MODELS: VCBK4R &VCBK4L FAN KIT
INSTALLATION AND OPERATING INSTRUCTIONS
INSTALLING BLOWER BEFORE MOUNTING FIREPLACE
Figure 1 Figure 2
Knockout Tab
Electrical Connection
Fireplace
Rocker Switch
and Wiring Male Electrical
Connector
Blower
Assembly
Figure 3 Figure 4
Fireplace
Sheet Metal
Screws
Blower
Assembly
Rectangular
Bracket
ON/OFF Switch
Fireplace Face
Note: Fireplace must be properly connected to a 110V power source
before blower can be operated.
1. Remove large knockout tab (see Figure 1).
2. Align two holes on side of rectangular bracket with two holes
on side frame. Secure with screws provided (see Figure 7).
3. Place blower assembly in replace and plug male electrical
connectorintofemaleconnectoralreadyinreplace.Makesure
rockerswitchwireprotrudesthroughnotchinreplaceside(see
Figure 2). Connect wires with rocker switch.
4. Take four sheet metal screws provided and secure blower as-
semblytoreplacethroughholes(seeFigure3).Blowershould
now be in place and look similar to Figure 4.
Note See instructions on reverse side if FULL VIEW glass doors
are installed.

INSTALLING BLOWER AFTER MOUNTING THE
FIREPLACE
Note: Fireplace must be properly connected to a 110V power source
before blowers can be operated.
1. Remove three screws that secure side brick retainers. Pull out
sidebrickexposingblowercoverplateonrightsideofreplace
(see Figure 5).
2. Remove blower cover plate (see Figure 6).
3. Placeblowerassemblythroughholeinrebox.Makesurewire
protrudesthroughnotchinreplaceside.Aligntwoholeson
side of rectangular bracket with two holes on side frame. Secure
withscrewsprovided(seeFigure7).Blowerassemblyshould
now look similar to Figure 8.
4. Beforereplacingblowercoverplate,plugmaleelectricalconnec-
toronblowerassemblyintofemalesocketalreadyinreplace.
Replaceblowercoverplate,sidebrickandretainerbeforeusing
replace.
SPECIAL INSTRUCTIONS FOR GLASS DOORS
Ifdoorsareinstalled,itisnecessarytoremovetherightdoorandsideframe.Toremovedoor,pressupperhingespringindoortrackand
slidetrackandslidedoorassemblytotheleft.Toremovesidedoorframe,removetopandlowermosthexheadscrewssecuringframe.
Figure 8
ON/OFF Switch
Fireplace Face
Figure 7
Figure 6Figure 5
Side Brick
Side Brick
Retainer
Fan
Cover
Plate
Knockout
Plate
Rectangular
Bracket
Rectangular
Bracket
Fireplace
Side
Fan Assembly
Firebox
56105
Rev. C
01/06
NOT A UPC
2701 Industrial Drive
P.O. Box 90004
Bowling Green, KY 42102-9004
56105
For more information, visit www.desatech.com
ON/OFF
Switch Wiring
