DENTSPLY Cavitron Prophy-Jet Manual

Please read carefully and completely before operating unit.
Veuillez lire soigneusement et complètement avant d’utiliser le système.
Por favor lea detenida y completamente las instrucciones para el uso de hacer funcionar la unidad.
Bitte vor Inbetriebnahme des Geräts sorgfältig und vollständig durchlesen.
Leggere attentamente tutte le istruzioni prima di utilizzare il sistema.
Cavitron™PROPHY-JET®Air Polishing Prophylaxis System
Directions For Use
Système de prophylaxie par polissage à l’air Cavitron™PROPHY- JET®
Mode d’emploi
Sistema profiláctico de pulido neumático Cavitron™ PROPHY-JET®
Instrucciones para el uso
Cavitron™PROPHY-JET®Airpolishing-Prophylaxegerät
Gebrauchsanweisung
Sistema di profilassi e pulizia a getto d’aria Cavitron™PROPHY-JET®
Istruzioni per l’uso

ENGLISH • 1
ENGLISH
Cavitron™ PROPHY-JET®
Air Polishing Prophylaxis System
Introduction
Directions For Use
DENTSPLY®PreventiveCareisanISO9001andEN46000certified
company.TheCavitron™PROPHY-JET®AirPolishingProphlaxis
SystemisclassifiedbyUnderwritersLaboratoriesInc.withrespectto
electric shock, fire, mechanical hazards only in accordance
UL 2601-1 assigned control #.
The Cavitron™PROPHY-JET®Air Polishing system is a precision
engineered and manufactured instrument. It contains controls and
components for air polishing operation.
Technical Support
There are no serviceable parts in this device. Refer all service to a
qualified service repair facility. For technical support and repair
assistancein theU.S. call1-800-347-7412MondaythroughFriday,
8:00 AM to 5:00 PM (Eastern Time). For other areas, contact your
local DENTSPLY representative.
Supplies & Replacement Parts
To order supplies or replacement parts for your PROPHY-JET
System, contact your local DENTSPLY®Dealer. If your dealer is
unable to assist you, call 1-800-989-8826 Monday through Friday,
8:00 AM to 5:00 PM (Eastern Time). For other areas, contact your
local DENTSPLY®representative.
Caution: U.S. Federal Law restricts this device to sale by or on the
order of a dentist.
Cavitron™PROPHY-JET®
Air Polishing
Prophylaxis System
Please read carefully and completely before operating unit.

ENGLISH • 2
Table of Contents
Section Section Title Page
Number Description of Contents Number
1 Indications ............................................................................................................................................................3
1.1 Air Polishing procedures
2 Contraindicationsand Warnings ...........................................................................................................................3
2.1Contraindications
2.2Warnings
3 Precautions ...........................................................................................................................................................3
3.1 Precautions for All Systems
3.2 Precautions for Airpolishing Procedures
4 InfectionControl ..................................................................................................................................................4
4.1 Infection Control Information Reference Card
4.2 General Infection Control Recommendations
4.3 Water Supply Recommendations
5 Installation Instructions......................................................................................................................................4-5
5.1 General Information
5.2 Water Line Requirements
5.3 Air Line Requirements and Recommendations
5.4 Electrical Requirements
5.5 Unpacking the System
5.6Power Cord/Power Connection
5.7 Foot Control Cable Assembly Connection
5.8 Incoming Water Supply Line Connection
5.9 Air Supply Line Connection
6 Cavitron™PROPHY-JET®System ....................................................................................................................6-7
6.1 System Controls
6.2 Handpiece
6.3 Cavitron™ JET Air Polishing Insert Nozzle
6.4 Foot Control Information and Operation
6.5 Operation for Air Polishing Prodedures
7 Accessories ............................................................................................................................................................8
7.1 Accessories List
8 Techniques for Use ..........................................................................................................................................8-11
8.1 General Information on Patient Positioning
8.2 Air Polishing Powder Chamber
8.3 Air Polishing using the JetShield™ Accessory
8.4 Performing JET Air Polishing Procedures with JetShield™
8.5 Performing Air Polishing Procedures without JetShield™
8.6 Proper Angulation of the Air Polishing Insert without JetShield™
9 System Care ...................................................................................................................................................11-12
9.1 Daily Maintenance —Start-Up Procedures, Between Patients, Shut-Down Procedures
9.2PeriodicMaintenance
10 Troubleshooting..................................................................................................................................................12
10.1Troubleshooting
10.2 Technical Support and Repairs
11 Specifications ...................................................................................................................................................... 13
12 Classifications .....................................................................................................................................................13
13 Disposal of Unit..................................................................................................................................................13

ENGLISH • 3
Section 1: Indications
Section 2: Contraindications and Warnings
Section 3: Precautions
3.1 Precautions for All Systems
• DonotplacetheSystemonor nextto aradiatoror otherheat
source. Excessive heat may damage the System’s electronics.
PlacetheSystemwhere air is free to circulate on all sides and
beneath it.
• The Systemis portable,but mustbe handledwith care when
moving.
•Equipment flushing and dental water supply system
maintenanceare strongly recommended.
• Close the water shut-off valve to the System every night
before leaving the office. The use of an in-line water filter is
recommended.
• The use of an air dryer on the compressor line supplying the
System will prevent condensation from forming in the air
line which in turn may cause “caking” of the air polishing
cleaning powder and clogging the lines at the air polishing
insert tip.
• Cavitron®Prophy-Jet®Cleaning Powder is a water-soluble
sodium bicarbonate powder specially formulated for use in
Cavitron®Air Polishing Systems. Do not attempt to use any
other cleaning materials in the air polishing powder
reservoir.
• Empty the air polishing powder reservoir and dispose of its
contents at the end of the day to prevent “caking”of the
powder and clogging the lines and air polishing tip.
2.1 Contraindications
•InsertNozzleforbestperformance,useonlytheCavitron™
Air Polishing JET manufactured by Dentsply®Preventive
Care.
• Use only Cavitron®Prophy-Jet®Cleaning Powder.
1.1 Air polishing procedures:
• Removal of a variety of extrinsic stains, e.g., tobacco, coffee
& tea, chlorhexidine.
• Prophylaxis of orthodontic patients.
• Preparing tooth surfaces prior to bonding and sealant
procedures.
2.2 Warnings
• Do not direct the air polishing stream at soft tissue or into
the sulcus. Tissue emphysema has been reportedly caused
when the air/water/powder stream was directed at the soft
tissues or into the sulcus.
3.2 Precautions for Air Polishing Procedures
• Only set the air polishing powder flow control to the
maximumposition(fully Clockwise ) when it is necessary to
remove particularly difficult stains. Return the powder flow
control to the medium position upon the completion of the
procedure.
• Avoid prolonged or excessive use on restorative dental
materials.
• Avoid prolonged use on cementum or dentin.
• Avoid prolonged use on polished metal surfaces as a matte
finish may result.
• Patients who are on a restricted sodium diet, or have severe
respiratory illness, should consult their physician before
undergoing air polishing prophylaxis procedures.
• Patients wearing contact lenses should remove them prior
to air polishing treatment.

ENGLISH • 4
Section 4: Infection Control
4.1 Infection Control Information
Reference Card
For your convenience, an Infection Control Information reference
card,printedondurablestock,hasbeenincludedwithyourCavitron™
PROPHY-JET®Air Polishing Prophylaxis System. If your card is
missing or misplaced, you can request a replacement in the U.S. by
calling Customer Service at 1-800-989-8826 Monday through Fri-
day, 8:00 AM to 5:00 PM (Eastern Time) For other areas, contact
your local DENTSPLY representative.
4.2 General Infection Control
Recommendations
•As with all dental procedures, use standard personal
protection equipment (i.e., wear face mask, eyewear or face
shield, gloves and protective gown).
•Aswith high speed handpieces, and otherdentaldevices,the
combination of water, air and powder from your Cavitron™
Section 5: Installation Instructions
5.1 General Information
If the installation of your Cavitron™ PROPHY-JET®Air Polishing
Prophylaxis System is performed by someone other than trained
DENTSPLY®Dealer personnel, care should be taken to observe the
followingrequirements and recommendations.
5.2 Water Line Requirements
•The System’s water supply line is factory installed. Do not
disconnect from the System.
•The System's water line filter is factory installed. Do not
disconnect from the system.
•Incoming water supply line pressure to the System must be
25 psi (172 kPa) to 60 psi (414kPa). If your dental water
system’ssupplylinepressureisabove60psi(414kPa),install
a water pressure regulator on the supply line to your
Cavitron™PROPHY-JET® Air Polishing Prophylaxis
System.
•A manual shut-off valve on the dental water system supply
lineshould be usedsothat the watercanbe completely shut-
off when the office is unoccupied.
•A filter in the dental water system supply line is
recommended so that any particulates in the water supply
will be trapped before reaching the System.
•After the above installations are completed on the dental
water supply system, the dental office water line should be
thoroughly flushed prior to connection to the System.
PROPHY-JET®Air Polishing Prophylaxis System will
create aerosols. With proper technique, much of the
Cavitron™PROPHY-JET®System’s aerosol dispersion can
be effectively controlled and minimized. Please carefully
follow the procedural guide lines in this manualregarding
the use of your System.
•Formaximaloperatorand patientsafety, carefullyfollow the
Infection Control Information procedures detailed on the
reference card accompanying your System.
4.3 Water Supply Recommendations
It is highly recommended that all dental water supply systems
conform to applicable CDC (U.S. Centers for Disease Control and
Prevention)andADA(AmericanDentalAssociation)standards,and
thatallrecommendations be followed in termsofflushing,chemical
flushing, and general infection control procedures.
5.3 Air Line Requirements &
Recommendations
•An air supply line is factory installed on Cavitron™
PROPHY-JET®Air Polishing Prophylaxis System. Do
not disconnect it.
•Incoming air supply line pressure to the System must be
65psig (448kPa) to 100psig(690kPa). If your officeairline
pressure is above 100 psig (690kPa), install an air pressure
regulator on the supply line to your Cavitron™
PROPHY-JET® Air Polishing Prophylaxis System.
•A manual shut-off valve on the office air supply line should
be used so that the air line can be completely shut-off, and
the line pressure relieved when the office is unoccupied.
•Your System must be supplied with clean, dry air. To help
prevent water condensation from forming in the air supply
linewhichmaycausethesystemtomalfunction,itisstrongly
recommended that an air dryer be used on the compressor
line supplying the System.
5.4 Electrical Requirements
Refer to Section 11: Specifications.

ENGLISH • 5
5.7 Foot Control Cable Assembly
Connection
Align the Foot Control plug with the receptacle on the back of the
System and push it in until firmly seated.
5.5 Unpacking the System
Carefully unpack your Cavitron™ PROPHY-JET®Air Polishing
ProphylaxisSystemandverifythatallcomponentsandaccessoriesare
included:
1. Cavitron™PROPHY-JET®Air Polishing Prophylaxis
Systemwith watersupply line,airsupply line,handpiece
and cable connector assembly factory installed.
2. Air filter assembly.
3. Detachable AC Power Cord set.
4. Cavitron™JETAirPolishingInsertNozzlewithcleaning
tool.
5. Dual position Foot Control Assembly.
6. JetShield™ Aerosol Reduction Device.
7. Literature Packet.
Section 5: Installation Instructions cont'd
5.6 Power Cord/Power Connection
• Verify the Power Control ON/OFF rocker switch located
at the left front underside of the System is set to the OFF
positionbefore proceeding.
• Plug the detachable AC cord into the back of the System.
• Plug the 3 prong grounded plug into an approved outlet.
ON/OFF rocker switch
5.8 Water Supply Line Connection
• Connect the free end of the system’s water supply line to
office water supply line or a Cavitron®DualSelect™
Dispensing System.
• Inspect all connections to make certain there are no leaks.
5.9 Air Supply Line Connection
• Connect the free end of the system’s air supply line to office
air supply line or a Cavitron™ DualSelect™dispensing
System.
• Inspect all connections to make certain there are no leaks.

ENGLISH • 6
Section 6: Cavitron™PROPHY-JET® Air Polishing
Prophylaxis System Description
6.1 System Controls
Top Grooves
Provide a convenient, temporary place-
ment for the handpiece during treatment
procedures. Always place handpiece in
holder when not being used.
Powder Adjustment
Turn knob to select powder
level for operation: clockwise
increases powder level,
counter clockwise decreases
powder level. Handpiece
Holds the Cavitron™ JET insert
nozzle.
AC Power Indicator Light
Lighted when System is
switched ON.
Power Control
ON/OFF switch located at the left
front underside of the System. Air Polishing
The two-position Foot Control provides the ca-
pabilityto rinse inthefirstpositionandairpolish
in the second position. When lighted , indicates
foot control is fully depressed and system is in
the air polishing mode.
Lavage Flow Adjustment
Turn knob to select Lavage Flow level during System operation.
Clockwise increases flow at insert tip, counter clockwise decreases flow.
Powder Fill Cap
Removable cap for filling and
emptying the powder chamber.
Handpiece Holder
Securely holds the System's
Handpiece when system is
not being used.
Water Filter
Removable cap for filter
maintenance.
6.2 Handpiece
The handpiece accepts the JET air polishing insert nozzle.
Insert Port
Air Polishing Powder Delivery Port
Powder Flow Window Handpiece
Cable

ENGLISH • 7
Section 6: Cavitron
™
PROPHY-JET
®
cont'd
6.3 Cavitron™JET Air Polishing Insert nozzle
LubricatetherubberO-ringontheinsertwithwaterbeforeplacingitintothehandpiece.Placetheinsertrodintotheinsertportofthehandpiece.
Align the powder delivery tube with the powder delivery port and gently push into handpiece until fully seated.
6.4 Foot Control Information & Operation
The Foot Control is a two-position momentary switch, which activates both lavage and powder flow and air polishing at the insert tip.
6.5 Operation for Air Polishing Procedures
Cleaning Powder Delivery Tube: Directs
air/powder flow to insert tip.
O-Ring: Seals water when Insert Nozzle is
fully seated in Handpiece.
Air Polishing Insert Tip:
Tube-in-a-tube design
deliveres precise
air/water/powder mixture
at point of delivery.
Insert Rod
Bleed air exits insert
nozzle tip.
Foot control
depressed
half way.
Foot control
released.
Lavage flow
(rinsing function) is
activated.
Air Polishing
Function is activated.
Foot control
depressed
all the way.

ENGLISH • 8
8.2 Air Polishing Powder Chamber
NOTE: Refer to the Infection Control Information Card
(FormNo.80722 ) supplied with your unit for generalproce-
duresto befollowed atthebeginning ofeachday andbetween
patients.
• Use only Cavitron®Prophy-Jet®Cleaning Powder in your
Cavitron™ PROPHY-JET® System. Any other substances
oradditivesmayclogtheUnitandwillvoidthewarranty.For
your convenience, the cleaning powder is supplied in sealed
packets. Keep packets dry and stored in a location that does
not exceed 95oF ( 35o C).
• A special container is provided with your System for powder
filling. The opening in the container’s fill cap permits easy
filling of the powder chamber.
Section 7: Accessories
Section 8: Techniques for Use
8.1 Patient Positioning
•For optimal access to both the upper and lower arches, the
backrest of the chair should be adjusted as for other dental
procedures. This assures patient comfort and clinician
visibility.
7.1 Accessories List*
1. AC Power Cord Set
2. Cavitron™ Jet Insert Nozzle #63740
3. Dual position Foot Switch Assembly #565138003
4. DualSelect™Medicament Dispensing System #80528
5. JetShield™ Aerosol Reduction Device #80578
6. Water Filter Replacement
7. O-Ring to Powder Cap #628052001
*For detailed information, contact your local DENTSPLY®Representative.
• Have the patient turn their head to the right or left. Also
position their chin up or down depending upon the
quadrant and surface being treated. Evacuate irrigant using
either a saliva ejector or HVE.
• It is strongly recommended that the Powder Chamber be
emptied at the end of each day. This will reduce moisture
absorption and minimize clogging.
To fill, or refill, the powder chamber:
• Turn the Unit OFF.
• Unscrew the Powder Fill Cap.
• Transfer the powder from the packet into the fill container
and screw on fill cap.
• Place finger over hole and shake the powder container
vigorously to break up any lumps that may have formed
from settling. Carefully pour powder into the chamber until
the level reaches the top of the center tube.
• Replace the Chamber Powder Fill Cap and tighten.
• Turn the Unit ON.
NOTE: Use only Cavitron®Prophy-Jet®Cleaning Powder in the
unit.Prophy-Jet®CleaningPowdershouldbekeptdryandstoredin
a location that does not exceed 95° F ( 35o C).

ENGLISH • 9
Aerosol reduction device for use with air polishing systems.
JetShield™ assembly and accessories – see Fig. 1. The disposable
JetShield™ assembly is designed for single use; all other
components are reusable and are compatible with standard
clinicequipment.
Precautions:
TheJetShield™itselfisdesignedforsingleuseonly.Useofchemical
orheatsterilizationwillleadtopoorperformanceandmalfunctionof
product.
The reusable components are wipe-disinfectable, using clean cloths
and appropriate non-immersion type disinfectant. Wipe once with
disinfectant to remove gross debris, then use fresh cloth and more
disinfectant to clean surface. Dry with clean paper towel or air.
Section 8: Techniques for Use cont'd
To adjust the flow of powder:
• Adjust the powder flow rate by rotating the left most control
knob on the front panel.
• For heavy stain removal, Rotate fully clockwise.
• For light stain removal, Rotate fully counter clockwise.
• The control can be set at any position as necessary.
• The view window at the center of the pointer lets you observe
the powder flow (a white fluffing of powder) during
operation. If no flow is seen, check for clogging or add
cleaningpowder.
8.3 Air Polishing using the JetShield™
Accessory
B. JetShield™
assembly
F. Connector
C. Connector
D. Handpiece clip
E. Ejector tube clip
A. Ejector tube
Figure 1
Step-by-StepInstructions:
1) Remove entire assembly from package.
2) Insert air polishing nozzle through JetShield™ cup and seat
shoulder flush on nozzle. See Figure 2.
3) InsertconnectoronJetShield™ assemblyintotheflexibleejector
tube.
4) Insert connector of ejector tube into operator saliva ejector.
5) Place ejector tube clip around ejector tube and handpiece cable
such that cables drape together for patient and clinician comfort.
6) (Optional) Place handpiece clip along handpiece, close to hand-
piece/cable connection, such that clip is holding the JetShield™
evacuation tube in place along handpiece.
7) Verify that slurry exits from the JetShield™ when air polishing
unit is activated. Adjust saliva ejector as necessary.
8) Proceed with routine air polishing, applying cup to tooth so cup
flaresslightly.Pivotnozzleinsidecup,adaptingtomesialanddistal
surfaces. Apply 2 seconds of spray for each segment of tooth,
releasing foot control each time. If spray escapes, readjust cup to
maintain flat contact with tooth surface, adjusting angle by
pivoting nozzle inside of handpiece.
1. Insert air polishing nozzle
2. Seat shoulder flush on nozzle
3. Incorrect positioning
Figure 2

ENGLISH • 10
Section 8: Techniques for Use cont'd
Figure 3
After completion of each procedure, remove JetShield™ assembly
anddisposeofJetShield™accordingtoapplicableregulations.Wipe-
disinfect all other components before next use.
8.4 Performing JET Air Polishing
Procedures with JetShield™
NOTE: Refer to the Infection Control Card supplied with your
Systemforgeneralprocedurestobefollowedatthebeginningofeach
day and between patients.
• Install JetShield™ on Cavitron Air Polishing Nozzle as
indicated on instructions provided.
• Select the appropriate amount of powder using the front
panel control on the Cavitron™ PROPHY-JET® air
polishing system.
• Verify that slurry exits from the cup when held outside the
mouth; adjust saliva ejector as necessary.
• Divide the tooth visually into segments to polish (incisal,
middle, and gingival).
• Applycuptomiddle third with light pressure so cup flares
slightly.
• Pivot nozzle inside the cup to adapt to incisal, gingival,
mesial and distal surfaces.
• Apply two seconds of spray for each segment of the tooth,
releasing the Foot Control each time. If spray escapes,
readjust cup to maintain flat contact with tooth surface.
Adjust angle by pivoting nozzle inside the JetShield™
cup.
• The suction from the JetShield™ can be used to remove
excess saliva from the patient's mouth.
• After completing each procedure, dispose of clear
JetShield™assemblyaccordingtoFederal,State,andlocal
regulations. Properly disinfect all other JetShield™
accessories prior to reusing them on future patients.
8.5 Performing Air Polishing procedures
without JetShield™
•The recommended normalprocedureisto clean 2-3teethwith the
air polishing spray (foot control depressed to the second position)
andthenrinsetheareawithwateronly(footcontroldepressedtothe
firstposition)toinspecttheworksitebeforeproceedingtothenext
2-3 teeth. If desired, the bleed air (foot control released) passing
throughthe airpolishinginsert tipcanbe usedtodry the worksite
duringinspection.
•Flushingthepatient'stonguewithwateronly(footcontroldepressed
to the first position) helps reduce the saline taste)
• Maintain a 3 to 4mm insert tip-to-tooth operating distance.
•Thepatient'slipshouldbeheldbetweenthethumbandindexfinger
ofyourfreehandandpulledoutandup,ordown,toforma"cup".
Do not retract the lips.
• Tilt the patient's head toward you to help prevent puddling in the
cupped lip and minimize aerosol dispersion.
• Use a saliva ejector or HVE.
• In the upper anterior region, use the upper lip and your hand as a
shield to help contain the aerosol spray.
•Intheposteriorregions,usethecheektohelpcontainaerosolspray.
• When air polishing the facial surfaces of the anteriors, center the
spray on the middle third of the tooth and use a constant circular
motion. The edge of the spray will clean the teeth to the gingiva.
• Do not aim directly at the soft tissue.
•Avoidprolongeduseonpolishedmetalsurfacesasamattefinishmay
result.

ENGLISH • 11
Section 8: Techniques for Use cont'd
8.6 Proper Angulation of the Air Polishing Insert without JetShield™
Recommended angulation on the ante-
riorteethis60°withthetipaimed atthe
middle third of the tooth surface.
Recommended angulation to
occlusal surfaces is 90°.
Recommended angulation on the buccal and
lingualsurfacesofposteriorteethis80°withthe
tip aimed slightly distally.
Section 9: System Care
9.1 Daily Maintenance
Start-Up Procedures at the beginning of the day:
1. Open the manual shut-off valve on the dental water and air
supply systems.
2. With the system OFF, unscrew the powder chamber cap. Verify
the powder bowl is empty. Turn the Unit ON for 15 seconds
to eliminate residual powder or moisture in the lines. Turn the
system OFF.
3. Open a sealed packet of cleaning powder.
4. Transfer the powder from the packet into the fill container and
scew on fill cap.
5. Pour the powder into the chamber until it reaches the top of the
center tube and screw on powder fill cap.
6. Turn the system ON. Hold the Handpiece (without an insert
installed)overasinkordrain,activatetheFootControl,andflush
the water line at maximum water flow for at least 2 minutes.
7. Place a Cavitron™ JET Insert Nozzle into the Handpiece and
adjust the powder and Lavage Flow as required.
Between Patients:
1. Remove Cavitron™ JET Insert Nozzle (clean using the wire
cleaning tool). Sterilize (See insert instructions)
2. Set Water Control to highest setting. Activate the System and
flush at least 30 seconds.
3. Turn the System OFF.
4. Clean and disinfect the surfaces of the cabinet, Power Cord,
Handpiece Connector and cable assembly, Foot Control and
cable assembly by applying an approved non-immersion type
disinfectant solution* carefully following the instructions
provided by the disinfectant solution manufacturer. To clean
system, generously spray disinfectant solution on a clean towel
and wipe all surfaces. Discard used towel. To disinfect system,
generously spray disinfectant on a clean towel and wipe all
surfaces. Allow disinfectant solution to air dry.
5. If using a closed water supply, check for adequate fluid volumes
for next patient’s scheduled treatment.
Shut-Down Procedures at the end of the day:
1. Turn the Unit OFF.
2. Remove Cavitron™ JET Insert Nozzle (clean using the wire
cleaning tool). Sterilize.
3. Unscrew the powder chamber cap.
4. Remove the powder chamber from the cabinet. Discard the
unused powder from the powder bowl.
5. Hold the open end of the powder chamber away from you.
Activate theSystemfor15secondstoclearthepowderchamber.
A high volume evacuator can be used to remove any residual
powder.
6. Remove the o-ring seal from the Powder Fill Cap and clean
residual powder from the cap. Be careful not to scratch or
otherwise damage the plastic cap.
7. Wipe off the o-ring and place it in the fill cap.
8. If O-Ring is worn, please replace (see section 7.1 for listing).
9. Secure the lid on the powder chamber.
10.Clean and disinfect the surfaces of the cabinet, Power Cord,
Handpiece Connector and cable assembly, Foot Control and
cable assembly by applying an approved non-immersion type
disinfectant solution* carefully following the instructions
provided by the disinfectant solution manufacturer. To clean
system, generously spray disinfectant solution on a clean towel
and wipe all surfaces. Discard used towel. To disinfect system,
generously spray disinfectant on a clean towel and wipe all
surfaces. Allow disinfectant solution to air dry.
*NOTE: Water-based disinfection solutions are preferred. Some
alcohol-baseddisinfectantsolutionsmaybeharmfulandmaydiscolor
plastic materials.

ENGLISH • 12
Section 10: Troubleshooting
Although service and repair of the Cavitron™PROPHY-JET® Air
PolishingProphylaxisSystemshouldbeperformedbyDENTSPLY®
personnel, the following are some basic trouble shooting procedures
thatwillhelpavoidunnecessaryservicecalls.Generally,checkalllines
andconnectionstoand from the System, a loose plug or connection
willoftencreateproblems.CheckthesettingsontheSystem’sknobs.
10.1 Troubleshooting Guide
System will not operate:
(Power Indicator Light is not lighted)
1. Check that the Power switch is in the ON position, and that
detachablePowerCordisfullyseatedinthereceptacleonbackof
System.
2. Check that the System’s three-prong plug is fully seated in an
appropriate AC receptacle, and that AC current is present.
(Polish Indicator Light is not lighted)
1. CheckthattheFootControlConnectorisfullyseatedintheFoot
Control Receptacle on the back of the System.
System operates:
(No lavage flow at insert tip)
1. Assure that Lavage control is properly adjusted.
2. Check that irrigant supply control valve/s (dental office water
supply) are open.
3. IfconnectedtoDualSelect™DispensingSystem,checkthatfluid
level intheselectedbottleissufficient.Makesurevalvesareopen
when using external water source.
4. Check that water filter is clean. Replace water filter if needed.
(JET Insert Nozzle blocks repeatedly)
1. Powder is moisture contaminated (lumpy). Discard powder.
2. Air filter is contaminated. Clean or replace filter.
(No bleed air)
1. Blocked JET nozzle. Clean JET Nozzle using supplied tool.
2. Blocked filter. Clean or replace filter.
(No or poor cleaning action)
1. Very low powder level or empty Powder chamber. Fill Powder
Chamber.
2. Blocked JET Nozzle. Clean JET Nozzle using supplied tool.
3. Fill Cap is loose. Tighten powder fill cap, and turn System ON.
(Continuouspowder agitation)
Fill cap not securely sealed. Shut System OFF. Remove the
O-ringseal from thefillcap and cleanresidualpowder from thecap.
Becarefulnottoscratchorotherwisedamagetheplasticcap.Wipeoff
the O-ring and place it in the fill cap and turn System ON.
10.2 Technical Support and Repairs
For technical support and assistance call 1-800-347-7412 Monday
throughFriday,8:00AMto5:00PM(EasternTime). Forotherareas,
contact your local DENTSPLY®representative.
IftheSystemisconnectedtoaDualSelect™MedicamentDispensing
SystemfollowtherecommendedprocedureslistedintheDualSelect™
manual.
If powder fluffing is observed when Foot Control is not in use, this
wouldindicateanairleak.Tocorrect,turntheUnitOFF,removethe
FillCap,cleananyresidualpowderfromtheO-ringsealandthreads,
replace the Fill Cap, tighten, and turn the Unit back ON.
Section 9: System Care cont'd
9.2 Water Filter Maintenance
1. Disconnect water line from source (either Dental Unit or
DualSelect™)
2. Bleed out water line into sink.
3. Unscrew water filter cap.
4. Remove water filter and check condition of water filter.
5. Replace water filter if filter is dirty or discolored.
6. Screw water filter cap back on.
7. Connect water line to source.

ENGLISH • 13
Section 11: Specifications
Cavitron™ PROPHY-JET®Air Polishing Prophylaxis System: 100/115 VAC Systems
Mode of Operation: Continuous operation with intermittent loading:
10 minutes ON / 20 minutes OFF
Electrical Voltage 100V Gen 122J
115V Gen 122
Current 1.1/1.1 amps @ 100v/115v
Frequency 50/60 Hertz
Water Pressure 25-60 psig (172 - 414 kPa)
Air Pressure 65-100 psig (448 - 690 kPa)
Flow Rate Minimum setting (CCW) 0-15 ml/min
Maximum setting (CW) >55 ml/min
Weight 12 lb. -5,4 kg)
Dimensions Height: 4 in.
Width: 7 3/8 in.
Depth: 9 ½ in.
Handpiece Cable: 81 in.
Foot Control Cable: 96 in.
Power Cord: 84 in.
Water Supply Line: 96 in.
Air Supply Line: 98 in.
Cavitron™ PROPHY-JET®Air Polishing Prophylaxis System: 200/230 VAC Systems
Mode of Operation: Continuous operation with intermittent loading:
10 minutes ON / 20 minutes OFF
Electrical Voltage 200V Gen 122D
230V Gen 122U
Current .7/.6 amps @ 200v/230v
Frequency 50/60 Hertz
Water Pressure 172 - 414 kPa
Air Pressure 448-690 kPa
Flow Rate Minimum setting (CCW) 0-15 ml/min
Maximum setting (CW) >55 ml/min
Weight 5,4 kg
Dimensions Height: 10,2 cm
Width: 18,7 cm
Depth: 24,1 cm
Handpiece Cable: 2,0 m
Foot Control Cable: 2,4 m
Power Cord: 2,1 m
Water Supply Line: 2,4 m
Air Supply Line: 2,5 m
Section 12: Classification
• Type of protection against electric shock: Class 1
• Degree of protection against electric shock: Type B
• Degree of protection against the harmful
ingress of water: Ordinary
• Mode of operation: Continuous
• Degree of safety of application in the presence
of a flammable anaesthetic mixture with air or
with oxygen or nitrous oxide:
Equipment not suitable for use in the
presence of flammable
anesthetics or oxygen.
• According to medical device directive: IIA (rule 9)
OPERATING ENVIRONMENT
Temperature 10 to 25 degrees celsius
Relative Humidity 30 to 75 percent (non-condensing)
TRANSPORT AND STORAGE CONDITIONS
Temperature 0 to 70 degrees celsius
Relative Humidity 10 to 95 percent (non-condensing)
Atmospheric Pressure 500 HPa to 1060 HPa
POWER ON
POWER OFF
Section 13: Disposal of Unit
• Accordance with local and state laws.
TYPE B EQUIPMENT
FOOTSWITCH
AC POWER
Footswitch not for operating theatres
Protection Class - IPXO
IPX1 classification of increase of water
Refer to instruction
manual for information

Worldwide Service Centers
Centres de service après-vente mondiaux
Centros de servicio mundiales
Service-Zentren im Ausland
Centri di assistenza internazionali
U. S. A.
DENTSPLY®Preventive Care
Technical Service and Repair Department
1301 Smile Way
York, PA 17404
Phone: [phone]
Deutschland
DENTSPLY®DeTrey GmbH
De-Trey-Strasse 1
D-78467 Konstanz
Germany
Phone: [phone]
United Kingdom
DENTSPLY®Ltd.
Hamm Moor Lane
Addlestone, Weybridge
Surrey KT15 2SE
England
Phone: [phone]
Australia
DENTSPLY®(Australia) Pty. Ltd.
204-206 Gipps Street
Abbotsford, Victoria 3067
Australia
Phone: [phone]
(3) 9417 1777
Canada
DENTSPLY®Canada
161 Vinyl Court
Woodbridge, Ontario
L4L 4A3 Canada
Phone: [phone]
PrintedinU.S.A Form #80900 01/99
France
DENTSPLY®DeTrey
17 Michael FARADAY
78380 Montigny Le Bretonneux
France
Phone: [phone]
Italia
DENTSPLY®DeTrey Italia S.r.l.
Via A. Cavaglieri, 26
I-00173 Roma
Italia
Tel.: [phone]
Manufactured by
DENTSPLY®Preventive Care
DENTSPLY®International
1301 Smile Way
York, PA 17404
Authorized EU Representative
DENTSPLY®DeTrey GmbH
D-78467 Konstanz, Germany
Distributed by
DENTSPLY®Canada
Woodbridge, Ontario
L4L 4A3
Swiss Representative
DENTSPLY®DeTrey GmbH, Konstanz
Zweigniederlassung Baar
Oberdorfstrasse 11
CH-6342 Baar
