Dell EMC Storage with Milestone XProtect
Corporate
Surveillance
June 2018
H14501.4
Configuration Guide
Abstract
This configuration guide provides the storage-specific configuration requirements and
Milestone storage tiering options necessary for a successful Milestone XProtect
Corporate 2018 installation.
Dell EMC Solutions

Copyright ©2014-2018 Dell Inc. or its subsidiaries. All rights reserved.
Published June 2018
Dell believes the information in this publication is accurate as of its publication date. The information is subject to change without notice.
THE INFORMATION IN THIS PUBLICATION IS PROVIDED “AS-IS.“ DELL MAKES NO REPRESENTATIONS OR WARRANTIES OF ANY KIND WITH
RESPECT TO THE INFORMATION IN THIS PUBLICATION, AND SPECIFICALLY DISCLAIMS IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE. USE, COPYING, AND DISTRIBUTION OF ANY DELL SOFTWARE DESCRIBED IN THIS PUBLICATION REQUIRES AN
APPLICABLE SOFTWARE LICENSE.
Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be the property of their respective owners. Published
in the USA.
Dell EMC
Hopkinton, Massachusetts 01748-9103
1-508-435-1000 In North America 1-866-464-7381
www.DellEMC.com
2Dell EMC Storage with Milestone XProtect Corporate

Introduction 5
Solution overview......................................................................................... 6
Purpose........................................................................................................ 6
Scope........................................................................................................... 6
Assumptions................................................................................................. 7
Configuring the solution 9
Dell EMC storage considerations for Milestone XProtect Corporate...........10
Video Flow..................................................................................... 10
Live DB...........................................................................................10
Archive DB......................................................................................11
Storage considerations for Live DB and Archive DB........................11
Summary of Dell EMC storage and network protocols................... 12
Releases tested...........................................................................................13
Dell EMC storage configuration 15
Block storage (SAN, local).......................................................................... 16
File storage (NAS)...................................................................................... 16
XProtect-specific configuration 17
Configuring Active Directory and domain controller.................................... 18
Hard disk formatting................................................................................... 18
Enabling motion detection...........................................................................19
Modifying the number of archive process threads...................................... 19
Modifying the Archive DB write block size................................................. 20
Isilon OneFS for the Archive DB.................................................................. 21
OneFS 8.1 job workers (required)...................................................21
Multipathing and NIC failures...................................................................... 21
Conclusion 23
Summary.................................................................................................... 24
EMC VNX arrays............................................................................24
EMC VNX-VSS arrays................................................................... 24
EMC VNXe arrays..........................................................................24
Dell EMC Isilon scale-out storage.................................................. 24
Chapter 1
Chapter 2
Chapter 3
Chapter 4
Chapter 5
CONTENTS
Dell EMC Storage with Milestone XProtect Corporate 3

CONTENTS
4Dell EMC Storage with Milestone XProtect Corporate

CHAPTER 1
Introduction
This chapter presents the following topics:
lSolution overview.................................................................................................6
lPurpose................................................................................................................6
lScope...................................................................................................................6
lAssumptions.........................................................................................................7
Introduction 5

Solution overview
Milestone XProtect Corporate is a tiered solution that works well with Dell EMC
Unity™or EMC VNX™family storage arrays as well as Dell EMC Isilon™scale-out
storage. The first tier of storage, Live DB, can accommodate stored video for the
retention period prior to being moved to the second tier, of storage, Archive DB or
deleted. The best practice retention time is between 2 and 24 hours. The second
storage tier is Archive DB, which can accommodate long video retention cycles prior
to being deleted from the second tier of storage.
Live DB requires block storage, such as Dell EMC Unity or EMC VNX family arrays
using iSCSI or Fibre Channel (FC), or storage local to the server. In a virtualized
environment, the Unity or VNX family arrays can serve a dual purpose by providing
storage for the LiveDB and VMware datastores. The Archive DB used as the
secondary storage for video and surveillance data can be stored either on an Isilon
scale-out storage cluster or on a unique Unity or VNX family array.
While the Milestone XProtect Corporate tiered storage solution can be deployed
within a site, depending on the requirements XProtect Corporate can also provide a
solution for distributed to central site architectures.
Purpose
This configuration guide aims to help Dell EMC field personnel understand how to
configure Dell EMC storage system offerings to simplify the implementation of
Milestone XProtect Corporate. This document is not a replacement for the Milestone
implementation guide nor is it a replacement for the Dell EMC Storage with Milestone
XProtect Corporate: Sizing Guide .
Use this guide to determine the requirements for a successful Milestone XProtect
Corporate 2013, 2014, 2016 or 2017 installation, Milestone storage tiering options, and
storage-specific configuration requirements.
Scope
This guide is intended for internal Dell EMC personnel and qualified Dell EMC and
Milestone partners. It provides configuration instructions for installing the Milestone
XProtect Corporate video management software using Dell EMC storage platforms.
The following Dell EMC storage systems have been tested:
lEMC VSS™
This guide supplements the standard and provides configuration information specific
to Milestone XProtect Corporate.
Note
All performance data in this guide was obtained in a rigorously controlled environment.
Performance varies depending on the specific hardware and software used.
Introduction
6Dell EMC Storage with Milestone XProtect Corporate

Assumptions
This solution assumes that internal Dell EMC personnel and qualified Dell EMC
partners are using this guide with an established architecture.
This guide assumes that the Dell EMC partners who intend to deploy this solution are:
lAssociated with product implementation
lMilestone-certified to install Milestone XProtect Corporate services
lProficient in installing and configuring VNX/VNXe storage solutions
lProficient in installing and configuring Isilon storage solutions
lFamiliar with installing and configuring VMware hypervisors and the appropriate
operating system, such as Microsoft Windows or a Linux distribution
lAble to access the
EMC VNX Storage with Video Management Systems:
Configuration Guide and Dell EMC Isilon Storage with Video Management Systems:
Configuration Guide
The configurations that are documented in this guide are based on tests that we
conducted in the Dell EMC Surveillance Lab using worst-case scenarios to establish a
performance baseline. Lab results might differ from individual production
implementations.
Introduction
Assumptions 7

Introduction
8Dell EMC Storage with Milestone XProtect Corporate

CHAPTER 2
Configuring the solution
This chapter presents the following topics:
lDell EMC storage considerations for Milestone XProtect Corporate.................. 10
lReleases tested.................................................................................................. 13
Configuring the solution 9

Dell EMC storage considerations for Milestone XProtect
Corporate
To successfully design and implement a Milestone XProtect Corporate system, you
need to consider many aspects of the system, including networks, cameras, storage,
and more. This section presents storage considerations and recommendations you
should take into account when deploying a Milestone XProtect Corporate system on
Dell EMC storage platforms.
Video Flow
There are many Dell EMC storage platform options for each storage tier. The Live DB
can be direct-attached storage (DAS), such as FC or iSCSI block storage. The Archive
DB can be DAS if the storage requirement is minimal, and network-attached storage
(NAS), FC, or iSCSI for virtualized server implementations and more substantial video
storage requirements.
The following figure illustrates the video flow using NAS, DAS, and storage-area
network (SAN).
Figure 1 Milestone XProtect Corporate architecture
Video is initiated at the camera and XProtect initially places that video in the Live DB.
Milestone recommends a retention period of from 2 to 24 hours for video in the Live
DB, as outlined in Retention periods.
XProtect moves video files at rest from the Live DB storage tier to the Archive DB
storage tier at regular intervals. The Archive DB stores each video file until that file’s
full retention time has expired.
Live DB
XProtect’s Live DB write algorithm is optimized for block storage. Therefore, the Live
DB works best with the server’s internal DAS, or with external FC or iSCSI storage
arrays such as the VNX, VSS, and VNXe series.
Internal DAS storage is ideal for small implementations with a few servers. As an
installation grows, the need to optimize storage for reliability, scalability,
manageability, and rack space increases. In larger environments, and in virtualized
Configuring the solution
10 Dell EMC Storage with Milestone XProtect Corporate

server environments, VNX, VSS, and VNXe arrays in a SAN (FC or iSCSI)
configuration are more practical for the Live DB.
Archive DB
The Archive DB is the long-term storage for XProtect and typically constitutes the
majority of the storage capacity requirement. Moving video from the Live DB to the
Archive DB involves many activities, including optimizing index files for the larger
video repository, and moving the files.
Starting with XProtect Corporate 2013, support for NAS was added and shared
storage provided by an Isilon scale out storage cluster or block storage provided by a
VNX family storage array can be used.
Storage considerations for Live DB and Archive DB
The Live DB can be a VNX, VSS, or VNXe storage array in a SAN configuration. The
Archive DB can be an Isilon scale-out cluster in a NAS configuration or a VNX storage
array in a SAN configuration.
lWith the VNX, VSS, or VNXe, both the Live DB and Archive DB can use either FC
or iSCSI protocols. For iSCSI, you can use GigE or 10 GbE NICs.
lWhen using smaller VNX, VSS, or VNXe arrays with iSCSI, we recommend that the
Live DB and Archive DB reside on different arrays.
lWhen using FC, Live DB and an FC Archive DB can co-exist on the same VNX
array.
lArrays such as the VNX5800 can be used with iSCSI for both the Live DB and
Archive DB.
lVNX, VSS, or VNXe storage can be used for:
nLiveDB only
nLiveDB as the first tier in a tiered implementation
nArchive DB as the second tier in a tiered implementation
lFor Isilon scale-out storage, NAS can be used with Isilon OneFS™7.0 or higher.
Use the default Isilon protection scheme unless the customer needs additional
protection.
lYou can use GigE or 10 GbE network interface cards (NICs). Test results for this
solution are based on both GigE and 10 GbE interfaces on the Isilon cluster. By
default, XProtect moves video from the Live DB to the Archive DB using a single
thread. With NAS, you can increase the Archive DB thread count to allow parallel
video file moves within the archive process.
lWe recommend you avoid using Isilon storage for the LiveDB storage tier.
lAlthough it is possible to use the NFS datastores for the Milestone boot drive in a
VMware environment, this configuration with Milestone XProtect has not been
tested in the Dell EMC Surveillance Lab.
Retention periods
A Live DB retention period longer than 24 hours may result in prolonged recording
server restart, as the restart process includes verifying the index files for the retained
video recordings.
For this reason, Milestone recommends that the Live DB retention period be limited to
no more than 24 hours, with a higher frequency preferred. Milestone recommends a
minimum retention period of two hours for the Live DB, although a one hour retention
Configuring the solution
Archive DB 11

period is the minimum supported. The default Live DB retention period of four hours
has been satisfactory for our tests.
The Archive DB retention period depends on business requirements and can range
from a few weeks to many months. The archived video index files are not verified upon
recording server restart, so server restart is not a consideration for the Archive DB.
Summary of Dell EMC storage and network protocols
Live DB and Archive DB are two distinct repositories with different write
characteristics.
They were evaluated on individual storage platforms and on a single platform in the
following configurations:
lFor the Live DB we tested various Unity and VNX family arrays with both FC and
iSCSI storage protocols.
lFor the Archive DB we tested an Isilon scale-out cluster, Unity arrays, and VNX
family arrays with iSCSI.
lFor a single storage platform including both the Live DB and Archive DB, we tested
a VNX5800™with FC and iSCSI.
The following table lists the Dell EMC storage platforms and network protocols
determined to be suitable for each XProtect video database storage tier.
Table 1 Storage and protocols for XProtect database tiers
Array/cluster Database Protocol Verified
DAS Live DB DAS Yes (by Milestone)
VNX series Live DB FC Yes (functional test)
VNX series Live DB iSCSI Yes
Unity series Live DB iSCSI Yes
VNXe series Live DB iSCSI Yes
VSS series Live DB iSCSI Yes
DAS Archive DB DAS Yes (by Milestone)
Isilon clusters* Archive DB SMB2 Yes
VNX series Archive DB FC Yes (extrapolated)
VNX series Archive DB iSCSI Yes
VNXe series Archive DB iSCSI Yes
VSS series Archive DB iSCSI Yes
Unity series Archive DB iSCSI Yes
* Isilon OneFS releases prior to OneFS 7.0 are not recommended.
Configuring the solution
12 Dell EMC Storage with Milestone XProtect Corporate

Releases tested
The Dell EMC Surveillance Lab continually tests Milestone XProtect Corporate with
the latest Dell EMC storage offerings.
For a complete list of XProtect releases and Dell EMC Storage offerings that have
been tested, see the Dell EMC Surveillance Validiation Matrix
Configuring the solution
Releases tested 13

Configuring the solution
14 Dell EMC Storage with Milestone XProtect Corporate

CHAPTER 3
Dell EMC storage configuration
This chapter describes best practices for Dell EMC storage configurations.
lBlock storage (SAN, local)..................................................................................16
lFile storage (NAS)..............................................................................................16
Dell EMC storage configuration 15

Block storage (SAN, local)
VNX storage is ideal for recording and managing terabytes of video from distributed
locations. The VNX family includes the VNX and VNX-VSS series arrays. The VNX
series is designed for midtier to enterprise storage environments, is ideal for
distributed environments, and can scale to handle large petabyte (PB) environments
with blockonly requirements at central locations.
For information about best practices for configuring VNX storage, see EMC VNX
Storage Best Practices with Video Management Systems: Configuration Guide.
File storage (NAS)
The Isilon scale-out network-attached storage (NAS) platform combines modular
hardware with unified software to harness unstructured data. Powered by the
distributed Isilon OneFS®operating system, an Isilon cluster delivers a scalable pool of
storage with a global namespace.
The platform's unified software provides centralized web-based and command-line
administration to manage the following features:
lA symmetrical cluster that runs a distributed file system
lScale-out nodes that add capacity and performance
lStorage options that manage files and tiering
lFlexible data protection and high availability
lSoftware modules that control costs and optimize resources
For information about best practices for configuring Isilon storage, see Dell EMC Isilon
Storage Best Practices with Video Management Systems: Configuration Guide.
Dell EMC storage configuration
16 Dell EMC Storage with Milestone XProtect Corporate

CHAPTER 4
XProtect-specific configuration
This chapter describes best practices for system and XProtect Corporate
configuration.
Note
Internal server storage was not tested. If using server-based storage, refer to the
Milestone recommendations and best practices.
lConfiguring Active Directory and domain controller............................................18
lHard disk formatting...........................................................................................18
lEnabling motion detection.................................................................................. 19
lModifying the number of archive process threads.............................................. 19
lModifying the Archive DB write block size......................................................... 20
lIsilon OneFS for the Archive DB..........................................................................21
lMultipathing and NIC failures..............................................................................21
XProtect-specific configuration 17

Configuring Active Directory and domain controller
Although local user account authentication is available, we configured Active Directory
(AD) user account authentication in the lab to simplify user management.
AD is a distributed directory service included with several Windows Server operating
systems. It identifies resources on a network in order for users or applications to
access them. If you wish to add users through the AD service, you must have a server
with AD installed that acts as the domain controller on your network. Consult your
network administrator regarding the use of AD with your XProtect deployment.
Procedure
1. Ensure that there is a server with AD installed and acting as the domain
controller on the network.
2. Add all recording servers and management hosts to the available domain
controller.
3. Add the Isilon cluster to the available domain controller.
4. Log in as the Domain user on the host.
5. In Windows Services, select Milestone XProtect Corporate Recording
Server. Click the Log On tab and update the credentials for the Active
Directory user.
6. Restart the service.
Hard disk formatting
One factor that can impact a disk's performance in a video surveillance system is the
cluster size of the formatted hard disk.
Note
Update the allocation unit size when formatting the hard drive to significantly
improve the performance of the archive process.
Multi-tier implementation-Live DB
Change the allocation unit size setting from 4 to 8 KB when formatting
the hard disk for the Live DB in a two-tier structure. This block size is better
suited for the balanced reads and writes rate caused by the archive process.
Multi-tier implementation-Archive DB
Change the allocation unit size setting from 4 to 64 KB when formatting
the hard disk for the Archive DB. A 64 KB block size significantly improves the
performance of the archive process.
Single-tier implementation
Change theallocation unit size setting to 64 KB when formatting the
hard disk for the Live DB only.
See the Microsoft Support article Default cluster size for NTFS, FAT, and exFAT for
more information about single and multi-tier allocation unit sizes.
XProtect-specific configuration
18 Dell EMC Storage with Milestone XProtect Corporate

Enabling motion detection
If motion detection is not working, you must enable a new rule for motion detection.
Procedure
1. Disable the Default Record on Motion Rule on the management server.
2. Add a new rule named Record Always using the following definition:
Perform an action in a time interval
always
start recording immediately on All Cameras
Perform an action when time interval ends
stop recording immediately
Modifying the number of archive process threads
When using archive storage, such as NAS attached Isilon scale-out cluster, each
XProtect Corporate recording server must be modified to use either three or four
archive processes. By default, XProtect uses a single thread.
Procedure
1. Stop the Milestone XProtect Corporate Recording Server Service.
2. Go to: C:\ProgramData\Milestone\XProtect Recording Server.
3. Open the RecorderConfig file.
4. Edit the file as follows to change the low priority archive thread pool size to 3
and the high priority archive thread pool size to 4:
<thread_pools>
<delete_thread_pool_size>2</delete_thread_pool_size
<low_priority_archive_thread_pool_size>3</
low_priority_archive_thread_pool_size>
<high_priority_archive_thread_pool_size>4</
high_priority_archive_thread_pool_size>
</thread_pools>
5. Save the file.
6. Start the Milestone XProtect Corporate Recording Server Service.
Note
These steps apply to XProtect starting with version 2014.
XProtect-specific configuration
Enabling motion detection 19

Modifying the Archive DB write block size
When using archive storage, such as NAS attached Isilon scale-out cluster, the
Archive DB write block must be modified.
Procedure
1. Stop your Recording Server Services.
2. Rename the file %ProgramFiles%\Milestone\XProtect Corporate
Recording Server\VideoOS.Platform.Database.dll to, for example,
VideoOS.Platform.Database.dll,orig.
3. Open the file %ProgramData%\Milestone\XProtect Recording
Server\RecorderConfig.xml in an editor.
4. Update the disk utilization section. Use one of the following methods:
lFor Milestone version 2013 5.0, add the following xml code highlighted in
bold:
<disk_utilization>
<max_bytes_in_block_files>16777216</
max_bytes_in_block_files>
<max_records_in_block_files>2000</
max_records_in_block_files>
<truncate_block_files>true</truncate_block_files>
<precreate_block_files>true</precreate_block_files>
<precreate_sizes>
<regular>16777216</regular>
<sequence>65536</sequence>
<signature>4194304</signature>
</precreate_sizes>
<media_block_files use_os_cache="true">
<read_buffer_size>4096</read_buffer_size>
<write_buffer_size>4096</write_buffer_size>
</media_block_files>
<sequence_block_files use_os_cache="true">
<read_buffer_size>4096</read_buffer_size>
<write_buffer_size>4096</write_buffer_size>
</sequence_block_files>
<signature_block_files use_os_cache="true">
<read_buffer_size>4096</read_buffer_size>
<write_buffer_size>4096</write_buffer_size>
</signature_block_files>
<index_files use_os_cache="true">
<read_buffer_size>4096</read_buffer_size>
<write_buffer_size>4096</write_buffer_size>
</index_files>
<chunk_files use_os_cache="true">
<read_buffer_size>65536</read_buffer_size>
<write_buffer_size>65536</write_buffer_size> <!--
default 4096 -->
</chunk_files>
</disk_utilization>
lFor Milestone version 2013 R2 and later. Update the chunk_files
use_os_cache section. Modify the read_buffer_size and
write_buffer_size values to 65536.
<chunk_files use_os_cache="true">
<read_buffer_size>65536</read_buffer_size>
<write_buffer_size>65536</write_buffer_size> <!-- default
XProtect-specific configuration
20 Dell EMC Storage with Milestone XProtect Corporate
