DANLERS DBPSU Quick start guide

Installation notes
DANLERS Limited, Vincients Road, CHIPPENHAM, Wiltshire, SN14 6NQ, UK.
Telephone: [phone] Fax: [phone]
E-mail: [email protected] Web: www.danlers.co.uk
Company Registered Number 2570169 VAT Registration Number 543 5491 38
Products available from DANLERS
• PIR occupancy switches • Daylight linked dimmers • Manual high frequency dimmers
• Photocells • Radio remote controls • Time lag switches • Outdoor security switches
• Dimmers • Heating, ventilation and air-conditioning controls • Bespoke / O.E.M. products
Please call for more information or a free catalogue, or visit our website.
This product conforms to EN 60598-1 and DALI standard IEC 60929 (DALI VO) and IEC
62386 (DALI V1).
Please ensure the most recent edition of the appropriate local wiring regulations are observed
and suitable protection is provided (protected with the appropriate MCB) 1kV over voltage.
Please ensure that this device is disconnected from the supply if an insulation test is made.
This product is covered by a warranty which extends to 5 years from the date of manufacture.
Precautions and Warranty
L
- DA
+
DA
Input: 100-230V. 50/60Hz
Output power supply:
40mA (20 ballasts)
tamb: 0°C ...50°C
DANLERS Limited
www.danlers.co.uk-
Made in UK
N
DBPSU
DALI / DSI Power Supply Unit
DALI/
DSI
Status
L
N
DBPSU DALI / DSI
Ballast
DANLERS
DALI / DSI Device
DALI Control Lines
DALI / DSI
Ballast
DALI / DSI Power Supply Unit
DBPSU
DALI / DSI Power Supply Unit (DBPSU) is designed for use with
DANLERS DALI or DSI dimmable devices.
The DALI / DSI Power Supply Unit is rated at 40mA (DALI standard
allows 250mA maximum). The controls interface of a DALI ballast
normally sources at 2mA.
Individual DALI / DSI circuits must not exceed 40mA.
Standard 2-core mains cable of minimum guage 1.5mm2is
recommended.
The maximum cable length of the DALI / DSI signal wires must not
exceed 300m or drop more than 2V on the signal line voltage.
To minimise voltage drop on the cable, the DBPSU can be installed
at the middle of the system so the cable is split into 2 equal lengths.
Technical Data
Supply Voltage: 120-240V
Supply Frequency: 50/60Hz
Supply Load: 4W maximum
Output: DALI / DSI
Output Current: 40mA
Output Voltage
Load Off: 18V maximum
Ambient temperature: 0-50 ºC maximum permitted.
Glow wire test: According to EN 60598-1 passed.
DALI standard: DALIPS is designed to supply control gear with DALI standard IEC 60929
(DALI VO) and IEC 62386 (DALI V1).
05/09/16 INS007 DBPSU
Circuit Diagram
L
N
DA1
DA2
Wiring connections
To control more than 20 ballasts (64
max) additional DBPSU can be installed
in the middle of the system with cable
split into equal lengths to minimise
voltage drop. Polarity sensitive when
installing multiple DBPSU.
