Delta ME300 Series User manual

www.deltaww.com
*We reserve the right to change the information in this manual without prior notice.
Industrial Automation Headquarters
Taiwan: Delta Electronics, Inc.
Taoyuan Technology Center
No.18, Xinglong Rd., Taoyuan District,
Taoyuan City 33068, Taiwan
TEL:[phone] / FAX:[phone]
Asia
China: Delta Electronics (Shanghai)Co., Ltd.
No.182 Minyu Rd., Pudong Shanghai, P.R.C.
Post code : 201209
TEL: [phone] / FAX: [phone]
Customer Service: 400-820-9595
Japan: Delta Electronics (Japan), Inc.
Industrial Automation Sales Department
2-1-14 Shibadaimon, Minato-ku
Tokyo, Japan 105-0012
TEL: [phone] / FAX: [phone]
Korea: Delta Electronics (Korea), Inc.
1511, 219, Gasan Digital 1-Ro., Geumcheon-gu,
Seoul, 08501 South Korea
TEL: [phone] / FAX: [phone]
Singapore: Delta Energy Systems (Singapore)Pte Ltd.
4 Kaki Bukit Avenue 1, #05-04, Singapore 417939
TEL: [phone] / FAX: [phone]
India: Delta Electronics (India)Pvt. Ltd.
Plot No.43, Sector 35, HSIIDC Gurgaon,
PIN 122001, Haryana, India
TEL: [phone] / FAX: [phone]
Thailand: Delta Electronics (Thailand)PCL.
909 Soi 9, Moo 4, Bangpoo Industrial Estate (E . P. Z ),
Pattana 1 Rd., T.Phraksa, A.Muang,
Samutprakarn 10280, Thailand
TEL: [phone] / FAX: [phone]
Australia: Delta Electronics (Australia)Pty Ltd.
Unit 20-21/45 Normanby Rd., Notting Hill Vic 3168, Australia
TEL: [phone]
Americas
USA: Delta Electronics (Americas)Ltd.
5101 Davis Drive, Research Triangle Park, NC 27709, U.S.A.
TEL: [phone] / FAX: [phone]
Brazil: Delta Electronics Brazil
Rua Itapeva, 26 - 3°, andar Edicio Itapeva,
One -Bela Vista 01332-000 -São Paulo -SP -Brazil
TEL: [phone] / FAX: [phone]
Mexico: Delta Electronics International Mexico S.A. de C.V.
Gustavo Baz No. 309 Edicio E PB 103
Colonia La Loma, CP 54060
Tlalnepantla, Estado de México
TEL: [phone]
EMEA
EMEA Headquarters: Delta Electronics (Netherlands)B.V.
Sales: [e-mail]
Marketing: [e-mail]
Technical Support: [e-mail]
Customer Support: [e-mail]
Service: [e-mail]
TEL: [phone]
BENELUX: Delta Electronics (Netherlands)B.V.
Automotive Campus 260,5708 JZ Helmond, The Netherlands
Mail: [e-mail]
TEL: [phone]
DACH: Delta Electronics (Netherlands)B.V.
Coesterweg 45, D-59494 Soest,Germany
Mail: [e-mail]
TEL: [phone]
France: Delta Electronics (France)S.A.
ZI du bois Challand 2, 15 rue des Pyrénées,
Lisses, 91090 Evry Cedex, France
Mail: Sales.IA.[email protected]
TEL: [phone]
Iberia: Delta Electronics Solutions (Spain)S.L.U
Ctra. De Villaverde a Vallecas, 265 1º Dcha Ed.
Hormigueras – P.I. de Vallecas 28031 Madrid
TEL: [phone]
Carrer Llacuna 166, 08018 Barcelona, Spain
Mail: [e-mail]
Italy: Delta Electronics (Italy)S.r.l.
Via Meda 2–22060 Novedrate(CO)
Piazza Grazioli 18 00186 Roma Italy
Mail: Sales.IA.It[email protected]
TEL: [phone]
Russia: Delta Energy System LLC
Vereyskaya Plaza II, o󰀩ce 112 Vereyskaya str.
17 121357 Moscow Russia
Mail: [e-mail]
TEL: [phone]
Turkey: Delta Greentech Elektronik San. Ltd. Sti. (Turkey)
Şerifali Mah. Hendem Cad. Kule Sok. No:16-A
34775 Ümraniye – İstanbul
Mail: [e-mail]
TEL: + 90 216 499 9910
MEA: Eltek Dubai (Eltek MEA DMCC)
OFFICE 2504, 25th Floor, Saba Tower 1,
Jumeirah Lakes Towers, Dubai, UAE
Mail: [e-mail]
TEL: [phone]
Delta Basic Compact Drive
ME300 Series User Manual
Delta Basic Compact Drive - ME300 Series User Manual

I
Copyright notice
©Delta Electronics, Inc. All rights reserved.
All information contained in this user manual is the exclusive property of Delta Electronics Inc. (hereinafter
referred to as "Delta ") and is protected by copyright law and all other laws. Delta retains the exclusive
rights of this user manual in accordance with the copyright law and all other laws. No parts in this manual
may be reproduced, transmitted, transcribed, translated or used in any other ways without the prior consent
of Delta.
Limitation of Liability
The contents of this user manual are only for the use of the AC motor drives manufactured by Delta. Except
as defined in special mandatory laws, Delta provides this user manual “as is” and does not offer any kind
of warranty through this user manual for using the product, either express or implied, including but not
limited to the following: (i) this product will meet your needs or expectations; (ii) the information contained
in the product is current and correct; (iii) the product does not infringe any rights of any other person. You
shall bear your own risk to use this product.
In no event shall Delta, its subsidiaries, affiliates, managers, employees, agents, partners and licensors
be liable for any direct, indirect, incidental, special, derivative or consequential damages (including but not
limited to the damages for loss of profits, goodwill, use or other intangible losses) unless the laws contains
special mandatory provisions to the contrary.
Delta reserves the right to make changes to the user manual and the products described in the user
manual without prior notice and afterwards.

II
PLEASE READ PRIOR TO INSTALLATION FOR SAFETY.
Disconnect AC input power before connecting any wiring to the AC motor drive.
Even if the power has been turned off, a charge may still remain in the DC-link
capacitors with hazardous voltages before the POWER LED is OFF. Do not touch
the internal circuits and components.
There are highly sensitive MOS components on the printed circuit boards.
These components are especially sensitive to static electricity. Take anti-static
measures before touching these components or the circuit boards.
Never modify the internal components or wiring.
Ground the AC motor drive by using the ground terminal. The grounding method must
comply with the laws of the country where the AC motor drive is to be installed.
DO NOT install the AC motor drive in a location with high temperature, direct sunlight
or inflammable materials or gases.
Never connect the AC motor drive output terminals U/T1, V/T2 and W/T3 directly to
the AC mains circuit power supply.
The rated voltage of power system to install motor drives is listed below. Ensure that
the installation voltage is in the correct range when installing a motor drive.
For 115V models, the range is between 85–132 V.
For 230V models, the range is between 170–264 V.
For 460V models, the range is between 323–528 V.
Refer to the table below for short circuit rating:
Model (Power) Short circuit rating
115V 5 kA
230V 5 kA
460V 5 kA
Only qualified persons are allowed to install, wire and maintain the AC motor drives.
Even if the three-phase AC motor is stopped, a charge with hazardous voltages may
still remain in the main circuit terminals of the AC motor drive.
If you store the AC motor drive in a not-charged condition for more than three months,
the ambient temperature should not be higher than 30°C. Storage longer than one
year is not recommended and could result in the degradation of the electrolytic
capacitors.
Pay attention to the following when transporting and installing this package (including
wooden crate, wood stave and carton box).
1 If you need to sterilize or deworm the wooden crate or carton box, do not
use steamed sterilization or you will damage the VFD. Use other methods to
sterilize or deworm.
2 You may use high temperatures to sterilize or deworm. Leave the packaging
materials in an environment of over 56°C for thirty minutes.
Connect the drive to a three-phase three-wire or three-phase four-wire Wye system
to comply with UL standards.

III
If the drive generates leakage current over AC 3.5 mA or DC 10 mA on a grounding
conductor, compliance with local grounding regulations or IEC61800-5-1 standard is
the minimum requirement for grounding.
NOTE
1. In the pictures in this manual, the cover or safety shield is disassembled only when explaining the
details of the product. During operation, install the top cover and wiring correctly according to the
provisions. Refer to the operation descriptions in the manual to ensure safety.
2. The figures in this instruction are only for reference and may be slightly different depending on your
model, but it will not affect your customer rights.
3. The content of this manual may be revised without prior notice. Consult our distributors or download
the latest version at http://www.deltaww.com/iadownload_acmotordrive.

IV
Table of Contents
CHAPTER 1 INTRODUCTION................................................................................................................ 1-1
1-1 Nameplate Information.............................................................................................................1-2
1-2 Model Name.............................................................................................................................1-3
1-3 Serial Number..........................................................................................................................1-3
1-4 Apply After Service by Mobile Device......................................................................................1-4
1-5 RFI Jumper..............................................................................................................................1-5
CHAPTER 2 DIMENSIONS .................................................................................................................... 2-1
2-1 Frame A……….........................................................................................................................2-2
2-2 Frame B....................................................................................................................................2-3
2-3 Frame C....................................................................................................................................2-4
2-4 Frame D....................................................................................................................................2-5
CHAPTER 3 INSTALLATION ................................................................................................................. 3-1
3-1 Mounting Clearance.................................................................................................................3-2
3-2 Airflow and Power Dissipation..................................................................................................3-4
CHAPTER 4 WIRING.............................................................................................................................. 4-1
4-1 System Wiring Diagram……………..........................................................................................4-3
4-2 Wiring........................................................................................................................................4-4
CHAPTER 5 MAIN CIRCUIT TERMINALS ............................................................................................ 5-1
5-1 Main Circuit Diagram................................................................................................................5-4
5-2 Main Circuit Terminals..............................................................................................................5-5
CHAPTER 6 CONTROL TERMINALS ................................................................................................... 6-1
6-1 Control Terminals......................................................................................................................6-2
CHAPTER 7 OPTIONAL ACCESSORIES.............................................................................................. 7-1
7-1 Brake Resistors and Brake Units Used in AC Motor Drives.....................................................7-2
7-2 Magnetic Contactor / Air Circuit Breaker and Non-fuse Circuit Breaker...................................7-6
7-3 Fuse Specification Chart ........................................................................................................7-10
7-4 AC / DC Reactor.....................................................................................................................7-12
7-5 Zero Phase Reactors..............................................................................................................7-28
7-6 EMC Filter...............................................................................................................................7-31
7-7 EMC Shield Plate...................................................................................................................7-35
7-8 Capacitive Filter......................................................................................................................7-38
7-9 NEMA 1 / UL Type 1 Kit..........................................................................................................7-40
7-10 Fan Kit..................................................................................................................................7-47
7-11 DIN-Rail Mounting................................................................................................................7-48
7-12 Mounting Adapter Plate .......................................................................................................7-50
7-13 Digital Keypad–KPC-CC01, KPC-CE01...............................................................................7-55
CHAPTER 8 OPTION CARD .................................................................................................................. 8-1

V
CHAPTER 9 SPECIFICATION................................................................................................................9-1
9-1 115V Series..............................................................................................................................9-2
9-2 230V Series..............................................................................................................................9-3
9-3 460V Series..............................................................................................................................9-5
9-4 General Specifications..............................................................................................................9-6
9-5 Environment for Operation, Storage and Transportation..........................................................9-7
9-6 Derating for Ambient Temperature, Altitude and Carrier Frequency.........................................9-8
CHAPTER 10 DIGITAL KEYPAD..........................................................................................................10-1
10-1 Keyboard panel.....................................................................................................................10-2
10-2 Descriptions of keypad functions..........................................................................................10-2
10-3 Keypad operation process....................................................................................................10-3
10-4 Reference Table for the 16-segment Digital Keypad LED Display........................................10-7
CHAPTER 11 SUMMARY OF PARAMETERS SETTINGS .................................................................. 11-1
CHAPTER 12 DESCRIPTION OF PARAMETER SETTINGS .........................................................12-00-1
12-1 Description of Parameter Settings...................................................................................12-00-2
00 Drive Parameters....................................................................................................12.1-00-2
01 Basic Parameters...................................................................................................12.1-01-1
02 Digital Input / Output Parameters...........................................................................12.1-02-1
03 Analog Input / Output Parameters..........................................................................12.1-03-1
04 Multi-Stage Speed Parameters..............................................................................12.1-04-1
05 Motor Parameters...................................................................................................12.1-05-1
06 Protection Parameters (1) ......................................................................................12.1-06-1
07 Special Parameters................................................................................................12.1-07-1
08 High-function PID Parameters...........................................................................12.1-08-1
09 Communication Parameters...................................................................................12.1-09-1
10 Speed Feedback Control Parameters....................................................................12.1-10-1
11Advanced Parameters............................................................................................12.1-11-1
12 Function Parameters..............................................................................................12.1-12-1
13 Macro / User-Defined Macro...................................................................................12.1-13-1
14 Protection Parameters (2) ......................................................................................12.1-14-1
12-2 Adjustment & Application...................................................................................................12.2-1
CHAPTER 13 WARNING CODES ........................................................................................................13-1
CHAPTER 14 ERROR CODES.............................................................................................................14-1
CHAPTER 15 SAFE TORQUE OFF FUNCTION..................................................................................15-1
15-1 Basic Function Description....................................................................................................15-2
15-2 Safe Torque Off Terminal Function Description.....................................................................15-3
15-3 Wiring Diagram.....................................................................................................................15-4
15-4 Failure Rate of the Drive Safety Function.............................................................................15-5
15-5 Reset the Parameter Settings...............................................................................................15-5
15-6 Timing Diagram Description..................................................................................................15-6
15-7 Error Code and Troubleshooting Instructions........................................................................15-9
15-8 Test and Fault Confirmation.................................................................................................15-11

VI
Issued Edition: 03
Firmware Version: V1.XX (Refer to Parameter 00-06 on the product to get the firmware version.)
Issued Date: 2021/08

Chapter 1 IntroductionME300
1-1
Chapter 1 Introduction
1-1 Nameplate Information
1-2 Model Name
1-3 Serial Number
1-4 Apply After Service by Mobile Device
1-5 RFI Jumper

Chapter 1 IntroductionME300
1-2
After receiving the AC motor drive, check for the following:
1. Inspect the unit after unpacking to ensure that it was not damaged during shipment. Make sure that
the part number printed on the package corresponds with the part number indicated on the nameplate.
2. Make sure that the mains voltage is within the range indicated on the nameplate. Install the AC motor
drive according to this manual.
3. Before applying power, make sure that all devices, including mains power, motor, control board, and
digital keypad, are connected correctly.
4. When wiring the AC motor drive, make sure that the wiring of input terminals “R/L1, S/L2, T/L3”, and
output terminals "U/T1, V/T2, W/T3” are correct to prevent damage to the drive.
5. When power is applied, select the language and set values for parameters with the digital keypad.
When executing a trial run, begin with a low speed and then gradually increase the speed until the
desired speed is reached.
1-1 Nameplate Information

Chapter 1 IntroductionME300
1-3
1-2 Model Name
*1. For 230V input voltage (one-phase) and 460V input voltage (three-phase) models only.
1-3 Serial Number

Chapter 1 IntroductionME300
1-4
1-4 Apply After Service by Mobile Device
1-4-1 Location of Service Link Label
The service link label (Service Label) is pasted on the keypad area on the case body, as shown below.
Frame A, B Frame C, D
1-4-2 Service Link Label
Scan QR Code to apply for service
1. Locate the QR code sticker (as shown above).
2. Use a smartphone to run a QR Code reader App.
3. Point your camera at the QR Code. Hold your camera steady so that the QR code comes into focus.
4. Access the Delta After Service website.
5. Enter your information in the column marked with an orange star.
6. Enter the CAPTCHA and click Submit to complete the application.
Cannot find out the QR Code?
1. Open a web browser on your computer or smartphone.
2. In the browser address bar, enter https://service.deltaww.com/ia/repair and press Enter.
3. Enter your information in the columns marked with an orange star.
4. Enter the CAPTCHA and click Submit to complete the application.

Chapter 1 IntroductionME300
1-5
1-5 RFI Jumper
The drive contains Varistors / MOVs that are connected from phase to phase and from phase to ground to
protect the drive against mains surges or voltage spikes.
Because the Varistors / MOVs from phase to ground are connected to ground with the RFI jumper,
removing the RFI jumper disables the protection.
1. In models with a built-in EMC filter, the RFI jumper connects the filter capacitors to ground to form a
return path for high frequency noise. This isolates the noise from contaminating the mains power.
Removing the RFI jumper strongly reduces the effect of the built-in EMC filter.
2. Although a single drive complies with the international standards for leakage current, an installation
with several drives with built-in EMC filters can trigger the RCD. Removing the RFI jumper can help,
but the EMC performance of each drive is no longer guaranteed.
Frame A–D Screw Torque: 4–6 kg-cm / [3.5–5.2 lb-in.] / [0.39–0.59 Nm]
Loosen the screw and remove the RFI jumper (as shown below). Fasten the screw again after you remove
the RFI jumper.
Frame B–D (model with built-in EMC filter)
Remove the RFI jumper with a screwdriver (as shown below).

Chapter 1 IntroductionME300
1-6
Isolating main power from ground:
When the power distribution system for the drive is a floating ground system (IT Systems) or an asymmetric
ground system (Corner Grounded TN Systems), you must remove the RFI jumper. Removing the RFI
jumper disconnects the internal capacitors from ground to avoid damaging the internal circuits and to
reduce the ground leakage current.
Important points regarding the ground connection:
To ensure the safety of personnel, proper operation, and to reduce electromagnetic radiation, you must
properly ground the drive during installation.
The diameter of the cables must comply with the local safety regulations.
The shields of shielded cables must be connected to the ground of the drive to meet safety regulations.
The shields of shielded power cables can only be used as the ground for equipment when the above
points are met.
When installing more drives, do not connect the grounds of the drives in series but connect each drive
to ground. The following pictures show the correct and wrong ways to connect the grounds.
Pay particular attention to the following points:
Do not remove the RFI jumper while the power is on.
Removing the RFI jumper also disconnects the built-in EMC filter capacitors. Compliance with the EMC
specifications is no longer guaranteed.
Do not remove the RFI jumper if the mains power is a symmetrical grounded power system in order to
maintain the efficiency for EMC circuit.
Do not remove the RFI jumper while conducting high voltage tests. When conducting a high voltage
test to the entire facility, you must disconnect the mains power and the motor if the leakage current is
too high.
Floating Ground System (IT Systems)
A floating ground system is also called an IT system, an ungrounded system, or a high
impedance/resistance (greater than 30 Ω) grounded system.
Disconnect the RFI jumper.
Check whether there is excess electromagnetic radiation affecting nearby low-voltage circuits.
In some situations, the transformer and cable naturally provide enough EM radiation suppression. If in
doubt, install an extra electrostatic shielded cable on the power supply side between the main circuit
and the control terminals to increase security.
Do not install an external EMC filter. The EMC filter is connected to ground through the filter capacitors,
and connects the power input to ground. This is very dangerous and can easily damage the drive.

Chapter 1 IntroductionME300
1-7
Asymmetric Ground System (Corner Grounded TN Systems)
Caution: Do not remove the RFI jumper while there is power to the input terminal of the drive.
In the following four situations, you must remove the RFI jumper. This is to prevent the system from
grounding through the RFI and filter capacitors and damaging the drive.
You must remove the RFI jumper
1. Grounding at a corner in a triangle configuration
L2
L3
L1
2. Grounding at a midpoint in a polygonal
configuration
L2
L3
L1
3. Grounding at one end in a single-phase
configuration
L1
N
4. No stable neutral grounding in a three-phase
autotransformer configuration
L1
L2
L3
L1
L2
L3
You can use the RFI jumper
Internal grounding through RFI capacitors that reduce
electromagnetic radiation. In a symmetrically grounding
power system with higher EMC requirements, install an
EMC filter. As a reference, the diagram on the right is a
symmetrical grounding power system.
L2
L3
L1

Chapter 1 IntroductionME300
1-8
[This page intentionally left blank]

Chapter 2 DimensionsME300
2-1
Chapter 2 Dimensions
2-1 Frame A
2-2 Frame B
2-3 Frame C
2-4 Frame D

Chapter 2 DimensionsME300
2-2
2-1 Frame A
A1: VFD0A8ME11ANNAA; VFD0A8ME11ANSAA; VFD0A8ME21ANNAA; VFD0A8ME21ANSAA;
VFD0A8ME23ANNAA; VFD0A8ME23ANSAA; VFD1A6ME11ANNAA; VFD1A6ME11ANSAA;
VFD1A6ME21ANNAA; VFD1A6ME21ANSAA; VFD1A6ME23ANNAA; VFD1A6ME23ANSAA
A2: VFD2A8ME23ANNAA; VFD2A8ME23ANSAA
A3: VFD2A5ME11ANNAA; VFD2A5ME11ANSAA; VFD2A8ME21ANNAA; VFD2A8ME21ANSAA
A4: VFD1A5ME43ANNAA; VFD1A5ME43ANSAA
A5: VFD4A8ME23ANNAA; VFD4A8ME23ANSAA
A6: VFD2A7ME43ANNAA; VFD2A7ME43ANSAA
Unit: mm [inch]
Frame W H D W1 H1 D1 S1
A1 68.0 [2.68] 128.0 [5.04] 78.0 [3.07] 56.0 [2.20] 118.0 [4.65] 3.0 [0.12] 5.2 [0.20]
A2 68.0 [2.68] 128.0 [5.04] 92.0 [3.62] 56.0 [2.20] 118.0 [4.65] 3.0 [0.12] 5.2 [0.20]
A3 68.0 [2.68] 128.0 [5.04] 107.0 [4.21] 56.0 [2.20] 118.0 [4.65] 3.0 [0.12] 5.2 [0.20]
A4 68.0 [2.68] 128.0 [5.04] 113.0 [4.45] 56.0 [2.20] 118.0 [4.65] 3.0 [0.12] 5.2 [0.20]
A5 68.0 [2.68] 128.0 [5.04] 125.0 [4.92] 56.0 [2.20] 118.0 [4.65] 3.0 [0.12] 5.2 [0.20]
A6 68.0 [2.68] 128.0 [5.04] 127.0 [5.00] 56.0 [2.20] 118.0 [4.65] 3.0 [0.12] 5.2 [0.20]

Chapter 2 DimensionsME300
2-3
2-2 Frame B
B1: VFD7A5ME23ANNAA; VFD7A5ME23ANSAA; VFD4A2ME43ANNAA; VFD4A2ME43ANSAA
B2: VFD4A8ME21ANNAA; VFD4A8ME21ANSAA
B3: VFD0A8ME21AFNAA; VFD0A8ME21AFSAA; VFD1A6ME21AFNAA; VFD1A6ME21AFSAA;
VFD2A8ME21AFNAA; VFD2A8ME21AFSAA; VFD4A8ME21AFNAA; VFD4A8ME21AFSAA;
VFD1A5ME43AFNAA; VFD1A5ME43AFSAA; VFD2A7ME43AFNAA; VFD2A7ME43AFSAA;
VFD4A2ME43AFNAA; VFD4A2ME43AFSAA
Unit: mm [inch]
Frame W H D W1 H1 D1 S1
B1 72.0 [2.83] 142.0 [5.59] 127.0 [5.00] 60.0 [2.36] 130.0 [5.12] 6.4 [0.25] 5.2 [0.20]
B2 72.0 [2.83] 142.0 [5.59] 127.0 [5.00] 60.0 [2.36] 130.0 [5.12] 3.0 [0.12] 5.2 [0.20]
B3 72.0 [2.83] 142.0 [5.59] 143.0 [5.63] 60.0 [2.36] 130.0 [5.12] 4.3 [0.17] 5.2 [0.20]

Chapter 2 DimensionsME300
2-4
2-3 Frame C
C1: VFD4A8ME11ANNAA; VFD4A8ME11ANSAA; VFD7A5ME21ANNAA; VFD7A5ME21ANSAA;
VFD11AME21ANNAA; VFD11AME21ANSAA; VFD11AME23ANNAA; VFD11AME23ANSAA;
VFD17AME23ANNAA; VFD17AME23ANSAA; VFD5A5ME43ANNAA; VFD5A5ME43ANSAA;
VFD7A3ME43ANNAA; VFD7A3ME43ANSAA; VFD9A0ME43ANNAA; VFD9A0ME43ANSAA
C2: VFD7A5ME21AFNAA; VFD7A5ME21AFSAA; VFD11AME21AFNAA; VFD11AME21AFSAA;
VFD5A5ME43AFNAA; VFD5A5ME43AFSAA; VFD7A3ME43AFNAA; VFD7A3ME43AFSAA;
VFD9A0ME43AFNAA; VFD9A0ME43AFSAA
Unit: mm [inch]
Frame W H D W1 H1 D1 S1
C1 87.0 [3.43] 157.0 [6.18] 136.0 [5.35] 73.0 [2.87] 144.5 [5.69] 5.0 [0.20] 5.5 [0.22]
C2 87.0 [3.43] 157.0 [6.18] 163.0 [6.42] 73.0 [2.87] 144.5 [5.69] 5.0 [0.20] 5.5 [0.22]

Chapter 2 DimensionsME300
2-5
2-4 Frame D
D1: VFD25AME23ANNAA; VFD25AME23ANSAA; VFD13AME43ANNAA; VFD13AME43ANSAA;
VFD17AME43ANNAA; VFD17AME43ANSAA
D2: VFD13AME43AFNAA; VFD13AME43AFSAA; VFD17AME43AFNAA; VFD17AME43AFSAA
Unit: mm [inch]
Frame W H D W1 H1 D1 S1
D1 109.0 [4.29] 207.0 [8.15] 138.0 [5.43] 94.0 [3.70] 193.8 [7.63] 6.0 [0.24] 5.5 [0.22]
D2 109.0 [4.29] 207.0 [8.15] 171.0 [6.73] 94.0 [3.70] 193.8 [7.63] 6.0 [0.24] 5.5 [0.22]
