Denon DHT-391XP User manual

D&M Holdings Inc.
SERVICE MANUAL
e
e
Copyright 2010 D&M Holdings Inc. All rights reserved.
WARNING: Violators will be prosecuted to the maximum extent possible.
MODEL JP E3 E3B E2 EK EA E1 E1C
AVR-1311
33
AVR-391
33
AV SURROUND RECEIVER
MODEL JP E3 E3B E2 EK EA E1 E1C
DHT-1311XP
3
DHT-391XP
33 3
5.1CH HOME THEATER SYSTEM
Ver. 3
•Some illustrations using in this service manual are slightly different from the actual set.
•Please use this service manual with referring to the operating instructions without fail.
•For purposes of improvement, specifications and design are subject to change without notice.
S0141-0V03DM/DG1010
s
Please refer to the
MODIFICATION NOTICE.

2
SAFETY PRECAUTIONS
The following check should be performed for the continued protection of the customer and service technician.
LEAKAGE CURRENT CHECK
Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis
resistance check. if the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
power cord is less than 460 kohms, the unit is defective.
Be sure to test for leakage current with the AC plug in both polarities, in addition, in each power ON, OFF and STANDBY
mode, if applicable.
CAUTION Please heed the points listed below during servicing and inspection.
◎Heed the cautions!
Spots requiring particular attention when servicing, such
as the cabinet, parts, chassis,etc., have cautions indicated
on labels. be sure to heed these causions and the
cautions indicated in the handling instructions.
◎Caution concerning electric shock!
(1) An AC voltage is impressed on this set, so touching
internal metal parts when the set is energized could
cause electric shock. Take care to avoid electric
shock, by for example using an isolating transformer
and gloves when servicing while the set is energized,
unplugging the power cord when replacing parts, etc.
(2) Tere are high voltage parts inside. Handle with extra
care when the set is energized.
◎Caution concerning disassembly and
assembly!
Through great care is taken when manufacturing parts
from sheet metal, there may in some rare cases be burrs
on the edges of parts which could cause injury if fingers
are moved across them. Use gloves to protect your hands.
◎Only use designated parts!
The set's parts have specific safety properties (fire
resistance, voltage resistance, etc.). For replacement
parts, be sure to use parts which have the same
poroperties. In particular, for the important safety parts
that are marked z on wiring diagrams and parts lists, be
sure to use the designated parts.
◎Be sure to mount parts and arrange the wires
as they were originally!
For safety seasons, some parts use tape, tubes or other
insulating materials, and some parts are mounted away
from the surface of printed circuit boards. Care is also
taken with the positions of the wores omsode amd clamps
are used to keep wires away from heating and high
voltage parts, so be sure to set everything back as it was
originally.
◎Inspect for safety after servicing!
Check that all screws, parts and wires removed or
disconnected for servicing have been put back in their
original positions, inspect that no parts around the area
that has been serviced have been negatively affected,
conduct an inslation check on the external metal
connectors and between the blades of the power plug,
and otherwise check that safety is ensured.
(Insulation check procedure)
Unplug the power cord from the power outlet, disconnect
the antenna, plugs, etc., and turn the power switch on.
Using a 500V insulation resistance tester, check that the
inplug and the externally exposed metal parts (antenna
terminal, headphones terminal, input terminal, etc.) is
1MΩor greater. If it is less, the set must be inspected and
repaired.
Many of the electric and structural parts used in the set
have special safety properties. In most cases these
properties are difficult to distinguish by sight, and using
replacement parts with higher ratings (rated power and
withstand voltage) does not necessarily guarantee that
safety performance will be poreserved. Parts with safety
properties are indicated as shown below on the wiring
diagrams and parts lists is this service manual. Be sure to
replace them with parts with the designated part number.
(1) Schematic diagrams ......Indicated by the z mark.
(2) Parts lists ......Indicated by the zmark.
Using parts other than the designated
parts could result in electric shock, fires
or other dangerous situations.
CAUTION Concerning important safety
parts

3
NOTE FOR SCHEMATIC DIAGRAM
WARNING:
Parts marked with this symbol zhave critical characteristics. Use ONLY replacement parts recommended by the manufacturer.
CAUTION:
Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis resistance check. If the
leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the unit is defective.
WARNING:
DO NOT return the unit to the customer until the problem is located and corrected.
NOTICE:
ALL RESISTANCE VALUES IN OHM. k=1,000 OHM / M=1,000,000 OHM
ALL CAPACITANCE VALUES IN MICRO FARAD. P=MICRO-MICRO FARAD EACH VOLTAGE AND CURRENT ARE MEASURED AT NO SIGNAL
INPUT CONDITION. CIRCUIT AND PARTS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
Parts for which "nsp" is indicated on this table cannot be supplied.
When ordering of part, clearly indicate "1" and "I" (i) to avoid mis-supplying.
Ordering part without stating its part number can not be supplied.
Not including General-purpose Carbon Chip Resistor in the P.W.Board parts list. (Refer to the Schematic Diagram for those parts.)
Parts marked with this symbol zhave critical characteristics. Use ONLY replacement parts recommended by the manufacturer.
Not including General-purpose Carbon Film Resistor in the P.W.Board parts list. (Refer to the Schematic Diagram for those parts.)
Part indicated with the mark "★" is not illustrated in the exploded view.
WARNING:
1.
2.
3.
4.
5.
6.
●Resistors
RD : Carbon
RC : Composition
RS : Metal oxide film
RW: winding
RN : Metal film
RK : Metal mixture
P : Pulse-resistant type
NL : Low noise type
NB : Non-burning type
FR : Fuse-resistor
F : Lead wire forming
2B : 1/8 W
2E : 1/4 W
2H : 1/2 W
3A : 1 W
3D : 2 W
3F : 3 W
3H : 5 W
F:±1%
G:±2%
J:±5%
K:±10%
M:±20%
Ex.: RN
Type
14K
Shape
and per-
formance
2E
Power
182
Resist-
ance
G
Allowable
error
FR
Others
*Resistance
1800ohm=1.8kohm1 8 2
Indicates number of zeros after effective number.
2-digit effective number.
1.2ohm1 R 2
2-digit effective number, decimal point indicated by R.
1-digit effective number.
: Units: ohm
●Capacitors
CE : Aluminum foil
electrolytic
CA : Aluminium solid
electrolytic
CS : Tantalum electrolytic
CQ : Film
CK : Ceramic
CC : Ceramic
CP : Oil
CM: Mica
CF : Metallized
CH : Metallized
HS : High stability type
BP : Non-polar type
HR : Ripple-resistant type
DL : For change and discharge
HF : For assuring high requency
U : UL part
C : CSA part
W : UL-CSA part
F : Lead wire forming
0J : 6.3 V
1A : 10 V
1C : 16 V
1E : 25 V
1V : 35 V
1H : 50 V
2A : 100 V
2B : 125 V
2C : 160 V
2D : 200 V
2E : 250 V
2H : 500 V
2J : 630 V
F:±1%
G:±2%
J:±5%
K:±10%
M:±20%
Z:±80%
: - 20%
P : +100%
C:±0.25pF
D:±0.5pF
= : Others
Ex.: CE
Type
04W
Shape
and per-
formance
1H
Dielectric
strength
3R2
Capacity
M
Allowable
error
BP
Others
・Units:μF.
2200μF2 2 2
Indicates number of zeros after effective number.
2-digit effective number. ・Units:μF.
2.2μF2 R 2
2-digit effective number, decimal point indicated by R
1-digit effective number.
*Capacity (electrolyte only)
・When the dielectric strength is indicated in AC,"AC" is included after the dieelectric strength value.
*Capacity (except electrolyte)
・Units:pF
2200pF=0.0022μF2 2 2
Indicates number of zeros after efective number. (More than 2)
2-digit effective number. ・Units:pF
220pF2 2 1
2-digit effective number.
Indicates number of zeros after effective numver. (0 or 1)
NOTE FOR PARTS LIST

4
TECHNICAL SPECIFICATIONS
nAudio Section
• Power amplifier
Rated output :
Front :
75 W + 75 W (8 Ω, 20 Hz – 20 kHz with 0.08 % T.H.D.)
110 W + 110 W (6 Ω, 1 kHz with 0.7 % T.H.D.)
Center :
75 W (8 Ω, 20 Hz – 20 kHz with 0.08 % T.H.D.)
110 W (6 Ω, 1 kHz with 0.7 % T.H.D.)
Surround :
75 W + 75 W (8 Ω, 20 Hz – 20 kHz with 0.08 % T.H.D.)
110 W + 110 W (6 Ω, 1 kHz with 0.7 % T.H.D.)
Output connectors : 6 – 16 Ω
• Analog
Input sensitivity/Input impedance : 200 mV/47 kΩ
Frequency response: 10 Hz – 100 kHz — +1, –3 dB (DIRECT mode)
S/N : 98 dB (IHF–A weighted, DIRECT mode)
nVideo Section
• Standard video connectors
Input/output level and impedance : 1 Vp-p, 75 Ω
Frequency response : 5 Hz – 10 MHz — +1, –3 dB
• Color component video connector
Input/output level and impedance :
Y (brightness) signal — 1 Vp-p, 75 Ω
PB/ CBsignal — 0.7 Vp-p, 75 Ω
PR/ CRsignal — 0.7 Vp-p, 75 Ω
Frequency response : 5 Hz – 10 MHz — +1, –3 dB
nTuner section
[FM](Note: μV at 75 Ω, 0 dBf = 1 x 10–15 W)
Receiving Range (for 391E3,391E3B) :
[FM] 87.5 MHz – 107.9 MHz [AM]520 kHz – 1710 kHz
Receiving Range (for 1311E2,1311E1C,391EA) :
[FM] 87.5 MHz – 108.0 MHz [AM]522 kHz – 1611 kHz
Usable Sensitivity :
[FM]1.2 μV (12.8 dBf) [AM]18 μV
50 dB Quieting Sensitivity :
[FM]MONO 2.8 μV (20.2 dBf)
S/N (IHF-A) :
[FM]MONO 70 dB
STEREO 67 dB
Total harmonic Distortion (at 1 kHz) :
[FM]MONO 0.7 %
STEREO 1.0 %
nGeneral
Power supply (for 391E3,391E3B) : AC 120 V, 60 Hz
(for 1311E2,391EA) : AC 230 V, 50 Hz
(for 1311E1C) : AC 220 V, 50 Hz
Power consumption :
330 W
Less than 0.5 W (Standby)
Maximum external dimensions :
435 (W) x 166 (H) x 381 (D) mm
Weight : 9.2 kg
nRemote Control Unit (RC-1149)
Batteries : R03/AAA Type (two batteries)
Maximum external dimensions : 50 (W) x 211 (H) x 22 (D) mm
Weight : 110 g (including batteries)
SYSTEM CONFIGURATION
• AVR-1311
• AVR-391
• DHT-1311XP (AVR-1311 + SYS-391HT)
• DHT-391XP (AVR-391 + SYS-391HT)
SYS-391HT : Refer to page 104-113 for the service manual.
DSW-391 SC-C391SC-F391(x2) SC-R391(x2)
SYS-391HT
s
s

5
245.0
43.5
30.0 30.5
20.0
20.7 22.2
86.0
340.0
166.5
146.5
43.5
381.4
338.5
248.0
435.0
DIMENSION
The illustration is AVR-1311 model.

6
CAUTION IN SERVICING
Initializing AV SURROUND RECEIVER
AV SURROUND RECEIVER initialization should be performed when the μcom, peripheral parts of μcom, and Digital
P.W.B. are replaced.
1. Turn off the power using ON/STANDBY button.
2. Press ON/STANDBY button while simultaneously pressing SURROUND MODE 0and SURROUND MODE 1
buttons.
3. Check that the entire display is flashing with an interval of about 1 second, and release your fingers from the 2
buttons and the microprocessor will be initialized.
Service Jigs
When you update the firmware, you can use the following
JIG (RS232C to internal connector conversion adapter with 4P FFC cable kit ).
Please order to Denon Official Service Distributor in your region if necessary.
8U-210100S : WRITING KIT : 1 Set
606050028012P : 7P FFC(1.0) L-240 : 1 Set
(Refer to "VERSION UPGRADE PROCEDURE OF FIRMWARE".)
Note: •If step 3 does not work, start over from step 1.
•All user settings will be lost and this factory setting will be recovered when this initialization mode.
So make sure to memorize your setting for restoring after the initialization.
SURROUND MODE 0
SURROUND MODE 1
ON/STANDBY

7
DISASSEMBLY
• Disassemble in order of the arrow of the figure of following flow.
• In the case of the re-assembling, assemble it in order of the reverse of the following flow.
• In the case of the re-assembling, observe "attention of assembling" it.
• If wire bundles are untied or moved to perform adjustment or parts replacement etc., be sure to rearrange them neatly
as they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
About the photos used for descriptions in the DISASSEMBLY" section.
• The direction from which the photographs used herein were photographed is indicated at "Direction of photograph: ***"
at the left of the respective photographs.
• Refer to the table below for a description of the direction in which the photos were taken.
• Photographs for which no direction is indicated were taken from above the product.
The viewpoint of each photograph
(Photografy direction)
[View from above]
Front side
Direction of photograph: B
Direction of photograph: D
Direction of photograph: C
Direction of photograph: A
FRONT PANEL ASSY
Refer to "DISASSEMBLY
1. FRONT PANEL ASSY"
and "EXPLODED VIEW"
AUX UNIT
(Ref. No. of EXPLODED VIEW : C1)
PHONE UNIT
(Ref. No. of EXPLODED VIEW : C2)
VOLUME UNIT
(Ref. No. of EXPLODED VIEW : C3)
HEADPHONE UNIT
(Ref. No. of EXPLODED VIEW : C8)
POWER UNIT
(Ref. No. of EXPLODED VIEW : C9)
FRONT UNIT
(Ref. No. of EXPLODED VIEW : C10)
HDMI UNIT
Refer to "DISASSEMBLY
2. HDMI UNIT"
and "EXPLODED VIEW"
HDMI UNIT
(Ref. No. of EXPLODED VIEW : C7)
INPUT UNIT
Refer to "DISASSEMBLY
3. INPUT UNIT"
and "EXPLODED VIEW"
INPUT UNIT
(Ref. No. of EXPLODED VIEW : C6)
RADIATOR ASSY
Refer to "DISASSEMBLY
4. RADIATOR ASSY"
and "EXPLODED VIEW"
MAIN UNIT
(Ref. No. of EXPLODED VIEW : C5)
TOP COVER
POWER UNIT
Refer to "DISASSEMBLY
5. POWER UNIT"
and "EXPLODED VIEW"
REGULATOT UNIT
(Ref. No. of EXPLODED VIEW : C13)
POWER TRANS
Refer to "DISASSEMBLY
6. POWER TRANS "
and "EXPLODED VIEW"
POWER TRANS
(Ref. No. of EXPLODED VIEW : C14)

8
1. FRONT PANEL ASSY
(1) Remove the screws.
(2) Cut the wire clamp band, then disconnect the connector wires and FFC cable. Remove the screws.
(3) Remove the screws.
TOPCOVER FRONT PANEL ASSY
→
Proceeding :
View from bottom
CN209
CN71
FFC cable CN44 cut
cut
FRONT PANEL ASSY
WIRE SUPPORT UNIT
Please refer to "EXPLODED VIEW" for the disassembly method of each P.W.B included in FRONT PANEL ASSY.

9
2. HDMI UNIT
(1) Remove the screws.
(2) Disconnect the connector wire and FFC cable.
TOPCOVER HDMI UNIT
→
Proceeding :
Direction of photograph: A
CN12FFC cable
HDMI UNIT

10
3. INPUT UNIT
(1) Remove the screws.
(2) Disconnect the connector wires and FFC cables, then remove the screws.
TOPCOVER HDMI UNIT
→INPUT UNIT
→
Proceeding :
Direction of photograph: A
CN42
CN71 CN43
FFC cable
FFC cable
INPUT UNIT

11
4. RADIATOR ASSY
(1) Remove the screws.
(2) Disconnect the connector wires, then remove the screws.
TOPCOVER HDMI UNIT
→INPUT UNIT
→RADIATOR ASSY
→
Proceeding :
Direction of photograph: A
RADIATOR ASSY
CN71 CN44
CN45
CN41
CN47 CN48
CN46

12
(3) Remove the RADIATOR ASSY from the main unit.
5. POWER UNIT
6. POWER TRANS
Direction of photograph: C
Please refer to "EXPLODED VIEW" for the disassembly method of each P.W.B included in RADIATOR ASSY.
TOPCOVER POWER UNIT
→
Proceeding :
Please refer to "EXPLODED VIEW" for the disassembly method of POWER UNIT.
CABINET TOP TRANS MAIN
→
Proceeding :
Please refer to "EXPLODED VIEW" for the disassembly method of POWER TRANS.

13
SPECIAL MODE
Special mode setting button
bPress the ON/STANDBY button to turn on while pressing both buttons A and B at the same time.
Mode Button A Button B Contents
μcom/DSP Version display mode STATUS DIMMER
Firmware versions such as Main, DSP are displayed in the FL
display. Errors are displayed when they occur.
(Refer to page 14.)
Initialization mode SURROUND
MODE 0
SURROUND
MODE 1Backup data initialization is carried out. (Refer to page 6.)
Mode for switching tuner frequency step SURROUND
MODE 0RESTORER
---E2 model only---
Change tuner frequency step to AM9k/FM50kHz STEP or
AM:10k/FM:200kHz.
Mode for preventing remote control
acceptance
SURROUND
MODE 0STATUS
Operations using remote control are rejected.
"REMOTE LOCK:ON" is displayed in FL display.
(Mode cancellation: Turn off power and execute the same
button operations as when performing setup.)
SURROUND
0 MODE 1
ON/STANDBY
RESTORER STATUS
DIMMER

14
1. μcom/DSP Version display mode
1.1. Operation specifications
μcom/DSP version display mode:
When started up, the version information is displayed.
Starting up:
With the "DIMMER" and "STATUS" buttons pressed, press the "ON/STANDBY" button to turn the power on.
Now, press the "STATUS" button to the display the 2nd item information on the FL Display.
1.2. Display Order
Model name →Main-μcom version →DSP version →iPod Dock version (Connecting iPod Dock)
Display State
Model name
AVR-391 E3 model
AVR391 E3
AVR-1311 E2 model
AVR1311 E2
AVR-391 EA model
AVR391 EA
AVR-1311 E1C model
AVR1311 E1C
Main-μcom version
Main **.**
DSP version
DSP.*.*.*
iPod Dock (ASD-1R/11R)
Dock Ver :**.**
iPod Dock (ASD-3/51)
Dock :I********
Cleared of mode:
Press the "ON/STANDBY" button to turn the power off.
1.3. Error display
See the following table for each "Error information" display and its contents (status).
Condition - State
DSP NG When DSP boot, executing DSP reset makes to becomes error.
DSP ERROR 01
DSP OK (No error display, version display only)

15
ABOUT REPLACE THE MICROPROCESSOR WITH A NEW ONE
When replaced of the U-PRO (Microprocessor) or the Flash ROM, conrm contents of the following.
PWB Name Ref. No. Description After
replaced Remark
DIGITAL IC91 T5CN5 BSOFTWARE: Main
DIGITAL IC82 ST25VF080B-50-4C-S2AF BSOFTWARE: DSP ROM
After replaced
A : Mask ROM (With software). No need write-in of software to the microprocessor.
B : Flash ROM (With software). Usually, no need write-in of software. But, when the software was updated, you should be
write-in of the new software to the microprocessor or ash ROM. Please check the software version.
C : Empty Flash ROM (Without software). You should be write-in of the software to the microprocessor or ash ROM.
Refer to "Update procedure" or "writing procedure", when you should be write-in the software.
VERSION UPGRADE PROCEDURE OF FIRMWARE
1. Preparations
-Before starting the operation-
(1) Personal Computer (Installed “BootTool_M330(Writing program).exe”).
(2) RS-232 cable (9P (Male), Straight).
(3) 8U-210100S Writing Kit.
(4) 606050028012P / 7P FFC(1.0) L=240.
-Connection of the AV receiver-
(1) Conrm the power on/off switch of the AV receiver is turning off.
(2) Connect the update terminal of AV receiver with the “Writing Kit”.
(Refer to gure below for the connection of the 7P FFC cable.)
(3) Connect the RS-232C cable from PC with the “Writing Kit”.
PC
Writing Kit
RS-232C Cable
This side is contacts of
7P FFC Cable.
S709
S708
S707
S706
S702
S706-709 : HIGE S702 : 3.3V
7P FFC Cable
7P FFC Cable
1 pin

16
2. UPDATE FIRMWARE
(1) Connect the update terminal of AV receiver with the “Writing Kit”.
(2) Set the switch of “Writing Kit" (Refer to the table below).
DSPBOOT CE EPM CNVSS
HHHH
(3) Press the "ON/STANDBY" button to turn the power on of AV receiver.
(4) Set the switch of “Writing Kit" (Refer to the table below).
DSPBOOT CE EPM CNVSS
H H L H
(5) Press the "RESET" switch of “Writing Kit".
(6) Run the “BootTool_M330(Writing program).exe” on desktop of PC.
(7) Click the “Connect” button.
"Connected" is displayed, it is OK.

17
DSP SF1
(8) Choose Ram File(OnBoard_M330.s32).
Choose Ram File(OnBoard_M330.s32).

18
(9) Choose Flash File(DSP : SF1).
Choose "AVR1311_SF1_*_*_*_01.s32".
Choose "Hex File (*.S32)".

19
(10) Click the “Start” button.
The Setup Status bar appears.

20
(11) "Finished!!" is displayed. Click the "OK"” button.
(12) Set the switch of “Writing Kit" (Refer to the table below).
DSPBOOT CE EPM CNVSS
HHHH
(13) Press the "RESET" switch of “Writing Kit".
(14) AV receiver is power on and starts update of DSP1.
(15) "Write Comleted" is displayed in the FL tube.
(16) Set the switch of “Writing Kit" (Refer to the table below).
DSPBOOT CE EPM CNVSS
H H L H
(17) Press the "RESET" switch of “Writing Kit".
DSP SF2
(18) Click the “Resend” button.
"Connected" is displayed, it is OK.
Other manuals for DHT-391XP
3
This manual suits for next models
3
Table of contents
Other Denon Home Theater System manuals

Denon
Denon DHT-S416 User manual

Denon
Denon S-301 User manual

Denon
Denon DHT-683DVD User manual

Denon
Denon ADV-700 User manual

Denon
Denon S-102 Administrator guide

Denon
Denon DHT-S316 User manual

Denon
Denon DHT-488XP User manual

Denon
Denon DHT-500SD User manual

Denon
Denon S-102 User manual

Denon
Denon D-AJ03 User manual

Denon
Denon ADV-M51 User manual

Denon
Denon DHT-682XP User manual

Denon
Denon S-302 - AV System User manual

Denon
Denon S-301 User manual

Denon
Denon S-302 User manual

Denon
Denon DHT-591BA Dimensions

Denon
Denon S-101 User manual

Denon
Denon DHT-1312XP User manual

Denon
Denon DHT-684XP User manual

Denon
Denon DHT-FS3 User manual
