Design Within Reach Coda User manual

When Using Your Own Frame:
• You may need to remove the U-bracket from
the headboard. See page 3.
• You may require a modi-plate. See page 3.
• The headboard must rest against the wall during
and after frame assembly for added support.
1 | WWW.DWR.COM | 1.800.944.2233 | DESIGN WITHIN REACH STUDIOS
Customer Service:
1.800.944.2233 inside the U.S.
1.203.614.0600 outside the U.S.
For care instructions, please visit
dwr.com/learn.
Coda Headboard Assembly

Hardware List
Parts List
40" Coda Headboard x 1
Twin, Full, Queen or King
48" Coda Headboard x 1
Twin, Full, Queen or King
OR
Optional Felts for
Footboard Legs
READ BEFORE BEGINNING ASSEMBLY
Please identify all parts and have the required hardware before you begin. Read all instructions before assembly. Carefully remove all of the
components from the packaging and set aside for assembly. Assemble on a clean and at soft surface to prevent scratching during assembly.
Tighten all components securely before use. DO NOT use this product if any parts are missing or broken. DO NOT substitute parts. Check parts
and hardware periodically for tightness and positioning. If replacement components and additional instructions are needed, or if you have any
questions, contact customer service. Failure to follow these warnings and assembly instructions could result in serious injury or death.
Large Flat Washer x 6
1/4" inside dia
3/4" outside dia
Short Bolt x 6
1/4" dia
3/4" length
Optional Tool Allen Wrench x 1
Spring Washer x 6
1/4" inside diameter
1/2" outside diameter
2 | WWW.DWR.COM | 1.800.944.2233 | DESIGN WITHIN REACH STUDIOS
Coda Headboard Assembly

Check these dimensions to see if this
headboard will t your frame.
(A) Distance from oor to
mounting holes
(B) Mounting hole spacing
Twin 37.6"
Full 52.2"
Queen 58.5"
King 74.6"
(C) Leg dimensions
W 2.5" D 2.5" H 4.5"
A
B
C
5.05"6.85"8.95"11.05"13.25"
If pairing a DWR Headboard with your own frame,
please reference hardware sizes, hole spacing
guides, and leg heights to determine compatibility.
Attachment to any frame other than a coordinating
DWR platform frame may require a modi-plate.
We recommend having a second person hold
headboard while it rests against destination wall
during assembly. Headboard should remain resting
against wall after assembly for support.
U-bracket on headboard (excluded from twin size)
may need to be removed to work with your own
frame. To do this, use a Phillips screwdriver.
3 | WWW.DWR.COM | 1.800.944.2233 | DESIGN WITHIN REACH STUDIOS
Coda Headboard Assembly
