DANLERS EasyZAPP EZ CEFL DALI Quick start guide

Installation notes
DANLERS Limited, Vincients Road, CHIPPENHAM, Wiltshire, SN14 6NQ, UK.
Telephone: [phone] Fax: [phone]
E-mail: [email protected] Web: www.danlers.co.uk
Company Registered Number 2570169 VAT Registration Number 543 5491 38
Products available from DANLERS
• PIR occupancy switches • Daylight linked dimmers • Manual high frequency dimmers
• Photocells • Radio remote controls • Time lag switches • Outdoor security switches
• Dimmers • Heating, ventilation and air-conditioning controls • Bespoke / O.E.M. products
Please call for more information or a free catalogue, or visit our website.
This product conforms to BS EN 60669-2-1, BS EN 55015 and BS EN 60730.
Please ensure the most recent edition of the appropriate local wiring regulations are observed
and suitable protection is provided (protected with the appropriate MCB) 1kV over voltage.
Please ensure that this device is disconnected from the supply if an insulation test is made.
This product is covered by a warranty which extends to 5 years from the date of manufacture.
Precautions and Warranty
08/09/16 INS334 EZ CEFL DALI
Variants
DANLERS design and manufacture other EasyZAPP CZCEFLP variants, coded by
the following order codes:
EZ CEFL Suitable for mains switching
EZ CEFL 10VDC Suitable for 1-10VDC ballasts.
Troubleshooting
The load will not switch on:
• TheLUXsettingasspeciedbytheEasyZAPPAppissettoolowandisinhibiting
the switch.
• The moving body is not emitting more IR than the background.
(Person wearing insulating clothing in a warm environment)
• Person is too far from the PIR switch, see detection diagram.
• Person is moving unusually slowly (perhaps when testing).
• The control unit battery is not engaged (ON).
Switch RED dip switch next to the telejack connector on the control
unit to the DOWN position.
The load switches on when nobody is present:
• Heater causing infra-red variations in a small cold room.
Resite the EZ CEFL DALI control away from heater.
• Please contact DANLERS for further technical support.
 EasyZAPPCeilingushmountedswitches
EZ CEFL DALI
EasyZAPPceilingushpassiveinfra-redswitches(PIR)canbeushmountedinto
suspended and plasterboard ceilings (diagram A).
These PIR switches incorporate a passive infra-red quad sensor to detect
movement of a warm body within their detection zone (diagram B) and a photocell
to monitor the ambient light level.
PleaseNote:ALLadjustmentsaremadeviaafreelydownloadableEasyZAPP
AppavailablefromtheDANLERSwebsite.EasyZAPPproductscannotbe
conguredbyDANLERSControlZAPPorScheduleZAPPapps.
If EZ CEFL DALI is set as PIR with LUX input, upon detecting movement, if
the ambient light is dark enough, the EasyZAPP device will turn the load ON.
The ambient threshold can be set to between approximately 30 lux to 1000 lux
andinnitelux(photocellinactive)viathe‘RespondtoDaylight’settingsonthe
EasyZAPP App.
If no more movement is detected within a pre-selected time as determined by the
EasyZAPPApp,thentheEasyZAPPdevicewillturntheloadoff.This‘TimeOff
Timeout’ortimelagcanbesetviatheEasyZAPPAppadjusterbetween10sec
and 23hrs 59min 59sec.
Loading
EZ CEFL DALI is suitable for switching and dimming DALI ballasts (broadcast only).
They can control up to 40mA, eg. 20 ballasts at 2mA (varies according to make and
model of ballasts).
EZ CEFL DALI can also switch up to:
• 10 amps (3000W) of resistive loads
• 6amps(1500W)uorescentlamps,highfrequencyorswitchstart,
incandescent or mains halogen lamps (recommended with integral safety fuse)
• 3 amps (750W) of electronic or wire wound transformers.
• 2 amps (500W) of low energy lamps: CFL, LED, 2D etc.
• 1 amp (250W) of fans or most metal halide lamps.
IMPORTANT: To control DALI ballasts you will require a DALI Power Supply Unit.
Please refer to your ballast instructions.
DANLERS DALI Power Supply Unit (order code DBPSU) is rated at 40mA (DALI
standard allows 250mA maximum). The controls interface of a DALI ballast normally
sources at 2mA.
Start-upmodeandDefaultsettings
When the EZ CEFL DALI is powered up, it will take 1 minute for the circuitry to
stabilise(detectionLEDashing)andensuretheoutputisoff,theEZCEFLDALI
will then enter its Default Operating Mode.
Please Note: When in the Default Operating Mode the EZ CEFL DALI is set up as
an occupancy switch with a 20 minute turn OFF timeout (time lag) and photocell
disabled.

Installation procedure
1. Please read these notes carefully before commencing work. In case of doubt
pleaseconsultaqualiedelectrician.Ensurewiresandcablesaresecurelyheld
within the connection terminals.
 IMPORTANT:TheEZCEFLDALIControlUnitclockbatterymustbeengaged
(ON)priortoinstallationbyswitchingtheREDdipswitch(seediagramD)to
theDOWNposition.
2. POSITIONING: The EZ CEFL DALI switch should be installed to achieve correct
coverage of the area, see diagram B.
If the photocell override facility (enabled
via EasyZAPP app) is required, the switch must be located above an area where
daylightcangivegreaterilluminationthanthearticiallight.Avoidlocatingthis
product where it is exposed to drafty conditions (exposed lobbies, open ceiling
voids or near fans) or near heat sources. To cover large areas PIRs should be
spaced in a 5 metre grid formation.
3. Disconnect the EasyZAPP device from the circuit before performing insulation
testing of the wiring circuit.
4. Do not connect on a circuit with large inductive loads, as induced spikes may
cause false triggering or damage the device.
5. EZ CEFL DALI must be connected to its EasyZAPP Power Supply via the
EasyZAPP communication cable provided, for wiring see diagram C.
NOTE: The use of non EasyZAPP connectors may damage the EZ CEFL DALI
device and will invalidate the warranty.
Settingsandcalibration
ALL settings are adjusted by EasyZAPP App as detailed in the free to download
EasyZAPP App User Guide, including:
Timeout: Adjustable time lag from 10 seconds to 24 hours.
Brightness: Adjustable switching threshold, 30 to 1000 lux and inactive. EZCEFLP
must be calibrated as instructed on the user guide manual.
BatchCongure:ForconguringmultipleEZCEFLDALIcontrolswithidentical
settings.
Name:For identifying individual controls.
Password: For security against accidental or malicious alteration.
Please visit www.danlers.co.uk to download the EasyZAPP user guide.
up to 5m
up to 7m
Strong detection zone
i.e. person moving arm
or walking towards PIR Secondary detection
zone i.e. person
walking perpendicular
to PIR
For optimum coverage
recommended
mounting height: 2.4 to 5m
C:Wiringdiagram
SL
L
L
N
Telejack connector Control Unit
Power Supply
Red dip switch (MUST be
switched DOWN (towards lens)
to engage clock battery ON)
IMPORTANT
DA
DA
D:Connectordiagram
L
N
DALI Power
Supply Unit*
DALI
Ballast
EasyZAPP device
EZ CEFL DALI
DALI Control Lines
DALI
Ballast
*DANLERS Order code: DBPSU
Optional
other load
100 - 260VAC 50/60Hz
SL
L
N
CEILING VOID
(At least 78mm deep)
75mm circular hole
cut for PIR switch
A:Mountingdiagram
B:Detectiondiagram
