The Midwest®Stylus™ATC
Handpiece Maintenance Instructions
Refer to DFU included with handpiece for detailed instructions on operation,
sterilization, warranty and ordering Information. Additional information can be
obtained at www.stylusatc.com or by calling 1.800.800.7202
After Every Use
1
2
3
4
5
6
7
8
Disconnect handpiece from coupler.
Press push button and remove bur.
Connect ATC Lubrication Nozzle and Cap
assembly onto Midwest Aerosol Spray.
Fully insert nozzle into handpiece,
listening for a “click.”
Cover handpiece head with paper
towel. Hold spray can upright; spray
for one second.
Connect ATC Maintenance Coupler
to back end of handpiece.
Cover ATC handpiece head with
spray guard.
11 Wipe off excess lubricant on outside
of handpiece with dry gauze pad or
paper towel.
12 Steam sterilize handpiece (without bur)
at maximum 135˚C/275˚F (bagged cycle).
10 If not using air station, connect to
4- or 5-hole hose to expel.
Caution: ATC Maintenance Coupler
must be used to expel lubricant. Do
not use the ATC controller unit to expel.
Scrub and rinse handpiece under warm
water with soft sponge. Scrub fiber-optic
light port well.
9Connect handpiece to Midwest air
station with ATC Maintenance Coupler.
Run air through handpiece for 30
seconds at 40 psi to expel lubricant.
ATC Lubrication Nozzle Capp (880080)
Midwest Aerosol Spray (380080)
ATC Maintenance Coupler (880090)
Spray Gaurd (380150)
Midwest Air Station (380800)
Spray Guard (380150)

www.StylusATC.com
Technical Customer Service / Air Repair
1.800.800.7202
Code No. 87135-0610
©2010 DENTSPLY. All rights reserved.
1Cleaning Wires
2Maintenance Coupler
3Bulbs
4O-Rings
5Lubrication Nozzle and Cap
6Spray Guard
7Midwest Plus™Lubricant
1
2
3
4
5
6
7
The Midwest®Stylus™ATC
Handpiece Maintenance Instructions
Refer to DFU included with handpiece for detailed instructions on operation,
sterilization, warranty and ordering Information. Additional information can be
obtained at www.stylusatc.com or by calling 1.800.800.7202
Weekly
1
2
Lubricate chuck once a week
a. Weekly, or if push button gets stiff,
insert a drop of Midwest Plus™
lubricant (REF380130) into
handpiece chuck only. Do this
before sterilization.
b. Free run handpiece without a bur
until excess lubricant is expelled
(minimum 30 seconds).
Wipe off excess lubricant on
outside of handpiece with dry
gauze pad or paper towel.
Lubricate coupler O-Rings
Weekly or if handpiece swivel gets stiff,
lightly lubricate the coupler O-Rings with
Midwest Plus™lubricant (REF380130).
O-Rings
1Clean handpiece water spray holes
Run the cleaning wire back and forth in
spray holes to loosen and remove
any mineral build-up at spray surface.
As Needed
2
Contents of the Maintenance Kit (380145)
(464197)
(880090)
(880040)
(880070)
(880080)
(380150)
(380130)
