Design Within Reach Edel 100168617 User manual

Edel Table
Designed by Jenkins & Uhnger for Design Within Reach
1 | WWW.DWR.COM | 1.800.944.2233 | DESIGN WITHIN REACH STUDIOS
Customer Service:
1.800.944.2233 inside the U.S.
1.203.614.0600 outside the U.S.
For care instructions, please visit
dwr.com/learn.

Edel Table
2 | WWW. D W R .COM | 1. 800 . 944.2233 | DESIGNWITHIN REACH STUDIOS
Hardware List
Parts List
Table top x 1
Wooden dowel x 12
M8 x 35mm
Short bolt x 16
M6 x 20mm
Long bolt x 8
M6 x 80mm
Leg frame x 2
Connection plate x 4 Allen wrench x 1
M4
Rubber mallet
(not provided)

Edel Table
3 | WWW. D W R .COM | 1. 800 . 944.2233 | DESIGNWITHIN REACH STUDIOS
1. 2.
3.
Insert dowels in predrilled holes in top of leg frames. Turn tabletop upside down and place on a soft, flat surface such as
a rug or blanket to protect finish. Align leg frames with predrilled
holes on tabletop, as shown, then press to seat firmly. Gently tap
the legs straight down with rubber mallet if needed.
Insert four long bolts into each leg frame, as shown, and tighten all loosely. Using Allen wrench, tighten bolts equally until all are nearly snug, then
return to each and tighten fully.

Edel Table
4 | W W W . DW R . COM | 1. 8 0 0 . 944 . 2233 | DESIGN W ITHIN REACH STUDIO S
4.
5.
Attach two connection plates on one leg frame, as shown, using four short bolts each and tighten loosely. Using Allen wrench, work from plate to plate
to gradually tighten bolts equally until all are nearly snug, then return to each and tighten fully. Repeat with other leg frame.
Turn table upright, then adjust feet, as shown, until table is level, turning clockwise to raise and counterclockwise to lower.
Lower Raise

Edel Table
5 | W W W . DW R . COM | 1. 8 0 0 . 944 . 2233 | DESIGN W ITHIN REACH STUDIO S
6a.
6b.
Cable routing plugs can be inserted from the outside of the desk for easy removal.
As a more permanent solution, cable routing plugs can be inserted from the interior of the desk.
