Danfoss Ikargo2 User manual

User Manual
Ikargo2 Transmitter
Remote Control
www.danfoss.com

Revision history Table of revisions
Date Changed Rev
February 2021 Changed name Ikargo10 to Ikargo2 0201
July 2019 Rebranded to Danfoss. 0101
User Manual
Ikargo2 Transmitter
2 | ©Danfoss | February 2021 BC312438493831en-000201

Safety instructions General safety....................................................................................................................................................................................4
Safety warnings.................................................................................................................................................................................4
Technical description Ikargo2 Dimensions.........................................................................................................................................................................5
Ikargo2 Start-up................................................................................................................................................................................ 6
Maintenance Ikargo2 Maintenance Recommendations............................................................................................................................... 8
Troubleshooting............................................................................................................................................................................... 8
Charger and battery BC70K and BT11K specifications.................................................................................................................................................9
BC70K Battery Charger Set-up.....................................................................................................................................................9
BC70K Charger LEDs Status .......................................................................................................................................................10
Battery Charging Recommendations..................................................................................................................................... 10
BC70K Battery Charger Dimensions........................................................................................................................................11
User Manual
Ikargo2 Transmitter
Contents
©Danfoss | February 2021 BC312438493831en-000201 | 3

Ikargo2 General Safety
The following safety instructions must be read carefully to install and use the product properly, and to
keep it in perfect working condition, and to reduce the risk of misuse.
•Strictly adhere to the installation instructions contained in this document.
•Make sure that professional and competent personnel carry out the installation.
•Ensure that all site and prevailing safety regulations are fully respected.
•Make sure that this document is permanently available to the operator and maintenance personnel.
•Keep the transmitter out of reach of non-authorized personnel.
•Remove the transmission key when the set is not in use.
•Check each working day the STOP button and other safety measures. When in doubt, press the STOP
button.
•Whenever several sets have been installed, make sure the transmitter is the right one. Identify the
machine controlled on the label for this purpose on the transmitter or by using the display (in case it
has one).
•Service the equipment periodically.
•When carrying out repairs, use spare parts supplied by Danfoss only.
W
Warning
Potential damage to the operator or the product. Do not use this product on machines in potentially
explosive atmospheres unless the model is ATEX/RATEX certified to work in such conditions.
Ikargo2 Safety Quick Guide
Follow the Safety Quick Guidelines below to reduce risk of injury to the operator or the product.
Changes or modifications not approved by Danfoss can void the user's authority to operate this product.
Remove the transmission key only when the
set is not in use or to deny the access.
When in doubt, press the STOP button. Make sure the transmitter works with the
machine to be handled.
After use set the contact key and the STOP
button.
Do not use the set when visibility is limited. Avoid knocking or dropping the set.
User Manual
Ikargo2 Transmitter
Safety instructions
4 | ©Danfoss | February 2021 BC312438493831en-000201

Ikargo2 Dimensions
Dimensions (mm)
1. Range limiter
2. RGB display
3. Status LED
4. Maneuver push button
5. Multi-key/START
6. STOP button
7. Movement pictogram housing
8. BT11K battery housing
9. Extractable EEPROM housing
User Manual
Ikargo2 Transmitter
Technical description
©Danfoss | February 2021 BC312438493831en-000201 | 5

Ikargo2 Start-up
In order to turn the transmitter on - OPERATION mode, follow the steps bellow:
1. Insert the charged BT11K battery model in the transmitter and ensure the EEPROM module is in place.
The battery must be charged according to the charger manual's instruction.
2. Turn the multi-key from the position 0to the 1position.
The multi-key cannot be removed while in the 1position.
3. Push and pull out the stop button.
The LED will blink in blue-green colors and the battery level will appear in the display. It is
recommended to introduce the machine identifier (example: EOT crane number).
User Manual
Ikargo2 Transmitter
Technical description
6 | ©Danfoss | February 2021 BC312438493831en-000201

4. Press START with the multi-key until the radio link is performed.
The LED color will turn green to indicate that the transmitter and receiver link is confirmed.
5. After confirmation, press the maneuver buttons to verify corresponding movements.
User Manual
Ikargo2 Transmitter
Technical description
©Danfoss | February 2021 BC312438493831en-000201 | 7

Ikargo2 Maintenance Recommendations
This product is designed for use in an industrial environment that may shorten the product's lifespan. Use
these recommendations to maximize the lifespan of the product.
•Use the hook/belt provided with the transmitter to prevent the transmitter from falling
•Do not clean the transmitter with solvents or pressurized water; use a damp cloth or soft brush for
cleaning
•If the push buttons show signs of deterioration, contact the Authorized Technical Service for repair
•Check if the battery contacts are correct, otherwise replace them.
•Be sure to recharge or replace battery regularly
Maintenance tips quick reference
Ikargo2 Troubleshooting
The transmitter has status monitoring LED's which help identify irregularities. The most common signals
are contained in the table below:
LED color | Frequency Pulse Frequency Description Action
Green | continuous The transmitter works properly. Operation
mode is OK. No action needed.
Green | pulses STANDBY mode. If transmitter is 4 minutes
ON and no action has been taken. Press START to return to operation mode.
Red | slow pulses Low battery signal. In 5 minutes you need to replace with full
battery.
Red | fast pulses EEPROM module missing or corrupted. Check EEPROM module or reprogram if
necessary.
Red | double pulses A maneuver is activated at transmitter start up
process; may indicate hardware damage if no
order is active.
Release maneuver or replace transmitter if
necessary.
Red | continuous General hardware failure or damage. Replace transmitter
User Manual
Ikargo2 Transmitter
Maintenance
8 | ©Danfoss | February 2021 BC312438493831en-000201

BC70K and BT11K specifications
BC70K battery charger
Specification Value
AC power supply 110 – 230 V, 50/60 Hz, ± 10%, automatic switching
DC power supply, nominal 12 – 24 V
BT11K battery
Specification Value
Voltage 3.7 V
Capacity 1130 mAh Li-Ion
Charging temperature 0°C to 45°C
Discharge temperature -20°C to 60°C
Charging mode Fast (<2.5 h) and intelligent
Weight 23 g
BC70K Battery Charger Set-up
The battery charger has two charging compartments that can simultaneously charge two BT11K
batteries. Use the information below to set up the BC70K battery charger.
1. Connect the charger to a power source using the cable provided.
The red LED will switch on if the charger is properly connected.
2. Place the batteries in the charger.
3. Optional: If charging two batteries, wait at least five seconds before inserting the second battery into
the compartment.
W
Warning
Possible damage to battery.
Be sure to charge batteries in environments with temperatures over 0°C.
User Manual
Ikargo2 Transmitter
Charger and battery
©Danfoss | February 2021 BC312438493831en-000201 | 9

BC70K Charger LEDs Status
The BC70K charger has a LED for each compartment (BAT 1 and BAT 2) and a common indicator
(POWER).
LED color / frequency Description
Green LED / pulsing (BAT 1, BAT 2) The battery is being charged
Green LED / continuous (BAT 1, BAT 2) The battery is completely charged
Red LED / pulsing or continuous (BAT 1, BAT 2) The battery charger fault
Red LED / continuous (POWER) The charger is properly connected to power source
Battery Charging Recommendations
The battery lifespan is estimated to 500 recharging cycles and is largely dependent on the conditions of
use. To maximize the lifespan of the batteries and battery charger, follow these recommendations:
•Do not recharge the battery until it is completely flat, as shown with red LED slow pulse on the
transmitter
•Always charge the batteries at temperatures between 0° and 45°C (the batteries will not become fully
charged at temperatures exceeding 45°C)
•Do not leave the battery charger or batteries in a direct sunlight
•Charge batteries at least once every six months
•Avoid short circuits between the battery contacts; do not carry charged batteries in toolboxes or next
to other metal objects (keys, coins, etc.)
•Always keep contacts clean
User Manual
Ikargo2 Transmitter
Charger and battery
10 | ©Danfoss | February 2021 BC312438493831en-000201

BC70K Battery Charger Dimensions
Dimensions (mm)
97.15
103.31
30.10
23.50
127.90
2.57
User Manual
Ikargo2 Transmitter
Charger and battery
©Danfoss | February 2021 BC312438493831en-000201 | 11
