Delta Vector Control Drive
C2000 (690V) Series User Manual
www.deltaww.com
Delta Vector Control Drive C2000 (690 V ) Series User Manual
5014043600-C6E0-201606

I
PLEASE READ PRIOR TO INSTALLATION FOR SAFETY.
'$1*(
5
;AC input power must be disconnected before any wiring to the AC motor drive is made.
;Even if the power has been turned off, a charge may still remain in the DC-link
capacitors with hazardous voltages before the POWER LED is OFF. Please do not
touch the internal circuit and components.
;There are highly sensitive MOS components on the printed circuit boards. These
components are especially sensitive to static electricity. Please do not touch these
components or the circuit boards before taking anti-static measures. Never reassemble
internal components or wiring.
;Ground the AC motor drive using the ground terminal. The grounding method must
comply with the laws of the country where the AC motor drive is to be installed.
;DO NOT install the AC motor drive in a place subjected to high temperature, direct
sunlight and inflammables.
&$8 7,21
;Never connect the AC motor drive output terminals U/T1, V/T2 and W/T3 directly to the
AC mains circuit power supply.
;Only qualified persons are allowed to install, wire and maintain the AC motor drives.
;Even if the 3-phase AC motor is stop, a charge may still remain in the main circuit
terminals of the AC motor drive with hazardous voltages.
;If the AC motor drive is stored in no charge condition for more than 3 months, the
ambient temperature should not be higher than 30 °C. Storage longer than one year is
not recommended, it could result in the degradation of the electrolytic capacitors.
;Pay attention to the following when transporting and installing this package (including
wooden crate, wood stave and carton box)
1. If you need to sterilize, deform the wooden crate or carton box, please do not
use steamed smoking sterilization or you will damage the VFD.
2. Please use other ways to sterilize or deform.
3. You may use high temperature to sterilize or deform. Leave the packaging
materials in an environment of over 56ɗfor 30 minutes.
4. It is strictly forbidden to use steamed smoking sterilization. The warranty does
not covered VFD damaged by steamed smoking sterilization.
127(
The content of this manual may be revised without prior notice. Please consult our distributors or download the latest version at
http://www.deltaww.com/services/DownloadCenter2.aspx?secID=8&pid=2&tid=0&CID=06&itemID=060101&typeID=1&downloadI
D=&title=&dataType=&check=0&hl=en-US

II
7DEOHRI&RQWHQWV
&+$37(5,1752'8&7,21
1-1 Receiving and Inspection..................................................................................................1-2
1-2 Nameplate Information.....................................................................................................1-2
1-3 Model Name....................................................................................................................1-3
1-4 Serial Number.................................................................................................................1-3
1-5 RFI Jumper.....................................................................................................................1-4
1-6 Dimensions.....................................................................................................................1-7
&+$37(5,167$//$7,21 
&+$37(5029,1*813$&.,1*
3-1 Unpacking.........................................................................................................................3-2
3-2 The Lifting Hook..............................................................................................................3-13
&+$37(5:,5,1*
4-1 Wiring...............................................................................................................................4-3
4-2 System Wiring Diagram.....................................................................................................4-8
&+$37(50$,1&,5&8,77(50,1$/6 
5-1 Main Circuit Diagram.........................................................................................................5-4
5-2 Main Circuit Terminals.......................................................................................................5-7
&+3$7(5&21752/7(50,1$/6
6-1 Specifications of Control Terminal........................................................................................6-6
6-2 Remove the Terminal Block................................................................................................6-9
&+$37(5237,21$/ $&&(6 625,(6
7-1 All Brake Resistors and Brake Units Used in AC Motor Drives................................................7-2
7-2 Non-fuse Circuit Breaker....................................................................................................7-5
7-3 Fuse Specification Chart ....................................................................................................7-6
7-4 AC/DC Reactor..................................................................................................................7-7
7-5 Zero Phase Reactor.........................................................................................................7-14
7-6 EMI Filter........................................................................................................................7-16
7-7 Digital Keypad.................................................................................................................7-18
7-8 Panel Mounting...............................................................................................................7-22
7-9 Conduit Box Kit...............................................................................................................7-24
7-10 Fan Kit.........................................................................................................................7-30

III
7-11 Flange Mounting Kit ......................................................................................................7-41
7-12 USB/RS-485 Communication Interface IFD6530…........................................................7-54
&+$37(5237,21&$5'6
8-1 Removed key cover...........................................................................................................8-2
8-2 Screws Specification for Option Card Terminals....................................................................8-5
8-3 EMC-D42A......................................................................................................................8-10
8-4 EMC-D611A....................................................................................................................8-10
8-5 EMC-R6AA.....................................................................................................................8-10
8-6 EMC-BPS01....................................................................................................................8-11
8-7 EMC-PG01/02L...............................................................................................................8-12
8-8 EMC-PG01/02O..............................................................................................................8-15
8-9 EMC-PG01/02U...............................................................................................................8-18
8-10 EMC-PG01R.................................................................................................................8-20
8-11 CMC-MOD01.................................................................................................................8-23
8-12 CMC-PD01....................................................................................................................8-27
8-13 CMC-DN01....................................................................................................................8-29
8-14 CMC-EIP01...................................................................................................................8-32
8-15 EMC-COP01.................................................................................................................8-37
&+$37(563(&,),&$7,21
9-1 575V Series…………………………………...........................................................................9-2
9-2 690V Series…………………………………...........................................................................9-3
9-3 Environment for Operation, Storage and Transportation………………………….......................9-5
9-4 Specification for Operation Temperature and Protection Level…….........................................9-6
9-5 Derating of Ambient Temperature and Altitude………………………........................................9-7
&+$37(5',*,7$/.(<3$'
10-1 Descriptions of Digital Keypad ………………………………….............................................10-2
10-2 Function of Digital Keypad KPC-CC01.............................................................................10-5
10-3 TPEditor Installation Instruction ....................................................................................10-23
10-4 Fault Code Description of Digital Keypad KPC-CC01.......................................................10-36
&+$37(56800$53<2)3$5$0(7(56
&+$37(5'(6&5,37,212)3$5$0(7(56(77,1*6
&+$37(5:$51,1*&2'(6
&+$37(5)$8/7&2'(6$1''(6&5,37,216

IV
&+$37(5&$123(129(59,(:
&+$37(53/&)81&7,21
&+$37(56$)(7<72548(2)))81&7,21««««««««««««««««««««««


$SSOLFDWLRQ  &RQWURO%RDUG9
 .H\SDG9


Chapter 1 Introduction_& 9 6HULHV
1-1
Chapter 1 Introduction

1-1 Receiving and Inspection
1-2 Nameplate Information
1-3 Model Name
1-4 Serial Number
1-5 RFI Jumper
1-6 Dimensions

Chapter 1 Introduction_&96HULHV
1-2
5HFHLYLQJDQG,QVSHFWLRQ
After receiving the AC motor drive, please check for the following:
1. Please inspect the unit after unpacking to assure it was not damaged during shipment. Make sure
that the part number printed on the package corresponds with the part number indicated on the
nameplate.
2. Make sure that the voltage for the wiring lie within the range as indicated on the nameplate. Please
install the AC motor drive according to this manual.
3. Before applying the power, please make sure that all the devices, including power, motor, control
board and digital keypad, are connected correctly.
4. When wiring the AC motor drive, please make sure that the wiring of input terminals “R/L1, S/L2,
T/L3” and output terminals”U/T1, V/T2, W/T3” are correct to prevent drive damage.
5. When power is applied, select the language and set parameter groups via the digital keypad
(KPC-CC01). When executes trial run, please begin with a low speed and then gradually increases
the speed untill the desired speed is reached.
1DPHSODWH,QIRUPDWLRQ
02'(/9)'&%
9HUVLRQ 
DELTA ELECT RON ICS, INC.
X.XX 370C63B6W11490001
⚳晃娵嫱㧁䣢⋨烊
⚳晃娵嫱㧁䣢⋨烊
Ce rt ific ations
⸷嘇烊
⸷嘇烊
Serial number
㨇䧖⎵䧙烊
㨇䧖⎵䧙烊
Mo del name
廠ℍ䪗暣⡻İ暣㳩䭬⚵烊
廠ℍ䪗暣⡻İ 暣㳩䭬⚵烊
I nput voltag e/c urre nt
廠↢䪗暣⡻İ暣㳩䭬⚵烊
廠↢䪗暣⡻İ 暣㳩䭬⚵烊
Outpu t volt age/c urrent
柣䌯䭬⚵烊
柣䌯䭬⚵烊
Frequency range
杴橼䇰㛔烊
杴橼䇰㛔烊
Firmware version
En closure (IPXX)✳ン 婒 㖶 ⋨烊
Enclo sure(IP XX)✳ン婒㖶⋨烊
E nclosure type (IP XX)
䓇䓊嬀⇍烊
⭏ӗ䇶࡛烊
P
r
o
d
u ct i
d
e
n
t
ific
a
t
i
o
n

Chapter 1 Introduction_& 9 6HULHV
1-3
0RGHO1DPH
V
F
D 3
7
0 C 6 3 B -
X
X
6HULDO1XPEHU
3
7
0C6
3
B6 W 11 4 9 000
1

Chapter 1 Introduction_&96HULHV
1-4
5),-XPSHU
RFI Jumper: The AC motor drive may emit the electrical noise. The RFI jumper is used to suppress the
interference (Radio Frequency Interference) on the power line.
Frame A~C
Screw Torque: 8~10kg-cm(6.9-8.7 lb -in.) ( 0.78~0.98 Nm)
Loosen the screws and remove the MOV-PLATE. Fasten the screws back to the original position after
MOV-PLATE is removed.
Frame D~H
Remove the MOV-PLATE by hands, no screws need to be loosen.

Chapter 1 Introduction_& 9 6HULHV
1-5
Isolating main power from ground:
When the power distribution system of the Power Regenerative Unit is a floating ground system (IT) or an
asymmetric ground system (TN), the RFI short short-circuit cable must be cut off. Cutting off the
short-circuit cable cuts off the internal RFI capacitor (filter capacitor) between the system's frame and the
central circuits to avoid damaging the central circuits and (according to IEC 61800-3) reduce the ground
leakage current.
Important points regarding ground connection
;To ensure the safety of personnel, proper operation, and to reduce electromagnetic radiation, the
Power Regenerative Unit must be properly grounded during installation.
;The diameter of the cables must meet the size specified by safety regulations.
;The shielded cable must be connected to the ground of the Power Regenerative Unit to meet safety
regulations.
;The shielded cable can only be used as the ground for equipment when the aforementioned points
are met.
;When installing multiple sets of Power Regenerative Units, do not connect the grounds of the Power
Regenerative Units in series. As shown below.
Wrong wiring setup for ground wires
Ground terminal
Pay particular attention to the following points:
;After turning on the main power, do not remove the RFI jumper while the power is on.
;Make sure the main power is turned off before removing the RFI jumper.
;Removing the RFI jumper will also cut off the conductivity of the capacitor. Gap discharge may occur
once the transient voltage exceeds 1000V.
;If the RFI jumper is removed, there will no longer be reliable electrical isolation. In other words, all
controlled input and outputs can only be seen as low-voltage terminals with basic electrical isolation.
Also, when the internal RFI capacitor is cut off, the Power Regenerative Unit will no longer be
electromagnetic compatible.
;The RFI jumper may not be removed if the main power is a grounded power system.
;The RFI jumper may not be removed while conducting high voltage tests. When conducting a high
voltage test to the entire facility, the main power and the motor must be disconnected if leakage
current is too high.
Floating Ground System(IT Systems)
A floating ground system is also called IT system, ungrounded system, or high impedance/resistance
(greater than 30) grounding system.
;Disconnect the ground cable from the internal EMC filter.
;In situations where EMC is required, check whether there is excess electromagnetic radiation
affecting nearby low-voltage circuits. In some situations, the adapter and cable naturally provide
enough suppression. If in doubt, install an extra electrostatic shielded cable on the power supply side
between the main circuit and the control terminals to increase security.
;Do not install an external RFI/EMC filter, the EMC filter will pass through a filter capacitor, thus
connecting power input to ground. This is very dangerous and can easily damage the Power
Regenerative Unit.

Chapter 1 Introduction_&96HULHV
1-6
Asymmetric Ground System(Corner Grounded TN Systems)
Caution: Do not remove the RFI jumper while the input terminal of the Power Regenerative Unit carries
power.
In the following four situations, the RFI jumper must be removed. This is to prevent the system from
grounding through the RFI capacitor, damaging the Power Regenerative Unit.
RFI jumper must be removed
1. Grounding at a corner in a triangle configuration
L2
L3
L
1
2. Grounding at a midpoint in a polygonal
configuration
L2
L3
L
1
3. Grounding at one end in a single-phase
configuration
L
1
N
4. No stable neutral grounding in a three-phase
autotransformer configuration
L1
L2
L3
L1
L2
L3
RFI jumper can be used
Internal grounding through RFI capacitor, which reduces
electromagnetic radiation. In a situation with higher
requirements for electromagnetic compatibility, and using a
symmetrical grounding power system, an EMC filter can be
installed. As a reference, the diagram on the right is a
symmetrical grounding power system.
L2
L3
L
1

Chapter 1 Introduction_& 9 6HULHV
1-7
'LPHQVLRQV
Frame A
VFD015C53A-21; VFD022C53A-21; VFD037C53A-21
Unit: mm [inch]
Frame W H D W1 H1 D1* S1 ĭ1 ĭ2 ĭ3
A1 130.0
[5.12]
250.0
[9.84]
170.0
[6.69]
116.0
[4.57]
236.0
[9.29]
45.8
[1.80]
6.2
[0.24]
22.2
[0.87]
34.0
[1.34]
28.0
[1.10]
D1*: Flange mounting

Chapter 1 Introduction_&96HULHV
1-8
Frame B
VFD055C53A-21; VFD075C53A-21; VFD110C53A-21; VFD150C53A-21
Detail A (Mounting Hole)
Detail B (Mounting Hole)
See Detail A
See Detail B
Unit: mm [inch]
Frame W H D W1 H1 D1* S1 ĭ1 ĭ2 ĭ3
B1 190.0
[7.48]
320.0
[12.60]
190.0
[7.48]
173.0
[6.81]
303.0
[11.93]
77.9
[3.07]
8.5
[0.33]
22.2
[0.87]
34.0
[1.34]
43.8
[1.72]
D1*: Flange mounting

Chapter 1 Introduction_& 9 6HULHV
1-9
Frame C
VFD185C63B-21;VFD220C63B-21;VFD300C63B-21;VFD370C63B-21
Detail A (Mounting Hole)
Detail B (Mounting Hole)
See Detail A
See Detail B
Unit: mm [inch]
Frame W H D W1 H1 D1* S1 ĭ1 ĭ2 ĭ3
C1 250.0
[9.84]
400.0
[15.75]
210.0
[8.27]
231.0
[9.09]
381.0
[15.00]
92.9
[3.66]
8.5
[0.33]
22.2
[0.87]
34.0
[1.34]
50.0
[1.97]
D1*: Flange mounting

Chapter 1 Introduction_&96HULHV
1-10
Frame D
D1: VFD450C63B-00; VFD550C63B-00
W
W1
H1
H2
S1S1
SEE DETAIL A
DETAIL A
(MOUNTING HOLE)
DETAIL B
(MOUNTING HOLE)
SEE DETAIL B
D
H3
D1
S2
D2
Unit: mm [inch]
D1*: Flange mounting
Frame W H D W1 H1 H2 H3 D1* D2 S1 S2 ĭ1 ĭ2 ĭ3
D1
330.0
[12.99] - 275.0
[10.83]
285.0
[11.22]
550.0
[21.65]
525.0
[20.67]
492.0
[19.37]
107.2
[4.22]
16.0
[0.63]
11.0
[0.43]
18.0
[0.71] - - -

Chapter 1 Introduction_& 9 6HULHV
1-11
Frame D
D2: VFD450C63B-21; VFD550C63B-21
W
W1
1
2
3
H
H1
H2
S1S1
SEE DETAIL A
DETAIL A
(MOUNTING HOLE)
DETAIL B
(MOUNTING HOLE)
SEE DETAIL B
3
2
1
D
H3
D1
S2
D2
Unit: mm [inch]
D1*: Flange mounting
Frame W H D W1 H1 H2 H3 D1* D2 S1 S2 ĭ1 ĭ2 ĭ3
D2
330.0
[12.99]
688.3
[27.10]
275.0
[10.83]
285.0
[11.22]
550.0
[21.65]
525.0
[20.67]
492.0
[19.37]
107.2
[4.22]
16.0
[0.63]
11.0
[0.43]
18.0
[0.71]
76.2
[3.00]
34.0
[1.34]
22.0
[0.87]

Chapter 1 Introduction_&96HULHV
1-12
Frame E
E1: VFD750C63B-00; VFD900C63B-00; VFD1100C63B-00; VFD1320C63B-00
W1
W
H2
H1
H3
D1
D
Unit: mm [inch]
Frame W H D W1 H1 H2 H3 D1* D2 S1, S2 S3 Ɏ1 Ɏ2 Ɏ3
E1 370.0
[14.57] - 300.0
[11.81]
335.0
[13.19
589
[23.19]
560.0
[22.05]
528.0
[20.80]
143.0
[5.63]
18.0
[0.71]
13.0
[0.51]
18.0
[0.71] - - -
D1*: Flange mounting

Chapter 1 Introduction_& 9 6HULHV
1-13
Frame E
E2: VFD750C63B-21; VFD900C63B-21; VFD1100C63B-21; VFD1320C63B-21
W1
W
H2
H1
H3
H
D1
D
ŀ
ŀ
ŀ
ŀ
ŀ
ŀ
ŀ
ŀ
Unit: mm [inch]
Frame W H D W1 H1 H2 H3 D1* D2 S1, S2 S3 Ɏ1 Ɏ2 Ɏ3
E2 370.0
[14.57]
715.8
[28.18]
300.0
[11.81]
335.0
[13.19
589
[23.19]
560.0
[22.05]
528.0
[20.80]
143.0
[5.63]
18.0
[0.71]
13.0
[0.51]
18.0
[0.71]
22.0
[0.87]
34.0
[1.34]
92.0
[3.62]
D1*: Flange mounting

Chapter 1 Introduction_&96HULHV
1-14
Frame F
F1: VFD1600C63B-00; VFD2000C63B-00
H1
H2
S1
S1
W
W1
S2
See Detail A
See Detail B
Detail A (Mounting Hole)
Detail B (Mounting Hole)
D2
D
D1
H3
S3
Unit: mm [inch]
Frame W H D W1 H1 H2 H3 D1* D2 S1 S2 S3
F1 420.0
[16.54] - 300.0
[11.81]
380.0
[14.96]
800.0
[31.50]
770.0
[30.32]
717.0
[28.23]
124.0
[4.88]
18.0
[0.71]
13.0
[0.51]
25.0
[0.98]
18.0
[0.71]
D1*: Flange mounting

Chapter 1 Introduction_& 9 6HULHV
1-15
Frame F
F2: VFD1600C63B-21; VFD2000C63B-21
H1
H2
S1
S1
D2
W
W1
D
D1
H3
H
S2
S3
3
2
1
2
2
2
3 1
See Detail A
See Detail B
Detail A (Mounting Hole)
Detail B (Mounting Hole)
Unit: mm [inch]
Frame W H D W1 H1 H2 H3 D1* D2 S1 S2 S3
F2 420.0
[16.54]
940.0
[37.00]
300.0
[11.81]
380.0
[14.96]
800.0
[31.50]
770.0
[30.32]
717.0
[28.23]
124.0
[4.88]
18.0
[0.71]
13.0
[0.51]
25.0
[0.98]
18.0
[0.71]
Frame Ɏ1 Ɏ2 Ɏ3
F2 92.0
[3.62]
35.0
[1.38]
22.0
[0.87]
D1*: Flange mounting
