DeVilbiss IntelliPAP Series: Single Battery Connection
BATTERY POWER SOLUTIONS
Page 1 of 2 February 2017
DeVilbiss IntelliPAP series devices can be connected directly to the FreedomTM CPAP Battery using the DC power
pigtail cord and appropriate connector tip included in the FreedomTM CPAP Battery Kit. Please note IntelliPAP 2 series
devices will require the use of the 150W sine wave power inverter in conjunction with the FreedomTM CPAP Battery
Kit to complete the connection between the PAP device and the battery.
REQUIRED COMPONENTS
FreedomTM CPAP Battery Kit
CONNECTION INSTRUCTIONS
Plug the DC power pigtail cord into the DC OUT jack of the battery.
Insert the connector tip with blue top labeled “J” into the DC power pigtail cord.
Plug the DC power pigtail cord with “J” connector tip attached into the DC input port of the PAP device.
Turn the PAP device on and it should begin functioning.
The digital display screen will show the charge level of the battery. You may press the charge level indicator
button to illuminate this screen. It will stay illuminated for a few seconds at a time.
When not in use disconnect all devices from the battery thus allowing the battery to completely shut down.

CONNECTOR TIP INSERTED
INTO PAP DC INPUT PORT
DC POWER PIGTAIL CORD

DC OUT JACK

OPTIONAL FREEDOMTM CPAP BATTERY CHARGING ACCESSORIES


Auto Charge DC Cable {BPS DC.CABLE}: Used to charge the battery in a vehicle (vehicle must be running).


150W Sine Wave Power Inverter {BPS 150 INVERTER}: Used to charge the battery in a vehicle (vehicle does not need to
be running) and allows the battery to power/charge other small electronic devices.


SunPower 40W Solar Panel {BPS SP40}: Used to charge the battery using the power of the sun.

BATTERY POWER SOLUTIONS
Page 2 of 2 February 2017
DeVilbiss IntelliPAP Series: Dual Battery Connection
OPTIONAL FREEDOMTM CPAP BATTERY CHARGING ACCESSORIES


Auto Charge DC Cable {BPS DC.CABLE}: Used to charge the battery in a vehicle (vehicle must be running).


150W Sine Wave Power Inverter {BPS 150 INVERTER}: Used to charge the battery in a vehicle (vehicle does not need to
be running) and allows the battery to power/charge other small electronic devices.


SunPower 40W Solar Panel {BPS SP40}: Used to charge the battery using the power of the sun.
DeVilbiss IntelliPAP series devices can be connected directly to the FreedomTM CPAP Battery using the DC power
pigtail cord and appropriate connector tip included in the FreedomTM CPAP Battery Kit. Please note IntelliPAP 2 series
devices will require the use of the 150W sine wave power inverter in conjunction with the FreedomTM CPAP Battery
Kit to complete the connection between the PAP device and the battery.
REQUIRED COMPONENTS
FreedomTM CPAP Battery Kit
FreedomTM CPAP Battery (additional battery only)
CONNECTION INSTRUCTIONS
Plug the DC power pigtail cord into the DC OUT jacks of both batteries.
Insert the connector tip with blue top labeled “J” into the DC power pigtail cord.
Plug the DC power pigtail cord with “J” connector tip attached into the DC input port of the PAP device.
Turn the PAP device on and it should begin functioning.
The digital display screen will show the charge level of the battery. You may press the charge level indicator
button to illuminate this screen. It will stay illuminated for a few seconds at a time.
When not in use disconnect all devices from the battery thus allowing the battery to completely shut down.
DC POWER PIGTAIL CORD


DC OUT JACKS

CONNECTOR TIP INSERTED
INTO PAP DC INPUT PORT
