Delta 600VA Operating instructions

www.deltapowersolutions.com
Package Inspection
1
No. Item Q'ty
1 UPS 1 PC
2 Quick Guide 1 PC
3 USB Cable 1 PC
4 Output Power Cord (10A) 1 PC
Remove the UPS from its package and inspect it for damage that may have
occurred during shipping. If any damage is discovered, re-pack the unit and
return it to the place of purchase.
Front Panel & Rear Panel
2
3
3
4
4
5
5
6
6
1
1
2
2
1
2
4
5
6
3
7
(Front Panel) (Rear Panel)
600VA
(Front Panel) (Rear Panel)
1000VA
(Front Panel) (Rear Panel)
1500VA
No. Item No. Item
1
LED Indicator
(Only For 600VA Model)
LCD Touch Panel (Only For
1000VA/ 1500VA Model)
4AC Input
5Fuse
2ON/ OFF Button 6USB Port
3Output Socket 7Cooling Fan
(Only For 1500VA Model)
Operation
3
yyConnect to Utility Power
Connect the AC power cord to the utility power. Then, the UPS will start
to charge its inside battery (batteries). For best result, charge the battery
(batteries) for 6 hours prior to initial use. It is not recommended to connect
the UPS’s AC power cord to any generator.
yyPlug in Equipment
Plug your equipment to the Output Socket on the rear panel of the UPS.
WARNING:
1. Make sure that the UPS is powered on to protect all important
devices from data loss during power failure.
2. NEVER connect a laser printer or scanner to the Output
Socket of the UPS. The equipment may draw significant
power to overload the UPS.
yyConnect to USB Port and Install Software
Connect one end of the supplied USB cable to your PC and the other to
the USB port located at the rear of the UPS. Download the latest version of
ViewPower software (http://www.deltapowersolutions.com/en/mcis/600va-
1500va-single-phase-ups-vx-series-software-download.php) to your hard
drive. Follow on-screen instructions to complete the software installation.
yyTurn On/ Off the UPS
When the UPS is OFF, press the ON/ OFF Button to turn on the UPS and
the LED/ LCD will be on. When the UPS is ON, press the ON/ OFF Button
to turn off the UPS and the LED/ LCD will shut off.
yyFuse Replacement
When the UPS always runs in battery mode, it might be because the fuse
is damaged. If yes, please follow the following procedures to replace the
fuse.
(1500VA)
Remove the fuse cover from the rear panel.
Replace the original fuse with the provided backup fuse .
Replace the fuse cover back to the rear panel.
(Pull)
(Take Out) (Install)
(Fuse Cover)
Original Fuse
(Provided)
Backup Fuse
(Provided)
1
2
3
1
1
2
2
Continue to the Next Page 
4
LED Indicator (Only For 600VA Model)
LED Alarm UPS Status
ON OFF The main AC power is normal
and the UPS runs normally.
ON Sounds all the time UPS fault.
Flashing Sounds every
10 seconds
Power failure occurs and the
UPS runs in battery mode.
Flashing Sounds every second Low battery.
OFF OFF The UPS is off.
5
LCD Display (Only For 1000VA/ 1500VA Model)
yyOperation Display:
UPS Mode LCD Touch Panel Description
UPS
Power On
When the UPS is powered
on, it will enter this mode for
4 seconds.
AC Mode
When AVR is functioning,
icon will ash every
second.
LCD information will be
displayed in the following
order when the LCD
is touched.
1. Output voltage
2. Input voltage
3. Load level
4. Battery capacity
Overload
In AC
Mode icon will ash.
When overload occurs,
alarm will beep every 0.5
second.
Battery
Mode
When battery level is low,
icon will ash.
Alarm will beep every
10 seconds and LCD
information will be displayed
in the following order
when the LCD is touched.
1. Output voltage
2. Input voltage
3. Load level
4. Battery capacity
Overload
In Battery
Mode icon will ash.
When overload occurs,
alarm will beep every 0.5
second.
NOTE:
If backlight shuts off, you can activate it by touching the screen.
Delta UPS – Agilon Family
VX Series, Line-interactive
600-1500 VA
Installation & Operation Quick Guide
ENGLISH

www.deltapowersolutions.com
Technical Specifications
8
Model 600VA 1000VA 1500VA
Capacity 600VA/360W 1kVA/600W 1.5kVA/900W
Nominal
Input Voltage 230 Vac
Input Voltage Range 170 ~ 280 Vac
Output Voltage 230 Vac ± 10% (Bat. mode)
Transfer Time Typical 2 ~ 6 ms
Waveform Simulated Sine Wave
Battery Type & No. 12V/7Ah x 1 12V/7Ah x 2 12V/7Ah x 2
Charging Time Typical 6 ~ 8 hours
Dimensions
(D x W x H)
279 x 101 x
142 mm 320 x 130 x 182 mm
Net Weight (kgs) 4.2 8.2 9.7
Humidity 0 - 90% RH @ 0 - 40°C (non-condensing)
Noise Level Less than 40dB Less than
45dB
* Specications are subject to change without notice.
Warranty
9
Seller warrants this product, if used in accordance with all applicable
instructions, to be free from original defects in material and workmanship
within the warranty period. If the product has any failure problem within the
warranty period, Seller will repair or replace the product at its sole discretion
according to the failure situation.
This warranty does not apply to normal wear or to damage resulting from
improper installation, operation, usage, maintenance or irresistible force (i.e.
war, re, natural disaster, etc.), and this warranty also expressly excludes
all incidental and consequential damages. Maintenance service for a fee is
provided for any damage out of the warranty period. If any maintenance is
required, please directly contact the supplier or Seller.
WARNING:
The individual user should take care to determine prior to use
whether the environment and the load characteristic are suitable,
adequate or safe for the installation and the usage of this product.
The Quick Guide must be carefully followed. Seller makes no
representation or warranty as to the suitability or fitness of this
product for any specic application.
yyFault Code Table:
Fault Condition LCD Touch Panel Solutions
Output Short
Circuited
Disconnect short-circuited
loads and restart the UPS
again.
Overload Fault Disconnect all output loads
and restart the UPS again.
Over Charge Fault Call for service immediately.
Battery Too Low
Fault
Please replace the battery
(batteries).
Battery Mode Output
High Fault Call for service immediately.
Over Temperature
1. Turn off the UPS and wait
for cooling.
2. Or remove excessive
loads and wait for cooling.
If any fault alarm occurs, please call for service immediately.
Safety Caution
6
SAVE THESE INSTRUCTIONS-This quick guide contains important
instructions that should be followed during installation and
maintenance of the UPS and battery (batteries).
yyThe UPS utilizes voltage that may be hazardous. Do not attempt to dis-
assemble the unit. The unit contains no user replaceable parts. Only fac-
tory service personnel may perform repairs.
yyThis pluggable type A equipment with battery (batteries) already installed
by the supplier is operator installable and may be operated by laymen.
yyThe mains socket outlet that supplies the UPS shall be installed near the
UPS and shall be easily accessible.
yyDuring the installation of this equipment it should be assured that the
sum of the leakage current of the UPS and the connected loads does
not exceed 3.5mA.
yyConnection to any other type of receptacle other than a two-pole, three-
wire grounded receptacle may result in shock hazard as well as violate
local electrical codes.
yyIn the event of an emergency, press the ON/ OFF Button and disconnect
the power cord from the AC power supply to properly disable the UPS.
yyDo not allow any liquid or any foreign object to enter the UPS. Do not
place beverages or any other liquid-containing vessels on or near the
unit.
yyThe unit is intended for installation in a controlled environment (tempera-
ture controlled, indoor area free of conductive contaminants). Avoid in-
stalling the UPS in any location where there is standing or running water,
or excessive humidity.
yyDo not plug the UPS input into its own output.
yyDo not attach a power strip or surge suppressor to the UPS.
yyDo not attach non-computer-related items, such as medical equipment,
life-support equipment, microwave ovens, or vacuum cleaners to the
UPS.
yyDo not dispose of battery (batteries) in a re as they may explode.
yyA battery can present a risk of electrical shock and high short circuit cur-
rent. The following precautions should be observed when working on bat-
teries:
1. Remove watches, rings, or other metal objects from the hands.
2. Use tools with insulated handles.
3. Wear rubber gloves and boots.
4. Do not lay tools or metal parts on top of battery (batteries).
5. Disconnect charging source prior to connecting or disconnecting
the terminals of battery (batteries).
yyInternal battery voltage is 12Vdc. Battery type is sealed, lead-acid, 6-cell
battery.
yyServicing of batteries should be performed or supervised by personnel
knowledgeable of batteries and the required precautions. Keep unauthor-
ized personnel away from batteries.
yyWhen replacing battery (batteries), replace with the same number and
type of sealed lead-acid battery (batteries).
yyDo not open or mutilate the battery or batteries. Release electrolyte is
harmful to the skin and eyes. It may be toxic.
yyAttention! Hazardous through electric shock. Even disconnection of this
unit from the mains, hazardous voltage still may be accessible through
supply from the battery (batteries). The battery supply should be therefore
disconnected in the plus and minus pole at the connectors of the battery
(batteries) when maintenance or service work inside the UPS is neces-
sary.
yyTo reduce the risk of overheating the UPS, do not cover the UPS’s cooling
vents and avoid exposing the unit to direct sunlight or installing the unit
near heat emitting appliances such as heaters or furnaces.
yyUnplug the UPS prior to cleaning and do not use liquid or spray detergent.
Troubleshooting
7
Problem Possible Cause Solutions
LED doesn’t
illuminate
or nothing
is displayed
on the LCD
panel.
The UPS is not on. Press the ON/ OFF Button again to
turn on the UPS.
Battery voltage is too
low.
Charge the battery (batteries) at
least 6 hours.
Battery fault. Replace the battery (batteries).
The UPS
always runs
in battery
mode.
The power cord
becomes loose. Re-plug the power cord.
The fuse is damaged.
Replace the fuse. For how to
replace the fuse, please refer to
Operation
3
.
The UPS
continuously
beeps.
Please check the
Fault Code Table for
the details.
Please check the Fault Code Table
for the details.
Backup time
is too short.
Battery voltage
is too low.
Charge the battery (batteries) at
least 6 hours.
Overload.
Remove some unnecessary loads.
Before reconnecting equipment,
please verify that the load matches
the UPS capability specied in the
specs.
Battery defect. Replace the battery (batteries).
If any abnormal situations occur that are not listed above, please call for
service immediately.
Copyright © 2017by Delta Electronics Inc. All Rights Reserved.
This Quick Guide is subject to change without prior notice.
Version Date : 2017_08_16
