HCM Series
ELECTRIC CONVECTOR HEATER
Instructions for use

2
300 mm (min.
)
263 mm (min.)
380 mm (min.)
Fig. 1
Fig. 3
B
A
F
E
G
G
D
D
H
H
C
Fig. 2

3
IMPORTANT WARNINGS
Safety warnings
Danger!
Failure to observe the warning may result in life threatening in-
jury by electric shock.
- This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way
and understand the hazards involved.
Childrenshallnotplaywiththeappliance.
Cleaning and user maintenance shall not
bemadebychildrenwithoutsupervision.
- Children of less than 3 years should
be kept away unless continuously
supervised.
- Children aged from 3 years and less
than 8 years shall only switch on/
o the appliance provided that it has
been placed or installed in its intended
normal operating position and they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved.
Children aged from 3 years and less
than 8 years shall not plug in, regulate
and clean the appliance or perform user
maintenance.
CAUTION — Some parts of this
product can become very hot and
cause burns. Particular attention
has to be given where children and
vulnerable people are present.
- When the heater is used with feet do
not use in the vicinity of bathtubs, wash
basins, showers, sinks and swimming
pools.
- If you intend to x your appliance to the
wall, make sure that the switch or other
control devices are not within reach of
persons in the bath or shower.
- If the power cable has been damaged, it
must be replaced by the manufacturer
or the technical service centre or by a
qualied person so as to avoid all risks.
- ATTENTION: in order to avoid any danger
caused by an accidental resetting of the
safety system, this appliance must not
be powered through an external timer.
- Do not use the appliance in small rooms
when they are occupied by persons that
are not capable of leaving the room,
unless constant supervision is provided.
Important!
Failure to observe the warning could result in injury or damage
to the appliance.
- The appliance must not be located
immediately below a xed socket-outlet.
- The use of an extension lead is not recommended, as
overheating of the extension lead may occur during the
operation of the heater.
Danger of burns!!
Failure to observe the warning could result in burns or scalds.
- WARNING: In order to avoid
overheating, never under any
circumstances cover the
appliances during operation, as this
would lead to dangerous overheating.
Please note:
This symbol indicates recommendations and important
information for the user.
- Never use the heater to dry laundry.
- Never place the power cable on top of the heater while it is
hot.
- We recommend that you not place the heater in a draught,
because strong draughts of air may adversely aect the
equipment’s operational eciency.

4
- Only use the heater in an upright position.
- The heater must be positioned at least 30cm from furniture
or other objects.
- The rst time you use the appliance, operate it of at least 15
minutes with the thermostat at maximum to eliminate the
“new”smell.
A little smoke due to the protective substances applied to
the heating element before transport may be given o.
- Do not position the appliance on long hair carpets, in order
to avoid obstruction to the air intake grille located under it.
- Do not obstruct the hot air outlet grilles or the air intake
grille on the bottom of the appliance.
- Position the appliance so that the plug and the outlet can
be easily reached even after installation.
- Do not use the appliance in rooms less than 4m2in
area.
- The appliance is tted with a safety device which will
switch the appliance o in case of accidental overheating.
To reset, disconnect the plug from the power socket for a
few minutes, remove the cause of overheating then plug
the appliance in again.
The appliance complies with the following EC directive:
- EEC Directive on electromagnetic compatibility (EMC) and
subsequent amendments;
Use in compliance with intended use
Use this heater only as described in this manual. All other use is
considered improper. This appliance is not suitable for
commercial use.
The manufacturer is not liable for damage deriving from
improper use of the appliance. This is a household appliance
only. It is not intended to be used in:
• staff kitchen areas in shops, offices and other working
environments;
• farm houses;
• by clients in hotels, motels and other residential type
environments;
• bed and breakfast type environments.
Use in this manner will invalidate the manufacturers warranty.
Fundamental recommendations regarding safety
Dear Customer – The plug on this appliance will get ‘warm’
during use, this is perfectly normal. This product is A HIGH
POWER HEATING APPLIANCE designed to our usual high
standards but please make sure your wall sockets are in good
condition and the plug is inserted correctly to avoid any
accidental overheating.
We suggest that you check the plug AND THE SOCKET regularly
if the heater is in prolonged use, if you are in any doubt please
consult an electrician.
INTRODUCTION
Thank you for choosing a De’Longhi product.
Please take a few moments to read the instructions to avoid risks
or damage to the appliance.
DESCRIPTION
A Feet
B Thermostat dial
C Switches
Electrical connection
- Before plugging into the mains, make sure the voltage of
your mains supply corresponds to the value V indicated on
the appliance and that the socket and power line are appro-
priate for the load required.
- THIS APPLIANCE COMPLIES WITH DIRECTIVE 2004/108/EC
ON ELECTROMAGNETIC COMPATIBILITY.
ATTACHING THE FEET
The feet kit consists of:
2 x feet
2 screws 3.9X13 PH
Tools necessary and estimated mounting time:
Phillips 2x100 screwdriver
Estimated time: 5 minutes
To mount the feet, proceed as follows:
- Turn the appliance upside down on a rug or soft surface to
avoid damaging the paint
- Fix the feet with the 2 screws provided as shown in g. 1.
- Turn the appliance back upright, positioning it with the feet
on the oor.
WALL MOUNTING
IMPORTANT: before making the holes in the wall, make
sure that:
a. the appliance is not positioned directly beneath a power
socket
b. after installation, the plug on the appliance reaches the
power socket easily
c. there are no electrical wires or pipes which could be
damaged during installation
d. the appliance is located at a safe distance from curtains or
other ammable material

5
The kit to wall mount your convector heater contains:
D2 top brackets
E 2 bottom brackets
F 2 screws 3.5x9.5 PH
G4 screws 4.5x25 PH
H4 plastic anchors 6x30
Tools necessary and estimated mounting time:
- Drill: 6 mm drill bit suitable for drilling the wall where the
appliance will be xed
- Phillips 2x100 screwdriver
- Estimated time: 30 minutes
Proceed as follows:
- Position the appliance on a stable surface and x the
brackets (E) on the back, using the two screws (F) provided,
as shown in g. 3.
- Mark the xing positions of the two brackets (D) following
the distances shown in g. 2.
- Drill the holes and insert the two anchors (H).
- Fix the brackets (D) as shown in g. 2 using the two screws
(G).
- Hang the heater on the brackets (D) xed previously.
- Mark the position of the bracket xing holes on the wall (E).
- Remove the heater, drill the holes at the points marked
previously, then insert the two remaining anchors.
- Hang the heater on the two top brackets (D) and block in
place by inserting the two screws (G) in the bottom anchors
inserted previously.
Your heater is now mounted on the wall.
OPERATION AND USE
Turning the appliance on
Models with only a thermostat
This appliance can be turned on by rotating its thermostat knob
clockwise (B) until it stops at the last possible setting. To turn this
appliance o, rotate the knob to its lowest position and remove
its plug from the electrical outlet.
Models with a thermostat and two switches
Turn the thermostat dial (B) clockwise to maximum, then press
the switches (C) so that the red zone is visible:
- button in position“I”only = minimum power
- button in position“II”only = medium power
- buttons in both positions“I”and“II”= maximum power
Adjusting the thermostat
When the room has reached the desired temperature, turn the
thermostat knob slowly in an anti-clockwise direction until you
get to the setting — and not beyond it — where you hear a
click.
The thermostat will then adjust that set temperature
automatically and keep it constant.
If your appliance is the type with 2 switches, you could
utilize only one of them during mild seasons and on days not
particularly cold. You will thus use little electrical power and
obtain even greater savings in energy consumption.
Anti-freeze function (only for models with a thermostat)
Turn the switch (or switches) to make the red area show, then
turn the thermostat knob to the setting. When so regulated,
this appliance will keep a room at a temperature of 5° C. while
consuming a minimum of energy.
MAINTENANCE
Always pull the plug out of its electrical outlet before beginning
any cleaning.
This electric convector requires no special maintenance. All
you have to do is dust it o with a soft, dry cloth — but do so
only when the appliance is cold. Never use abrasive powders or
solvents.
TECHNICAL CHARACTERISTICS
Power supply See rating label
Absorbed power “
