Dedicated Micros SD Range Operating instructions

SD Range
Installation and
Operation Guide

Dedicated Micros ©2007
2
SD Range
Whilst every attempt is made to ensure these manuals are accurate and current, Dedicated Micros reserve the right to alter or

Contents
Introduction3
Features4
Important Safeguards5
Installing the Unit7
Installation10
Remote Control12
21
Status22
General23
Cameras24
Schedule26
Recording27
32
Alarms35
Activity38
Serial43
Audio44
Text45
Admin47
Maintain49
Demos50
Help51
Unit Operation52
Event List58
Copy Menu60
62
Appendix A66
Appendix B67
Appendix C69

Dedicated Micros ©2007 3
SD Range
Introduction
What is …
SD Range ?
A comprehensive, digital recording solution, the SD Range allows customers to improve the
functionality of their CCTV solution without increasing their budget.Offering either JPEG or
MPEG-4 recording at scalable quality settings in PAL or NTSC format, the SD Range provides the
user with both high quality video images and minimum storage consumption.
Available with either 8, 12, 16 or 32* camera inputs and offering telemetry control, the SD range has
built in Alarm functionality and onboard Activity detection software. The MultiMode recording featurerecording feature
enables different recording rates, resolutions and compression formats to be set across scheduled,
normal, and alarm modes for each individual camera.
Its size and design enables it to be an ideal desktop solution, a perfect replacement for an existing
VCR/Mux installation, or an outstanding rst-time CCTV solution.
The user interface has a colour coded ‘Softkey’ interface and the conguration menus are common
to both the local monitor and web interface, making for easy set-up and operation.
The SD Range includes both an integrated CD-R Writer and USB ports for video archiving. The unit
also offers integrated text support, allowing users to connect with cash registers in retail applications
to monitor Point Of Sale (POS) locations. Capturing and associating video with the relevant text
information allows the user to search video footage by time, event, and text data to provide evidence
of fraud or to aid identication of regular offenders.
Among the many other features included as standard on the SD Range are; multiway display, picture
in picture viewing, remote monitoring using NetVu ObserVer, which uses DM’s unique TransCoding
capabillities to provide uent live and replay images, plus Dedicated Micros’ trademark plug and play
set-up with a user-friendly interface to keep installation and operator training to a minimum.
With telemetry control of up to 32 cameras, including coax telemetry, control of dome cameras,
audio recording and activity detection. The SD Range is the ideal product for single site and small to
medium sized businesses wishing to deploy a fully functional digital recording solution.
* 4 camera input model available after future development.
For further information, please visit the website:
www.dedicatedmicros.com
or contact customer services in your region.

Dedicated Micros ©2007
4
SD Range
Features
• 8, 12, 16 or 32 camera input options (8, 12, 16 or 32 camera input options (4 camera input model available after future
development)
 
• Telemetry support (Coax & Serial)Telemetry support (Coax & Serial)
          
          
• MultiMode

        
         
• Built in activity detectionBuilt in activity detection
       
                
memory
       
• Alarm Inputs & OutputsAlarm Inputs & Outputs
         
• BS8418 compliantBS8418 compliant
• Text support and text search features ideal for retail installationsText support and text search features ideal for retail installations
     
         
Design of the manual
The manual has three parts:
 
 
 




Dedicated Micros ©2007 5
SD Range
Important Safeguards
Read Instructions

Power Sources


Servicing
Do not attempt to service this unit yourself as opening or removing covers may expose you to


Ventilation








Lightning Strike


Regulatory Notes and FCC and DOC Information
(USA and Canadian Models Only)













Dedicated Micros ©2007
6
SD Range



CE Mark




Laser


 

• To prevent exposure to laser emanations (harmful to the eyes), do not attempt to


Dedicated Micros ©2007 7
SD Range
Installing the Unit
Before you start
Check the contents of the box
The following items are included in the box:

• SD DVR (either 8, 12, 16 or 32 input)
• IR Remote Control (x 2)
• IR Remote Control Extender
 
 

Note: Before installing the SD DVR, carefully read all Safety Instructions and the following
information on where the unit should be located.
Choosing a location for installation
 

 
 
• Ensure the IR receiver on the front of the unit faces the operator position, and is not
more than 10 feet (3

 
 

 

 

 
 

Electrical Connections
Please ensure the following are available and have been tested prior to the installation:
• Mains point
 
 
 
 


Dedicated Micros ©2007
8
SD Range
Quick Overview Of Default SD Record Settings
SD units provide out of the box:
High performance recording on ALL cameras with minimal conguration.
Consistent recording duration and smooth motion video per camera regardless of the number of
cameras.
The product range has Normal, Medium and Low record rate models.
Normal

Medium

Low

Complete Flexibility








Note: It is the Installer/Owner’s responsibilty to ensure that the record duration is set to the
necessary requirements of the application.
MultiMode Recording
The unit supports MultiMode recording, which is a storage technology developed by Dedicated
Micros. This offers the ability to set different recording rates, resolutions and compression formats
across scheduled, normal and alarm modes for each individual camera.
By varying the quality, bit rate and le size of the recorded images, the MultiMode function can
increase recording capabilities of the unit.
MultiMode offers:
 
 
 
 
 

Differences between MPEG-4 and MJPEG(JPEG)





Dedicated Micros ©2007 9
SD Range



MPEG-4 is used primarily to compress audio and visual (AV) digital data (moving images and




















Note: Dedicated Micros recommends using MPEG4 as a background recording setting; switching
to MJPEG on event or alarm.

Dedicated Micros ©2007
10
SD Range
Installation
Front Panel connections
Data
 
internal unit
 
 
 
 
 
 
 
 
Rear Panel connections
32 Input model
16 Input model
12 Input model

Dedicated Micros ©2007 11
SD Range
8 Input model

Video

 
             
MON B Spot Monitor outputMONIOONITOO
Audio
         input
 
    
 
Note: The 32 input model has two Audio IN / Audio OUT connections.
Data
 
 
 
    
 
 
 
 
 
Power
 
Alarms and relays
 
Range of Alarm states are
  
  
  
  
 

Dedicated Micros ©2007
12
SD Range
Remote Control
The IR Remote Control offers all the control functionality traditionally available via front panel
navigation.
Button Guide
Key Function

 
 

 
 
Toggle the speed of PTZ camera
 

 
 
 

 
 
This 
operation to focus or iris functions
 
  
 
 
carry out auxiliary actions on a PTZ
 

 

 

Dedicated Micros ©2007 13
SD Range

  
  

  

  

  
How to navigate the pages
Using the IR Remote Control
















Using a USB Mouse or the webpages




Dedicated Micros ©2007
14
SD Range
Note: A selected item in the drop down list will appear highlighted.



Dedicated Micros ©2007 15
SD Range
Installing the SD Unit
This procedure shows the sixteen camera input version.
Step 1 Connecting Video



Step 2 Monitor


Dedicated Micros ©2007
16
SD Range
Step 3 Connecting Audio



* 32 input model supports two channels of bi-directional audio, 8, 12 and 16 input models
support one.

        
   
   
               
  
Note:Note: The Audio ouptut can be congured as a challenge output or as a replay output.
Step 4 Connecting to the Network





Dedicated Micros ©2007 17
SD Range



3Step 5 Relays
KEYBOARD
USB
NETAUDIO
IN
VID 1
MON
B
VID 2VID 3
SERIAL1
SATA1
SERIAL2PTZ
OUT
SATA2
A
VID 13
VID 8
VID 6
VID 4VID 5VID 7 VID 9 VID 10VID 12
VID 11 VID 14 VID 16
ALARMSRELAYS
POWER
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
Pin 4 Relay 4 Signal
Pin 3 Relay 3 Signal
Pin 2 Relay 2 Signal
Pin 1 Relay 1 Signal
Pin 6 Relay 1 Signal
Pin 7 Relay 2 Signal
Pin 8 Relay 3 Signal
Pin 9 Relay 4 Signal
RELAYS

Relay Connector
Pins Connection
1 & 6 Relay 1 signal
2 & 7 Relay 2 signal
3 & 8 Relay 3 signal
4 & 9 Relay 4 signal
Step 6 Alarms
KEYBOARD
USB
NET AUDIO
IN
VID 1
MON
B
VID 2 VID 3
SERIAL 2
SERIAL 3 PTZ
OUT A
VID 13
VID 8
VID 6
VID 4 VID 5 VID 7 VID 9 VID 10 VID 12
VID 11 VID 14 VID 15 VID 16
ALARMS RELAYS
POWER
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
SERIAL 4 PTZ
SERIAL 1
Pin 2 DTX
Pin 4 DTX
Pin 6 DTX
Pin 8 DTX
Pin 10 DTX
Pin 12
Pin 1 DTX
Pin 3 DTX
Pin 5 DTX
Pin 7 DTX
Pin 9 DTX
Pin 11 DTX
Pin 13 DTX
Pin 25 Earth
Pin 23 Earth
Pin 21 Earth
Pin 19 Earth
Pin 17 DTX
Pin 15 DTX
Pin 24 Earth
Pin 22 Earth
Pin 20 Earth
Pin 18 Earth
Pin 16 Earth
Pin 14 DTX
ALARMS







Dedicated Micros ©2007
18
SD Range
Relay Connector
Pin Alarm Input Connection
1 - 17 1-17
18-25 Earth Common
End Of Line Circuitry









Step 7 Connecting Serial Ports

 
 
Note: Telemetry cameras should be connected to Serial 3 and 4. Text data can be retrieved from
any serial port.

Dedicated Micros ©2007 19
SD Range
RS232
RS485

Step 8 Connecting a Keyboard


Note: Refer to the Unit Operation section of this manual for further guidance regarding the
supported keyboards.
Step 9 Connecting Dennard 2060 & 2040 Domes







Dome Cable SD Serial Connector
 
Green 9 TX-

Dedicated Micros ©2007
20
SD Range
Step 10 Connecting Power



RF
