DeLonghi HVA Series User manual

De’Longhi Appliances via Seitz, 47 31100 Treviso Italia www.delonghi.com
5711413681_00_0218

HVA Series
FAN HEATER
Instructions for use
This product is only suitable for well insulated spaces or occasional use

23
A) If your appliance comes tted with a plug, it will incorporate a 13 Amp fuse. If it does not t your socket, the plug should
be cut o from the mains lead, and an appropriate plug tted, as below.
WARNING: Very carefully dispose of the cut o plug after removing the fuse: do not insert in a 13 Amp socket elsewhere
in the house as this could cause a shock hazard.
With alternative plugs not incorporating a fuse, the circuit must be re-tted when changing the fuse using a 13 Amp
Asta approved fuse to BS 1362. In the event of losing the fuse cover, the plug must NOT be used until a replacement
fuse cover can be obtained from your nearest electrical dealer. The colour of the correct replacement fuse cover is that as
marked on the base of the plug.
B) If your appliance is not tted with a plug, please follow the instructions provided below:
Important
The wires in the mains lead are coloured in accordance with the following code:
Blue: Neutral
Brown: Live
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.
ELECTRICAL CONNECTION

3
2250 mm
600 mm
600 mm
600 mm
AB
C
1
DESCRIPTION OF APPLIANCE

45
IMPORTANT WARNINGS
Safety warnings
Danger!
Failure to observe the warning may result in life threatening
injury by electric shock.
- The appliance must not be placed im-
mediately under a xed power socket.
- Do not use the appliance near show-
ers, bathtubs, sinks, swimming pools,
etc.
- If the power cable is damaged, it must
be replaced by the manufacturer, an
authorised service centre or a qualied
electrician in order to eliminate all risk.
Important!
Failure to observe the warning could result in injury or dam-
age to the appliance.
- This appliance can be used by children
aged from 8 years and above and per-
sons with reduced physical, sensory or
mental capabilities or lack of experi-
ence and knowledge if they have been
given supervision or instruction con-
cerning use of the appliance in a safe
way and understand the hazards in-
volved. Children shall not play with the
appliance. Cleaning and user mainte-
nance shall not be made by children
without supervision.
- Children of less than 3 years should be
kept away unless continuously super-
vised.
- Children aged from 3 years and less
than 8 years shall only switch on/o
the appliance provided that it has been
placed or installed in its intended nor-
mal operating position and they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved. Children aged from 3 years
and less than 8 years shall not plug
in, regulate and clean the appliance or
perform user maintenance.
CAUTION — Some parts of this
product can become very hot and
cause burns. Particular attention
has to be given where children
and vulnerable people are pres-
ent.
- CAUTION: To avoid the safety system
resetting accidentally, this appliance
must not be powered through an ex-
ternal on/o device such as a timer, or
connected to a circuit which is turned
o and on regularly by the energy sup-
plier.
- WARNING: Do not use this heater in
small rooms when they are occupied
by persons not capable of leaving the
room on their own, unless constant
supervision is provided.
Danger of burns!!
Failure to observe the warning could result in burns or scalds.
- WARNING: To avoid overheat-
ing, never under any circum-
stances cover the appliance
during operation as this would lead to
a dangerous rise in temperature.
- WARNING: to reduce the risk of re,
keep textiles, curtains, or any other
ammable material a minimum dis-
tance of 1 m from the air outlet.
Safety functions
-Safety device: the appliance is tted
with a safety device which switches it
o in the event of accidental overheat-
ing (e.g. obstruction of air intake and
outlet grilles, motor turning slowly or

5
not at all).
To reset, unplug the appliance from
the mains socket for a few minutes,
remove the cause of overheating then
plug in again. If the appliance doesn’t
work please contact the De’Longhi
Customer Service.
-Tip over safety device: Certain mod-
els are tted with a tip-over switch
which turns the appliance o if it falls
over. To restart the appliance, simply
place it upright again.
Please note:
This symbol indicates recommendations and important infor-
mation for the user.
- Use this heater on a horizontal and sta-
ble surface.
- Always use the appliance in an upright
position.
- Do not use this heater if it has been
dropped.
- Do not use if there are visible signs of
damage to the heater.
- The use of extension leads is not rec-
ommended.
However if they cannot be avoided,
follow the instructions accompanying
the extension lead and never exceed
the power limit marked on the exten-
sion.
- The heater must be positioned at least
50 cm from furniture or other objects.
- Do not use the appliance near walls,
furniture, curtains, etc.
- Do not use the appliance in rooms with
a oor area of less than 4m2.
- Before putting the appliance away,
make sure it is completely o and un-
plugged from the mains socket.
Do not store in dusty atmospheres.
- Do not rest anything on the appliance.
- Do not use the appliance to dry laun-
dry. Do not obstruct the air intake and
outlet area (danger of overheating).
- The appliance must not be hung.
- Some models are supplied with a de-
vice which delays of few seconds the
fan shut o.
Extra Europe market only:
- This appliance is not intended for use
by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been giv-
en supervision or instruction concern-
ing use of the appliance by a person
responsible for their safety.
Children should be supervised to en-
sure that they do not play with the
appliance.
Disposing of the appliance
The appliance must not be disposed
of with household waste, but taken
to an authorised waste separation
and recycling centre.
DESCRIPTION
(page 3)
A Thermostat
B Function selector
C Switches (only in certain models)
USE
Electrical connection
- Before plugging into the mains, make sure the voltage of
your mains supply corresponds to the value V indicated
on the appliance and that the socket and power line are
appropriate for the load required.
Functioning and use
MODELS WITH FUNCTION SELECTOR AND THERMOSTAT.
Make sure the appliance is o before plugging into the mains.

6TM
1. Plug into the mains.
2. Turn the thermostat dial to maximum.
3. Summer mode (fan only): turn the function selector to
the position.
4. Low power operation: turn the function selector to po-
sition 1.
5. Max power operation: turn the function selector to po-
sition 2.
6. Switching o: turn the function selector to the“0”posi-
tion.
Setting the thermostat
Position the thermostat on maximum.
When the room has reached the required temperature, turn
the thermostat dial slowly anticlockwise until you hear a click
and the fan goes o. The thermostat will then keep room
temperature at the selected level automatically.
Frost prevention mode
With the function selector in position 2 and the thermostat
dial in position , the appliance maintains room tempera-
ture at about 5°C, preventing freezing with minimal energy
consumption.
Models with thermostat only
To switch the appliance on turn the thermostat dial as far as
it will go to maximum position. To set refer to the paragraph
“Setting the thermostat”. To turn the appliance o comple-
tely, turn the dial anticlockwise to minimum, then unplug
from the mains socket.
MODELS WITH SWITCH
- Heating at low power: press switch (the red zone can
be seen on the switch).
- Heating at maximum power: press both switches ;
(the red zone can be seen on the switch).
- Turning o: turn o both switches.
We recommend unplugging the power cord when the ap-
pliance is not in use.
Please note: the maximum power is only active when
the switch is pressed.
MODELS WITH SWIVELLING BASE ON/OFF PEDAL
SWITCH
A number of models have a swivelling base and ON/OFF pedal
switch.
The appliance can be manually oriented to an angle of 30°
to the right or left to direct the air ow in the preferred di-
rection.
To turn the appliance on, set the thermostat dial and function
selector as described above, then press the pedal on the base.
To turn the appliance o, just press the pedal again.
Important! the appliance will come on only if you
press the pedal.
MAINTENANCE
- Always unplug from the mains socket before cleaning.
- Clean the air intake and outlet grilles regularly.
- Do not use abrasive products or solvents to clean the
appliance.
TECHNICAL CHARACTERISTICS
Supply voltage See rating plate
Absorbed power “
