Dash Zero 9 User manual

User Manual
All manuals and user guides at all-guides.com

all-guides.com

Getting Started
1
All manuals and user guides at all-guides.com

P01: Backlight. Range 1-3, 3 = Brightest
P02: Units. 1 = KPH, 2= MPH
P03: Battery Voltage. 24, 36, 48, 52, 60.
Default = 48V
P04: Dash Timeout. Range 1-60 minutes
Default = 10 minutes
P06: Tire Diameter. Default = 8.5
P07: Motor Poles. Default = 28
P08: Speed Limiting. Default = 50
P09: Start Method. Default = 0, instant
1 = Push start
P10: Reserved. Default = 0
P15: Reserved. Default = 100
P99: Reserved. Default = 99
d0: Reserved. Default = 14
Enable the Settings Mode: Pressing the Power + Mode
simultaneously will enter the Dashboard setting mode.
Short pressing the power button will toggle through the 10
available settings for the scooter
Toggling through
the Settings
Changing the
P Value
Once you have the P setting you wish to change, press the mode
button will increase value, the power button to decrease it
Setting the
Change
Holding the mode button will set the value & return you to the P
menu. Also, after 5 seconds the Dash will return to the main screen.
2
Dash: Dashboard Settings
All manuals and user guides at all-guides.com

Zero 9
LG 12.8Ah 48V, 614Wh
Front disc, rear drum + regenerative
Front disc, rear drum + regenerative
600W rear-hub motor
Twin front & rear lights, with braking mode
Front spring & dual-rear shock absorbers
18 Kg
~48 KM/H
~30 Kilometers
3
Dash: Technical Specifications
All manuals and user guides at all-guides.com

4
Dash: Unfolding
All manuals and user guides at all-guides.com

5
Dash: folding
All manuals and user guides at all-guides.com

all-guides.com

6
Instructions for battery usage
All manuals and user guides at all-guides.com

7
Safety
All manuals and user guides at all-guides.com

8
Care & Maintenance
All manuals and user guides at all-guides.com

9
Care & Maintenance
IMPORTANT
