User Guide
FP720
Two Channel Heating Timer

User Guide FP720 Two Channel Heating Timer
2Danfoss Heating VUSUH102 05/2019
1 Functional Overview
Symbols Function
description Symbols Function description
Mon–Sun Current set day Heating active
(1 or 2 Zone)
Current on/o
period
Domestic hot water
heating active
Schedule setup Heating channel 1
current mode
AM
PM
Current set time /
parameter setup
Heating channel2 or
DHW current mode
Time and date setup Away mode
2 Buttons
Symbols Function description
Schedule setup
(menu access*)
OK Conrm settings
(date and time setup*)
Menu navigation / day
selection
< > Time and setting changes
/ channel mode selection
CH Channel selection
(holiday mode selection*)
* To access additional feature press and hold button for 3 secs
3 Set Date & Time
• Press and hold OK button for 3 seconds; Yr ashes. Press <or >buttons to adjust year
• Press OK button again; Mth ashes. Press <or >buttons to adjust month
• Press OK button again; Day ashes. Press <or >buttons to adjust day of the month
• Press OK button again; Hr ashes. Press <or >buttons to adjust hour
• Press OK button again; Min ashes. Press <or >buttons to adjust minute
• Press OK button to exit, automatic exit after 20 seconds if no buttons pressed

User Guide FP720 Two Channel Heating Timer
Danfoss Heating VUSUH102 05/2019 3
4 Timer Schedule Setup
• Press button to access schedule setup
• Press CH button to select between SET CH1 or SET HW schedule (CH1 and CH2 if set for two heating zones),
press OK to conrm
Example below for 5/2 day setup, 2 periods
Mo. Tu. We. Th. Fr. ashing
Press OK to accept or right arrow to select Sa. Su.
Period 1:
1. Use <or >to select ON hour, press OK to conrm
2. Use <or >to select ON minute, press OK to conrm
3. Use <or >to select OFF hour, press OK to conrm
4. Use <or >to select OFF minute, press OK to conrm
Repeat 1 to 4 above for period 2
Sa. Su. Now showing in display.
Period 1
1. Use <or >to select ON hour, press OK to conrm
2. Use <or >to select ON minute, press OK to conrm
3. Use <or >to select OFF hour, press OK to conrm
4. Use <or >to select OFF minute, press OK to conrm
Display returns to home screen and schedule is set.
Where FP720 is set for 7day schedule, option will be given to select each day separately. In 24hr mode, option
will only be given to select Mo. to Su. together. See parameter P1.
Where FP720 is set for 3 periods, options will be given to select period 3 times. In 1 period mode, option will only
be given for one time period. See parameter P2.
A default program provides timer control if the user does not create own programs:
5/2 or 7 day – 3 Periods selected
Days Event 1 - On Event 2 - O Event 3 - On Event 4 - O Event 5 - On Event 6 - O
Start time Start time Start time Start time Start time Start time
Mon - Fri 6:30 8:30 11:30 13:30 16:30 22:30
Sat - Sun 7:30 9:30 11:30 13:30 16:30 22:30
* Floor temperature control mode.
For 24hr mode, default schedule follows Mo. to Fr. times above.
For 2 periods setup, default event times 1, 2, 5 & 6 are used. For 1 period setup, default event times 1 & 6 are
used.
Note: if parameter P1 or P2 are changed schedule will default to times above and user selected times will need to be
reset.

User Guide FP720 Two Channel Heating Timer
Danfoss Heating VUSUH102 | BC306937065292EN-000101 05/2019
5 Select Away Mode
• Press CH for 3 seconds to enter Away mode and will be displayed.
• Press CH again to exit Away mode.
6 Set Control Parameters
Press button for 6 seconds to enter the parameter setting mode. Press for parameter selection and
set the parameter range via <or >. Complete all adjustments.
To exit parameter setup press , automatic exit after 20 seconds in no button is pressed.
No. Parameter settings Settings range Default
P1 Working mode
01: Schedule timer 7 day
02: Schedule timer 5/2 day
03: Schedule timer 24hr
02
P2 Schedule periods
01: 1 period (2 events)
02: 2 periods (4 events)
03: 3 periods (6 events)
02
P3 Channel setup 01: Heating + Domestic hot water
02: Two heating zones 01
P4 Timer display 01: 24hr
02: 12hr 01
P5 Auto daylight saving 01: On
02: O 01
P6 Holiday mode setup 01: All channels o
02: Heating o only 01
P7 Service due setup Installer setting only
P8 Reset 00: Reset o
01: Select reset 00
