DeVilbiss®Vacu-Aide®QSU Suction Unit Instruction Guide 7314 Series
RX ONLY
Assembled in USA
ES
Guía de Instrucciones para la Unidad de Succión de la Serie 7314 de DeVilbiss®
Vacu-Aide®QSU
RX ÚNICAMENTE
Ensamblado en EE. UU.
FR
Manuel utilisateur de l’apirateur de mucosités Vacu-Aide®QSU Série 7314
UNIQUEMENT SUR PRESCRIPTION
Assemblé aux États-Unis

EN - 2 A-7314
EN ENGLISH......................................................................................................................................... EN-2
ES ESPAÑOL ........................................................................................................................................ ES-11
FR FRANÇAIS....................................................................................................................................... FR-21
TABLE OF CONTENTS
IEC Symbols.................................................................................................................................................................................................................................................... EN - 2
Important Safeguards...................................................................................................................................................................................................................................... EN - 2
International Travel.......................................................................................................................................................................................................................................... EN - 3
Introduction...................................................................................................................................................................................................................................................... EN - 3
Accessory/Replacement Items........................................................................................................................................................................................................................ EN - 3
Important Parts of Your 7314 Series DeVilbiss Suction Unit .......................................................................................................................................................................... EN - 4
Set-Up & Operation......................................................................................................................................................................................................................................... EN - 5
Battery Charging & Filter Maintenance .......................................................................................................................................................................................................... EN - 6
Cleaning Instructions....................................................................................................................................................................................................................................... EN - 7
Troubleshooting............................................................................................................................................................................................................................................... EN - 9
Provider’s Notes.............................................................................................................................................................................................................................................. EN - 9
Specifications/Classifications .......................................................................................................................................................................................................................... EN - 10
Warranty.......................................................................................................................................................................................................................................................... EN - 10
Electromagnetic Compatibility Information...................................................................................................................................................................................................... EN - 11
SYMBOL DEFINITIONS
Attention, consult instruction guide Center positive polarity indicator Battery charging
It is mandatory to read Operating
Instructions prior to use. This symbol has a
blue background on the product label. Type BF equipment-applied part Low battery
Date of manufacture “On” compressor Keep dry
Manufacturer “Off” compressor (external battery charging) Do not get wet
Direct current External power EC REP European Representative
Alternating current Catalog Number Federal (U.S.A.) law restricts this device to
sale by or on the order of a physician.
Choking Hazard – Small parts not for children under 3 years or any individuals who have a tendency to place inedible object in their mouths.
IP22 Protected against solid material of ≥ 12.5 mm and vertically falling water drops when enclosure is tilted up to 15˚
This device contains electrical and/or electronic equipment that must be recycled per EU Directive 2012/19/EU- Waste Electrical and Electronic Equipment
(WEEE)
IMPORTANT SAFEGUARDS
When using electrical products, especially when children or pets are present, basic safety precautions should always be followed. Read all instructions before using. Important
information is highlighted by these terms:
DANGER– Urgent safety information for hazards that will cause serious injury or death.
WARNING– Important safety information for hazards that might cause serious injury.
CAUTION– Information for preventing damage to the product.
NOTE– Information to which you should pay special attention.
READ ALL INSTRUCTIONS BEFORE USING THIS DEVICE.
THE USER SHALL BE PROPERLY TRAINED PRIOR TO OPERATING THE DEVICE.
SAVE THESE INSTRUCTIONS.
DANGER
To reduce the risk of electrocution:
1. Do not use while bathing.
2. Do not place or store product where it can fall or be pulled into a tub or sink.
3. Do not place in or drop into water or other liquid.
4. Do not reach for a product that has fallen into water. Unplug immediately.
WARNING
To reduce the risk of burns, electrocution, allergy, re or injury to persons:
1. Close supervision is necessary when this product is used by, on, or near children or physically incapacitated individuals.
2. Use this product only for its intended use as described in this guide.
3. Keep the power cord away from heated surfaces.

EN - 3A-7314
4. Never use while drowsy or asleep.
5. Do not cover the unit or the AC to DC adapter while power is applied.
6. Never operate this product if
a. It has a damaged power cord or plug.
b. It is not working properly.
c. It has been dropped or damaged.
d. It has been dropped into water.
Instead return the product to an authorized DeVilbiss Healthcare service center for examination and repair.
7. Check the collection container for cracks before each use. Do not use if cracked.
8. Universal precautions must be observed while providing care or handling equipment for persons with an infectious condition.
9. Do not place the suction unit in a position that would make it difcult to disconnect the AC power cord.
10. When the device is used under extreme operating conditions and in the carrying case, the surface temperature of the device may exceed 73°C.
11. The suction tube shall be kept isolated from other parts of the system to conrm that it does not exceed 43°C prior to patient contact.
12. The catheter to be used shall be carefully inserted to prevent strangulation/choking.
13. Don’t let children play with the tubing as this may lead to strangulation.
14. Consult the physician in case of any allergic reaction due the use of the device.
15. Keep the suction pump out of the reach of children and pets and away from pests.
NOTE– All the materials used in the suction pump are Latex free.
INTERNATIONAL TRAVEL
The 7314 series is equipped with an AC to DC adapter allowing operation on any AC voltage (100-240 VAC, 50/60 Hz). However the correct power cord must be used to
connect to adaptable wall power. AC power is removed by disconnecting the power cord from the AC outlet receptacle.
NOTE– Check power cord for adaptability before using.
INTRODUCTION
Your DeVilbiss suction unit is a compact medical suctioning device which has been designed for reliable, portable operation. Following the recommended operating and
maintenance procedures outlined in this instruction guide will maximize the life of this product. This guide provides an overview of the suction unit and operation. Your
equipment provider should give more detailed instructions related to patient care.
Intended Use Statement
The device is to be used to remove uids from the airway or respiratory support system and infectious materials from wounds. The device creates a negative pressure
(vacuum) that draws uids through disposable tubing that is connected to a collection container. The uids are trapped in the collection container for proper disposal. It is for
use on the order of a physician only.
Contraindications (specific situation in which the device shall not be used)
The Vacu-Aide QSU should not be used for:
• thoracic drainage
• nasogastric suction
DANGER
The DeVilbiss Vacu-Aide is a vacuum suction device designed for the collection of nonammable uid materials in medical applications only. Improper use during
medical applications can cause injury or death. For all medical applications:
1. All suctioning should be done in strict accordance with appropriate procedures that have been established by a licensed medical authority.
2. Some attachments or accessories may not t the tubing supplied. All attachments or accessories should be checked prior to use to assure proper t.
ACCESSORY/REPLACEMENT ITEMS
The following items can be purchased separately as accessories or replacement items for your 7314 Series DeVilbiss Suction Unit:
Description Part No. Description Part No.
6’ Patient Tubing (USA) SUCP TUBING 72 Carrying case 7314D-606
6’ Patient Tubing (International) 6305D-611 12V DC power cord (1 each) 7304D-619
800 Disposable Container (container and lid only) for use with external bacteria
lter (48 pack) 610-48BP AC to DC adapter/charger 7314P-613
Collection Container Kit (800 ml disposable container, external bacteria lter, elbow,
10” and 6’ tubing package) 22330 Power cord for USA DV51D-606
Collection Container Kit (Internal lter cartridge, splash guard, 800 ml container,
4-1/2” (11.43 cm) and 6’ tubing package) 7305D-633 Power cord for Continental Europe DV51D-607
800 ml disposable container with internal lter cartridge, splash guard and 4-1/2”
(11.43 cm) tubing (48 each) 7305D-632 Power cord for UK DV51D-608
Filter cartridge (12 pack) (For Disposable Container with internal lter) 7305D-635 Power cord for Australia DV51D-609
Collection Container Kit (1200 ml reusable container, external bacteria lter, elbow,
4-1/2” (11.43 cm) tubing) 7314D-603 Power Cord for Brazil DV51D-612
1200 ml reusable container (external bacteria lter, elbow, 4-1/2” (11.43 cm) tubing)
(6 pack) 7314D-604 Power cord for Japan DV51D-613
External bacteria lter (non-sterile) (12 pack) For reusable container and disposable
container with external lter 7305D-608 Power Cord for China DV51D-614
Splash Guard (12 pack) for Disposable Container with internal lter cartridge 7305D-641 Power Cord for Argentina 180-0006-011
NOTE– The use of electrical cables and accessories other than those specied in this manual or referenced documents may result in increased electromagnetic emissions
from the product or decreased electromagnetic immunity of the product.

EN - 4 A-7314
IMPORTANT PARTS
Disposable Container with Internal Filter
Cartridge and Splash Guard
1. 4-1/2” (11.43 cm) connection tubing
2. Filter cartridge (Do not get wet)
3. Lid
4. Jar
5. Splash guard
6. Patient tubing connector
Disposable Container with External Bacteria
Filter
1. 3-3/8” (8.57 cm) connection tubing
2. Patient tubing connector
3. Lid
4. Jar
5. Connection elbow
6. Bacteria lter
Reusable Container with External Bacteria
Filter
1. 4-1/2” (11.43 cm) connection tubing
2. Lid with o-ring
3. Overow valve
4. Jar
5. Patient tubing connector
6. Connection elbow
7. Bacteria lter
6
1
4
2
7
8
9
5
3
7
1
5
2
8
9
10
6
4
3
1
5
3
6
2
4
7
1
2
5
3
4
6
1
5
2
4
6
3
with Disposable Container and Internal Filter
Cartridge
1. Vacuum gauge
2. Vacuum regulator knob
3. 6’ patient tubing
4. Patient tubing connector
5. Disposable container with lid (oat shut off
incorporated into lid) and lter cartridge
6. Filter cartridge with 4-1/2” (11.43 cm) tubing
7. DC power input (on side)
8. Power switch
9. LED power lights
AC to DC adapter (not shown)
DC power cord (not shown) optional
Internal rechargeable battery (not shown) 7314P
series only
Carrying case (not shown) 7314P series only
with Disposable Container and External
Bacteria Filter
1. Vacuum gauge
2. Vacuum regulator knob
3. 3-3/8” (8.57 cm) connection tubing
4. 6’ patient tubing
5. Patient tubing connector
6. Disposable container with lid (oat shut off
incorporated into lid)
7. DC power input (on side)
8. Power switch
9. LED power lights
10. External bacteria lter
AC to DC adapter (not shown)
DC power cord (not shown) optional
Internal rechargeable battery (not shown) 7314P
series only
Carrying case (not shown) 7314P series only
with Reusable Container and External
Bacteria Filter
1. Vacuum gauge
2. Vacuum regulator knob
3. 4-1/2” (11.43 cm) connection tubing
4. External bacteria lter
5. Patient tubing connector
6. 6’ patient tubing
7. Lid
8. DC power input (on side)
9. Power switch
10. LED power lights
AC to DC adapter (not shown)
DC power cord (not shown) optional
Internal rechargeable battery (not shown) 7314P
series only
Carrying case (not shown) 7314P series only
7314 Series DeVilbiss Vacu-Aide QSU Suction Unit
75
6
10 1
4
83
2
9

EN - 5A-7314
5B
SET-UP & OPERATION
Fully charge battery for 17
HOURS. (7314P series only) Insert container into holder and gently push into place. NOTE– Do not use excessive force. Pushing container down
too hard could cause potential leak or loss of suction.
Attach 6’ patient tubing to
container lid at outlet labeled
<Patient>.
Turn the unit “on”.
If using AC or DC power, plug
the small connector into the
DC power input on the side of
unit.
Plug the other end into an AC
wall outlet or DC receptacle.
NOTE– The AC adapter may
become warm to the touch
during charging or running of
the unit. This is normal.
Adjust the suction level.
Verify suction level.
NOTE - Always verify suction
level before beginning by
occluding open end of patient
tubing while observing gauge.
Adjust knob to desired level.
WARNING
If the unit is not receiving power from an external source or the battery was not recharged, the low battery indicator light will remain
on and the performance of the unit will drop off rapidly. Switch to another power source immediately after the low battery light appears
to avoid an interrupted suction procedure.
NOTE– The vacuum (negative) pressure should be set as directed by a physician or other appropriate health care professional. Published expert
consensus suggests the suction vacuum pressure should be set as low as possible to effectively clear secretions.1For tracheal and/or
endotracheal suctioning, a vacuum (negative) pressure of less than 100 mmHg in infants, less than 120 mmHg in children and less than 150
mmHg in adults has been recommended.2
NOTE– Gauge is for reference only. If the unit sustains a severe drop, accuracy of the gauge must be checked.
CAUTION– When automatic oat shut-off is activated, contents of the collection container should be emptied. Further suctioning could cause
damage to the vacuum pump.
CAUTION– Should uid be aspirated back into the unit, equipment provider servicing is necessary as possible vacuum pump damage may
result.
WARNING
This device is rated for intermittent operation use as noted in the specications. Do not operate device with no ow (or suction port
blocked). Continuous operation under this condition may cause the unit to thermal shut off or damage the device.
1
Ensure power switch is “off”.
7
Disposable Container w/
internal lter cartridge
Connection: Attach 4-1/2”
(11.43 cm) tubing from lter
cartridge to tubing connector
on unit.
5A 6
7314P - Select desired power
source. (Skip step 8 if using
internal battery power.)
7A 8 10 11
12
NOTE–Inspect suction tubing and container for leaks, cracks, etc. and assure that all connections are secure and without leaks before using.
9
Reusable Container and Disposable Container w/external
Bacteria Filter Connection: Connect either end of the 4-1/2”
(11.43 cm) (reusable) or 3-3/8” (8.57 cm) (disposable) tubing to
the tubing connector then connect the other end to the bacteria
lter. NOTE–If connection tubing in the 22330 Kit is longer than
specied measurements, cut tube to 4-1/2 inches to provide a
good t with the unit. Ensure that the clear side of the bacteria
lter is toward elbow and bottle when installing. Do not reverse
direction of lter. The bacteria lter should then be connected to
the 90˚ elbow connection, and the elbow should be connected
to the top of the container lid where it says <Vacuum>.
5C
7B
NOTE– The 7314D series is not factory equipped with an
internal rechargeable battery. 7314P series is factory equipped
with an internal rechargeable battery and all information
regarding battery operation in this guide is applicable.
7314D series (non-battery
label)
If applicable, ensure splash
guard is securely attached to
inside of lid over lter
cartridge.
4
Securely attach lid to
container.
23
1 AARC Clinical Practice Guideline. Endotracheal Suctioning of Mechanically Ventilated Patients With Articial Airways-2020. Respir Care 2010;55(6): 758- 764.
2 AARC Clinical Practice Guideline. Nasotracheal Suctioning-2004 Revision & Update. Respir Care 2004;49(9); 1080-1084

EN - 6 A-7314
NOTE– Charge battery for a minimum of 17 hours before rst use.
NOTE– Fully recharge battery after each use. The unit will continue to oat charge the battery after the charge indicator turns off, so leave the unit connected to AC when not in use.
CAUTION– Discharging the battery completely will shorten the life of the battery. Do not operate the unit more than a few minutes if the low battery indicator light is lit. Recharge as soon
as possible.
NOTE– Unit run time will decrease as the battery ages.
NOTE– Unit run time will also be reduced by letting the battery sit at a discharged state for extended periods.
STORAGE NOTE– Battery should be charged for a minimum of 17 hours prior to storage, and at least once every 6 months. Important - If battery recharge is delayed beyond 6 months,
battery may be able to provide full run time after completion of 3 full charge and discharge cycles.
NOTE– A fully charged battery will provide approximately 60 minutes of continuous operation at a zero vacuum level (free ow). Operation time will decrease with higher vacuum levels.
NOTE– When charging the battery, use an external power source and verify that the charge light illuminates when the unit is in the “Off’ position. If the battery does not charge, please
be sure the model you are using has a battery installed prior to contacting your authorized DeVilbiss Healthcare provider.
NOTE– The internal rechargeable battery is sealed lead-acid. Contact your local authorities for instruction on proper disposal.
NOTE– Do not connect the AC adapter to an outlet controlled by a switch to ensure power is supplied to unit at all times.
NOTE– Do not connect the DC power cord to an outlet that is not constantly energized.
BATTERY CHARGING & FILTER MAINTENANCE
Battery Charging (7314P Series Only)
On 7314P series, the units are equipped with a factory-installed rechargeable battery. The unit will have a light for low battery and charge indication.
Ensure power switch is “off”. Plug the small connector of
the AC or DC adapter into the
DC power input.
Plug the other end into an AC
wall outlet or DC receptacle. Battery charging begins; 17 hours for full charge.
1 2 4
Battery charging complete.
5
3
Changing Internal Filter Cartridge (single-patient use) Disposable Container
Change lter cartridge if overow occurs or every two months, whichever comes rst.
Turn unit “off”. Remove lter cartridge and
4-1/2” (11.43 cm) tubing. Install new cartridge and attach tubing.
1 2 3
Changing External Bacteria Filter (single-patient use) Reusable Container and/or Disposable Containter
Change bacteria lter if overow occurs or every two months, whichever comes rst.
NOTE– Do not substitute any other material for this
bacteria lter. Substitution may lead to contamination
or poor performance; use only DeVilbiss lters.
NOTE– Bacteria lter must be changed between
patients.
Turn unit “off”. Remove lter by disconnecting
it from suction unit and lid
assembly.
Replace with a clean DeVilbiss
bacteria lter (non-sterile) and
remount to suction unit and lid.
Ensure that the clear side of the
bacteria lter is toward elbow
and bottle when installing. Do
not reverse direction of lter.
Additional lters (7305D-608
12/pack) may be purchased
from your authorized DeVilbiss
Healthcare provider.
1 2 3
NOTE– Do not substitute any other material for this lter cartridge. Substitution may lead
to contamination or poor performance; use only DeVilbiss lter cartridges.
NOTE– The lter cartridge contains a hydrophobic lter. If the lter media becomes wet,
air ow will be stopped. The lter cartridge must then be replaced. Do not remove lter
media from lter cartridge.
NOTE– Filter cartridges are included with each disposable container. They are also
available separately (7305D-635 12/pack).
LED Explanations:
Green– Illuminated when external power is supplied to
unit from an AC or DC power source. Yellow– Battery is being charged. Light will go out when battery is fully charged. Red– Low battery. Seek another power source and charge battery as soon as possible when light illuminates.
Service Life
• Service life of the suction unit is 5 years.
• Service life of the battery is 200 discharge cycles.
• Service life of the disposable container is 30 dishwasher cycles.
• Service life of the reusable container is 30 autoclave cycles at 121°C.

EN - 7A-7314
Turn unit “off” and allow
vacuum to drop.
Disconnect from power source. Disconnect tubing and remove
container from holder.
1 32
Carefully remove lid and
empty contents. Remove lter cartridge and
4-1/2” (11.43 cm) tubing and
set aside.
4 5A
Filter MUST NOT get wet. The
lter material cannot be
removed from the elbow.
CLEANING INSTRUCTIONS
WARNING
To prevent possible risk of infection from contaminated cleaning/disinfection solutions, always prepare fresh solution for each cleaning cycle and discard solution
after each use.
NOTE– Disinfection information is based on AARC Clinical Practice Guideline Suctioning of the Patient in the Home.
Disposable Collection Container (with Internal Filter Cartridge)
NOTE– The disposable collection container and lid are meant for single-patient use.
5B
WARNING-Do not remove
oat ball from lid. If
removed, oat ball may
pose a choking hazard.
Turn unit “off” and allow
vacuum to drop.
Disconnect from power source. Disconnect tubing and remove
container from holder.
1 3
Carefully remove lid and
empty contents. Remove bacteria lter, elbow, and 3-3/8” (8.57 cm) tubing
and set aside.
5
Soak in 1 part vinegar (>=5%
acetic acid concentration) to 3
parts water (131˚F-149ºF/55˚C-
65˚C) solution for 60 minutes.
Rinse with clean, warm water
and air dry.
7
2
Wash container, lid and splash
guard in warm water/
dishwashing solution. Rinse
with clean, warm water.
6
NOTE– The disassembled container may also be washed in a dishwasher, top shelf only, using a cycle with a water temperature between 131ºF-149ºF/55ºC-65ºC.
Disposable Collection Container (with External Bacteria Filter)
NOTE– The disposable collection container and lid are meant for single-patient use.
NOTE– The disassembled container may also be washed in a dishwasher, top shelf only, using a cycle with a water temperature between 131ºF-149ºF/55ºC-65ºC.
Reusable Collection Container (with External Bacteria Filter)
Turn unit “off” and allow
vacuum to drop.
Disconnect from power source. Disconnect tubing and remove
container from holder.
1 3
Carefully remove lid and
empty contents. Remove bacteria lter, elbow, and 4-1/2” (11.43 cm) tubing
and set aside.
Wash jar, lid, o-ring, and
overow valve in a solution of
warm water with a mild, liquid
detergent (e.g. Dawn or
Palmolive) and rinse with
clean, warm tap water. Then
disinfect using one of the
following methods.
4 5 62
Wash container and lid in
warm water/dishwashing
solution. Rinse with clean,
warm water.
6
4

EN - 8 A-7314
Suction Unit (multi-patient use)
Device Cleaning and Disinfection When There is a Patient Change
DeVilbiss Healthcare recommends that at least the following procedures be carried out by the manufacturer or a qualied third party between uses by different patients.
NOTE– When the device is used as per instructions under normal conditions the interior of the device is protected from exposure to pathogens by the in-line lter on the
collection container, hence no disinfection of internal components is necessary.
NOTE– If the device is used without an in-line lter then the interior of the device may be exposed to pathogens and the device cannot be disinfected.
NOTE– If the following described complete processing of the device by an appropriately trained individual is not possible, the device should not be used by another patient.
1. Use disinfectants safely. Always read the label and product information before use.
2. Always wear personal protective equipment when performing this procedure. Use suitable gloves and safety glasses. Cover exposed skin on arms to prevent accidental
contact with bleach solution that has been applied to the device. Perform disinfection in a well-ventilated area.
3. Dispose of all accessories that are not suitable for reuse. This includes but may not be limited to the collection container, lter, tubing and carrying case.
4. With the power switch in the “Off” position, disconnect the device from all external power sources.
5. Visually inspect the device for any damage, missing parts, etc.
6. Clean the exterior of the device with a clean lint-free cloth. Heavy soil should be removed with a clean lint-free cloth dampened with water. A soft bristled brush
dampened with water can be used to remove stubborn soil. Dry the device using a clean lint-free cloth if water was used to remove soil.
7. Use 5.25% chlorine bleach (Clorox Regular Liquid Bleach or equivalent). Mix one (1) part bleach with four (4) parts water in an appropriate clean container. This ratio
produces a one (1) part bleach to ve (5) total parts solution (1:5). The total volume (amount) of solution required is determined by the number of devices in need of
disinfection. NOTE – An alternate suitable commercial (bacterial-germicidal) disinfectant that meets the requirements listed in the NOTE below and is used as per the
disinfectant manufacturer’s recommended dilution rates and instructions may also be used.
CAUTION– Do not submerge the device in water as this will result in damage to the vacuum pump.
NOTE– Do not use any cleaners or disinfectants that contain ammonia, benzene and/or acetone to clean the device.
8. Apply the bleach solution in an even manner to the enclosure and power cord using a clean lint-free cloth. The cloth should be dampened only and not dripping of
solution. Do not use a spray bottle to apply the solution. Do not saturate the device with the solution. Avoid over-saturating the enclosure seams so that no solution
residue builds up in these areas.
Suction Unit (single-patient use)
6’ Patient Tubing (single-patient use)
Rinse thoroughly by running
warm tap water through it. Follow by soaking in a solution of 1 part vinegar (>=5% acetic
acid concentration) to 3 parts
water (131ºF-149ºF/55ºC-
65ºC) for 60 minutes.Rinse
with clean, warm water and air
dry.
Disconnect from lid. Keep outer surface clean by
wiping with clean, damp cloth .
1 2 3 4
AC to DC Adapter
Disconnect AC to DC adapter
from unit and from power
source.
1 2
Wipe AC to DC adapter
housing and cords with a dry
cloth.
CAUTION– Do not submerge in water as this will result in damage to the vacuum pump.
NOTE– Do not use any cleaners or disinfectants that contain ammonia, benzene and/or acetone to clean the unit.
Carrying Case (single-
patient use)
Wipe with clean cloth
dampened with detergent or
disinfectant.
1
Turn unit “off” and allow
vacuum to drop.
Disconnect from power source. Wipe the housing with a clean
cloth and any commercial
(bacterial-germicidal)
disinfectant.
1 32
For single patient use:
1. Soak in 1 part vinegar (>=5% acetic acid concentration) to 3 parts water (131ºF-149ºF/55ºC-65ºC) solution for 60 minutes. Rinse with clean, warm water and air dry in a
clean environment.
2. Soak with a commercial (bacterial-germicidal) disinfectant. Follow disinfectant manufacturer’s recommended dilution rates and instructions carefully.
For multi patient use:
1. After parts are completely dry, place jar and lid in autoclave with the open end down. Ensure parts are not touching. Run one sterilization steam cycle at 250°F (121°C)
for 15 minutes. NOTE– Jar is guaranteed up to 30 cycles of autoclave sterilization at the indicated conditions.
2. Dispose of and replace lter, tubing and elbow between patients.

EN - 9A-7314
9. Exposure time of the disinfectant solution should be 10 minutes minimum to 15 minutes maximum.
10. After the recommended exposure time, all exterior surfaces of the device are to be wiped with a clean lint-free cloth dampened with drinking quality water no warmer than
room temperature. Dry the device with a dry, clean lint-free cloth. This is to remove residue that may stain or leave a lm on the device, especially after repeated
disinfections.
Disinfection
NOTE– The disinfection process can only be completed by the manufacturer or by an appropriately trained individual.
Recommended disinfection
interval
Number of
disinfection cycles Compatible disinfection method
Enclosure, power cord Between patients 20 1:5 chlorine bleach (5.25%) and water
solution, Mikrobac forte, Terralin Protect
Collection container, lter, tubing and carrying case Do not clean, replace between
patients N/A N/A
TROUBLESHOOTING
DANGER
Electric shock hazard. Do not attempt to open or remove cabinet, there are no user-serviceable internal components. If service is required, return unit to a
qualied DeVilbiss Healthcare provider or an authorized service center. Opening or tampering with the unit will void warranty.
NOTE– Your DeVilbiss Suction Unit contains no user-serviceable parts. If you believe your unit is not working properly, BEFORE YOU RETURN IT TO YOUR DEVILBISS
HEALTHCARE PROVIDER WHERE YOU PURCHASED IT, PLEASE TAKE A FEW MOMENTS TO CHECK FOR THESE POSSIBLE CAUSES:
PROBLEM ACTION
Unit does not turn on when external power is connected.
Green external power light does not illuminate.
1. Check power sources and connections.
2. Ensure wall outlet is live by plugging in a lamp.
Pump runs, but there is no suction. 1. Check that all tubing is connected properly.
2. Check tubing connections for breaks or leaks.
3. Ensure that oat shut-off in collection container is not activated or lter cartridge occluded.
4. Check for leaks or cracks in collection container assembly.
Low suction. 1. Use vacuum regulator knob to increase suction level.
2. Check system for leaks.
Unit does not turn on (no external power is connected).
7314P Series Only
1. Check that battery is fully charged and/or charge battery.
Battery will not charge (external power and charge
indicator lights should be illuminated during charge
mode) 7314P Series Only
1. Verify that both external power and charge indicator lights illuminate.
2. Check power sources and connections.
3. Ensure wall outlet is live by plugging in a lamp.
PROVIDER’S NOTES
No routine calibration or service is required provided the device is used in accordance with the manufacturer’s directions. In case of a change of patient, the device must be
reconditioned to protect the user. Reconditioning must only be carried out by the manufacturer or service provider. Between patients:
1. Visually inspect unit for any damage, missing parts etc.
2. Ensure that unit and accessories are clean.
3. Use an independent vacuum gauge to verify the unit provides the proper vacuum level as stated in Specications.
4. Discard and replace collection container, lter, tubing, and carrying case between patients.
5. Wipe the surface using a clean cloth dampened with disinfectant.

EN - 10 A-7314
SPECIFICATIONS/CLASSIFICATIONS
Size (including container) 8.3 H x 8.0 W x 8.5 D (21.1 cm x 20.3 cm x 21.6 cm) (not including AC to DC adapter)
Weight (including container) 7314P Series - 6.6 lb. (3 kg) (not including AC to DC adapter)
7314D Series - 4.3 lb. (2.0 kg)
Typical Operating Sound Level 55 dBA
Electrical Requirements 100-240V~, 50/60Hz, 1.2A max ; 12V ; 33 W Max
Vacuum Range 50-550 mm Hg +/- 10%*
Air Flow @ Pump Inlet: 27 LPM (free ow) typical (may be less when running from internal battery)*
Disposable Collection Container Capacity 800 ml (cc) with 2 lter options
Reusable Collection Container Capacity 1200 ml (cc)
Warranty Two-years limited, excluding internal battery (7314P series only) and collection container
Internal Battery (7314P Series Only) 90-day
Approvals IEC 60601-1:2005+AMD1:2012; EN 60601-1-2: 2015; ISO 10079-1:2015; IEC 60601-1-2:2014; IEC 60529:1989+AMD1:1999
+AMD2:2013; IEC 60601-1-6:2010; IEC 60601-1-11:2015;IP22
CONFORMS TO AAMI STD. ES 60601-1, AAMI STD. HA 60601-1-11, IEC STD. 60601-1-6, ISO STD. 10079-1
CERTIFIED TO CSA STD. C22.2 NO. 60601-1, NO. 60601-1-11, IEC STD. 60601-1-6, ISO STD. 10079-1
7314 Series complies with IEC 60601-1 3rd Edition
Environmental Conditions
Operating Temperature Range 32°F (0°C) - 104°F (40°C)
Operating Relative Humidity 0-95%
Operating Atmospheric Pressure 10.2 psi (70 kPa) - 15.4 psi (106 kPa)
Storage & Transport Temperature Range -40°F (-40°C) - 158°F (70°C)
Storage & Transport Relative Humidity 0-95%
Storage & Transport Atmospheric Pressure 7.3 psi (50 kPa) - 15.4 psi (106 kPa)
Equipment Classications
With respect to protection from electric shock Class II and internally powered
Degree of protection against electric shock Type BF Applied Parts
Degree of protection against ingress of liquids IP22 and ordinary power supply
Mode of Operation Intermittent Operation: 30 minutes on, 30 minutes off
Equipment not suitable for use in the presence of a ammable anaesthetic mixture with air or with oxygen or nitrous oxide.
ISO Classication
High Flow/High Vacuum
7314 series - Electrically powered medical suction equipment for non-transport use according to EN ISO 10079-1:2015
* Conditions may vary based on altitude above sea level, barometric pressure, and temperature.
TWO-YEAR LIMITED WARRANTY
The compressor portion of the DeVilbiss Vacu-Aide QSU Suction Unit 7314 Series (excluding internal rechargeable batteries and collection containers) is warranted to be free
from defective workmanship and materials for a period of two years from date of purchase. Internal rechargeable batteries are warranted for 90 days. Any defective part(s) will
be repaired or replaced at DeVilbiss Healthcare’s option if the unit has not been tampered with or used improperly during that period. Make certain that any malfunction is not
due to inadequate cleaning or failure to follow the instructions. If repair is necessary, contact your DeVilbiss Healthcare Provider or DeVilbiss Service Department for
instructions: U.S.A. 800-338-1988 or 814-443-4881, Europe [phone].
NOTE– Be sure to retain a dated proof of purchase document to verify unit is within 2-year warranty period.
NOTE– This warranty does not cover providing a loaner unit, compensating for costs incurred in rental while said unit is under repair, or costs for labor incurred in repairing or
replacing defective part(s).
THERE IS NO OTHER EXPRESS WARRANTY. IMPLIED WARRANTIES, INCLUDING THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
ARE LIMITED TO THE DURATION OF THE EXPRESS LIMITED WARRANTY AND TO THE EXTENT PERMITTED BY LAW ANY AND ALL IMPLIED WARRANTIES ARE
EXCLUDED. THIS IS THE EXCLUSIVE REMEDY AND LIABILITY FOR CONSEQUENTIAL AND INCIDENTAL DAMAGES UNDER ANY AND ALL WARRANTIES ARE
EXCLUDED TO THE EXTENT EXCLUSION IS PERMITTED BY LAW. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS,
OR THE LIMITATION OR EXCLUSION OF CONSEQUENTIAL OR INCIDENTAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU.
This warranty gives you specic legal rights, and you may also have other rights which vary from state to state.
Manufacturer’s Note
Thank you for choosing a DeVilbiss Suction Unit. We want you to be a satised customer. If you have any questions or comments, please send them to our address on the
back cover.
For Service Call Your Authorized DeVilbiss Healthcare Provider:
Phone Purchase Date Serial #
