1
Chart.3
Description
Size (mm) Fluid Tip Needle
1.0 FUNCY-4-1.0 FUNCY-41-1.0
1.3 FUNCY-4-1.3 FUNCY-41-1.3
1.5 FUNCY-4-1.5 FUNCY-41-1.5
1.8 FUNCY-4-1.8 FUNCY-41-1.8
FUNCY GUN Operation Manual
Important:Read and follow all instructions and SAFETY PRECAUTIONS
before using this equipment
MODELS
FUNCY - Air Cap № - Fluid Tip size – Type of feed(G:Gravity,S:Suction)
(例):FUNCY–343-1.3 -G ←( №343 Air Cap - Size1.3mm - Gravity )
SPECIFICATIONS
Maximum Working Air Pressure:9 bar , Maximum Working Fluid Pressure:14 bar
Chart.1
Air Cap №
Part
Number
Tip size(mm)Feed Air consumption
Gun inlet
pressure
Pattern
width
(mm) Application Fluid
inlet Air
inlet Weight
(g)
1.0 1.3 1.5 1.8
JGX-3C-343 ○○○○G 225L/min
0.2MPa 250 Mid-high Volume, fine
atomization, auto-refinishing,
Wood, plastic & metal finishing G1/4 G1/4 320
○○○S
PARTS LIST
Chart. 2
Note) Ref. No. 24 (FUN-34) is needed for Ref. 10 (FUNCY-
443) installation.
When removing it, be careful not to damage the surface of seat
where inserted. A damaged seat can lead air leakage.
Ref. №Part Number Description Qty
1 FUNCY-6 Retaining Ring Assy. 1
2 JGX-61C-K5 Seat Kit of 5 1
3 See Chart.1 Air Cap 1
4 See Chart.3 Fluid Tip 1
5 FUNCY-7 Baffle with Gasket 1
6 FUNCY-8-K5 Baffle Gasket Kit of 5 1
7 JGX-2C-G Fluid Inlet 1
8 FUNCY-BODY-G
FUNCY-BODY-S Gun Body (not for sale) 1
9 FUNCY-44 Pattern Valve 1
10 FUNCY-443 Valve Seal Kit (3 pieces) 1
11 FUNCY-43 Air Valve 1
12 FUNCY-25-K5 Valve Spring Kit of 5 1
13 FUNCY-12 Air Valve Bushing 1
14 See Chart. 3 Needle Assy. 1
15 FUNCY-14-K5 Needle Spring Kit of 5 1
16 FUNCY-13 Adjusting Screw 1
17 JGX-463C Needle Packing 1
18 JGX-11C-K3 Packing Gland Kit of 3 1
19 JGX-46C-K10 E-ring Kit of 10 1
20 JGX-45C Bearing Stud 1
21 FUNCY-108 Trigger 1
22 FUNCY-42 Cheater Valve 1
23 JGX-30C Air connector 1
24 FUN-34 (option) Valve Seal Inserting Tool 1
25 LUNA-34 Spanner 1
SB-E-FUNCY-A
2
SAFETY PRECAUTIONS
This manual contains information that is important for you to know and understand.
This information relates to USER SAFETY and PREVENTING EQIPMENT PROBLEMS.
Read and follow SAFETY PRECAUTIONS before using this equipment.
FIRE OR EXPLOSION HAZARD
1. When spraying, adequate exhaust must be provided to keep air free of accumulations of flammable vapors which may
cause fire or explosion.
2. Smoking must never be allowed in the spray area.
3. Static electricity is generated and a static spark could be produced in the spray area. To prevent the risk of fire or
explosion, ground without fail all conductive objects in the spray area.
4. Make it sure to use and ground hoses with static wire for spray gun operation. If improperly grounded, a static spark
possibly produced may cause fire or explosion.
5. Fire extinguishing equipment must be provided in the spray area.
6. Solvents used for cleaning must have a flash point equal to or higher than that of the coating. Those for general
cleaning must have flash points above 37.8℃(100°F) to prevent the risk of fire.
INHALING TOXIC SUBSTANCES
1. Toxic vapors and liquids are harmful to health. When spraying, adequate exhaust must be provided to keep the air
free of accumulations of toxic materials and the use at all times of respiratory protective equipment must be set
compulsory.
2. Always wear eye protection when spraying or cleaning the equipment.
3. Certain materials may be harmful if there is contact with the skin. Read carefully all the labels and safety performance
data of the materials and solvents to be used. Appropriate clothes and gloves must be worn for spraying or cleaning
the equipment.
MISUSE
1. Operators should be given adequate and appropriate training in the safe use and maintenance of this equipment.
2. Pressured liquids may injure eyes. Do not point the spray gun to any person.
3. Gravity or suction feed gun must not be used for pressure feed gun.
4. Parts with compressed air may damage the human body. Connect air hoses tightly by using a spanner so that air
never leaks. If tightened loosely, hoses can be removed which may result in damaging the human body, objects to be
coated and other equipment used together.
5. Parts with compressed air or under spring pressure may injure the human body. When replacing such parts, clean the
spray gun by discharging the materials, discharge the air, remove air hose and fluid cup and then replace such parts by
placing the gun flat. Eye protection must be worn when repairing the spray gun.
6. Do not use the gun at no more than maximum working pressure (0.69MPa).
INSTALLATION
1. The air supplied to spray gun must be cleaned air which any water, oil and solid material removed. To set up the Mist
Separator andAir Transformer near the gun is recommended. The use of air not cleaned may cause coating troubles.
2. Connect fluid cup and air hoses tightly. If tightened loosely, hoses can be removed which may result in damaging the
human body, objects to be coated and other equipment used together.
3. Adjust Needle Packing (17) before start using new gun. Tighten the Packing Nut (18) gradually and then to adjust the
needle moving smoothly, untighten a little where the Needle (14) is not well pulled back.
OPERATION
1. The recommended pressure of air supplied to gun is different among the types (Conventional / LVMP / HVLP).
However, do not supply the air pressure to gun in excess of the gun’s maximum working pressure (0.69MPa).
2. Try with the pressure starting from 0.2MPa or around, as the spraying pressure varies depending upon the inner
diameter of gun, triggering distance, materials etc.
3. The recommended spray distance is 200mm. If the spray distance is too far, good result does not appear.
4. In order to get uniform finishing the spray gun should be hold vertically toward the painting surface.
3
PREVENTIVE MAINTENANCE
1. Daily lubrication and cleaning is necessary to maintain the best condition of the gun.
2. To clean the gun body, wipe exterior with solvent dampened cloth. Do not submerge the gun body in solvent as any
solids may get into the air passage and cause troubles.
3. Do not leave the gun with solvent in fluid cup. Clean the spray gun after used with clean solvent and empty the cup.
To clean the fluid cup, after removing extra paint, through the appropriate solvent and flush down the residual paint.
4. The Air Cap can be immersed in solvent and brushed down for cleaning. If orifices are clogged, use a toothpick to
remove obstruction. Never use a steel wire or hard instrument. This will damage air cap and result in a distorted
spray pattern.
5. Do not immerse any plastic parts in solvent for long time.
6. Certain portions of gun should be lubricated. Do not lubricate to any portion where not instructed. For lubrication,
SSL-10 Gun Lube* is recommended (*sold separately, vegetable not repelling materials).
7. The following portions should be lubricated regularly ; Trigger Bearing Stud (20), Pattern Valve (9), threads of cheater
Valve (22) and Adjusting Screw (16), Air Valve stem (11), portion of Packing Gland (18) where Needle (14) comes in and
out.
8. When installing Air Cap (3), make sure no foreign materials adhered on Retaining Ring (1) and thread of Baffle and then
oil one drop of Gun Lube SSL-10.
9. Apply non-silicone grease lightly on Needle Spring (15) and Air Valve Spring (12). Do not apply too much grease as it
may clog the air passage.
REPLACEMENT OF PARTS
Before replacing gun parts, remove materials from the gun for cleaning. Then release the air pressure in the gun and
disconnect air hoses. All repairs should be made on a clean flat surface. Use only appropriate tools indicated for
replacement of parts.
Fluid Tip (4)and Needle (14)
1. It is recommended to replace Fluid Tip (4)and Needle (14)as a set.
2. Loosen completely Pattern Valve (9)by turning the knob counterclockwise.
3. Remove Adjusting Screw (16)and Needle Spring (15)and then withdraw Needle (14)from the gun body.
4. Remove Retaining Ring (1)and Air Cap (3).
5. Remove Fluid Tip (4)by using socket wrench or offset wrench.
6. Recommended torque of Fluid tip (4) is 8N・m.
Fluid Nipple (7)and Air Connector (23)
Fluid Nipple (7)and Air Connector (23)are fixed together with fluid packing. Use offset wrench for disassembling and
reassembling. When reassembling, apply fluid packing to threads of gun body.
Pattern Valve (9)and Cheater Valve (22)
When disassembling and reassembling Pattern Valve (9)and Cheater Valve (22), turn the knobs completely
counterclockwise and then disassemble or reassemble them.
Valve Seal Kit (10), Air Valve (11), Valve Spring (12)and Air Valve Bushing (13)
Valve Seal Inserting Tool (24)is required for replacing Valve Seal Kit (10). When replacing Valve Seal Kit (10),
be careful not to damage the surface of seals of Gun Body (8), Air Valve Bushing (13) and Air Valve (11)to
prevent air leakage.
1. Remove Needle Adjust Screw (16)and Needle Spring (15)and then withdraw Needle (14)from the Gun Body (8).
2. Remove Air Valve Bushing (13)by using 17mm offset wrench.
3. Withdraw Valve Spring (12)and Air Valve (11)from the gun body.
4. Withdraw Valve Seal Kit (10), being careful not to damage where fitted to.
5. Insert each seat by using Valve Seal Inserting Tool. (24).
6. Insert Air Valve (11)to the bottom end, being careful not to damage the seat, and then insert Air Valve Spring (12).
7. Install Air Valve Bushing (13)by using offset wrench.
Needle Packing (17)
1. Install Needle Packing (17)in the direction shown per drawing.
2. Adjust Needle Packing (17). Tighten the Packing Gland (18) gradually and then to adjust the needle moving smoothly,
untighten a little where the Needle (14) is not well pulled back.
4
SERVICE CHECKS
problem Cause Correction
Will not spray No pressure to gun.
Adjusting Screw (16) not properly adjusted. Check air and material lines.
Adjust.
Inproper spray pattern
A,B. Material build up on the Air Cap or Fluid Tip.
C,D Incorrect fluid delivery or viscosity.
A,B Clean the Air Cap or Fluid Tip.
C,D Adjust.
Jerky or fluttering spray
Insufficient material in the cup or Loose
connector.
Gun material passage plugged.
Worn Needle Packing (17).
Loose or damaged Fluid Tip (4)
Fill cup or tighten the Connector.
Clean.
Replace.
Tighten or replace.
Fluid leaking from
needle packing nut(18) Loose Packing Gland (18).
Worn or damaged Needle Packing (17).
Adjust Packing Gland(18).
Replace.
Dripping from fluid tip 1. Worn or damaged Fluid Tip (4) or Needle(14).
2. Stuck Needle Packing (17) or Needle (14).
3. Tight Packing Gland (18).
4. Loose Adjusting Screw (16).
1. Replace.
2. Lubricate.
3. Adjust.
4. Tighten.
ACCESSORIES
Part №Description Part №Description
KGP-4 Plastic Gravity Cup with Stand(400ml)HAV-501-B Air Adjusting Valve with Gauge
KG-250 Stainless Steel Gravity Cup with Stand(250ml)HAF-507 Disposable Air Filter
KG-400T Gravity Cup with Stand (400ml・Teflon coating) SSL-10 Gun Lube (60ml)
KGL-400 Gravity Cup with Stand (AnodizedAluminum) 42884-214-K5 Cleaning Brush (kit of 5)
KGL-400-FA KGL-400 with Free Angle Movement (400ml) KR-555-2C Suction Cup (1,000ml・Aluminum)
KR-470-2C Suction Cup (700ml・Aluminum)
BINKS・DEVILBISS DIVISION
RANSBURG INDUSTRIAL FINISHING KK
15-5 Fuku-ura 1Chome,Kanazawa-ku,Yokohama,Japan
〒
236-0004
℡045-785-6371 Fax045-785-6517
