible for your area.
• BurntSmellfromtheDevice
If you noce burnt smell or a formaon of smoke coming from the device,
immediately disconnect it from the power supply (pull out the power plug or
disconnect the device from the PoE enabled PSE port).
Contact the sales partner responsible for your area.
• Opening the Device
The device may only be opened by qualied personnel for commissioning,
inspecon, maintenance and repair.
• Disposal of the Device
Do not dispose waste electrical and electronic equipment into the household
trash.
Disconnect the device from the power supply.
Remove all connected peripherals.
Return the device to the sales partner responsible for your area.

12 Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com
SDF5410HD-DN Commissioning
5 General Notes
Scope of Delivery
The standard scope of delivery includes:
• Security Torx*) L-wrench with hollow point (T20 H) for
tamper-resistant housing screws (Torx-TR 20)
• Circular rubber gasket (adhesive-backed) for an opmum ghtness between the
mounted housing base and the supporng structure (ceiling or wall)
• PG16 cable gland with standard sealing insert and
sealing ring on connecon thread
• Sealing insert with longitudinal cut for easy inseron of pre-assembled cables
• Three mounng screws (including O-rings) and three plasc screw anchors for
mounng the housing base
• Three spare O-rings for mounng screws
• Drilling template (published in print and on DVD-ROM)
• Product documentaon (published in print and/or on DVD-ROM)
The scope of delivery may dier depending on the ordered equipment, device
variant or country of desnaon.

Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com 13
Commissioning SDF5410HD-DN
TransportaonandPackaging
Store the original packaging for later transportaon.
Dallmeier is not responsible for any damage resulng from unprofessional or
improper transportaon.
The device should only be shipped in the original packaging.
If the original packaging is no longer available, ensure that the used packaging
suciently protects the device against damage, moisture, heat and cold.
Warranty
The terms and condions valid at the me the contract was signed shall apply.

14 Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com
SDF5410HD-DN Commissioning
AppropriateUse
The SDF5410HD-DN is a high-resoluon single-sensor network camera with sheye
lens for detailed capturing of a 360° eld of view within a complete half-space (full
panoramic view of a hemisphere without blind spots – 360° horizontal and 90°
vercal eld of view).
The camera hardware is built into a compact IP54 dome housing that is designed
for indoor surface mount installaons on ceilings and walls.
The device can be operated with Power over Ethernet (PoE, Class 0, IEEE 802.3af)
or powered by an external 24 V DC power supply unit.
NOTICE
Damagetothedeviceduetounsuitablemounnglocaon
The device is exclusively designed for indoor use.
An outdoor installaon is prohibited and may result in malfuncon, damage,
data loss and loss of warranty.
➡Do not install/operate the device in outdoor environments.

Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com 15
Commissioning SDF5410HD-DN
Operaon
➡Observe the following notes for operang the device:
• If the device or the cables connected to the device are located near sources
with strong radiaon (e.g. radio transmiers, magnec elds), the video image
may be distorted.
• The device is equipped with Automac Gain Control (AGC). In low-light
condions the image may be altered (e.g. noise). This is not a malfuncon.
• The video image quality depends on the lighng condions and the used
monitor.
• The accuracy of the Automac White Balance (AWB) algorithm depends on the
used lighng.
Mixed light (consisng of arcial light and daylight) may cause color distorons
(inaccurate color reproducon).
• Poor lighng can lead to an incorrect white balance.

16 Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com
SDF5410HD-DN Commissioning
Approvals/Cercaons
The following approvals/cercaons were valid for the device at the me of this
document’s compilaon:
• CE
• FCC
• RCM
• UL
• DIN 50130-4 compliant
Visit www.dallmeier.com for possible updates.
Note(USA)
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protecon against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instrucon manual, may cause harmful
interference to radio communicaons. Operaon of this equipment in a residenal area is
likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.

Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com 17
Commissioning SDF5410HD-DN
6 Requirements
AmbientCondions
The device is designed for indoor use.
However, the device may not be installed and operated in environments with
• a large amount of dust and dirt,
• steam or oil vapors (e.g. kitchen),
• direct sunlight,
• high heat radiaon (e.g. radiator),
• improper ambient temperatures,
• nearby strong radiaon sources (e.g. radio transmiers, magnec elds),
• corrosive gases and liquids (e.g. salt water),
• insucient air venlaon (e.g. closed cabinet).
NOTICE
Damagetothedeviceduetounfavorableambientcondions
Use of the device under unfavorable ambient condions may shorten its life-
me and may cause malfuncon or damage to the device.
➡Only install/operate the device under favorable ambient condions.

18 Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com
SDF5410HD-DN Commissioning
Power Supply
The device can be operated with Power over Ethernet (PoE) and is compable
with all Power Sourcing Equipment (PSE) that is compliant with the IEEE 802.3af
PoE standard. Alternavely, the device can also be powered by an external 24 V DC
power supply unit.
WARNING
Electricalshockcausedbyexposedelectricalpartsandduetothelackofor
improper grounding/earthing
Risk of death or serious injury
➡The installaon of the device and the connecon of peripheral equipment
may only be carried out by qualied personnel and in a voltage-free state.
➡Before connecng or disconnecng an external DC power supply unit, make
sure that the power supply unit is disconnected from the mains socket (pull
the power plug out of the socket).
➡Carry out all protecve measures for a standard-compliant grounding/earth-
ing of the device in accordance with the currently applicable DIN, VDE and
ISO standards in order to ensure the safety of persons (protecon against
dangerous contact voltages).

Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com 19
Commissioning SDF5410HD-DN
NOTICE
Damage to the device due to improper power supply
Damage to electronic components or serious malfuncons
➡Always ensure the correct polarity when connecng an external DC power
supply unit.
➡Do not operate the device with Power over Ethernet (PoE) if the device is
powered by an external DC power supply unit.
Damagetothedeviceormalfunconsduetothelackoforimproperground-
ing/earthing
Damage to electronic components caused by lightning strikes and over-voltages
(electrical surges) or malfuncons due to electromagnec interferences
➡Carry out all protecve measures for a standard-compliant grounding/earth-
ing and a correct equipotenal bonding of the device in accordance with
the currently applicable DIN, VDE and ISO standards in order to ensure the
safety of the device (protecon against over-voltages) and its immunity to
electromagnec interferences (EMI).

20 Rev. 1.0.1 | © 2018 Dallmeier | www.dallmeier.com
SDF5410HD-DN Commissioning
If you operate the device with Power over Ethernet (PoE), observe the following
notes:
NOTICE
DamagetothecontactsoftheRJ45connectorsbycontacterosionwhenun-
mangthejack-plugconneconunderPoEload
Un-mang the jack-plug connecon while transming PoE power causes ero-
sion and ping by electrical arcs on both the jack and plug contacts (especially
when repeatedly un-mang the jack-plug connecon under PoE load).
Electrical arcs are generated, since the electric potenal dierence (voltage) and
therefore the intensity of the electric eld between the contacts rises sharply
when un-mang the jack-plug connecon.
The more un-mang cycles are carried out under PoE load, the higher the loss
of contact material due to metal evaporaon by electrical arcs, which in turn
accelerates the material erosion process on the contact surfaces.
Damaged contacts with an increased contact resistance may lead to a reduced
data transfer rate, unreliable network connecvity or even total device failure.
➡Always disable PoE on the relevant port of your PoE switch (or PoE midspan
device) or disconnect the used single-port PoE injector from the power sup-
ply before un-mang the jack-plug connecon in order to prevent damage to
the contacts of the RJ45 connectors by contact erosion.
