Line Storage Bed
Designed by Nathan Yong for Design Within Reach
Customer Service:
1.800.944.2233 inside the U.S.
1.203.614.0600 outside the U.S.
Wood Care
Dust with a slightly damp, soft,
lint-free cloth. Wipe dry with a
dry, soft cloth in the direction of
the wood grain. Do not use aerosol
cleaners or polishes. Also, do not
use polishes containing waxes
or abrasives, or polishes that are
oil-based.

2 | WWW.DWR.COM | 1.800.944.2233 | DESIGN WITHIN REACH STUDIOS
Line Storage Bed
Hardware Checklist
LONG BOLT X 1
(M6 X 50MM)
SMALL ALLEN WRENCH X 1 LARGE ALLEN WRENCH X 1 SPANNER WRENCH X 1
SHORT BOLT X 84
(M6 X 30MM)
MEDIUM BOLT X 18
(M6 X 35MM)
INSERT SCREW X 4
L-BRACKET X 1
ELECTRIC DRILL (OPTIONAL)

3 | WWW.DWR.COM | 1.800.944.2233 | DESIGN WITHIN REACH STUDIOS
Line Storage Bed
Parts Checklist
CENTER LEG X 1
HEADBOARD X 1 FOOTBOARD/DRAWER ASSEMBLY X 1
SIDE RAIL X 2 CENTER RAIL X 1
SLAT X 42

4 | WWW.DWR.COM | 1.800.944.2233 | DESIGN WITHIN REACH STUDIOS
Line Storage Bed
Drawer Adjustments
Underside of drawer
HOW TO RELEASE DRAWER SLIDES
Squeeze both handles at front underside of drawer and firmly pull drawer forward.
HOW TO REINSTALL DRAWER
Fully extend drawer slides and place drawer box on top of slides. Pull each drawer
slide forward until it locks into both left and right side clips. You will hear a “click”
when slide is locked properly.
HOW TO ADJUST DRAWER FACE
Drawer faces can be leveled by sliding small adjustment knob forward and back
or side to side. Each knob adjusts a single corresponding side of drawer face.

5 | WWW.DWR.COM | 1.800.944.2233 | DESIGN WITHIN REACH STUDIOS
Attach headboard to side rails, as shown, using six medium bolts all threaded in loosely at first, then tighten with small Allen wrench.
2.
Position drawer assembly near bed’s final location, then remove drawers and set aside. Attach one side rail, as shown,
using four medium bolts. Thread all bolts loosely at first, then tighten with small Allen wrench. Repeat with opposite side rail.
1.
Line Storage Bed
*A minimum of three people recommended for assembly.

6 | WWW.DWR.COM | 1.800.944.2233 | DESIGN WITHIN REACH STUDIOS
Line Storage Bed
Attach L-brackets to headboard and footboard using insert screws, as shown.
3.
Attach center leg to center rail with one long bolt. Tighten with small Allen wrench.
4.

7 | WWW.DWR.COM | 1.800.944.2233 | DESIGN WITHIN REACH STUDIOS
Line Storage Bed
Position center rail as shown and attach to L-brackets on headboard and footboard using insert screws.
Thread all screws loosely at first, then tighten with small Allen wrench.
5.
Use spanner and large Allen wrench to level bed with seven adjustable feet, including on center leg.
6.

8 | WWW.DWR.COM | 1.800.944.2233 | DESIGN WITHIN REACH STUDIOS
Line Storage Bed
Attach slats using 84 short bolts. Thread all bolts loosely at first, then tighten with small Allen wrench or electric drill fitted with a hex bit.
7.
Extend slides and reinstall drawers.
8.
