DeVilbiss IntelliPAP 2 Series User manual

DeVilbiss IntelliPAP 2 Series: Single Battery Connection
BATTERY POWER SOLUTIONS
Page 1 of 2 January 2018
REQUIRED COMPONENTS
FreedomTM CPAP Battery Kit
150W Sine Wave Power Inverter (inverter)
CONNECTION INSTRUCTIONS
Plug the DC input cord into the DC OUT jack of the battery.
Plug the inverter into the DC input cord.
Plug the AC power cord of the PAP device into the inverter.
Turn the PAP device on and it should begin functioning.
The digital display screen will show the charge level of the battery. You may press the charge level indicator
button to illuminate this screen. It will stay illuminated for a few seconds at a time.
When not in use disconnect all devices from the battery thus allowing the battery to completely shut down.

PLUG IN PAP DEVICE
AC POWER SUPPLY

DC INPUT CORD

150W SINE WAVE
POWER INVERTER

DC OUT JACK
The inverter can also be used to charge the battery in a vehicle (vehicle does not need to be running) and to power/charge
other small electronic devices with the battery. The inverter is not proprietary to the FreedomTM CPAP Battery and can be
used with other external batteries.
OPTIONAL FREEDOMTM CPAP BATTERY CHARGING ACCESSORIES


Auto Charge DC Cable {BPS DC.CABLE}: Used to charge the battery in a vehicle (vehicle must be running).


SunPower 40W Solar Panel {BPS SP40}: Used to charge the battery using the power of the sun.

BATTERY POWER SOLUTIONS
Page 2 of 2 January 2018
DeVilbiss IntelliPAP 2 Series: Dual Battery Connection
REQUIRED COMPONENTS
FreedomTM CPAP Battery Kit
FreedomTM CPAP Battery (additional battery only)
150W Sine Wave Power Inverter (inverter)
CONNECTION INSTRUCTIONS
Plug the DC power pigtail cord into the DC OUT jacks of both batteries.
Plug the DC input cord into the DC power pigtail cord.
Plug the inverter into the DC input cord and then plug the AC power cord of the PAP device into the inverter.
Turn the PAP device on and it should begin functioning.
The digital display screen will show the charge level of the battery. You may press the charge level indicator
button to illuminate this screen. It will stay illuminated for a few seconds at a time.
When not in use disconnect all devices from the battery thus allowing the battery to completely shut down.

150W SINE WAVE
POWER INVERTER

DC POWER
PIGTAIL CORD

DC INPUT CORD
DC OUT JACKS


PLUG IN PAP DEVICE
AC POWER SUPPLY
The inverter can also be used to charge the battery in a vehicle (vehicle does not need to be running) and to power/charge
other small electronic devices with the battery. The inverter is not proprietary to the FreedomTM CPAP Battery and can be
used with other external batteries.
OPTIONAL FREEDOMTM CPAP BATTERY CHARGING ACCESSORIES


Auto Charge DC Cable {BPS DC.CABLE}: Used to charge the battery in a vehicle (vehicle must be running).


SunPower 40W Solar Panel {BPS SP40}: Used to charge the battery using the power of the sun.
