DeLonghi DCH1030 User manual

instructions
CERAMIC FAN HEATER
DCH1030
Please retain these instructions for future reference

DCH1030 2
Mode selector On light Thermostat

Thank you for choosing this De’Longhi heater. To get the
very best out of your new heater it is advisable to read
these instructions before using it.This will ensure that you
gain optimum results and use the appliance safely.
Electrical connection
- Before plugging the appliance into the mains, check that your
supply voltage is the same as that shown on the rating plate of
the appliance.
-If using more than one appliance at a time, it is important to
ensure that the ring main is adequate to cope with the power
requirements.
- It is important to ensure that the socket is adequately earthed.
- This appliance complies with EEC directive 89/336 regarding
electromagnetic compatibility.
INSTALLATION
The appliance can be used on any horizontal surface.
Do not overload the electrical circuit. Avoid using the same socket
for other appliances.
OPERATION AND USE
1. Make sure the appliance is off before plugging into the mains
2. Turn the appliance on by placing the thermostat in the Max position
and the mode selector in one of the following positions: 1/2.
-Summer mode (fan only): turn the mode selector to the
position.
-Minimum mode: turn the mode selector to the "1" position.
The red light comes on.
- Maximum mode: turn the mode selector to the "2" position.
- To turn the appliance off: turn the mode selector to the "●"
position.
Adjusting the thermostat
When the room has reached the required temperature, turn the
thermostat slowly until the red light goes off and no further.
The thermostat will then keep room temperature at the selected
level automatically.
Frost prevention mode
With the thermostat dial at minimum and the mode selector on
"2", the appliance maintains room temperature at about 5°C, pre-
venting freezing with minimal energy consumption.
DCH1030
3
*

Cleaning and maintenance
The heater should not required any maintenance. However before
attempting to clean the heater, remove the plug from the power
socket and allow the heater to cool. After the heater has cooled,
clean it with a soft damp cloth, do not use detergents or abrasives.
Periodically clean the air intake and outlet grilles during the period
in which the heater is in use with a vacuum cleaner. Should the
heater not be in use for a length of time, store it in a dry place.This
appliance has been built to provide many years of trouble free serv-
ice.
In case of malfunction, do not try to repair the heater yourself: it may
result in fire hazard or electric shock.
Warnings
-Do not use the heater in a bathroom or in the vicinity of bath-
tubs, wash basins, showers or swimming pools.
- Never use the heater to dry laundry.
-Only use the heater in an upright position.
-The heater must be positioned at least 50cm from walls, curtains,
furniture or other objects.
-If the supply cord is damaged, it must be replaced by the manu-
facturer, its service agent or similarly qualified persons in order
to avoid a hazard.
-Do not use this appliance in rooms which have a floor area small-
er than 4m2as this may lead to overheating.
- The heater must never be placed immediately under a fixed mains
socket.
- Never obstruct the heaters intake and outlet grilles as this could
cause dangerous overheating.
- IMPORTANT: Never for any reason cover the appliance during
operation as this could lead to dangerous overheating.
- A safety device intervenes and turns the appliance off and the pilot
light will switch on in the event of overheating. To reactivate the
heater, remove the plug from the mains, allow the appliance to
cool (for about 10 minutes), remove the cause of the overheating
and then plug the appliance back into the mains and turn it back
on.
- The use of an extension lead is not recommended, however if it is
necessary then follow carefully the extension lead’s instructions,
and most importantly ensure that the extension lead is carefully
rated in accordance with the radiator being used and NEVER
overloaded.
- In order to avoid any danger caused by an accidental resetting of
the safety system, this appliance must not be powered through an
external timer.
DCH1030 4

- As with any electrical appliance, whilst the instructions aim to
cover as many eventualities as possible, caution and common
sense should be applied when operating your appliance, particu-
larly in the vicinity of young children.
WARNING: In order to avoid overheating, never under
any circumstances cover the appliances during operation, as
this would lead to dangerous overheating.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL
OF THE PRODUCT IN ACCORDANCE WITH EC
DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be
disposed of as urban waste. It must be taken to a special
local authority differentiated waste collection centre or
to a dealer providing this service. Disposing of a house-
hold appliance separately avoids possible negative conse-
quences for the environment and health deriving from
inappropriate disposal and enables the constituent mate-
rials to be recovered to obtain significant savings in
energy and resources. As a reminder of the need to dis-
pose of household appliances separately, the product is
marked with a crossed-out wheeled dustbin.
DCH1030
5

DCH1030 6
Electrical requirements
Before using this appliance ensure that the voltage indicated
on the product corresponds with the main voltage in your
home, if you are in any doubt about your supply contact your
local electricity company.
The flexible mains lead is supplied connected to a B.S. 1363 fused plug
having a fuse of 13 amp capacity. Should this plug not fit the socket out-
lets in your home, it should be cut off and replaced with a suitable plug,
following the procedure outlined below.
Note: Such a plug cannot be used for any other appliance and should
therefore be properly disposed of and not left where children might find
it and plug it into a supply socket - with the obvious consequent danger.
N.B. We recommend the use of good quality plugs and wall sockets that
can be switched off when the machine is not in use.
important: the wires in the mains lead fitted to this appliance are
coloured in accordance with the following code:
As the colours of the wires in the mains lead of this appliance may not
correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:
The wire which is coloured green and yellow must be connected to the
terminal in the plug which is marked with the letter E or by the earth
symbol or coloured green or green and yellow.
The wire which is coloured blue must be connected to the terminal
which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the terminal
which is marked with the letter L or coloured red.
When wiring the plug, ensure that all strands of wire are securely
retained in each terminal. Do not forget to tighten the mains lead clamp
on the plug. If your electricity supply point has only two pin socket out-
lets, or if you are in doubt, consult a qualified electrician.
Should the mains lead ever require replacement, it is essential that this
operation be carried out by a qualified electrician and should only be
replaced with a flexible cord of the same size.
After replacement of a fuse in the plug, the fuse cover must be refitted.
If the fuse cover is lost, the plug must not be used until a replacement
cover is obtained. The colour of the correct replacement fuse cover is
that of the coloured insert in the base of the fuse recess or elsewhere
on the plug. Always state this colour when ordering a replacement fuse
cover.
Only 13amp replacement fuses which are asta approved to B.S. 1362
should be fitted.
This appliance conforms to the Norms EN 55014 regarding the sup-
pression of radio interference.
GREEN ANDYELLOW
BLUE
BROWN
EARTH
NEUTRAL
LIVE
Green and Yellow to Earth
Blue to
Neutral
13 amp
Fuse
Brown
to Live
Cord Clamp
Warning - this appliance
must be earthed

514IDL/03.06
