Danfoss Ikompact User manual

Danfoss does not take responsibility of an incorrect installation, interferences produced by collision of frequencies, nor of the
management of the working frequencies in fixed facilities, where several radio remotes systems, share or can share, the same zone
or working area.
W
Warning
Proceed with caution; the equipment may not be connected correctly which may lead to unforeseeable movements on starting-
up. Make sure that the crane is stopped for the entire duration of the assembly process, keep the work area free and wear
protective clothing.
To guarantee the specified autonomy it is necessary to use AAA LR03 (x4) alkaline batteries with nominal capacities between 900
and 1155 mAh. It is highly recommended to use brands with + type or similar with nominal capacities close to 1155 mAh.
Rechargeable batteries are NOT recommended, as its nominal capacity is lower than the desired one.
Description
Legend:
1. Status LED
2. Feedback LEDs
3. START Button
4. STOP Button (if no STOP option)
5. STOP Pushbutton Option
6. Hook attachment
7. Removable EEPROM module
8. Alkaline batteries
Installation Guide
ikompact
Remote Control
©Danfoss | March 2020 AN312055927725en-000102 | 1

1. Proceed to connect the power supply and the outputs
according to the connection block diagram provided with the
system. The configuration of the radio node can last up to 1
minute.
2. Place the EEPROM and the charged alkaline batteries.
3. If the transmitter has the STOP button, press and pull it out.
The status LED will blink in blue until the Stand-by mode is
reached, then it will turn into fixed blue.
4. If the transmitter does not have the STOP button, press the
start button. The status LED will blink in green until the
transmitter is linked with the receiver.
5. When the receiver confirms the link, the status LED will turn
into fixed green, and will enter working mode. The system will
be fully operational in order to action any maneuver.
