dallmeier DF3000A-DN Operating and maintenance instructions

Installation and Configuration
Rev. 2.0.1 / 080711
English
Colour box camera (Day/Night)
DF3000A(-DN)
DF3000A(-DN) CasinoCam®
DF3000AS(-DN)
DF3000AS(-DN) CasinoCam®

DF3000A(-DN) / DF3000AS(-DN)
2Dallmeier electronic
Informations about copyright, trademarks, design patents
© 2008 Dallmeier electronic
All rights reserved. This document may not be copied, photocopied, reproduced, translated,
transferred to an electronic medium or converted to a machine-readable form either whole or in
part without first receiving written permission from Dallmeier electronic GmbH & Co.KG.
We reserve the right to make technical modifications.
The manufacturer accepts no liability for damage to property or pecuniary damages arising due
to minor defects of the product or documentation, e.g. print or spelling errors, and for those not
caused by intention or gross negligence of the manufacturer.
Dallmeier electronic GmbH & Co.KG
Cranachweg 1
D 93051 Regensburg, Germany
www.dallmeier-electronic.com
[email protected]
All trademarks identified by ®are registered trademarks of Dallmeier electronic.
All trademarks identified by *)are trademarks or registered trademarks of the following owners:
Digital Pixel System of Pixim, Inc. headquartered in Mountain View, California, USA
Third-party trademarks are named for information purposes only.
Dallmeier electronic respects the intellectual property of third parties and always attempts to ensure the complete identification of third-
partytrademarksandindication oftherespective holderofrights. Incasethat protectedrightsare notindicatedseparately,thiscircumstance
is no reason to assume that the respective trademark is unprotected.

DF3000A(-DN) / DF3000AS(-DN)
3Dallmeier electronic
Table of contents
1 This document ............................................................................................ 5
1.1 Validity .......................................................................................................... 5
1.2 Documents.................................................................................................... 5
1.3 Conventions.................................................................................................. 5
2 Safety instructions ..................................................................................... 7
3 General notes.............................................................................................. 9
3.1 Scope of delivery.......................................................................................... 9
3.2 Transportation and packaging....................................................................... 9
3.3 Appropriate use............................................................................................. 9
3.4 Performance features ................................................................................... 9
3.5 Warranty ..................................................................................................... 10
3.6 Certifications............................................................................................... 10
4 Notes on operating the camera ............................................................... 11
5 Views and connection assignment......................................................... 12
5.1 Views .......................................................................................................... 12
5.2 Connection assignment .............................................................................. 13
6 Installation and commissioning.............................................................. 14
6.1 Requirements at the installation site........................................................... 14
6.2 Attaching the lens ....................................................................................... 14
6.3 Adjusting the back focus............................................................................. 15
6.4 Installation and commissioning................................................................... 16
7 Preparing to configure ............................................................................. 18
7.1 UTC Remote Box ....................................................................................... 18
7.2 DMS recorder ............................................................................................. 19
7.3 PView.......................................................................................................... 19
8 Configuration ............................................................................................ 20
8.1 Configuration for lenses with manual iris .................................................... 20
8.2 Presets........................................................................................................ 21
8.3 Basic functions............................................................................................ 23
8.3.1 Camera ID .................................................................................................. 23
8.3.2 CCTV System ............................................................................................. 23
8.3.3 Horizontal Flip............................................................................................. 24
8.3.4 Lens Select ................................................................................................. 24
8.3.5 Color ........................................................................................................... 25
8.3.6 Day / Night Setup........................................................................................ 25
8.4 Image Functions ......................................................................................... 26
8.4.1 Progressive Scan........................................................................................ 26
8.4.2 Backlight ..................................................................................................... 26
8.4.3 Digital Zoom ............................................................................................... 27
8.4.4 White Balance ............................................................................................ 27
8.5 Exit Menu.................................................................................................... 28

DF3000A(-DN) / DF3000AS(-DN)
4Dallmeier electronic
9 Appendix ................................................................................................... 29
9.1 Menu structure ............................................................................................ 29
9.2 Technical data............................................................................................. 30
9.3 Technical drawings...................................................................................... 32
9.3.1 DF3000A(-DN) / DF3000A(-DN) CasinoCam®............................................................................32
9.3.2 DF3000AS(-DN) / DF3000AS(-DN) CasinoCam®....................................................................33
9.4 Pin assignment interfaces........................................................................... 34

DF3000A(-DN) / DF3000AS(-DN)
5Dallmeier electronic
1 This document
1.1 Validity
This document applies to the colour box cameras DF3000A-(DN),DF3000A(-DN)
CasinoCam®, DF3000AS(-DN), DF3000AS(-DN) CasinoCam®. It has been produced on
the basis of version 1.7 (software).
The descriptions in this document apply to all above-mentioned camera versions. For
simplification reasons, the term “DF3000” is thus used.
Iftextpassages require distinctions to be made between the cameras, thecompletecamera
name will be mentioned.
1.2 Documents
Commissioning
The quick guide headed “Commissioning“ lists the most important steps for the connection
and commissioning of the device.
Installation and Configuration (this document)
The document entitled “Installation and Configuration“ contains detailed descriptions of the
installation, connection, commissioning and configuration of the device. Safety instructions,
general notes and technical data are additionally provided.
Thetargetaudience isexclusivelyspeciallytrainedand authorizedprofessionals(“installers“).
1.3 Conventions
This document contains various warning words and symbols that indicate potential sources
of danger. Various symbols and formats are used to maintain the clarity of the document.
DANGER
The warning word DANGER denotes an immediate danger
that may cause death or serious injury if it is not averted.
WARNING
The warning word WARNING denotes a possible danger that
may cause death or serious injury if it is not averted.
CAUTION
The warning word CAUTION denotes a possible danger that
may cause minor injury if it is not averted.
IMPORTANT
The word IMPORTANT denotes information for preventing
damage, incorrect configurations or incorrect actions.

DF3000A(-DN) / DF3000AS(-DN)
6Dallmeier electronic
NOTE
A NOTE offers information on principles, special features and
efficient procedure as well as general recommendations.
Expression Expressions in bold and italics generally indicate a control
elementonthedevice(switchesorlabels)oronitsuserinterface
(buttons, menu entries).

DF3000A(-DN) / DF3000AS(-DN)
7Dallmeier electronic
2 Safety instructions
Only use this unit if it is technically in proper working order, to the intended purpose and
whilekeepingsafetyandpotentialdangersinmind.Havemalfunctionsordamages eliminated
immediately!
Appoint a professional
Installation, mounting, connection, start-up and configuration of the unit may only be carried
out by trained and authorized professionals (installers).
Unless otherwise expressly specified, this also applies to the maintenance, testing and
repair. In doing so the regulations of the DIN VDE 0701 series of standards (repair,
modification and inspection of electrical appliances) must be followed in addition.
Read and pay attention to the documents
Carefully and completely read the documents included in delivery. Always pay attention to
the provided instructions, notes and warnings.
Regulations surveillance systems
The use of video and audio surveillance systems is strictly regulated in most countries.
Therefore,inform yourself on laws and regulations that governindividualapplicationsbefore
using the unit. Ensure compliance with these laws and regulations and also observe
regulations regarding data, working and environmental protection.
Do not make modifications
Do not make any modifications to the unit (neither to the software nor the hardware) without
consultingDallmeier electronic. Impropermodificationscan cause malfunctionsordamages.
Dallmeierelectronic accepts noliabilityfor damages resulting from unauthorizedorimproper
modifications to the unit.
Protection against condensation water
If the unit is brought from a cold to a warm environment, condensation water can form
inside the unit. Short-circuits may then lead to damage to the system. Wait up to 8 hours for
the unit to reach room temperature before starting it up.
Observe the rated voltage
The unit can be damaged or destroyed by the application of an incorrect voltage.
The mains voltage must always match the rated voltage of the unit. The rated voltage is
specified on the rating plate of the unit.
Observe ratings
Unsuitableambient conditionsandimproper installation(mainlytoo highambient temperature
and insufficient ventilation) may reduce the unit’s life cycle. Ensure compliance with the
stated operating conditions (see technical data), requirements at the installation site and, if
applicable, maintenance regulations.
Expansion components/peripheral devices
Useonly expansioncomponentsconformingwith the technical dataof the unit. Inappropriate
peripheral devices may result in the violation of local laws and regulations and damages to
the unit. In case of doubt, contact the sales partner responsible for your area.

DF3000A(-DN) / DF3000AS(-DN)
8Dallmeier electronic
Do not open the unit
Do not open the housing of the unit. There are no components inside the unit that require
maintenance by the user. The inspection, maintenance and repair with an open housing
must only be carried out by trained and authorized professionals (installer).
Penetration of foreign bodies and liquids
No objects or liquids may be allowed to get into the device. In this case, immediately
disconnect the unit from the power supply (pull out the power plug). Please contact the
sales partner responsible for your area.
Measures to be taken in the event of damage and burnt smell
If you notice burnt smell or formation of smoke from a unit, immediately disconnect it from
the power supply (pull out the power plug). Please contact the sales partner responsible for
your area.
Disposal
Disconnect the unit from the power supply. Remove all connected units and system
components. Return the unit to your respective sales partner.

DF3000A(-DN) / DF3000AS(-DN)
9Dallmeier electronic
3 General notes
3.1 Scope of delivery
Included in the standard scope of delivery is:
1 x DF3000 (standard version without lens)
1 x Documentation “Installation and Configuration“ (CD)
1 x Documentation “Commissioning“ (in print)
The scope of delivery may differ depending on the ordered equipment or device variant.
The device’s range of functions depends on the ordered equipment or device variant and
may therefore not correspond with this document’s content. Certain functions and features
may require an activation that is subject to costs.
3.2 Transportation and packaging
Store the original packaging for transportation at a later date. Dallmeier electronic is not
responsible for damage resulting from unprofessional/improper transportation. The goods
should only be shipped in their original packaging.
If the original packaging is no longer available, ensure that the packaging used sufficiently
protects the unit against damage, moisture, heat and cold.
3.3 Appropriate use
The DF3000 is a HiRes UWDR Cam_inPIX®colour box camera. It is designed for indoor
use.
3.4 Performance features
The DF3000 is especially characterised by the following functions and properties:
zDigital Pixel System*)(DPS) chipset
z1/3” DPS sensor with Cam_inPIX® technology
zPure 17-bit Digital Signal Processing
zHigh sensitivity for low-light images at F0.95, 50IRE: 0,5 lux and (-DN): 0,2 lux
zProgressive Scan image capture
zProgressive With Segmented Frames (PsF) image data transmission
zAdvanced noise reduction
zEnhanced image quality by means of numerous control functions like AWB, AGC, BLC
and extended Slow Shutter
zDC auto iris
zConfiguration via UTC commands

DF3000A(-DN) / DF3000AS(-DN)
10Dallmeier electronic
NOTE
For detailled information please see the chapter Technical
data.
3.5 Warranty
The terms and conditions valid at the signing of the contract apply.
3.6 Certifications
The following certifications were in effect at the time this document was produced:
zCE
zFCC
zUL
zACA
zUVV-Kassen
zCB

DF3000A(-DN) / DF3000AS(-DN)
11Dallmeier electronic
4 Notes on operating the camera
zThe DF3000A(-DN) / DF3000A(-DN) CasinoCam®can be operated at 12V DC or
24V AC.
The DF3000AS(-DN) / DF3000AS(-DN) CasinoCam®is operated at 12V DC.
zThe camera is designed for use with CS-mount lenses. A C/CS-mount adapter ring
(5 mm) is required for use with C-mount lenses. Note the lens type before using it. When
using C-mount lenses without an adapter ring, the camera could be damaged. This
applies especially for the sensor.
zLenses with DC control can be used for automatic iris control. Video signal-controlled
lenses are not supported.
zIf the camera or the cables connected to the camera are located near sources of strong
radiation, the video picture may be distorted.
zThe camera is equipped with automatic gain control (AGC). In low light the picture may
be altered (e.g. noise). This is not a camera malfunction.
zThe quality of the video picture depends on the lighting and the monitor used to display
the video picture.
zAutomatic white balance depends on the lighting used and can cause color distortions in
artificial light.
zPoor lighting can lead to faulty white balance.

DF3000A(-DN) / DF3000AS(-DN)
12Dallmeier electronic
5 Views and connection assignment
5.1 Views
ADC auto iris lens (not included in the standard scope of delivery)
BLocking screw for back focus adjustment ring (2 mm Allen screw)
C¼’’ tripod socket (on top and bottom side)
DCS lens mount and back focus adjustment ring
A
BC
D
Fig.5-1

DF3000A(-DN) / DF3000AS(-DN)
13Dallmeier electronic
5.2 Connection assignment
EPower input terminal:
zDF3000A(-DN) / DF3000A(-DN) CasinoCam®
12V DC / 24V AC (internal inverse-polarity protection)
zDF3000AS(-DN) / DF3000AS(-DN) CasinoCam®
12V DC (internal inverse-polarity protection)
FRS232 interface (for service purposes only)
GVideo output (CVBS, BNC)
HPower LED
IDC auto iris interface for iris control
JSelector, with integrated Enter button (depending on model)
KSeparate Enter button (depending on model)
G
F
E
H
I
J
K
Fig.5-2

DF3000A(-DN) / DF3000AS(-DN)
14Dallmeier electronic
6 Installation and commissioning
6.1 Requirements at the installation site
The camera is designed for indoor use. If used outdoors, the camera has to be mounted
into a corresponding weather-proof housing.
Unfavorable local conditions may shorten the life of the product or lead to malfunctions.
Do not install/operate the camera in places:
zwith large scale dust and dirt
zwith steam or oil vapors (e.g. kitchen)
zwith direct sunlight
zwith improper ambient temperatures (see technical data)
znear sources of strong radiation (i.e. X-rays, radio transmitters or magnetic fields)
zwith corrosive surroundings (e.g. gases or salt water).
6.2 Attaching the lens
MLens
NLens thread
IMPORTANT
Possible damage to the sensor.
The length of the lens thread plus any protruding parts must
not exceed 5 mm (L).
If using a C-mount lens, you have to screw a C-/CS-mount
adapter ring (5 mm) between the lens and the camera.
L= max. 5 mm
MN
Fig.6-1

DF3000A(-DN) / DF3000AS(-DN)
15Dallmeier electronic
NOTE
The camera is by default configured for use with DC auto iris
lenses.
If using a lens with manual iris control, you have to reconfigure
the camera accordingly (see section 8.1).
Video signal-controlled lenses are not supported.
IMPORTANT
Possible damage to the sensor caused by improper cleaning.
Only use approved methods and products for sensor cleaning.
For more information please contact the Dallmeier support.
¾Remove the rear lens cap and the camera body cap.
¾Screw the lens carefully into the CS lens mount (D).
¾If using a DC auto iris lens, connect the lens cable to the DC auto iris interface (I).
6.3 Adjusting the back focus
The back focus is the distance between the lens support on the camera and the image
sensor. Optimum focus is only possible when the correct distance is set.
Itmay be necessary to adjusttheback focus in individual cases duetoproduction tolerances
of the lens. The iris of the lens must be open as wide as possible (smallest iris value) to
adjust the back focus.
For lenses with automatic iris control, you will require a ND filter (gray filter) to prevent the
iris from closing in bright light.
Adjustment for lenses with a fixed focal distance
If the focus cannot be set exactly by turning the focus ring (lens), please proceed as follows:
1Point the camera at an object with sufficient contrast. The distance to the object should
be greater than 1000 x the focal distance.
2Open the iris on the lens.
3Set the distance at the lens to infinity (∞).
4Loosen the locking screw (B) on the camera with an adequate Allen wrench.
5Turn the back focus adjustment ring (D) until the optimum focus is achieved.
6Tighten the locking screw (B).

DF3000A(-DN) / DF3000AS(-DN)
16Dallmeier electronic
Adjustment for lenses with a variable focal distance (zoom)
If the focus changes as the focal distance changes, please proceed as follows:
1Point the camera at an object with sufficient contrast at a distance of approx. 2 m.
2Open the iris on the lens.
3Set the maximum focal distance (tele end) at the lens.
4Set the optimum focus with the focus ring.
5Set the smallest focal distance (wide end).
6Loosen the locking screw (B) on the camera with an adequate Allen wrench.
7Turn the back focus adjustment ring (D) until the optimum focus is achieved.
You may need to repeat steps 3, 4, 5, and 7 several times to obtain the best results.
8Tighten the locking screw (B).
6.4 Installation and commissioning
The camera has a ¼’’ tripod socket located on the top and bottom side.
IMPORTANT
Possible damage to the camera caused by inappropriate
mounting equipment.
The length of the tripod screw must not exceed 7 mm.
IMPORTANT
Possibledamage tothe camera causedby incorrect installation.
Pay attention to the manufacturer’s documentation when
installing the camera into a weather-proof housing.
CAUTION
Danger of injury from camera falling down!
Before initial startup, ensure that the camera is securely
mounted.
¾Mount the camera on a wall/ceiling bracket or on a pan/tilt head etc. using the ¼’’tripod
socket (C) and an appropriate tripod screw.
WARNING
Danger of death from lightning strike!
Do not connect/disconnect the video cable during a
thunderstorm.

DF3000A(-DN) / DF3000AS(-DN)
17Dallmeier electronic
¾Connect the video output (G) via video cable (coaxial) to the monitor.
WARNING
Danger of death from electric shock!
Disconnectthe power supply unit from the mains socket before
connecting the camera.
IMPORTANT
Possible damage to the camera caused by an inadequate po-
wer supply unit.
If used in North America, you must use a UL-certified, limited-
power Class 2 power supply unit (12V DC / 0.42A or 24V AC /
0.20A).
NOTE
Thecamera is providedwithinternal inverse-polarity protection.
¾Connect the camera via power input terminal (E) to an appropriate power supply unit.
¾Connect the power supply unit to the mains socket.
The power LED (H) illuminates and the camera is ready for operation.

DF3000A(-DN) / DF3000AS(-DN)
18Dallmeier electronic
7 Preparing to configure
The camera is supplied with factory settings which enable it to be used for most scenarios
without further configuration. However, if required, certain camera properties can be
configured using the camera menu.
The camera can be configured directly using the Enter button (K) / Selector (J) or by means
of the UTC Remote Box, the recorder or PView.
NOTE
There must be no video distributor or signal amplifier between
the camera and the UTC Remote Box (or recorder or PView).
NOTE
Refer to the separate operator’s manuals for the devices or
software used.
7.1 UTC Remote Box
Direct
Camera UTC Remote Box CVBS monitor
Via recorder
Camera UTC Recorder Monitor
Remote Box
Fig.7-1
Fig.7-2

DF3000A(-DN) / DF3000AS(-DN)
19Dallmeier electronic
7.2 DMS recorder
Camera Recorder Monitor
NOTE
This method requires a recorder with software version 5.3.1 or
higher and a built-in FG-11 frame grabber card.
7.3 PView
Camera Recorder PView station Monitor
NOTE
This method requires a recorder with software version 5.3.1 or
higher and a built-in FG-11 frame grabber card, using PView
version 5.6.0 or higher.
Fig.7-3
Fig.7-4

DF3000A(-DN) / DF3000AS(-DN)
20Dallmeier electronic
8 Configuration
The configuration dialog is opened as follows:
Direct: ¾Press the Enter button (K) for approx. 2 seconds.
UTC Remote Box: ¾Press the OK button for approx. 2 seconds.
DMS Recorder: ¾Select Camera control > Open / Close menu
PView: ¾Select Camera control > Open / Close menu
Navigating the configuration menu is always by means of 4 directions keys, which are
referred to as Selector in the following. The button for input confirmation and calling a
submenu is called Enter button.
Twodotsafteramenuentry indicatethat additionalconfiguration
options are available in a submenu.
One dot means that the selected entry (command) is executed
by pressing the Enter button.
¾Press the Selector up or down (cd) to select a menu item from the list.
¾Press the Enter button to call up the selected submenu or to execute the command.
¾Press the Selector to the left or right (ef) to change the respective setting value.
¾To return from a submenu to the higher-order menu, select Previous Page and press
the Enter button.
NOTE
Please pay attention to chapter 8.5 Exit Menu when saving/
resetting settings already made or leaving the configuration.
8.1 Configuration for lenses with manual iris
If you use a lens with manual iris control, the factory preset must be changed before any
further configuration occurs.
¾Choose Basic Functions in the main menu and set Lens Select to Manual.
Now you can make further settings or leave the configuration.
----------------- 3000------------------
>Presets..
Basic Functions..
Image Functions..
Save / Exit Menu..
