Dancover Titanium User manual

Assembly Manual
Titanium:
3,5x8x3x4
3,5x10x3,5x4,5
3,5x12x3,5x4,5

Table of content.
1. FrontPage.
2. Table of content.
3. List of parts.
4. Assembly.
7. Mounting the covers.
9. Contact Information.

Part list for Titanium 3,5x8x3x4/3,5x10x3x4/3,5x12x3x4
Part Number
Description
Qty. (pc.)
1
Curved roof tube (top)
at two ends
2/2/2
2
Curved roof tube (top) in
the middle
3/4/5
3
Curved roof tube (side)
at two ends
4/4/4
4
Curved roof tube (side)
in the middle
6/8/10
5
Lower sidewall with
base plate (middle)
6/8/10
6
Lower sidewall with
base plate (ends)
4/4/4
7
Upper side wall (middle)
6/8/10
8
Upper side wall (ends)
4/4/4
9
Roof purlins and
horizontal wall at both
sides
52/65/78
10
Cross tube in front and
back panel
8/8/8
11
Slant supporting tube
8/8/8
12
Roof cover
1
13
Front cover
1
14
Back cover
1
15
Stake peg
44/48/52
16
Rope for fixing cover
17
Bolts M14x30
104/154/204
M14x70
30/36/42
M12x50
16/16/16
M14x50
8/8/8
18
Inner joints for cross
tubes and slant
supporting tubes.
8/8/8

Assembly.
3,5 x 8 x 3 x 4
3,5 x 10 x 3 x 4
3,5 x 12 x 3 x 4
Step #1:
Place base plates as shown in figure #1. Make sure that diagonals are equal in
length. Secure base plates with stake pegs. Make sure to use at least 2 stake
pegs per base plate and drive them into the ground so they cross each other as
shown in figure #3.
Step #2:
Assemble two sidewalls and connect them as shown in figure #2. Make sure that
all bolts are secured tightly and placed from the outside and in, to avoid damage
on the cover. Figure 3 and 4 shows how joints should be assembled, both
shown from inside.
Figure 1
Figure 2
Figure3 Figure 4

Step #3:
Connect the two sidewalls with the curved roof tubes. Then connect these with the
horizontal bars as shown in figure # 5. Figure #6 and #7 show how joints are sup
posed to be assembled.
Step #4:
Assemble the next two sidewalls in extension of the already erected sides as
shown
Figure 5
Figure 6
Figure 7

Step # 5
Repeat steps #3 and #4 until the entire frames has been erected. Note that you
have to install windcrosses in the sidewall sections closest to the corners. (see
Figure #4). It should look like figure #8.
Step #6:
Make sure that all bolts are inserted from the outside in before proceeding with
the cover. Make sure all foot plates are secured to the ground.
Figure 8
Figure 9

Mounting the Cover
Step #7
Tie in a crossbeam in one side of the cover. as shown in figure # 10.
Step #8
Pull the cover over the top of the structure using 3 ropes tied to the crossbeam.
See figure # 11
Step #9:
Make sure that the cover sits on evenly on both sides of the frame.
Step #10:
Tie the cover to the bottom tensioning bar. Make sure that it is tightened.
Figure 10
Figure 11

Step # 11:
Mount the front and the back cover by weaving the rope around the bars as
shown in figure # 12 and # 13. Do the same with the roof cover. Make sure to use
one rope for each covers.
Step # 12:
Make sure that the edge of the roof cover overlaps the front/back cover (over the
end bars) as shown in figure #14. Slide a rope through the end sleeves and
tighten the rope through the hoops of the corner footplates.
Step # 13:
Make sure all ropes are secured and tight.
Figure 12
Figure 13
figure 14

Contact Information.
Dancover UK
Tel. [phone]
Fax. [phone]
E-mail: [e-mail]
VAT NO. 894 5631 80
For warranty/claims please fill out our form at:
http://www.dancovershop.com/info.asp?text=5
And we will get back to you as soon as possible.
